Epson PowerLite 735c Dimensiones

Page 1 of 1

PSB.2006.04.002

EPSON PRODUCT SUPPORT BULLETIN

Date: 04/20/2006 Originator: AP

PSB #: PSB.2006.04.002 Authorization:

Reference: TI 05-95e Rev. A Total Pages: 1

Product(s): PowerLite 735c / 737c / 745c / 755c / 765c / 835p / 7850p

Subject: Animation converter issue found with EMP SlideMaker2 version 1.12

This bulletin was created to inform users of the EMP SlideMaker2 version 1.12 software of a

problem converting certain animations from Microsoft PowerPoint into a Scenario file.

Details:

In the previous EMP SlideMaker2 version 1.11, certain PowerPoint animations were supported

in the Scenario files which are created by EMP SlideMaker2. Table 1 shows the list of

animations supported in EMP SlideMaker2 version 1.11:

Table 1

Table 2 shows the list of animations from Table 1 that will not be ported from PowerPoint into

the Scenario file by EMP SlideMaker2 version 1.12:

Table 2

Countermeasure:

If it is necessary to use these animations in the Scenario files, use EMP SlideMaker2 version

1.11. Versions of EMP SlideMaker2 subsequent to version 1.12 are expected to incorporate

the animations shown in Table 1 above.

EMP SlideMaker2 version 1.11 may be downloaded at www.epson.com. Download

epson10855.exe to get this version of the software.

If it is not necessary to use these animations listed in Table 2 above, continue to use the EMP

SlideMaker2 version 1.12. Download epson11217.exe at www.epson.com for EMP

SlideMaker2 version 1.12.

- Fly - Blinds - Box - Checkerboard

- Crawl - Dissolve - Peek - Random Bars

- Spiral - Split - Stretch - Strips

- Swivel - Wipe - Zoom

- Crawl - Peek

- Spiral - Stretch

- Swivel - Zoom

Page 1 of 3

PSB.2005.05.001

EPSON PRODUCT SUPPORT BULLETIN

Date: 05/11/2005 Originator: VS

PSB #: PSB.2005.05.001 Authorization:

Reference: TI 03-42e Rev. B, TI 04-45e Rev. D Total Pages: 3

Product(s): PowerLite 735c

Subject: Supported Wired and Wireless LAN cards

Reason:

This bulletin is to inform you of the testing results for wired and wireless LAN cards used with

the PowerLite 735c.

Models and firmware versions used in the evaluation:

Projector PowerLite 735c

Firmware V1.11

IM-X firmware (EasyMP) V1.10

EMP Monitor Version 3.04

NS Connection Version 1.32

Wireless LAN cards configuration:

1) The tested Wireless LAN cards are inserted into the PC and a wireless LAN connection

(Ad hoc mode) is made to the projector.

2) The tested Wireless LAN cards are inserted into the PC and a wireless LAN connection

is made to the projector using an access point (Infrastructure mode).

Items evaluated:

The following items were tested and confirmed to work in both Ad hoc and Infrastructure

modes. (WEP is only supported in the Infrastructure mode.)

1) All functions of EMP Monitor.

2) The following was tested in Infrastructure mode:

•DHCP, ESSID and WEP can be setup by a browser and function properly.

•WPA and LEAP work when implemented.

3) EMP NS Connection functions properly with the freeze, mute, zoom, and video input

change features.

4) Power Point slide show works.

Page 2 of 3

PSB.2005.05.001

Evaluation results for the Wireless LAN cards:

Wireless LAN card POWERLITE 735c

3Com,3crshpw 196, office connect Pass

Cisco Aironet350 AIR-PCM341(2.4GHz) Pass

FMV Notebook (Broadcom BCM4306) Pass

FMV Notebook (Intersil Prism2.5) Pass

Fujitsu FMV-JW181(Agere) Pass

Fujitsu FMV-JW183(Agere HermesII) Pass

Fujitsu FMV-W182(Intersil Prism2.5) Pass

D-Link Airplus XtremeG DWL-G650 Pass

Intel,CR Pro Wireless 2011B, LAN PC Card Pass

Linksys WPC11 Wireless Network PC Card Pass

NetGear 54Mbps wireless PC Card WG511 Pass

SMC 2435W, EZ Connect Turbo, Pass

US Robotic Ref. 9514115MBP Pass

BUFFALO WLI-CB-G54 Pass

ADTEK ADLINK2422C Pass

FMV Notebook (Intel Calexico) Fail

Wired LAN cards configuration:

Inserted the wired LAN card to be tested into the projector, connected the projector to a hub

and connected two PCs to the same hub.

Items evaluated:

The following items were tested and confirmed to work.

1) All functions of EMP Monitor.

2) That DHC can be setup using a browser and functions properly.

3) EMP NS Connection functions properly with the freeze, mute, zoom, and video input

change features.

4) Power Point slide show works.

5) Using EMP NS Connection, a PC can take control of a projector from another PC.

Evaluation results for the Wired LAN cards:

Wired LAN Card name POWERLITE 735c

3Com 3C589C-TP Pass

3Com 3CXE589ET-JP Pass

D-Link DFE670TXD Pass

Fujitsu FMV-J182 Pass

Hawking PN652TX Pass

Linksys PCM100 ver2 Pass

Netgear FA411 Pass

Page 3 of 3

PSB.2005.05.001

SMC SMC8041TX Pass

3Com 10/100 LAN PC Card 3CCFE574BT Pass

PCET100-CL Pass

Linksys 10/100 PC Card Pass

SMC 8041TX V.2, EZ PC Card 10/100, SMC Pass

BUFFALO LPC-PCM-CLX Pass

ELECOM LD-CDK/TX Pass

Corega EtherII PCC-TD Pass

PLANEX FNW-3700-TX Pass

The following cards are NOT compatible:

01) 3Com 3CCFE575BT-JP

02) 3Com 3CXFE575CT-JP

03) 3Com 3CXFEM656C

04) Megahertz 10/100 LAN CardBus PC Card, 3Com

05) Come once (Taiwan card)

06) DFE-690TXD- Cardbus 32 bits

07) Fujitsu FMV-J184

08) Fujitsu FMV-J185

09) LPC3-CLTL

10) NetGear CardBus Notebook Adapter FA511

11) SMC 8036TX, EZ PC Card 10/100, SMC

12) TDK LAK-CB100X

13) Toshiba LANCB100A

14) Xircom CE3B-100BTX

15) Xircom CreditCard Ethernet CE3-10/10

16) I-O Data PCLA/TE

17) PCC-TXD

18) Kingston EtheRx PC Card KNE-PC2T

19) PLANEX GC-1000T

20) PLANEX FNW-3800-TX

21) BUFFALO LPC-CB-CLGT

22) IO DATA ETX-PCM

23) ELECOM LD-CBK/TX

NOTE:

No EMI (electro magnetic interference) was done, only a functionality evaluation.

Page 1 of 14

PSB.2004.10.002

EPSON PRODUCT SUPPORT BULLETIN

Date: 10/08/2004 Originator: DS

PSB #: PSB.2004.10.002 Authorization:

Reference: TI 04-46e Rev. A Total Pages: 14

Product(s): EMP NS Connection, EMP Network Manager, EMP Monitor,

EMP Multi Screen Adjustment, Cinema Color Editor, VCOM Driver

Subject: Evaluation results of Epson Projector PC applications tested in Windows XP

with SP2.

The purpose of this bulletin is to provide information on Epson PC projector applications tested

under the Windows XP SP2 (Service Pack2) environment.

Description:

Information is provided about the evaluation results and recommendations for Epson PC

projector applications functionality in Windows XP SP2 Firewall environment.

Reason:

Compatibility testing for functionality of EMP NS Connection, EMP Network Manager, EMP

Monitor, EMP Multi Screen Adjustment, Cinema Color Editor, VCOM Driver in the Windows

XP SP2 environment.

Results of Windows XP SP2 installation:

Installing SP2 on PCs did not disturb the installation of the above software applications.

Also, the application software can be installed on PCs where SP2 or earlier versions are

installed without any issues.

The information contained in the following pages provides details for executing the

applications in Windows XP SP2.

Page 2 of 14

PSB.2004.10.002

Executing the Software:

When executing the software noted below for the first time after SP2 installation completes,

the following security alert messages are displayed:

[EMP NS Connection]

Security alert screen (EMP NS Connection)

[EMP Network Manager]

Security alert screen (EMP Network Manager)

Page 3 of 14

PSB.2004.10.002

[EMP Monitor]

Security alert screen (EMP Monitor)

[EMP Multi Screen Adjustment]

Security alert screen (EMP Multi Screen Adjustment)

The Security Alert screen for EMP Multi Screen Adjustment is shown after clicking the

Auto button of Network or clicking the Add button after entering an IP address in the

IP Address box.

Page 4 of 14

PSB.2004.10.002

[Cinema Color Editor]

Security alert screen (Cinema Color Editor)

The functions of the three buttons displayed in the security alert screen are explained

below.

[Keep Blocking] --- Enables you to register a started application in the “Exceptions”

program of the Windows Firewall. The network port that the

application uses is blocked. By selecting this button once, this

security alert message will not be shown when starting the

application next time.

[Unblock] ------------- Enables you to register a started application in the “Exceptions”

program of the Windows Firewall and unblock the network port that

the application uses. By selecting this option once, this security alert

message will not be shown when starting the application next time.

[Ask me later]-------- When you want to select both buttons above or select either one

later, this button is selected. The started application is not registered

in the “Exceptions” program of the Windows Firewall and the

network that the application uses is not unblocked. However, when

restarting the application, the same security alert message is shown.

•PC applications will work normally on Windows XP with SP2 if the “Unblock

Item” is selected when the security alert screen is shown.

For the detail operation information of each application, please refer to the following:

Page 5 of 14

PSB.2004.10.002

Operating Status Report

When selecting the Keep Blocking button, the security alert message is closed and the

main screen of each application is displayed.

[EMP NS Connection Application]

Port 3620 is necessary for searching for projectors. If this port is blocked, projectors are not

detected.

The other applications operate normally. However, there is a case that execution of

automatic search disables automatic detection. This occurs when projectors are registered

for automatic detection in EMP Monitor before installing SP2, then the registered projectors

may not be detected again after SP2 installation. Therefore it is recommended to select

Unblock in the security alert screen.

If “Keep Blocking” has been selected when starting the application for the first

time, and the blocking needs to be removed, complete the execution of the application and

proceed with unblocking as follows:

a.) Start the Windows Security Center. Double click the icon in the shape of a shield that

is always displayed on the taskbar after the installation of SP2.

Windows Security Center screen

b.) Select and start Windows Firewall

Page 6 of 14

PSB.2004.10.002

Windows Firewall screen

[Caution]

In case the check box

for Don’t allow

exceptions

is checked (this box is

not checked at the

initial setting), a

network port for

software is not

unblocked even though

the software is checked

on Exceptions.

Make sure this option is

not selected.

Otros manuales para PowerLite 735c

Este manual sirve para los siguientes modelos

Otros manuales de Proyector de Epson

Epson

Epson EB-2265U Manual de usuario

Epson

Epson PowerLite D6150 Manual del sistema

Epson

Epson PowerLite 77c Hoja de especificaciones

Epson

Epson EF-100WATV Manual de usuario

Epson

Epson EMP-713 Manual de usuario

Epson

Epson EB-410W Manual de usuario

Epson

Epson EX50 Hoja de especificaciones

Epson

Epson EH-LS650B Hoja de especificaciones

Epson

Epson CO-FH01 Manual de usuario

Epson

Epson PowerLite Home Cinema 640 Hoja de especificaciones

Epson

Epson 410W - PowerLite WXGA LCD Projector Manual de usuario

Epson

Epson WorkForce 60 Manual de usuario

Epson

Epson BrightLink 475Wi Manual de usuario

Epson

Epson EMP 600 Manual de usuario

Epson

Epson VS315W Instrucciones de funcionamiento y seguridad

Epson

Epson EMP-9100 Manual de usuario

Epson

Epson EH-TW5825 Manual de usuario

Epson

Epson EB-G5600 Manual de usuario

Epson

Epson EH-TW8000 Manual de usuario

Epson

Epson PowerLite 820p Manual de usuario

Epson

Epson PowerLite 570 Manual del sistema

Epson

Epson 826W - PowerLite WXGA LCD Projector Dimensiones

Epson

Epson MovieMate 30s Manual de usuario

Epson

Epson EB-485Wi Manual de usuario

Manuales populares de Proyector de otras marcas

iEmmet

iEmmet MP-312 Manual de usuario

Sony

Sony VPL-HS10 Marketing Specifications & Features Manual de usuario

Sony

Sony VPL-HW65ES Manual de servicio

Toshiba

Toshiba TLP-791U Manual de usuario

Philips

Philips LC1341 Guía de referencia

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manual de usuario

NEC

NEC NP600S EDU Manual de usuario

BenQ

BenQ SH753P Manual de usuario

Eiki

Eiki EK-623U series Manual de usuario

Christie

Christie LHD700 Manual de usuario

Navitar

Navitar FX Manual de usuario

InFocus

InFocus LitePro 560 Manual de usuario

Sony

Sony SRX-R815P Manual de usuario

Vivitar

Vivitar DP1500 X Manual de usuario

Acer

Acer C20 Series Manual de usuario

Asus

Asus ZenBeam Latte Manual de usuario

BOXLIGHT

BOXLIGHT CP-322i/CP-634i Manual de usuario

JVC

JVC 1108TTH-AO-AO Manual de usuario
