EF5000
GAS FIRE USER GUIDE
Australia and New Zealand
www.escea.com
630114_4 Userguide Aus & NZ
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE.
DO NOT USE OR STORE FLAMMABLE MATERIALS NEAR THIS
APPLIANCE.
DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE
WHILST IT IS IN OPERATION.
IT IS NOT RECOMMENDED TO OPERATE THE FIRE WITH THE
FASCIA PANELS REMOVED.
THIS APPLIANCE IS NOT INTENDED FOR USE BY YOUNG
CHILDREN OR INFIRM PERSONS UNLESS THEY HAVE BEEN
ADEQUATELY SUPERVISED BY A RESPONSIBLE PERSON TO
ENSURE THAT THEY CAN USE THE APPLIANCE SAFELY.
YOUNG CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT
THEY DO NOT PLAY WITH THE APPLIANCE.
THE APPLIANCE MUST BE INSPECTED BEFORE USE AND AT LEAST
ANNUALLY BY AN AUTHORISED TECHNICIAN.
THIS APPLIANCE MUST BE INSTALLED IN ACCORDANCE WITH THE
MANUFACTURERS WRITTEN INSTRUCTIONS.
Any service work carried out on this appliance must only be done by a
recognised escea technician or authorised personnel.
The data plate for this appliance, containing technical information and
specifications, can be found to the right of the control tray, near the
base of the fire. To access this, the fascia must be removed.
Distributed in Australia by
Glen Dimplex
1/21 Lionel Road
Waverley, Melbourne
web: www.glendimplex.com.au
Phone: +61 3 87873500
Distributed in Western Australia by
Air Group
28 Division Street
Welshpool, Perth, Western Australia
web: www.airgroup.com.au
Phone: +61 8 93502200
NZ LTD
17 Carnforth st, Green Island
Dunedin, New Zealand
E-mail: [email protected]
Web: www.escea.com
Phone: 64 3 478 8220
Contents
Basic Operation 1 - 4
Removing the Fascia 5
Cleaning and Maintenance 6
Basic Operation
On / Off
The EF5000 is operated by the switch located on the right hand side
outer edge of the fascia. The basic operations possible are ON/OFF.
Before operating the fire, ensure the power transformer is
plugged into the mains wall socket & turned on, and the supply is
turned on.
To turn the fire on push the ON/OFF rocker switch to the on position.
The ignition unit will start sparking and the pilot and burners will ignite
almost immediately.
In the event of no gas, the ignition unit will attempt to try to light up to 3
times before shutting down.
Ignition:
To turn the fire off, simply flick the ON/OFF rocker switch to the off
position. This will shut down the gas flow to the pilot flame and both
burners.
Turning off the fire:
Please ensure the gas supply is also turned off, and as an extra
safety please turn off the main power supply at the house.
Basic Operation
Removing the Fascia
The EF5000 Stainless Steel fascia is attached to the fire by four
'hooks' on the corners of the fascia. If you need to remove the fascia,
first give the fascia a brief lift upwards as shown.
Now slide the fascia towards you until it falls into the additional slot,
. Now you can rest the Fascia on the ground.unplug the electrical cord
Reverse these steps to re-fit the Fascia, ensuring the two connections
are correctly plugged in by testing the fire.
Cleaning your EF5000
Note: Always ensure the fireplace is cold before starting any cleaning
or maintenance.
To clean the glass and stones in the front stone tray, first remove the
stones from inside the tray and the glass will then be free to slide
upwards.
The glass can be cleaned using standard window cleaner. The quartz
stones can be washed using soapy water
To clean the weather cover warm soapy water should be used.
Cleaning of the ceramic stones and burners can be carried out using a
brush and a dry cloth
Fascia:
The Fascia is the visible surround of your Escea Gas Fireplace and
must be treated carefully to prevent unsightly marks from tarnishing
the visual quality of the product. Some marking over time is inevitable
however, so the following directions will assist you in getting the
maximum enjoyment from your Escea Gas Fireplace.
Never ever rub the fascia.
The outside of an Escea Fascia must only be cleaned with a soft
microfibre cloth. If heavier cleaning is required for the likes of grease
or stubborn fingerprint removal we recommend the use of Steel Kleen
brand Ezi Wipes. These wipes have been tested by Escea technicians
and produce very satisfying results, when used correctly. Instructions
Cleaning your EF5000
For Stainless Steel Fascias:
1. Ensure that the Gas Fireplace is off, and that the fascia is cold.
2. Using the gloves provided with your fascia, remove the towelette
from the sachet and wipe the fascia with even, straight strokes.
3. Make sure your strokes follow the direction of the grain or brush
finish. Wiping across the grain can leave small scratches.
4. The wipe will leave a very fine film over the fascia, ensure this film is
distributed evenly.
5. If the film is applied too heavily and is quite visible, you can remove
the excess by gently wiping dry with a microfibre cloth. Ensure your
strokes still follow the direction of the grain or brush finish.
6. Ensure that no film is applied to the glass of your Escea Gas
Fireplace. If applied accidentally, wipe off with an absorbent microfibre
cloth.
For Powder Coated Fascias:
1. Ensure that the Gas Fireplace is off, and that the fascia is cold to the
touch.
2. Using the gloves provided with your fascia, remove the towelette
from the sachet and wipe the fascia with even, straight strokes.
3. Because the wipe leaves a protective film over the fascia, the entire
fascia will need to be wiped to avoid seeing a difference in surface
texture. Ensure this film is distributed evenly.
4. If the film is applied too heavily and is quite visible, you can remove
the excess by gently wiping dry with a microfibre cloth
5. Ensure that no film is applied to the glass of your Escea Gas
Fireplace. If applied accidentally, wipe off with an absorbent microfibre
cloth.
