ESI Maya 44 USB Manual de usuario

High Quality 4-in / 4-out

USB Audio Interface

User’s Guide

Revision 1, November 2012

www.esi-audio.com

ESI MAYA44 USB+

INDEX

1. Introduction..................................................................................................................................4

1.1 Features................................................................................................................................................................4

2. Installation....................................................................................................................................5

2.1 System Recommendation.....................................................................................................................................5

2.2 Hardware Installation...........................................................................................................................................5

2.3 Driver & Software Installation.............................................................................................................................5

2.3.1 Installation under Windows XP........................................................................................................................6

2.3.2 Installation under Windows Vista / 7 / 8...........................................................................................................7

2.3.3 Installation under Mac OS X.............................................................................................................................8

3. Control Panel under Windows ...................................................................................................9

3.1 Faders...................................................................................................................................................................9

3.2 Latency settings .................................................................................................................................................10

3.3 DirectWIRE .......................................................................................................................................................10

4. Control Panel under Mac OS X................................................................................................12

5. Setting in Applications...............................................................................................................13

5.1 Windows Multimedia setup...............................................................................................................................13

5.2 Deckadance LE..................................................................................................................................................13

6. Specifications..............................................................................................................................15

7. General Information..................................................................................................................16

ESI MAYA44 USB+

1. Introduction

MAYA44 USB+ is a powerful, yet affordable, USB audio solution for home recording - a perfect

solution for mobile live and recording applications!

Besides standard recording and playback functionality, MAYA44 USB+ provides what's needed for

professional music production. In its compact case MAYA44 USB+ provides 4 analog input and 4

analog output channels with RCA connectors and a combined optical S/PDIF digital output / stereo

headphone output.

With support for ASIO 2.0, CoreAudio and MME / WDM, MAYA44 USB+ is compatible to all

major music and DJ applications like Cubase, Logic, Sonar, Reason, Reaktor, MixVibes, Traktor

DJ Studio, BPM Studio and much more.

Just plug it in and it works!

1.1 Features

The MAYA44 USB+ hardware has these main features:

1. USB connection port (connects to your computer with the supplied cable)

2. Power & I/O activity LEDs

3. Input / Output channel LEDs, showing active input and output signals

4. S/PDIF optical output plus headphone output (channel 1 and 2) as a combo connector

5. 4 analog outputs (Line Out 1 / 2 – channel 4 to 1)

6. 4 analog inputs (Line In 1 / 2 – channel 4 to 1)

The cool compact design allows you to take MAYA44 USB+ with you, wherever you go. As

companion to a notebook computer, you can take your projects or your DJ setup with you.

MAYA44 USB+ is simple to install and even easier to use. Working with samples, as a DJ, with

software synthesizers or recording software has never been easier, with the help from MAYA44

USB+.

ESI MAYA44 USB+

2. Installation

2.1 System Recommendation

MAYA44 USB+ is not simply a standard digital audio interface card, but a high-resolution device

capable of advanced processing of audio content. Even though MAYA44 USB+ is built to have

low-CPU resource dependability, system specifications play a key part in the MAYA44 USB+s

performance. Systems with more advanced components are generally recommended.

Minimum System Requirements

- Intel Pentium III 600MHz CPU or comparable AMD CPU (or equivalent)

- Windows XP or Windows Vista / 7 / 8 (32- and 64-bit) operating system

- 1 available USB port

- at least 2 GB RAM

- high quality audio software with ASIO support recommended

Mac

- Macintosh with Intel CPU

- 1 available USB port

- at least 2 GB RAM

- Mac OS X 10.4 or higher

2.2 Hardware Installation

MAYA44 USB+ is simply connected to an available USB port of your computer. A separate power

supply is not required, as MAYA44 USB+ is a USB powered device. Simply install the hardware

by plugging it into your computer with the supplied cable.

USB port of a computer

2.3 Driver & Software Installation

After the connection of MAYA44 USB+, the operating system automatically detects it as a new

hardware device. Modern operating systems like Windows XP, Windows Vista/7/8 or Mac OS X

usually detect the hardware directly and are installing the correct USB audio drivers automatically.

You can use MAYA44 USB+ already now in typical consumer audio applications that do not need

special professional ASIO driver support. Under Windows XP this could be for example programs

ESI MAYA44 USB+

used for DVD playback or more simple DJ applications that don’t require ASIO. Under Mac OS X

this could be applications like Garageband.

2.3.1 Installation under Windows XP

Unplug the device before you start the installer if it is already connected. Then launch setup.exe

from the MAYA44 USB+/Windows folder of the included driver CD or from a download of a recent

driver from our website.

You will now see a dialog as shown on the left picture below. Click Next. You can define the target

directory for the installation now. Confirm it with Next.

The installer now informs you that the driver installation will start as shown on the left picture

below. Confirm this with Next. During the following process you will see a dialog box once or

several times that informs you that the driver software has not passed Windows Logo testing. Please

be assured that our drivers have been tested in various different ways and are OK to be used.

Confirm any such dialog with Continue Anyway.

You will now be prompted to connect the hardware on the next dialog that is shown below on the

left. Plug in MAYA44 USB+. Do not click Next yet. During the driver installation, Windows might

again prompt you to confirm the Windows Logo testing dialog once or several times with Continue

Anway before the driver installation is finalized.

ESI MAYA44 USB+

You can now finally click Next on the ESI MAYA44 USB Audio Driver Setup dialog. The

installation is now finished. To confirm this, please check if the ESI icon is displayed in the taskbar

notification area as shown below. Sometimes a reboot is required.

If yes, the driver installation has been completed successfully.

2.3.2 Installation under Windows Vista / 7 / 8

Unplug the device before you start the installer if it is already connected. Then launch setup.exe

from the MAYA44 USB+/Windows folder of the included driver CD or from a download of a recent

driver from our website.

When launching the installation, Windows Vista / 7 / 8 might prompt a security message. Make sure

to allow the installation. You will then see a dialog as shown on the left picture below. Click Next.

You can define the target directory for the installation now. Confirm it with Next.

The installer now informs you that the driver installation will start as shown on the left picture

below. Confirm this with Next. During the following process you might see a Windows Security

dialog box once or several times that asks you for confirmation to install the driver software.

Confirm any such dialog with Install.

ESI MAYA44 USB+

You will now be prompted to connect the hardware on the next dialog that is shown below on the

left. Plug in MAYA44 USB+. Do not click Next yet. Instead, wait a few seconds for the automatic

device driver installation. You can monitor this in the task notification area where Windows Vista /

7 informs that the driver is installed via a bubble message box.

You can now finally click Next on the ESI MAYA44 USB Audio Driver Setup dialog. The

installation is now finished. To confirm this, please check if the ESI icon is displayed in the taskbar

notification area as shown below. Sometimes a reboot is required.

If yes, the driver installation has been completed successfully.

2.3.3 Installation under Mac OS X

Mac OS X already provides support for class compliant USB audio devices such as MAYA44

USB+. This means that no software or driver needs to be installed to use MAYA44 USB+ under

Mac OS X. Simply connect the unit with the supplied USB cable to your Mac and you can start

using it.

To make the usage more simple, we provide a control panel application that can be installed from

the included CD (MAYA44 USB+/Mac OS X folder) or downloaded on our website. To install it,

open the .dmg file and then launch the installer by double clicking the contained .pkg package file.

Follow the instructions on screen to install it.

Controlling some of the basic options of MAYA44 USB+ under Mac OS X can also be done via the

Audio MIDI Setup utility from Mac OS X.

ESI MAYA44 USB+

3. Control Panel under Windows

This chapter describes the MAYA44 USB+ Control Panel under Windows.

To open the control panel double click on the ESI icon in the task notification

area. The following dialog will appear:

3.1 Faders

You can control the input monitor level, the input level and the output level with the faders in the

control panel.

The INPUT section controls the real input level through the input ports. You can control all 4 inputs

independently.

The MONITOR section can be used to control the input monitor level. You can monitor the signals

through the input channel 1 to 4 individually and/or simultaneously. It will not affect the actual

input level from the source. Even if these faders are muted (M), you can still record the signals from

the source, but you are not able to listen to (= monitor) the input source through the analog output.

The OUTPUT section contains the master output level faders. This controls the analog output

signals, except the digital optical output. You can control the monitoring level of the input source

through the input ports and/or the playing out level of the wave file through the analog output ports.

Please note that the analog headphone output and the digital optical output share the same

connector, i.e. they cannot be used simultaneously. Both send out the stereo signal from output

channel 1 and 2.

ESI MAYA44 USB+

3.2 Latency settings

With the Latency menu entry under Config, you can change the latency of the driver of MAYA44

USB+. Depending on the typical application (e.g. for playback of software synthesizers) a smaller

latency is an advantage. At the same time, the best latency setting indirectly depends on the

performance of your system. For most default applications, a typical latency buffer size between

128 and 256 is standard. On a slow system, 512 is an option.

Please note that the latency has to be setup before launching any audio application.

3.3 DirectWIRE

What is DirectWIRE?

DirectWIRE is a driver technology, developed by ESI, which can be used for routing audio streams

internally within applications using EWDM Audio MIDI Drivers exclusively developed by ESI.

With the DirectWIRE router, an application can record from other application’s audio outputs

without external wiring or any loss of data when they are running at the same time.

DirectWIRE also allows you to easily rip any audio stream in real time by transferring data thru

DirectWIRE from MP3s, live On-line Broadcast and On-demand content, and more.

DirectWIRE is not available under Mac OS X.

DirectWIRE Panel

Click on DirectWIRE on the MAYA44 USB+ control panel. The DirectWIRE dialog as shown

below will appear. DirectWIRE digital virtual wiring technology, developed by ESI, routes audio

streams internally within applications using standard audio drivers such as WDM, ASIO and MME,

even when they are running at the same time.
