Epson PowerLite D6150 Manual del sistema

INSTALLATION HANDBOOK

Remote Control Info

Epson PowerLite D6150 /

D6155W / D6250

Remote Control Operation

The remote control lets you control the projector from almost anywhere in the room, up to 19.7 feet (6 m)

away. You can point it at the screen, or the front or back of the projector.

Make sure that you aim the remote control at the projector's receivers within the angles listed here.

1 19.7 feet (6 m)

2 60º

3 30º

4 10º (no reception)

5 70º

6 60º

Note: Avoid using the remote control in conditions with bright fluorescent lights or in direct sunlight, or

the projector may not respond to commands. If you will not use the remote control for a long time,

remove the batteries.

Using the Remote Control as a Wireless Mouse

You can use the projector's remote control as a wireless mouse so you can control your computer

presentation from a distance.

1. Connect the projector to a computer using the projector's Computer or HDMI port.

2. Using a USB cable, connect the projector's USB TypeB port to a USB port on your computer (for

wireless mouse support).

3. Start your presentation.

INSTALLATION HANDBOOK

Epson PowerLite D6150 /

D6155W / D6250

Remote Control Info

4. Use the following buttons on the remote control to control your presentation:

•To move through slides or pages, press the Up and Down Page buttons.

•To move the cursor on the screen, use the arrow buttons.

•To left-click, press the Enter button once (press it twice to double-click).

•To right-click, press the Esc button.

•To drag-and-drop, hold the Enter button as you move the cursor with the arrow buttons, then

release Enter at the destination.

Using the Remote Control as a Presentation Pointer

You can use the projector's remote control as a pointer to help you call out important information

a presentation. The default pointer shape is an arrow, but you can select an alternative shape

Settings menu.

1. Press the Pointer button on the remote control.

2. Use the arrow buttons on the remote control to move the pointer on the screen.

3. Press Esc to clear the pointer from the screen.

INSTALLATION HANDBOOK

Epson PowerLite D6150 /

D6155W / D6250

Remote Control Info

Selecting an Image Source

If you connected multiple image sources to the projector, such as a computer and DVD player, you may

want to switch from one image source to the other.

1. Make sure the connected image source you want to use is turned on.

2. For video image sources, insert a DVD or other video media and press Play (if necessary).

3. Do one of the following:

•Press the Source Search button on the projector or remote control until you see the image from

the source you want.

•Press the button for the source you want on the remote control. If there is more than

that source, press the button again to select the other source.

1 Computer port sources

2 Video and HDMI sources

3 USB port sources (external devices)

4 Network source

4. If you see a blank screen or a "No Signal" message, try the following:

•Check that the device cables are securely connected to the projector and the device.

•Make sure the projector is turned on.

•For laptop computers, make sure you have set up your laptop to output its display properly.

INSTALLATION HANDBOOK

Epson PowerLite D6150 /

D6155W / D6250

Remote Control Info

Replacing the Remote Control Batteries

The remote control uses the two AA manganese or alkaline batteries. Replace the batteries as soon as

they run out.

Caution: Use only the type of batteries specified in this manual. Do not install batteries of different types,

or mix new and old batteries.

1. Open the battery cover as shown.

2. Remove the old batteries.

Warning: If the battery fluid has leaked, wipe it away with a soft cloth and avoid getting the fluid on

your hands. If it gets on your hands, wash them immediately to avoid injury.

3. Insert the batteries with the +and –ends facing as shown.

4. Close the battery cover and press it down until it clicks into place.

Warning: Dispose of used batteries according to local

regulations. Do not expose batteries to heat or flame.

Keep batteries out of the reach of children; they are

choking hazards and are very dangerous if swallowed.
