Equinox Systems Megabar System EQLED63 Manual de usuario

www.prolight.co.uk

WARNING

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY

BEFORE YOUR INITIAL START-UP!

CAUTION!

Keep this equipment away from rain,

moisture and liquids.

SAFETY INSTRUCTIONS

Every person involved with the installation, operation & maintenance of this

equipment should:

- Be competent

- Follow the instructions of this manual

CAUTION! TAKE CARE USING THIS EQUIPMENT!

HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!

Before your initial start-up, please make sure that there is no damage caused during

transportation. Should there be any, consult your dealer and do not use the

equipment.

To maintain the equipment in good working condition and to ensure safe operation, it is necessary

for the user to follow the safety instructions and warning notes written in this manual.

Please note that damages caused by user modifications to this equipment are not

subject to warranty.

Equinox Megabar Safety

IMPORTANT:

The manufacturer will not accept liability for any resulting damages caused

by the non-observance of this manual or any unauthorised modification to the

equipment.

• Never let the power-cable come into contact with other cables. Handle the power-cable

and all mains voltage connections with particular caution!

• Never remove warning or informative labels from the equipment.

• Do not open the equipment and do not modify the equipment.

• Do not connect this equipment to a dimmer-pack.

• Do not switch the equipment on and off in short intervals, as this will reduce the

system’s life.

• Only use the equipment indoors.

• Do not expose to flammable sources, liquids or gases.

• Always disconnect the power from the mains when equipment is not in use or before

cleaning! Only handle the power-cable by the plug. Never pull out the plug by pulling the

power-cable.

• Make sure that the available voltage is between 220v/240v.

• Make sure that the power-cable is never crimped or damaged. Check the equipment and

the power-cable periodically.

• If the equipment is dropped or damaged, disconnect the mains power supply immediately.

Have a qualified engineer inspect the equipment before operating again.

• If the equipment has been exposed to drastic temperature fluctuation (e.g. after

transportation), do not switch it on immediately. The arising condensation might damage

the equipment. Leave the equipment switched off until it has reached room temperature.

• If your product fails to function correctly, discontinue use immediately. Pack the unit

securely (preferably in the original packing material), and return it to your Prolight dealer

for service.

• Only use fuses of same type and rating.

• Repairs, servicing and power connection must only be carried out by a qualified

technician. THIS UNIT CONTAINS NO USER SERVICEABLE PARTS.

• WARRANTY; One year from date of purchase.

OPERATING DETERMINATIONS

If this equipment is operated in any other way, than those described in this manual,

the product may suffer damage and the warranty becomes void.

Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks,

lamp failure etc.

Do not endanger your own safety and the safety of others!

Incorrect installation or use can cause serious damage to people and property.

Equinox Megabar Technical specifications

You should find inside the carton the following items:

1, Equinox Megabar 2, Power cable 3, User manual

Technical Specifications:

DMX channels: 6, 9 and 15 selectable

Operating modes: 1, Sound Activated

2, Built-in programmes

3, Auto Run

4, DMX

5, Slave

28 x 3W Tri-colour LEDs (total) - 7 x RGB tri-colour - per panel

14 built-in programmes

4 Push button LCD digital display

Beam angle: 25˚

Mains IEC Power In/Out sockets

3-Pin XLR In/Out sockets for DMX

5-Pin socket for foot controller (MB-1)

Power consumption: Max.100W

Power supply: 240V

Dimensions: 1030x 100 x 290mm

Weight: 7Kgs

Fuse: F2A

Overview

Identification:

1, Power output

2, Power input

3, On/Off switch

4, Remote input

5, DMX In

6, DMX out

O N

7, LCD digital display

8, Mode button

9, Setup button

10, Up button

11, Down button

Operation modes:

The Equinox Megabar has five modes of operation as follows:

1, Sound active mode

To select the sound active mode, press the “MODE” button to show “SOUND MODE” in the LCD

display window. Now press the “SETUP” button and use the “UP” and “DOWN” buttons to

adjust the sound sensitivity level (SENS00-31) and press the “SET UP” button again to adjust the

frequency level (FQN01-99). Finally press the “SETUP” button to confirm your setting.

2, Built-in programmes mode

To access the built-in programme mode, press the “MODE” button to show “01.STATIC” in the

LCD display window. Now press the “SETUP” button and use the “UP” and “DOWN” buttons to

choose one of the 14 built-in programmes (01-14) (see table overleaf).

To choose one of the seven colours in the “STATIC” mode, press the set “SETUP” button and

use the “UP” and “DOWN” buttons to choose one of the following 7 colours:

(1) RGB = all on, (2) BR = purple, (3) B = blue, (4)GB = cyan,

(5) G = green, (6) RG = yellow, (7) R = red, BLA = blackout.

To adjust the speed level in the remaining 13 built-in programmes, press the SETUP” button and

use the “UP” and “DOWN” buttons to set the desired speed level (00-99).

To adjust the flash speed press the “SETUP” button and use the “UP” and “DOWN” buttons to

set the desired flash speed level (00-99). Finally press the “SETUP” button to confirm

your setting.

3, Auto Run mode

To select the Auto run mode, press the “MODE” button to show “AUTO RUN” in the LCD display

window. Now press the “SET UP” button to adjust the frequency level (FQN01-99). Finally press

the “SETUP” button to confirm your setting. The unit will now run all 13 built-in programmes one

after another.

4, DMX mode

To select the DMX mode, press the “MODE” button to show “DMX MODE” in the LCD display

window. Press the “SETUP” button and use the “UP” and “DOWN” buttons to set a DMX

address from 001-512. Now press the “SETUP” button again and use the “UP” and “DOWN”

buttons to choose one of the 3 DMX channel settings (6CH, 9CH or 15CH) Finally press the

“SETUP” button to confirm your setting. (see DMX chart). The starting address for this fixture is

001.

5, Slave mode

To select Slave mode, first link the units together via 3-Pin XLR cable(s), press the “MODE”

button to show “SLAVE MODE” on all of the slave units. Now the slave units will follow in

conjunction with the master unit.

NOTE: If the Mega Bar is being used in conjunction with the MB-1 foot controller any

number of Mega bars can be controlled via the foot controller by setting all bar systems

into “SLAVE” mode.

NOTE: The frequency level (FQN01-99) adjusts how many times the programme repeats

before moving to the next programme.

Equinox Megabar Operation modes

Built-in programme chart

Equinox Megabar Operation modes

Static Colour

BLAC-RGB Flash00-99

Dream

Speed00-99 Flash00-99

Meteor

Speed00-99 Flash00-99

Fade

Speed00-99 Flash00-99

Change

Speed00-99 Flash00-99

Flow 1

Speed00-99 Flash00-99

Flow 2

Speed00-99 Flash00-99

Flow 3

Speed00-99 Flash00-99

Flow 4

Speed00-99 Flash00-99

Flow 5

Speed00-99 Flash00-99

Flow 6

Speed00-99 Flash00-99

Flow 7

Speed00-99 Flash00-99

Flow 8

Speed00-99 Flash00-99

1. BLAC-RGB 2. BLAC-RGB

Flow 9

Speed00-99 Flash00-99

1. BLAC-RGB 2. BLAC-RGB

Red-Yellow-Green-Cyan-Blue-Purple-White-Blackout

Flash speed adjustable

7 colour dreaming

Speed & Flash adjustable

7 colour flow

Speed & Flash adjustable

7 colour fade

Speed & Flash adjustable

7 colour change

Speed & Flash adjustable

7 colour chase in 1 direction

Speed & Flash adjustable

7 colour chase in 2 directions

Speed & Flash adjustable

7 colour relay chase in 1 direction

Speed & Flash adjustable

7 colour relay chase in 2 directions

Speed & Flash adjustable

7 colour chase from sides to centre

Speed & Flash adjustable

7 colour chase from centre to side

Speed & Flash adjustable

7 colour chase

Speed & Flash adjustable

2 colour chase in 1 direction

Speed & Flash adjustable

Red-Yellow-Green-Cyan-Blue-Purple-White-Blackout

2 colour chase in 2 directions

Speed & Flash adjustable

Red-Yellow-Green-Cyan-Blue-Purple-White-Blackout

6 channel DMX chart (All four LED pods adjusted at the same time)

9 channel mode (Adjusts the LED pods in pairs)

15 channel mode (Adjusts each LED pod individually)

Equinox Megabar DMX Charts

CH 4

Red

pods

3+4

CH 5

Green

pods

3+4

CH 6

Blue

pods

3+4

CH 7

Red

pods

1+2

CH 8

Green

pods

1+2

CH 9

Blue

pods

1+2

CH 4

Red

pod

CH 5

Green

pod

CH 6

Blue

pod

CH 7

Red

pod

CH 8

Green

pod

CH 9

Blue

pod

CH 10

Red

pod

CH 11

Green

pod

CH 12

Blue

pod

CH 13

Red

pod

CH 14

Green

pod

CH 15

Blue

pod

Further DMX cables can be purchased from all

good sound and lighting suppliers or Prolight

dealers.

Please quote:

CABL10 – 2M

CABL11 – 5M

CABL12 – 10M

DMX Control Mode

Operating in a DMX control mode environment gives the user the greatest flexibility when it comes

to customising or creating a show. In this mode you will be able to control each individual trait of

the fixture and each fixture independently.

Setting the DMX address

The DMX mode enables the use of a universal DMX controller. Each fixture requires a

“start address” from 1- 511. A fixture requiring one or more channels for control begins to read the

data on the channel indicated by the start address. For example, a fixture that occupies or uses 7

channels of DMX and was addressed to start on DMX channel 100, would read data from

channels: 100,101,102,103,104,105 and 106. Choose a start address so that the channels used

do not overlap. E.g. the next unit in the chain starts at 107.

DMX-512:

• DMX (Digital Multiplex) is a universal protocol used as a form of communication between

intelligent fixtures and controllers. A DMX controller sends DMX data instructions form the

controller to the fixture. DMX data is sent as serial data that travels from fixture to fixture via the

DATA “IN” and DATA “OUT” XLR terminals located on all DMX fixtures (most controllers only have

a data “out” terminal).

DMX Linking:

• DMX is a language allowing all makes and models of different manufactures to be linked together

and operate from a single controller, as long as all fixtures and the controller are DMX compliant.

To ensure proper DMX data transmission, when using several DMX fixtures try to use the

shortest cable path possible. The order in which fixtures are connected in a DMX line does not

influence the DMX addressing. For example; a fixture assigned to a DMX address of 1 may be

placed anywhere in a DMX line, at the beginning, at the end, or anywhere in the middle. When a

fixture is assigned a DMX address of 1, the DMX controller knows to send DATA assigned to

address 1 to that unit, no matter where it is located in the DMX chain.

DATA Cable (DMX cable) requirements (for DMX operation):

• The Equinox Megabar can be controlled via DMX-512 protocol. The DMX address is set on the

back of the unit. Your unit and your DMX controller require a standard 3-pin XLR connector for

data input/output (figure 1).

Figure 1

Also remember that DMX cable must be daisy chained and cannot be split.

Equinox Megabar DMX set up

Notice:

• Be sure to follow figures 2 & 3 when making your own cables. Do not connect the cable’s shield

conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer

casing. Grounding the shield could cause a short circuit and erratic behaviour.

Special Note: Line termination:

• When longer runs of cable are used, you may need to use a terminator on the last unit to

avoid erratic behaviour.

Using a cable terminator (part number CABL90) will decrease the possibilities of erratic

behaviour.

5-Pin XLR DMX Connectors:

• Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-Pin

XLR fixtures may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin

XLR connectors in to a 3-pin line a cable adaptor must be used. The Chart below details the

correct cable conversion.

Termination reduces signal transmission problems

and interferance. it is always advisable to connect a

DMX terminal, (resistance 120 Ohm 1/4 W) between

pin 2 (DMX-) and pin 3 (DMX+) of the last fixture.

Equinox Megabar DMX Set Up

Overview (top)

Overview (back)

Operations

This foot controller is made specially for the Megabar system. All of the built-in programmes can

be accessed via the 4 foot switches. To control the Megabar using the foot switch controller, you

must first set the bar systems into “SLAVE” mode.

Static colour selection mode:

To activate this mode, press the “MODE” foot switch so the “R” LED indicator is lit, now use

the “UP” and “DOWN” foot switches to select the desired colour. To blackout the unit, press the

“BLACKOUT” foot switch and press it again to return it to the previous setting.

Sound active mode:

To activate this mode, press the “MODE” foot switch so the “G” LED indicator is lit, now the unit

will work to the music. If you require to blackout the unit at any point, press the “BLACKOUT” foot

switch and press it again to return it to the previous setting.

Built-in programmes:

To activate this mode, press the “MODE” foot switch so the “Y” LED indicator is lit, now use the

“UP” and “DOWN” foot switches to select the desired built-in programme. To blackout the unit,

press the “BLACKOUT” foot switch and press it again to return it to the previous setting.

Full on mode:

To set the unit to Full On you can press and hold down for 3 seconds any of the four foot switches,

this will give Full ON “WHITE”. To return to the previous setting press the “MODE” foot switch.

When Full On is activated you can still use the “BLACKOUT” foot switch.

Equinox Megabar Footswitch Operation

Tabla de contenidos

Otros manuales de Equipo de iluminación de Equinox Systems

Equinox Systems

Equinox Systems ATRIA Manual de usuario

Equinox Systems

Equinox Systems Cirrus Manual de usuario

Equinox Systems

Equinox Systems LED Par 64 Manual de usuario

Equinox Systems

Equinox Systems Eyebar Manual de usuario

Equinox Systems

Equinox Systems PEGASUS II Manual de usuario

Equinox Systems

Equinox Systems Terminator 2 Manual de usuario

Equinox Systems

Equinox Systems EQLED040 Manual de usuario

Equinox Systems

Equinox Systems Party Par EQLED015 Manual de usuario

Equinox Systems

Equinox Systems Goboceptor Manual de usuario

Equinox Systems

Equinox Systems Vortex Manual de usuario

Equinox Systems

Equinox Systems Nimbus Manual de usuario

Equinox Systems

Equinox Systems FUSION SPOT MAX MKII Manual de usuario

Equinox Systems

Equinox Systems UV Mini Batten 9 Manual de usuario

Equinox Systems

Equinox Systems PIXELpoint Batten Manual de usuario

Equinox Systems

Equinox Systems VS 1500 Fogger Manual de usuario

Equinox Systems

Equinox Systems CARINA Manual de usuario

Equinox Systems

Equinox Systems SpectraPix Lithium Batten Manual de usuario

Equinox Systems

Equinox Systems XP 80W Manual de usuario

Equinox Systems

Equinox Systems FLAM11 Manual de usuario

Equinox Systems

Equinox Systems CAPRICORN EQLA22 Manual de usuario

Equinox Systems

Equinox Systems Gigabar MKII COB Manual de usuario

Equinox Systems

Equinox Systems MidiPar Tri Plus Manual de usuario

Equinox Systems

Equinox Systems Domin8r IIEQLED53 Manual de usuario

Equinox Systems

Equinox Systems GEMINI Manual de usuario

Manuales populares de Equipo de iluminación de otras marcas

Brizo

Brizo 8SP-MU-4 Manual de usuario

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Manual de usuario

IKEA

IKEA BJÖRKSPIREA Manual de usuario

Laserworld

Laserworld Evolution Series ES-400RGB Manual de usuario

Alien

Alien RG STAR Manual de usuario

EuroLite

EuroLite LED B-40 Manual de usuario

Qazqa

Qazqa Suplux SL 3 Black 103062 Manual de usuario

Commercial Electric

Commercial Electric 54568141 Manual de usuario

CREE LIGHTING

CREE LIGHTING 304 Series Manual de usuario

Goobay

Goobay 49867 Manual de usuario

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Manual de usuario

Alkalite

Alkalite Krypton KT-81 Manual de usuario

Clas Ohlson

Clas Ohlson GU10 Manual de usuario

DTS

DTS DELTA 10 F Manual de usuario

ring

ring Solar Steplight Manual de usuario

One Stop Gardens

One Stop Gardens 57696 Instrucciones de montaje

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Manual de usuario

SIREM

SIREM Swimeo A2 Manual de usuario
