Escea EF5000 Manual de usuario
EF5000
GAS FIRE USER GUIDE
Australia
www.escea.net
630114_2 Userguide AUS
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE.
DO NOT USE OR STORE FLAMMABLE MATERIALS NEAR THIS
APPLIANCE.
DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE
WHILST IT IS IN OPERATION.
IT IS NOT RECOMMENDED TO OPERATE THE FIRE WITH THE
FASCIA PANELS REMOVED.
THIS APPLIANCE IS NOT INTENDED FOR USE BY YOUNG
CHILDREN OR INFIRM PERSONS UNLESS THEY HAVE BEEN
ADEQUATELY SUPERVISED BY A RESPONSIBLE PERSON TO
ENSURE THAT THEY CAN USE THE APPLIANCE SAFELY.
YOUNG CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT
THEY DO NOT PLAY WITH THE APPLIANCE.
THE APPLIANCE MUST BE INSPECTED BEFORE USE AND AT LEAST
ANNUALLY BY AN AUTHORISED TECHNICIAN.
THIS APPLIANCE MUST BE INSTALLED IN ACCORDANCE WITH THE
MANUFACTURERS WRITTEN INSTRUCTIONS.
Any service work carried out on this appliance must only be done by a
recognised escea technician or authorised personnel.
The data plate for this appliance, containing technical information and
specifications, can be found to the right of the control tray, near the
base of the fire. To access this, the fascia must be removed.
NZ LTD
31 Devon St, PO Box 5277
Dunedin, New Zealand
E-mail: [email protected]
Web: www.escea.co.nz
Phone: +64 3 4790302
Distributed in Australia by
Glen Dimplex
Unit 2, 205 Abbotts Road
Dandenong, Melbourne
web: www.escea.com.au
Phone: +61 3 87873567
Distributed in Western Australia by
Australian Heating Distributors
31 Clune Street
Bayswater, Perth, Western Australia
web: www.escea.com.au
Phone: +61 8 93737000
Contents
Basic Operation 1 - 4
Removing the Fascia 5
Cleaning and Maintenance 6
Basic Operation
On / Off
The EF5000 is operated by the switch located on the right hand side
outer edge of the fascia. The basic operations possible are ON/OFF.
Before operating the fire, ensure the power transformer is
plugged into the mains wall socket & turned on, and the supply is
turned on.
To turn the fire on push the ON/OFF rocker switch to the on position.
The ignition unit will start sparking and the pilot and burners will ignite
almost immediately.
In the event of no gas, the ignition unit will attempt to try to light up to 3
times before shutting down.
Ignition:
To turn the fire off, simply flick the ON/OFF rocker switch to the off
position. This will shut down the gas flow to the pilot flame and both
burners.
Turning off the fire:
Please ensure the gas supply is also turned off, and as an extra
safety please turn off the main power supply at the house.
Basic Operation
Removing the Fascia
The EF5000 Stainless Steel fascia is attached to the fire by four
'hooks' on the corners of the fascia. If you need to remove the fascia,
first give the fascia a brief lift upwards as shown.
Now slide the fascia towards you until it falls into the additional slot,
. Now you can rest the Fascia on the ground.unplug the electrical cord
Reverse these steps to re-fit the Fascia, ensuring the two connections
are correctly plugged in by testing the fire.
Cleaning your EF5000
To clean the glass and stones in the front stone tray simply reverse the
steps in section 14.0 of the Installation Manual.
The glass can be cleaned using standard window cleaner. The quartz
stones can be washed using soapy water
If the stainless steel fascia requires cleaning the following products
are recommended; 3M Stainless steel cleaner or methylated spirits.
To clean the weather cover or the powder coated or stone fascia
options warm soapy water should be used.
Cleaning of the ceramic stones and burners can be carried out using a
brush and a dry cloth.
