Epson Expression 1600 Manual de usuario

Color Graphics Scanner

User’s Guide

saffron.book Page i Tuesday, January 11, 2000 2:32 PM

any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior

written permission of SEIKO EPSON CORPORATION. The information contained herein is designed only for

use with this EPSON scanner. EPSON is not responsible for any use of this information as applied to other

scanners.

Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to the purchaser of this product or third

parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse,

or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the

U.S.) failure to strictly comply with SEIKO EPSON CORPORATION’s operating and maintenance instructions.

SEIKO EPSON CORPORATION shall not be liable for any damages or problems arising from the use of any

options or any consumable products other than those designated as Original EPSON Products or EPSON

Approved Products by SEIKO EPSON CORPORATION.

A Note Concerning Responsible Use of Copyrighted Materials

Digital cameras and scanners, like photocopiers and conventional scanners, can be misused by improper copying of

copyrighted material. While some countries’ laws permit limited copying of copyrighted material in certain

circumstances, those circumstances may not be as broad as some people assume. EPSON encourages each user to

be responsible and respectful of the copyright laws when using digital cameras and scanners.

Trademarks

EPSON and EPSON Stylus are registered trademarks of SEIKO EPSON CORPORATION.

EPSON SoundAdvice is a service mark. Micro Step Drive and EPSON FaxAdvice are trademarks, and Expression

and ColorTrue are registered trademarks of Epson America, Inc.

General Notice: Other product names used herein are for identification purposes only and may be trademarks of

their respective owners. EPSON disclaims any and all rights in those marks.

1/00

Printed on recycled paper with at least 10% post-consumer content.

saffron.book Page ii Tuesday, January 11, 2000 2:32 PM

iii

Contents

CHAPTER 1 WELCOME 9

About Your Scanner 9

About Your Software 10

Getting More Information 11

Warnings, Cautions, Notes, and Tips 12

Reading Your Reference Guide 13

Viewing Your Other Electronic Manuals 15

Registering 17

CHAPTER 2 SETTING UP YOUR SCANNER 19

Unpacking Your Scanner 20

Choosing a Good Place for Your Scanner 22

Unlocking the Scanner 23

Testing Your Scanner’s Operation 24

Connecting the Scanner to Your Computer 25

Connecting to a USB Interface 26

Connecting to a SCSI Interface 27

Connecting to an IEEE 1394 FireWire Interface 29

Installing the Windows Software 30

Installing the Windows 98 Software 30

Installing the Windows 95 Software 37

Installing the Windows NT 4.0 Software 42

Installing Additional Windows Software 45

Installing TextBridge Classic 45

Installing Adobe Photoshop 5.0 LE 46

Installing MonacoEZcolor 46

saffron.book Page iii Tuesday, January 11, 2000 2:32 PM

Installing the Macintosh Software 47

Starting the Macintosh Software Installation 47

Installing Other Software on Your Scanning Tools CD-ROM 49

Installing Adobe Photoshop 5.0 LE 50

Installing MonacoEZcolor 51

Selecting the Expression 1600 as Your Default Scanner 51

CHAPTER 3 HOW TO SCAN 53

Scanning Tips 53

Selecting Resolution 53

Scaling (Resizing) Images 54

Scanning Color Images 54

Batch Scanning 55

Using the Dual Focus Mechanism 55

Recommended Settings 56

Step-by-Step Scanning Instructions 57

Placing Your Original Document 57

Scanning with EPSON TWAIN Pro 58

Using the

] Start Button 60

Setting Up the

] Start Button 61

Setting Up Presto! PageManager for One-Touch Scanning 64

CHAPTER 4 NETWORK SCANNING 67

Setting Up the Scanner Server 68

Installing the Scanner Server Software on Windows 98 68

Installing the Scanner Server Software on

Windows 95 and Windows NT 4.0 74

Changing the Scanner Server Start Up Mode 81

Setting Up Client Computers 82

Installing EPSON TWAIN Pro Network on Windows 82

Installing EPSON TWAIN Pro Network on a Macintosh 85

saffron.book Page iv Tuesday, January 11, 2000 2:32 PM

Using a Network Scanner 88

Starting EPSON Scan Server 89

Starting EPSON TWAIN Pro Network 90

Starting a Scan 91

Stopping a Scan in Progress 92

CHAPTER 5 USING OPTIONAL EQUIPMENT 93

Transparency Unit 93

Unpacking the Transparency Unit 94

Removing the Shipping Screw 95

Installing the Transparency Unit 95

Using the Film Guides 97

Scanning Reflective Documents 101

Automatic Document Feeder 102

Unpacking the Automatic Document Feeder 102

Installing the Automatic Document Feeder 103

Loading Paper in the Automatic Document Feeder 105

Fixing Paper Jams 106

IEEE 1394 FireWire Scanner Interface Card 106

Installing the Card in Your Scanner 107

CHAPTER 6 SCANNER MAINTENANCE 109

Transporting the Scanner 109

Transporting the Transparency Unit 110

Cleaning the Scanner 111

saffron.book Page v Tuesday, January 11, 2000 2:32 PM

CHAPTER 7 SOLVING PROBLEMS 113

Lights and Buttons 113

Problems and Solutions 115

Setup Problems 115

Scanner Problems 117

Software Problems 118

Scanning Problems 120

Uninstalling the Expression 1600 Software 125

Uninstalling EPSON TWAIN Pro 125

Uninstalling EPSON TWAIN Pro Network 126

Uninstalling EPSON Scan Server 127

Where To Get Help 128

EPSON Technical Support 128

Software Technical Support 129

APPENDIX A SPECIFICATIONS 131

Scanner 131

General 131

Electrical 132

Environmental 133

Safety Approvals 133

SCSI Interface 133

USB Interface 133

Option Interface Connector 134

Initialization Methods 134

Transparency Unit (B813182) 134

General 134

Electrical 134

Environmental 134

saffron.book Page vi Tuesday, January 11, 2000 2:32 PM

vii

Automatic Document Feeder (B813162) 135

General 135

Electrical 135

Environmental 135

IEEE 1394 FireWire Scanner Interface Card (B808342) 135

General 135

Environmental 135

APPENDIX B INSTALLING THE TCP/IP PROTOCOL 137

Installing the TCP/IP Protocol on Windows 95 and Windows 98 138

Assigning an IP Address 139

Installing the TCP/IP Protocol on Windows NT 4.0 140

Assigning an IP Address 141

APPENDIX C NOTICES 143

System Requirements 143

Windows 143

Macintosh 144

Year 2000 Ready 145

Important Safety Instructions 145

ENERGY STAR Compliance 146

Declaration of Conformity 147

FCC Compliance Statement 148

For United States Users 148

Warning 148

For Canadian Users 148

Limited Warranty 149

INDEX 151

saffron.book Page vii Tuesday, January 11, 2000 2:32 PM

viii

saffron.book Page viii Tuesday, January 11, 2000 2:32 PM

Welcome

The EPSON®Expression®1600 is a 36-bit

professional graphics scanner designed to meet the

needs of artists, graphics professionals, and business

graphics users. It’s ideally suited for small LAN

(Local Area Network) users who want to share a

scanner within their workgroup. Using EPSON’s

ColorTrue®II Imaging System, it reproduces

images with amazingly accurate detail and color.

Your scanner can achieve up to 1600 × 3200 dpi hardware resolution with EPSON’s

proprietary Micro Step Drive™technology, and is one of the fastest scanners in

its class.

About Your Scanner

Your EPSON Expression 1600 scanner comes with these features:

■Superior image quality with true optical resolution of 1600 dpi

■36-bit color depth for capturing images with over 68 billion colors and 4,096

shades of gray

■Start button for easy, automated scanning

■Unique Dual Focus mechanism lets you choose the focus position

■Can be shared by several users in a small workgroup

■USB, SCSI 2, and IEEE 1394-compatible FireWire®

(USB and SCSI 2 interfaces

are standard)

■Optional transparency unit, automatic document feeder, and IEEE 1394

FireWire scanner interface card

saffron.book Page 9 Tuesday, January 11, 2000 2:32 PM

About Your Software

The EPSON Expression 1600 scanner includes these leading-edge applications for

professional-quality scans:

EPSON TWAIN Pro

Exclusive professional-quality scanner driver with powerful

features for controlling every aspect of your scan. Includes

Auto Area Segmentation (AAS) to separate text from

background colors, and Text Enhancement Technology

(TET) for more accurate OCR scanning.

EPSON Scan Server (PC only)

Enables you to share the Expression 1600 with other users in a

small workgroup.

EPSON TWAIN Pro Network

This network version of EPSON TWAIN Pro lets client

computers use the Expression 1600 when it’s attached to

another computer. (EPSON Scan Server must be installed

on the computer sharing the scanner.)

Adobe®Photoshop®5.0 LE

Edit your photos with this version of the ultimate

imaging application. Add special effects, overlay titles and

captions, restore old photos, and add many other creative

enhancements to your photographs. (Not included with the

Special Edition model.)

Xerox®TextBridge®Classic

Use the premiere OCR (Optical Character Recognition)

software to turn your paper documents into electronic text

without retyping. (Not included with the Special Edition

model.)

saffron.book Page 10 Tuesday, January 11, 2000 2:32 PM
