Steering wheel setting (Optional)
1. Click icon on setup interface so as to access steering wheel setting interface (PIC 4).
2. Connect anode and cathode of direction control wire of the car with anode and cathode of
direction control wire of this device, and press the buttons on steering wheel one by one and record
the corresponding sequence and functions.
3. Click the button of steering wheel needs to be allotted so as to select the corresponding setting
function, such as volume +.
4. Buttons on steering wheel shall display the corresponding functions, such as volume +.
To modify function settings, repeat procedures 3~4.
To reset functions, click [Reset] icon, all the settings set before shall be cleared, repeat procedures 3~4 for resetting.
Language
During use, you can select your familiar language to display menu by language setup.
setting
Click icon on setup interface to access language setting interface, as shown in right (PIC 1) diagram:
Click the corresponding [English] icon on the language bar desired to be set so as to switch the
language type, when there are more than 3 languages, direction icon shall pop up, click it to select
your familiar language.
Audio setting
Click icon on setup interface to access audio setting interface, as shown in right (PIC 2) diagram:
You can turn on or turn off the existing functions on audio setting interface and adjust the rearview
volume.
Video setting
Click icon on setup interface to access video setting interface, as shown in right (PIC 3) diagram:
At video setting interface, you can adjust brightness, contrast, saturation and hue of the video.
Panel Introduction
In energized state, press this button to turn on the power, and long press this button in boot-up state to turn off the power. In any mode,
press the button can switch to the main interface.
1. /SRC/POWER (Power on &off / Return to main menu)
Please check the appropriate buttons listed below for function introduction according to the actual panel used. (The introduction of
some buttons may be different, the actual function is the standard.)
2. VOL Button (VOL+/VOL-)/(VOL/VOL)
Press the button to adjust volume level.
3. SEEK Knob/( / )/ (SEEK+/SEEK-)/(SEEK/SEEK)(Speed forward/backward/Select station/song)
In radio mode, press/rotate the knob to select station upward/backward. Long press/rotate the knob to automatically scan station.
In playback mode, short press/rotate the knob to select song upward/backward, long press/rotate it to achieve speed forward/backward
function.
4. TFT OFF (TFT off button)
Long press it to turn off TFT screen, and short press it so that TFT screen shall be re-lit after turned off.
Under playback mode, press this button so as to switch between play/pause; while press this button at main menu or setup menu to
confirm to access. (Optional)
5. (Play/Pause/Enter button)
6. MUTE (Enable mute function)
Press this button to turn off volume output, press it again to restore the previous volume level. Long press MUTE button to turn off
TFT screen, and short press it so that TFT screen shall be re-lit.
In audio mode, press the button to access equalizer setup, users can select Standards rock, or classic mode., pop
7. EQ (Preset equalizer settings)
8. BAND/P/N (Band switch/System switch)
In radio mode, short press the button to switch band in the following sequence
FM1 FM2 FM3 Am1 AM2 FM1
In playback mode, press the button to switch among the following systems---PAL, AUTO, NTSC.
9. Number Button 1-6 (Radio station Radio Select bit)
In radio mode, press this button to hear radio preset;
In disc playback mode, press this button to select song .features
10. AST/SCN (Scan)
In radio mode, click the button to search station automatically and then browse automatically, 5 seconds later search continues until
confirm button is pressed.
Note: For certain machine models short press number button to browse memorized stations for 5 seconds each time, long press to
automatically search memorized stations.
