INSTRUCTION MANUAL
FREE STANDING ELECTRIC COOKER
CFSE60W17
Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 1Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 1 14/01/2021 16:2614/01/2021 16:26
Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 2Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 2 14/01/2021 16:2614/01/2021 16:26
Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 7
Product Overview......................................................................................................................... 8
Front View ...................................................................................................................................................................8
Top View.......................................................................................................................................................................8
Control Panel..............................................................................................................................................................9
Before Using Your Cooker ............................................................................................................ 9
Using Your Hotplates.................................................................................................................... 9
First Time Use of the Hotplates............................................................................................................................9
Choosing the Right Cookware.............................................................................................................................9
Controlling Your Hotplates.................................................................................................................................10
Using the Oven ........................................................................................................................... 10
First Time Use of the Oven .................................................................................................................................10
Shelf Positions.........................................................................................................................................................11
Temperature (Thermostat) Control................................................................................................................. 11
Using the Grill ............................................................................................................................. 12
Oven Function Selector Control....................................................................................................................... 12
Cleaning Instructions ................................................................................................................. 13
Cleaning the Outside of the Cooker...............................................................................................................13
Cleaning the Oven Door Glass..........................................................................................................................13
Cleaning the Inside of Your Oven .................................................................................................................... 13
Removing the Oven Door .......................................................................................................... 14
Replacing the Oven Lamp.......................................................................................................... 15
Hints and Tips ............................................................................................................................. 15
Product Fiche and Specications .............................................................................................. 16
Energy Saving Tips and Energy Label....................................................................................... 17
- Main Oven..................................................................................................................................................... 17
- Hob ..................................................................................................................................................................17
- New Energy Label
February 2019..............................................................................................................................................17
Installation .................................................................................................................................. 18
Adjusting the Feet ...................................................................................................................... 19
Moving the Cooker ..................................................................................................................... 19
Stability Bracket ......................................................................................................................... 20
Electrical Connection ................................................................................................................. 21
Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 3Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 3 14/01/2021 16:2614/01/2021 16:26
4
Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
• It is recommended that this appliance is installed by a qualied electrical
engineer. The manufacturer is not responsible for any damage caused
by incorrect installation.
• Check whether there is any damage to the appliance after you have
unpacked it. If any damage is found, do not use the appliance and
contact the store where you purchased it.
• This appliance is for indoor domestic use only.
• This appliance is for cooking purposes only. It must not be used for other
purposes, for example room heating.
• For disconnection from the mains supply you must have a switch with
a contact separation of at least 3.0 mm in all poles and rated 32 Amp that
provides full disconnection, this must be incorporated in the xed wiring
in accordance with the local wiring rules.
• If the mains cable gets damaged, it should be replaced by an authorized
service agent or qualied electrician in order to avoid a hazard.
• The oven must be used in a well ventilated location and installed on
at/level ground.
• Only operate your appliance in a dry atmosphere.
• Keep the electrical cables of your other appliances away from hot areas;
do not let them touch the appliance.
• Ensure that the appliance is switched o at the mains supply switch
and allowed to completely cool down before cleaning, replacing the
oven lamp or performing any maintenance to avoid the possibility of an
electric shock or burns.
• Use of your appliance creates moisture in the room in which it is placed,
make sure that your kitchen is well ventilated. Maintain the natural
ventilation ducts properly.
Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 4Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 4 14/01/2021 16:2614/01/2021 16:26
5
• This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory and mental capabilities, or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision. Cleaning and user maintenance shall not be made by
children without supervision.
• Cleaning and user maintenance shall not be made by children without
supervision.
• Children should be supervised to ensure that they do not play with
the appliance.
• During use the appliance becomes hot. Care should be taken to avoid
touching the heating elements inside the oven or the hotplates.
• The appliance and its accessible parts become hot during use. Young
children should be kept away.
• Unattended cooking on a hob with fat or oil can be dangerous and may
result in re. NEVER try to extinguish a re with water, but switch o the
appliance and then cover the ame e.g. with a lid or a re blanket.
• Danger of re: Do not store items on the cooking surfaces.
• When the oven is hot never touch the oven glass or any other parts that
get hot. Allow the oven to cool before touching these parts.
• Do not use harsh abrasives cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the surface, which may result in
the glass shattering.
• Before starting to use your appliance, keep curtains, tulle, paper or
ammable materials away from your appliance. Do not keep combustible
or ammable things in or on the appliance.
• Do not use steam cleaners for cleaning the appliance.
• Do not rest any items on or stand on the open door.
• If the hob surface is cracked, switch o the appliance to avoid possibility
of electric shock.
• Take care when handling parts with glass, knocks, chips, heavy handling
and dropping could cause the glass to shatter.
• The glass oven door uses toughened glass and is designed to break into
Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 5Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 5 14/01/2021 16:2614/01/2021 16:26
6
many‘nugget’ size pieces if it breaks. These pieces will still have sharp
edges, please handle broken glass with care.
• The appliance is not intended to be operated by means of an external
timer or separate remote-control system.
• The supplied stability bracket or a recognized cooker stability device
must be tted.
• To prevent the appliance tipping, the stabilizing
bracket must be installed.
Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 6Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 6 14/01/2021 16:2614/01/2021 16:26
7
Thank you for purchasing your new Currys Essentials Freestanding Electric Cooker.
You must read this manual in order to fully understand how to operate your appliance correctly.
This cooker must be installed by a competent engineer. Please allow the installer to view the
installation section of this manual.
Read all the safety instructions carefully before use and keep this manual for future reference.
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to local
regulations.
The following items are included:
0
50°
100°
150°
0
1
6
5
4
0
1
6
5
4
0
1
6
5
4
0
1
6
5
4
Oven Tray x 1Oven Shelf x 1
The Main Unit Stability Bracket x 1
If items are missing or damaged please contact Partmaster (UK only).
Tel: 0344 800 3456 for assistance.
* All images are for indication only; please refer to your individual unit for actual item.
Grill Rack x 1
Grill Pan x 1
Grill Pan Handle x 1
Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 7Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 7 14/01/2021 16:2614/01/2021 16:26
8
Product Overview
Front View
1. Cooktop
2. Control Panel
3. Oven Shelf
4. Oven Tray
5. Oven Door
6. Oven Handle
7. Levelling Feet
Top View
1. Large Hotplate
2. Small Hotplate
1
2
2
1
0
50°
100°
150°
0
1
6
5
4
0
1
6
5
4
0
1
6
5
4
0
1
6
5
4
1
3
4
5
6
7
2
* All images are for indication only; please refer to your individual unit for actual item.
Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 8Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 8 14/01/2021 16:2614/01/2021 16:26
9
Choosing the Right Cookware
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits at, and is the same size as the cooking zone. Always centre
your pan on the cooking zone.
Using Your Hotplates
First Time Use of the Hotplates
Operate your electric hotplates at level 3 for 5 minutes. This will remove any manufacturing residues.
The chrome rings may discolour, this is normal and not a fault with the cooker.
Before Using Your Cooker
Before using your new cooker, please:
• Make sure all the controls are turned o.
• Read this Instruction/Installation Manual, taking special note of the “Safety Warnings” section.
• Turn the mains power on.
This appliance is for cooking purposes only. It must not be used for other purposes, for example room
heating.
Control Panel
1. Oven Function Selector Control
2. Thermostat lamp
3. Temperature (Thermostat) Control
6
5
4
3
2
1
6
5
44
33
22
116
5
4
3
2
16
5
4
3
2
1
1 3 42 5 5 5 5
4. Hotplate Warning Lamp
5. Hotplate Controls
* All images are for indication only; please refer to your individual unit for actual item.
Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 9Currys Essentials Free Standing Electric Cooker CFSE60W17 Manual.indd 9 14/01/2021 16:2614/01/2021 16:26
10
Low cooking
temperatures
Normal cooking
temperatures
Frying
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 LEVEL 5 LEVEL 6
145 mm 100 W 165 W 250 W 500 W 750 W 1000 W
180 mm 135 W 220 W 300 W 850 W 1150 W 1500 W
2. When the hotplate warning lamp illuminates, this means that one or more of the hotplates are switched on.
3. When you are nished cooking rotate the control back to the“0”position, the hotplate warning lamp will
turn o.
The hotplates will remain hot for some time; do not touch until they have completely cooled down.
Controlling Your Hotplates
1. Rotate the control to the heat level you wish to use for the selected hotplate.
Using the Oven
First Time Use of the Oven
Ensure that nothing has been left in the oven. Remove any insert cards, packaging, labels or plastic bags and
the grill pan handle.. Before connecting the power, use a damp cloth to carefully wipe the inner cavity wall and
housing. Clean all the detachable parts in hot, soapy water before using.
Heat the oven on maximum for 45 minutes. There may be a little smoke and odour upon initial start up (for about
15 mins). This is normal. It is due to the protective substance on the heating elements which protects the cooker
from the eects of corrosion during shipping from the factory.
* All images are for indication only; please refer to your individual unit for actual item.
• Under no circumstances should the oven be lined with aluminium foil as overheating may occur.
• Do not place dishes or baking trays directly onto the base of the oven as it becomes very hot and
damage may occur.
• During use, this appliance becomes hot. Care should be taken to avoid touching hot surfaces,
e.g., oven door, heating elements.
• Accessible parts may become hot when in use. Children should be kept away.
6
5
4
3
2
1
6
5
44
33
22
116
5
4
3
2
16
5
4
3
2
1
