STATUTORY WARNINGS.

Please read these operating instructions carefully for full

information on the safe installation, use and care of your new Esse

appliance.

This appliance must be correctly installed in accordance with these

instructions by a suitably qualified person.

We cannot accept responsibility for damage to persons or items

due to poor or incorrect installation of this appliance.

Make sure that the voltage (230v) and frequency (50Hz) of the

mains supply correspond to the details on the cooker data plate

which is located on the inside of the control compartment panel

door.

Maintenance and servicing work must only be carried out after the

power supply has been disconnected by switching off at the socket

and removal of both plugs.

Page 3

990ELX-I02-220319

Due to our policy of continuous innovation, we reserve the right to

adjust or modify our product without prior notification.

Do not let children near the oven during use to avoid the danger of

burns or injury. Use of the appliance by the elderly or infirm should

be supervised.

An electromagnetic field is generated when the

induction hob is activated. Although unlikely that

this could affect a pacemaker of other medical

device, we recommend that individuals with these

devices consult the device manufacturer or your

doctor if you have concerns.

The appliance and its accessible parts become hot

during use. Care should be taken to avoid touching

heating elements. Children less than 8 years of age

shall be kept away unless continuously supervised.

This appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities

or lack of experience and knowledge if they have been given

supervision or instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children shall not play

with the appliance. Cleaning and user maintenance shall not be

carried out by children without supervision.

Unattended cooking on a hob with fat or oil can be

dangerous and may result in fire, NEVER try to

extinguish a fire with water, instead switch off the

appliance, cover the flame with a lid or use a fire

blanket.

Danger of fire: do not store items on the cooking

surfaces.

Page 4

990ELX-I02-220319

If the Induction zone glass is cracked or broken the

cooker MUST NOT BE CONNECTED and no part of it

may be used. Switch off and unplug the appliance

to avoid possibility of electric shock.

Metallic objects such as knives, forks, spoons and lids should not be

placed on the hob surface since they can get hot.

Any spillages on the heat conserving lids should be removed from

the lid before opening.

Do not use a steam cleaner to clean any part of this appliance.

This appliance is not intended to be operated by means of an

external timer or separate remote-control.

If any of the supply cords are damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in

order to avoid a hazard.

Induction Zone: After use, switch off the hob element by its control

and do not rely on the pan detector.

During cooking, food naturally produces steam, which is vented

away to prevent excessive build-up within the ovens. As steam can

condense to water droplets on the cooler outer trim of the oven, it

may be necessary during cooking to wipe away any moisture with a

soft cloth. This will also help to prevent soiling and discolouration

of the oven exterior by cooking vapours.

Page 5

990ELX-I02-220319

TECHNICAL DATA

Fig.1 990ELX Cooker data plate

The cooker data plate is located on the inner door panel of the

control compartment.

UNPACKAGING YOUR NEW COOKER.

Unpack your new Esse Cooker, removing all of the outer packing

and accessories from the top and bottom ovens, including

protective film on the door liners. At this time please examine the

cooker for any damage to the enamel finish and hob glass.

Any damage to the cooker or anything missing, please contact your

supplier for advice.

We ask that you dispose of any packaging in a safe, responsible

manner and recycle where possible.

INSTALLATION.

You must be aware of the following safety requirements &

regulations:

This appliance shall be installed in accordance with the regulations

in force.

Read the instructions before installing or using this appliance.

Page 6

990ELX-I02-220319

The cooker must be installed in accordance with: All relevant

British Standards / Codes of Practice and the relevant Building / IEE

regulations

Location of the Oven

This appliance is designed for domestic cooking only. Use for any

other purpose could invalidate any warranty or liability claim.

CONNECTING YOUR COOKER

For your own safety we recommend that a competent person

installs your cooker. This cooker is designed to be installed using

two standard 13 Amp plugs or a single hardwired connection to a

40 Amp cooker spur. A qualified electrician is not required if the

cooker is supplied with 13 Amp plugs but is required for hardwired

connections.

Electrical connection

Ovens with a three-pole power supply cable are designed to

operate with alternated current at the supply frequency and

voltage indicated on the data plate (located on the inner door panel

of the control compartment).

Connecting the power supply cable to the mains:

The appliance is supplied fitted with either two 1.5 metre cables

and two normalized 13 amp plugs, or a single 40 Amp cable for

hardwiring, which correspond to the load indicated on the data

plate. Before making the connections check that: the circuit

breakers or fuses of the home system can support the appliance

load (see data plate); the power supply system has a sufficient

earth connection which complies with the provisions of current

regulations and the law; there is easy access to the socket. Do not

use coiled extension cables or adapters as these could cause

overheating, burning or RCD trip out..

Page 7

990ELX-I02-220319

Calibrating the induction unit

Before using your induction hob, you must ‘calibrate’ the sensitivity

of the controls. It is crucial that this is done correctly, to ensure that

the induction hob operates appropriately.

To calibrate the controls on your induction unit please follow the

below steps:

1. Ensure that the power to your ESSE 990 ELX is switched

off at the wall.

2. Turn the power to your ESSE 990 ELX on at the wall.

a. The induction hob will run through a start-up

routine for a few seconds, during which time all

the numerical LEDs will show ‘8’.

b. When the start-up routine is complete, a single

LED above the ‘lock button’ on the control panel

will be lit up.

3. Firmly press the ‘lock button’ for 2 seconds, until the LED

goes out.

Your ESSE 990 ELX induction hob controls are now successfully

calibrated

You must recalibrate the induction hob controls every

time power is lost. I.E. when your ESSE 990 ELX is

switched off at the mains, or there is a power cut.

Page 8

990ELX-I02-220319

YOUR COOKER.

Fig.2 990ELX Cooker

SLOW COOK OVEN.

CONTROL COMPARTMENT.

3 ZONE INDUCTION.

HEAT CONSERVING BOLSTER LIDS.

HOTPLATE.

TOP OVEN & GRILL.

BOTTOM OVEN.

Page 9

990ELX-I02-220319

SPACING AND DIMENSIONS.

Fig. 3 990ELX Cooker Dimensions

All dimensions are in mm

Page 10

990ELX-I02-220319

Fig. 4 990ELX Flex Reach

The above diagram shows the possible locations where the Flex of

the cooker reaches, the plug sockets for the cooker must be within

this arc.

The cooker is not to be grouted or sealed at the back or sides of the

worktop as if any maintenance is required the cooker will have to

be pulled away from the wall at the rear.

The cooker weighs 327kg and so the floor must be capable of

withstanding the load. Make sure the cooker is level, use packing

pieces if necessary.

The cooker does not require access via the side panels once it is

installed, however we do ask that a 10mm gap is provided at the

rear of the cooker and a 3mm gap between the cooker sides and

any adjoining non-combustible work surfaces that may be fitted is

provided, this is to allow for the safe removal of the top plate

should this be required at a later date. If the adjoining work

surfaces are combustible, a 20mm gap is required.
