ErgoAV ERMCM1-01B Manual de usuario
(A)
Ceiling TV Mount Instruction Manual
Thank You for Choosing this ErgoAV Product!
At ErgoAV, we want to add value to your AV experience by providing the
highest quality products and services in the industry. If you have any
concerns or comments, please contact us.
ErgoAV Customer Care
Phone: (877) 419-7832
Email: [email protected]
Website: www.ergoav.com
Address: 9501 Louisiana Ave N, #200, Brooklyn Park, MN 55445
Model: ERMCM1-01B
Check the VESA Pattern of Your TV before You Begin the Installation
IMPORTANT SAFETY INFORMATION
If your TV's VESA Pattern is smaller than 100mm x 100mm / 3.9” x 3.9” or
greater than 400mm x 400mm / 15.7” x 15.7”, this mount is NOT COMPATIBLE
with your TV. Please contact our Technical Support at (877) 419-7832 or
[email protected] to find a compatible mount.
Weight Restrictions
99 lbs/
(44 kg)
MAX
If your TV weighs
more, do not use
this product.
W
HMinimum: 100mm x 100mm / 3.9” x 3.9” (W x H)
Maximum: 400mm x 400mm / 15.7” x 15.7” (W x H)
Measure Your TV VESA Pattern:
DANGER! Please carefully read all instructions before attempting installation. If you do not
understand the instructions or have any concerns, please contact our Technical Support at
CAUTION: Avoid potential personal injuries and property damage!
• Do not use this product for any purpose that is not explicitly specified in this manual. Do not
exceed weight capacity. We are not liable for damage or injury caused by improper mounting,
incorrect assembly or inappropriate use.
• This product is designed for use in wood ceiling joist or solid concrete ceilings. – DO NOT
install into drywall alone.
• The ceiling must be capable of supporting four times the weight of the TV and mount combined.
• Use this mounting system only for its intended use as described in these instructions. Do not use
attachments not recommended by the manufacturer.
• Do not use outdoors.
• Route cords and cables properly to avoid mechanical damage.
• SAVE THESE INSTRUCTIONS.
DO NOT exceed the maximum weight indicated. This mounting
system is intended for use only within the maximum weights
indicated. Use with products heavier than the maximum
weights indicated may result in failure of the mount and its
accessories, causing damage and or injury.
WARNING
02
03
x2
TV Bracket
L2.5mm
[F1]
x8
L10mm
[F2]
x4
L22mm
[F3]
x4
04
M4/M5 Washer
[B1]
x4
M6/M8 Washer
[B2]
x4
05 Spacers
[If necessary]
NOTE: The spacers shown are actual size.
Supplied Parts and Hardware for Step 1
3/8” (10 mm)
Concrete Drill Bit Hammer
(Needed for concrete installs)(Needed for wood stud installs)
Verify Your Ceiling Construction
If you are not sure of
your ceiling
construction, please
contact our Technical
Support at
(877) 419-7832 or
Customer Service at
CAUTION
DO NOT
install into
drywall alone Ceiling Joist
(with Drywall) Solid Concrete
Wall
Phillips
Screwdriver
Tools Needed (Not lncluded)
Stud Finder
Tape Measure
Electric DrillAwl
Pencil Level
Supplied Parts and Hardware
WARNING: This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. Do not use
damaged or defective parts. If you require replacement parts, please contact our
• PLEASE NOTE: Not all hardware included in this package will be used.
7/32” (5.5mm)
Wood Drill Bit
3/8” (10mm)
Socket Wrench
1/2” (13mm)
Socket Wrench
03
M4
M6
M8
M6M4 M8
NOTE: The bolts shown are in actual size.
TV Bolts (Only one size of the bolt fits your TV)
06
Select TV Bolts
Only one size of the bolt fits your TV.
Step 1 Secure the TV Brackets to the TV
Bolt length: Verify adequate thread engagement with bolts or bolts/spacers
combination. We recommend thread engagement by at least 5 turns.
-Too short will not hold the TV.
-Too long will damage the TV.
NOTE: Please do not over tighten the TV bolts to avoid damaging your TV.
[C1] x4
M4x12mm
[C2] x4
M4x30mm
M6x15mm
[D1] x4
M6x35mm
[D2] x4
[E2] x4
M8x50mm
M8x25mm
[E1] x4
04
PLEASE NOTE: If Spacers are required for your installation, a combination of
different Spacers can be stacked to obtain a proper length. See examples in the
image below. If you have any difficulty understanding how to install the TV Bolts or
Spacers, please contact our Technical Support at (877) 419-7832 or Customer
Too Short Correct Too Long
Parts Needed if You Have a TV as Shown Below
Recessed Holes
See Option E
Cables See
Option D
Bump See
Option C
Curved TV See
Option B
Spacers
F1+F1 F1+F2 F1+F1+F2 F1+F1+F3 F1+F2+F3F2+F3 F1+F1+F2+F3F1+F3
CAUTION: When attaching the TV
Brackets to the back of the TV,
ensure the end with round holes on
the TV Brackets are pointing to the
top of the TV and are equally centered
on the back of the TV.
PLEASE NOTE: The bolt hole
locations on your TV may vary in
accordance with the manufacturer's
design of the TV. We are only
illustrating possible locations
of the bolt holes.
UP
05
C1/D1/E1
06
B1/B2
04
F1
05
(If needed)
Option A (For Flat Back TV)
Refer back to Spacer Instructions
on Page 5, If needed
Phillips Screwdriver
(Not lncluded)
D
o
n
o
t
o
v
e
r
-
t
i
g
h
t
e
n
Spacers must be tall enough so that the curve on the back
of the TV will not interfere with the mounting plate.
D
o
n
o
t
o
v
e
r
-
t
i
g
h
t
e
n
Option B (For Curved Back TV)
Refer back to Spacer Instructions
on Page 5, If needed
C2/D2/E2
06
B1/B2
04
F1/F2/F3
05
Phillips Screwdriver
(Not lncluded)
06
Refer back to Spacer Instructions
on Page 5, If needed
Phillips Screwdriver
(Not lncluded)
03
F1/F2/F3
05 B1/B2
04
C2/D2/
E2
06
Option C (For TV with A “Bump”)
D
o
n
o
t
o
v
e
r
-
t
i
g
h
t
e
n
Refer back to Spacer Instructions
on Page 5, If needed
C2/D2/E2
06
B1/B2
04
F1/F2/F3
05
Phillips Screwdriver
(Not lncluded)
For cable interference, use Spacers [F1], [F2] and [F3] to create extra space
between the TV and TV brackets.
Option D (for TV with Cable Interference)
D
o
n
o
t
o
v
e
r
-
t
i
g
h
t
e
n
Spacers must be tall enough so there is no gap between TV bracket and
bump on the back of the TV.
07
Supplied Parts and Hardware for Step 2
Option E (For Recessed Holes )
F1/F2/F3
05
C2/D1/
E2
06
B1/B2
04 03
The Spacers need to fill in the recessed holes on the back of the TV so that
the TV Brackets are as close to the TV as possible.
D
o
n
o
t
o
v
e
r
-
t
i
g
h
t
e
n
Refer back to Spacer Instructions
on Page 5, If needed
Phillips Screwdriver
(Not lncluded)
08 x1
3/16 in(5mm)
Allen Key
02 x1
Ceiling Plate
Bolt
M6x12mm
x2
b1 x2
b2
Washer
22x6.4
x1
b3
M6 Washer
01 x1
Upper Pole
x1
b4
Bolt
M6x60mm M6 Nut
x1
b5
08
A1
Anchor
10X60 mm
x4
A2
CAUTION!
This Anchor is for concrete
ceiling ONLY. DO NOT use
them in drywall or ceiling
joist.
Supplied Hardware for Step 3
x4
NOTE: The lag screw is shown in actual size.
3/8” (10mm)
Socket Wrench
(NOT Included)
Step 2 Attach the Ceiling Plate to the Top of the Upper Pole
3/16” (5mm)
Allen Key
[05]
Lag Screw
5/16” x 2 3/4"
02
b4b5
b2
b3
b1b1
01
09
Step 3 Secure the Ceiling Plate to the Ceiling
For wood stud installation, follow STEP 3A
For concrete installation, follow STEP 3B
Use a Stud Finder (not included)
to locate ceiling joist to verify
the edges. Mark the edge and
center locations.
3A-1
Step 3A Wood Stud Option
● To avoid personal injury or property damage, Do Not over-tighten the Lag
Screws [A1]. Using a self-supplied socket wrench, tighten the Lag Screws [A1]
only until they are pulled firmly against the Ceiling Plate and ceiling.
● DO NOT USE ANCHOR FOR THIS STEP.
● Ensure the Ceiling Plate is securely fastened to the ceiling
before continuing to the next step.
● Nominal ceiling joist size: common 2” x 8” (51mm x 203mm) .
● Stud center must be verified.
● Do not use a drill for tightening the Lag Screws!
● Only use a Socket Wrench.
WARNING:
Anchor
XA2
Position the Ceiling Plate [02]
at your desired position, and
mark the pilot hole locations.
3A-2
Stud Finder
(NOT lncluded)
Pencil
(NOT Included)
Pencil
(NOT Included)
10
