INSTRUCTION MANUAL
FRIDGE FREEZER
C55CW12
C55CS12
Contents
Safety Warnings............................................................................................................................................. 4
Unpacking...................................................................................................................................................... 6
Installation ..................................................................................................................................................... 7
Location............................................................................................................................................................................................ 7
Levelling the Unit.......................................................................................................................................................................... 7
Free Space Requirements.......................................................................................................................................................... 7
Cleaning Before Use...................................................................................................................................................................11
Before Using Your Unit..............................................................................................................................................................11
Product Overview........................................................................................................................................ 12
Operation ..................................................................................................................................................... 13
Switching On Your Unit ............................................................................................................................................................13
Adjusting the Temperature .....................................................................................................................................................13
Noises Inside the Unit! ..............................................................................................................................................................13
Tips for Keeping Food in the Unit ........................................................................................................................................14
Preparations for Freezing.........................................................................................................................................................14
Defrosting Frozen Food............................................................................................................................................................15
Cleaning ....................................................................................................................................................... 16
Defrosting......................................................................................................................................................................................16
Cleaning the Interior and the Exterior of the Unit..........................................................................................................16
Maintenance ................................................................................................................................................ 17
Changing the Internal Light....................................................................................................................................................17
Care When Handling / Moving the Unit .............................................................................................................................17
Servicing ........................................................................................................................................................................................17
Switching O for Long Periods of Time..............................................................................................................................17
Condensation...............................................................................................................................................................................17
Disposal........................................................................................................................................................ 17
Specications............................................................................................................................................... 18
4
Safety Warnings
For your continued safety and to reduce the risk of injury or electric shock,
please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them for
future reference.
• Retain the manual. If you pass the unit onto a third party, make sure to
include this manual.
• This appliance is intended for indoor household use and similar
applications such as:
- farm houses and by clients in hotels, motels and other residential type
environment;
- bed and breakfast type environment;
- catering and similar non-retail applications.
• Ensure that the plug is easily accessible to enable disconnection from
the mains supply.
• Keep ventilation openings in the unit enclosure clear of obstructions.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not use electrical appliances inside the food storage compartments
of the unit, unless they are of the type recommended by the
manufacturer.
• If the mains cable is damaged, it must be replaced by the manufacturer,
its service agent or a qualied technician in order to avoid a hazard.
• Choose a location for your unit away from heat sources such as radiators
or res as refrigerant and vesicant are burnable.
• Do not damage the refrigerant circuit (The refrigerant is a very
environmentally friendly gas but is also combustible. Take care when
transporting or moving the unit to ensure that the refrigeration circuit
is not damaged. In the event of damage avoid naked ames or ignition
sources and ventilate the room in which the unit is placed for a few
minutes.)
• The unit must be manoeuvred by a minimum of 2 persons.
5
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Children should be supervised to ensure that they do not play with the
unit.
• If your unit is tted with a lock to prevent children being trapped inside,
keep the key out of reach and not in the vicinity of the unit.
• Do not store volatile or ammable substances, such as aerosol cans with
a ammable propellant, in the unit.
• Do not store bottles or glass containers in the freezer compartment.
Contents can expand when frozen (zzy drinks) which may break the
bottle and damage your freezer compartment.
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED
SERVICE PERSONNEL TO CARRY OUT SERVICING OF REPAIRS WHICH
INVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT
REPAIRS YOURSELF.
6
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new Currys Essentials Fridge Freezer.
We recommend that you spend some time reading this instruction manual
so that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
The Main Unit
Adjustable Glass Shelf x 2 Salad Bin Cover Shelf
Salad Bin Upper Freezer Drawer x 2
Lower Freezer Drawer Upper Fridge Door Shelf x 2
Instruction Manual
Lower Fridge Door Shelf
Egg Tray x 2 Ice Tray
If items are missing, or damaged please contact Partmaster (UK only).
Tel: 0844 800 3456 for assistance.
Instruction
Manual
INSTALLATION
7
Installation
Location
When selecting a position for your unit you should make sure the floor is flat and firm, and
the room is well ventilated with an average room temperature of between 16°C and 38°C.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct
sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures
may also cause the unit not to perform properly. This unit is not designed for use in a garage
or outdoor installation. Do not drape the unit with any covering.
Levelling the Unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal alignments
will not be covered properly.
Free Space Requirements
When installing the unit, ensure that 25 mm
of free space is left at both sides, 50 mm at
the rear of the unit and 25 mm at the top
of the unit. The door can be opened to the
right or the left, depending on which best
suits the location. Please ensure there is
adequate space for the door to fully open to
160°.
INSTALLATION
8
1. Stand the refrigerator, use a flat bladed
screw driver to remove the 4 screw
covers at the rear of the refrigerator lid.
2. Unscrew and life the refrigerator lid from
the rear and remove it, then lift it.
3. Remove the three bolts, then remove
the upper hinge that hold the door in
place. Lift the upper door and place it
on a padded surface to prevent it from
scratching.
4. Remove the two flange screw, then
remove the middle hinge that hold the
lower door in place. Lift the lower door
and place it on a padded surface to
prevent scratching it.
5. Remove the hinge hole cover from the
right holes as illustrated and transfer
them to the uncover hole at the left side.
INSTALLATION
9
6. Remove both adjustable feet and remove
the bottom hinge bracket by unscrewing
the bolts.
7. Unscrew and remove the bottom hinge
pin, turn the bracket over and replace it.
Refit the bracket fitting the bottom hinge
pin. Replace both adjustable feet.
9. Transfer the lower door to the property
position. Secure the door’s level, make
the bottom hinge pin into the lower hole
of the door, then tight the bolts.
8. Remove the screw nail of the lower door
stopper, and transfer them to the left side
of the lower door, then tight the screw
nail.
INSTALLATION
10
10. Make the middle hinge reverse the
direction 180°C, then transfer it to the left
property position. Make the middle hinge
pin in the upper hole of the lower door,
then tight the bolts. Transfer the upper
door to the property position. Secure the
door’s level; make the middle hinge pin
into the lower hole of the upper door.
11. Move the accessory B from the upper
cover of upper door and fit the accessory
A that is a small detachable part from a
small bag.
B
A
12. With the reassembled top hinge located
in the hole in the top inside left corner of
the upper door, fix the top hinge using
the 3 screws. Remove the decorative
block of top cover to the other side.
Replace the top cover using screws,
replace the circular hole plugs.
13. With the doors closed, check that the
doors are aligned horizontally and
vertically and that the seals are closed
on all sides before finally tightening the
bottom hinge. Re-adjust the levelling feet
as needed.
