PowerLite®4100/4200W/4300

Multimedia Projector

User’sGuide

Important Safety Information

WARNING: Never look into the projector lens when the lamp is turned on; the bright light can damage your eyes.

Never let children look into the lens when it is on. Never open any cover on the projector, except the lamp and

filter covers. Dangerous electrical voltages inside the projector can severely injure you. Except as specifically

explained in this User’s Guide, do not attempt to service this product yourself. Refer all servicing to qualified service

personnel.

WARNING: The projector and its accessories come packaged in plastic bags. Keep plastic bags away from small

children to avoid any risk of suffocation.

Caution: When you replace the lamp, never touch the new lamp with your bare hands; the invisible residue left by

the oil on your hands may shorten the lamp life. Use a cloth or glove to handle the new lamp.

any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior

written permission of Seiko Epson Corporation. The information contained herein is designed only for use with

this Epson product. Epson is not responsible for any use of this information as applied to other products.

Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for

damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of

this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to

strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.

Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any options or

any consumable products other than those designated as Original Epson Products or Epson Approved Products by

Seiko Epson Corporation.

Trademarks

Epson, Quick Corner, EasyMP, and Instant Off are registered trademarks, and Epson Exceed Your Vision is a

registered logomark of Seiko Epson Corporation.

PowerLite and PrivateLine are registered trademarks; SizeWise is a trademark; and Extra Care is a service mark of

Epson America, Inc.

Pixelworks, DNX, and the DNX logo are trademarks of Pixelworks, Inc.

General Notice: Other product names used herein are for identification purposes only and may be trademarks of

their respective owners. Epson disclaims any and all rights in those marks.

This information is subject to change without notice.

CPD-28140

Contents

Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Using Your Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Getting More Information . . . . . . . . . . . . . . . . . . . . . . . . 8

Registration and Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Optional Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1Setting Up the Projector . . . . . . . . . . . . . . . . . . . . . 11

Unpacking the Projector. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Additional Components. . . . . . . . . . . . . . . . . . . . . . . . . 12

Positioning the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Connecting to a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . 16

Connecting to the Computer Port . . . . . . . . . . . . . . . . . 17

Connecting to the BNC Connectors . . . . . . . . . . . . . . . 18

Connecting to Video Equipment . . . . . . . . . . . . . . . . . . . . . 19

Connecting a Composite Video Source . . . . . . . . . . . . . 20

Connecting a Component Video Source . . . . . . . . . . . . 21

Connecting an RGB Video Source. . . . . . . . . . . . . . . . . 22

Turning the Projector On and Off . . . . . . . . . . . . . . . . . . . . 23

Using the Direct Power On Function . . . . . . . . . . . . . . 25

Shutting Down the Projector . . . . . . . . . . . . . . . . . . . . . 26

2Displaying and Adjusting the Image . . . . . . . . 27

Displaying an Image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Adjusting the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Adjusting the Position of the Image . . . . . . . . . . . . . . . . 29

Focusing and Zooming the Image . . . . . . . . . . . . . . . . . 30

Adjusting the Image Shape. . . . . . . . . . . . . . . . . . . . . . . 30

Selecting the Color Mode . . . . . . . . . . . . . . . . . . . . . . . 32

Resizing Video Images . . . . . . . . . . . . . . . . . . . . . . . . . . 33

3Presenting With the Remote Control. . . . . . . . 35

Using the Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Controlling the Picture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Switching Between Picture Sources . . . . . . . . . . . . . . . . 36

Turning Off the Picture. . . . . . . . . . . . . . . . . . . . . . . . . 37

Stopping Action. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Zooming Part of Your Image . . . . . . . . . . . . . . . . . . . . . 37

Highlighting Your Presentation . . . . . . . . . . . . . . . . . . . . . . 38

Using the Pointer Tool . . . . . . . . . . . . . . . . . . . . . . . . . 38

Choosing a Different Pointer Shape. . . . . . . . . . . . . . . . 39

Operating Your Computer With the Remote Control . . . . . 39

Operating Two or More Projectors With the Remote Control40

Setting the Projector ID. . . . . . . . . . . . . . . . . . . . . . . . . 40

Checking the Projector ID. . . . . . . . . . . . . . . . . . . . . . . 41

Setting the Remote Control ID . . . . . . . . . . . . . . . . . . . 42

4Using the Projector on a Network. . . . . . . . . . . 43

Connecting to a Wired Network . . . . . . . . . . . . . . . . . . . . . 44

Configuring Basic Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Using Projector E-mail Alerts . . . . . . . . . . . . . . . . . . . . . . . . 47

Using SNMP to Monitor the Projector . . . . . . . . . . . . . . . . 48

Using a Browser to Control the Projector. . . . . . . . . . . . . . . 49

Using Web Remote Control . . . . . . . . . . . . . . . . . . . . . 50

5Fine-Tuning the Projector. . . . . . . . . . . . . . . . . . . 53

Using the Menu System . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Restoring the Default Settings . . . . . . . . . . . . . . . . . . . . 55

Adjusting the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Six-Axis Color Adjustment. . . . . . . . . . . . . . . . . . . . . . . 57

Adjusting Signal Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Customizing Projector Features . . . . . . . . . . . . . . . . . . . . . . 60

Using the Projector Security Features . . . . . . . . . . . . . . . . . . 62

Enabling Password Protection . . . . . . . . . . . . . . . . . . . . 62

Creating Your Own Startup Screen . . . . . . . . . . . . . . . . 64

Disabling the Projector’s Buttons. . . . . . . . . . . . . . . . . . 66

Customizing Power and Operation. . . . . . . . . . . . . . . . . . . . 67

Multi-screen Color Adjustment . . . . . . . . . . . . . . . . . . . . . . 69

Projector Menu and Options List . . . . . . . . . . . . . . . . . . . . . 70

6Maintaining the Projector. . . . . . . . . . . . . . . . . . . 73

Cleaning the Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Cleaning the Projector Case . . . . . . . . . . . . . . . . . . . . . . . . . 74

Cleaning the Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Replacing the Air Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Replacing the Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Resetting the Lamp Timer . . . . . . . . . . . . . . . . . . . . . . . 81

Checking Lamp Usage . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Replacing the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Transporting the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . 83

7Solving Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Using On-Screen Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Checking Projector Status. . . . . . . . . . . . . . . . . . . . . . . . . . . 87

What To Do When the Lights Flash . . . . . . . . . . . . . . . 87

Solving Projector Operation Problems . . . . . . . . . . . . . . . . . 89

Solving Problems With the Image. . . . . . . . . . . . . . . . . . . . . 90

Solving Network Problems . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Solving Problems With the Remote Control . . . . . . . . . . . . 97

Where To Get Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Internet Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Speak to a Support Representative . . . . . . . . . . . . . . . . . 98

Purchase Supplies and Accessories . . . . . . . . . . . . . . . . . 99

AProjector Installation . . . . . . . . . . . . . . . . . . . . . . . 101

Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Security Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102

BTechnical Specifications . . . . . . . . . . . . . . . . . . . . 105

CNotices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . 113

FCC Compliance Statement. . . . . . . . . . . . . . . . . . . . . . . . 116

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Welcome

The PowerLite®4100/4200W/4300 is an easy-to-use, lightweight

projector. It offers up to 4500 lumens (PowerLite 4100/4200W) or

5200 lumens (PowerLite 4300) of brightness, and provides a native

XGA (PowerLite 4100 and 4300) or WXGA (PowerLite 4200W)

resolution. You can connect it to a wide range of computers and video

sources.

Your projector offers these easy setup, control, and security features:

■Manual horizontal and vertical lens shift

■Centered lens design

■Instant Off ®feature for fast setup and shut down

■Quick Corner®for easy image shape/size adjustment

■1.8x optical zoom lens for flexible placement and positioning

■One-touch filter replacement

■Side-loading easy lamp access

■Security features include password, user’s logo, the ability to lock

the projector buttons, a security cable attachment (cable not

included), a slot for an optional Kensington®security lock, and a

lens theft deterrent screw

Additional enhancements:

■Closed captioning for the hearing impaired

■1000:1 contrast ratio

■Color match images from two or more projectors for a uniform,

wide-screen view

8Welcome

■When you present with PowerPoint®, project only the slide

images while viewing handout notes and controls on the

computer screen

■Perform six-axis color adjustment for fine art and photography

Using Your Documentation

This electronic User’s Guide contains all the information you need to

set up and use your projector.

Please follow these guidelines as you read through this manual:

■Warnings must be followed carefully to avoid bodily injury.

■Cautions must be observed to avoid damage to your equipment.

■Notes contain important information about your projector.

■Tips contain additional projection hints.

Getting More Information

Need tips on giving presentations? Quick steps for setting up your

projector? Here’s where you can look for help:

■Quick Reference card

Provides information for connecting the projector to your

equipment, displaying and adjusting the image, using the remote

control, and solving display problems.

■EasyMP Monitor Operation Guide

Provides instructions on using the EasyMP Monitor software

(available for Windows only) to manage projectors on a network

(to download both the software and the guide, visit Epson’s

support website at www.epson.com/support (U.S.) or

www.epson.ca/support (Canada) and select your product).

■Built-in help system

Provides assistance for common problems. Available from the

Help button on the projector or the remote control. See page 86

for details.

Welcome 9

■epson.com/support (U.S.) or epson.ca/support (Canada)

Download FAQs and e-mail your questions to Epson support.

■PrivateLine®support

If you still need help after checking this User’s Guide and the

sources listed in this section, you can use the Epson PrivateLine

Support service to get help fast. Call (800) 637-7661 and enter

the PIN on the PrivateLine card. See page 97 for more

information.

Registration and Warranty

Your projector comes with a basic warranty that lets you project with

confidence. For details, see the warranty brochure included with your

projector.

In addition, Epson offers free Extra CareSM Road Service. In the

unlikely event of an equipment failure, you won’t have to wait for

your unit to be repaired. Instead, Epson will ship you a replacement

unit anywhere in the United States or Canada. See the brochure

included with your projector for details.

Registering also lets you receive special updates on new accessories,

products, and services.

Optional Accessories

To enhance your use of the projector, Epson offers the following

optional accessories:

Product Part number

Replacement lamp for PowerLite 4100 V13H010L62

Replacement lamp for PowerLite 4200W and 4300 V13H010L63

Replacement air filter V13H134A17

Wireless IR Mouse Receiver for Remote Control V12H007T16

Replacement remote control 1531179

10 Welcome

You can purchase screens or other accessories from an Epson

authorized reseller. To find the nearest reseller, call 800-GO-EPSON

(800-463-7766). Or you can purchase online at www.epsonstore.com

(U.S. sales) or www.epson.ca (Canadian sales).

Advanced projector ceiling mount with precision gear

Adjustable suspended ceiling channel kit

False ceiling plate kit

Structural round ceiling plate

Adjustable extension column (pipe) 8”–11”

ELPMBPRG

ELPMBP01

ELPMBP02

ELPMBP03

ELPMBC01

Kensington®MicroSaver®security lock ELPSL01

ES3000 Ultra Portable Projector Screen

50-inch portable screen (4:3 aspect ratio)

60-inch portable pop-up screen (4:3 aspect ratio)

80-inch portable pop-up screen (4:3 aspect ratio)

DUET™ portable projector screen

V12H002S3Y

ELPSC06

ELPSC07

ELPSC08

ELPSC80

Component-to-VGA video cable ELPKC19

Distribution amplifier ELPDA01

DC-10s document camera ELPDC10S

1-Year Extended Depot Repair Service Plan EPPFTPB1

1-Year Extended Exchange Warranty EPPEXPB1

2-Year Extended Depot Repair Service Plan EPPFTPB2

Product Part number

Otros manuales para PowerLite 4100

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Proyector de Epson

Epson

Epson PowerLite Pro Cinema 9100 Manual de usuario

Epson

Epson PowerLite 750HD Manual de usuario

Epson

Epson PowerLite 8700 UB Manual de usuario

Epson

Epson EB-S100 Manual de usuario

Epson

Epson 755c - PowerLite XGA LCD Projector Hoja de especificaciones

Epson

Epson PowerLite TW-100 Manual de usuario

Epson

Epson EB-L630U Manual de usuario

Epson

Epson PowerLite 8000i Manual de usuario

Epson

Epson EH-TW420 Manual de usuario

Epson

Epson PowerLite S1 Manual de instalación y operación

Epson

Epson EH-TW750 Manual de usuario

Epson

Epson PowerLite S31+ Hoja de especificaciones

Epson

Epson EB-1480Fi Manual de usuario

Epson

Epson AP-60 - Projector Sound Solution Manual de usuario

Epson

Epson PowerLite Home Cinema 1080 Manual de usuario

Epson

Epson 8100i - PowerLite XGA LCD Projector Manual de usuario

Epson

Epson PowerLite Pro Z8455WUNL Instrucciones de funcionamiento y seguridad

Epson

Epson ActionLaser 1300 Manual de usuario

Epson

Epson 3LCD - PowerLite S4 Projector Manual de usuario

Epson

Epson EMP-710 Manual de usuario

Epson

Epson BrightLink 475Wi Manual de usuario

Epson

Epson EB-945 Instrucciones de instalación

Epson

Epson 830p - PowerLite XGA LCD Projector Hoja de especificaciones

Epson

Epson 7800p - PowerLite XGA LCD Projector Manual de usuario

Manuales populares de Proyector de otras marcas

iEmmet

iEmmet MP-312 Manual de usuario

Sony

Sony VPL-HS10 Marketing Specifications & Features Manual de usuario

Sony

Sony VPL-HW65ES Manual de servicio

Toshiba

Toshiba TLP-791U Manual de usuario

Philips

Philips LC1341 Guía de referencia

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manual de usuario

NEC

NEC NP600S EDU Manual de usuario

BenQ

BenQ SH753P Manual de usuario

Eiki

Eiki EK-623U series Manual de usuario

Christie

Christie LHD700 Manual de usuario

Navitar

Navitar FX Manual de usuario

InFocus

InFocus LitePro 560 Manual de usuario

Sony

Sony SRX-R815P Manual de usuario

Vivitar

Vivitar DP1500 X Manual de usuario

Acer

Acer C20 Series Manual de usuario

Asus

Asus ZenBeam Latte Manual de usuario

BOXLIGHT

BOXLIGHT CP-322i/CP-634i Manual de usuario

JVC

JVC 1108TTH-AO-AO Manual de usuario
