Epson EMP S52 Manual de usuario

Epson (UK) Ltd. (03.07.2007)

New Product Summary

Launch Date – 2nd July 2007

Under NDA Until – 1st June 2007Epson

EMP

S52

The multimedia partner that brings the

big screen to work and home

The versatile Epson EMP-S52multimedia

projector givesa professional performance

at work and at home. Outstanding for

business or education presentations, but

just as happy bringing big screen

entertainment to your living room.

You choose –it’s always ready to go

With one of the quickest start-up times on the market, this

projector will turn on in just 5seconds. Afterwards you can turn

off, disconnect the power cable and be ready to move straight

away.

You choose –it’s so adaptable

After a quick, simple set up, you can rely on a perfect, uniform

image from a wide range of positions, thanks to a large 30º

vertical keystone correction angle. And it’s great in smaller

rooms too -a 60” image can be created just 1.8m from the

screen.

You choose –it’s so easy

This projector is designed for simple operation. The convenient,

intuitive control panel gives you quick access to a range of

information in key areas including power, status, adjustments,

controls and a comprehensive help function.

You choose –it’s brighter and better

Epson’s long life, low wattage ‘E-TORL’ lamp is smaller and

more efficient without compromising brightness and lasts for up

to 4000 hours. This projector is quiet too -at just 28dB sound

level, your audience will always be concentrating on your

presentation.

You choose –it’s up to you

With the Epson projectors, you’re always in control. Password

protection offers security, and a lockable control panel means if

you have the remote, you have complete control.

Big screen home entertainment

You choose –it’s your lifestyle

Whatever you choose to give the big screen treatment, from

photos and movies to sports and video games, the 7 preset

colour modes ensure excellent colour every time. And with the

black and white enhancer, you’ll see every detail even on dark

or bright images.

You choose –it’s the big screen solution

You can even create a genuine movie experience. Simply

change the aspect of the screen from 4:3 format to 16:9 –just

like a real cinema!

Entry level value, top level features.

For business presentations

•Compact and light, simple to set up and operate

•Enjoy unbeatable quality with Epson 3LCD technology

•Keep on the move with Quick Start, Instant Off

•AV mute slide for more effective presentations

For home entertainment

•Choose from 7 colour modes to optimise quality

•Add the cinema experience to your home with the 16:9

viewing format

•A true multimedia partner –from computers to gaming and

DVD player to digital cameras

•Place the projector off centre with no distortion

Ordering information

Description EMP- S52 LCD Projector

Part Number V11H252140DA

Barcode 8715946390321

Carton

Dimensions 427x379x182mm

Carton Weight net= 2.7kg; gross=5.3kg

Remote control

Epson EMP-S52 New Product Summary (03.07.2007)

Screen size and projection distance

Use the Epson Projection Distance Calculator software

available from www.epson.co.uk for distances and screen sizes

not shown below.

Accessories

(Model code) order code

Consumables

Spare Lamp (ELPLP41)

V13H010L41

Air Filter Set (ELPAF13)

V13H134A13

Screens

50" Portable Screen (ELPSC06)

V12H002S06

60" Portable Screen (ELPSC07)

V12H002S07

80" Portable Screen (ELPSC08)

V12H002S08

Mountings

Ceiling Plate (ELPFC03)

Required if using a ceiling pipe.

V12H003C03

Ceiling Pipe (silver) 370mm

(ELPFP04)

V12H003P04

Ceiling Pipe (silver) 570mm

(ELPFP05)

V12H003P05

Ceiling Pipe (silver) 770mm

(ELPFP06)

V12H003P06

Ceiling Mount (ELPMB18)

Connects to the projector and either

directly to the ceiling, or to a ceiling

pipe.

V12H003B18

Cables

VGA Computer Cable HD-15 to HD-

15 1.8m (ELPKC02)

V12H005C02

VGA Computer Cable HD-15 to HD-

15 3.0m (ELPKC09)

V12H005C09

VGA Computer Cable HD-15 to HD-

15 20m (ELPKC10)

V12H005C10

Component Video Cable

(ELPKC19)

V12H005C19

HD-TV Cable

(ELPKC22)

V12H005C22

What’s in the Box?

Projector

with Slide Lens Shutter

Remote Control

2 x AAA alkali batteries

for the remote control

Power Cable

1.8m cable

Computer Cable

Mini D-Sub 15-pin/mini D-Sub

15-pin, 1.8 m (6 ft.)

Use when projecting images

from a computer

Read This First Booklet

Explains the contents of the box

and which manuals the user

should refer to.

Image TBC

Setup Guide

Contains information on basic

operations for preparing the

projector before use (setup and

connecting video equipment or

a computer) and for starting

projection.

Image TBC

Document CD-ROM

Contains information on

common and useful functions,

configuration, troubleshooting,

and maintenance.

Image TBC

Safety Instructions

/ World Wide Warranty Terms image TBC

Epson EMP-S52 New Product Summary (03.07.2007)

Specifications

MODEL EMP-S52

Projection System RGB liquid crystal shutter projection system

Projection Method Front / Rear / Ceiling mount

Specifications of Main Parts

LCD Size 0.55-inch without MLA

Driving Method Poly-silicon TFT active matrix

Pixel Number 480,000 dots (800x 600) x 3

Native Resolution SVGA

Aspect Ratio 4:3

Pixel Arrangement Cross stripe

Refresh Rate 50 Hz -60 Hz

Projection Lens

Type Digital zoom / Manual focus

F-Number 1.44

Focal Length 16.6 mm

Zoom Ratio Digital Zoom 1 –1.35

Lens Cover Slide lens shutter

Lamp Type 170 W UHE

Life 3000 hours (High bright) / 4000 hours (Low bright)

Screen Size (Projected Distance)

30" to 300" [1.19 to 12.12 m] (Zoom:Tele)

30" to 300" [0.87 to 8.97 m] (Zoom:Wide)

60" screen 1.8 -2.4m

Brightness

High Brightness

Mode 1800 ANSI lumens

(Colour mode: Game, Zoom: Wide)

Low Brightness

Mode 1440 ANSI lumens

(Colour mode: Game, Zoom: Wide)

Contrast 400:1

(Colour mode : Game, High brightness mode)

Brightness Uniformity

90%

Colour Reproduction

Full-colour (16.77 million colours)

Video Quality Simple Interlace-Progressive conversion

Sound Output 1 W Monaural

Speaker 35•• ×20•• x 1

Function User logo, A/V mute, Freeze, E-Zoom, Help

Colour Mode PC: Photo, Presentation, Theatre, Game, sRGB,

Blackboard, Text

Video: Sports, Presentation, Theatre, Game, sRGB,

Blackboard, Text

Remote Control Infrared Receiver Position / Distance / Directivity

Front & rear , 6 m

Right / Left : -30 to +30 degrees

Upper / Lower : -15 to +15 degrees

Effective Scanning Frequency Range (Analogue)

Pixel Clock 13.5 MHz to 162 MHz

up to UXGA 60 Hz

Horizontal 15 kHz to 92 kHz

Vertical 50 Hz to 85 Hz

Adjustment Function

Projector / Remote

Control Brightness / Contrast / Tint / Saturation /

Sharpness / Input signal / Sync / Tracking / Position /

Colour temperature / Volume / etc.

Foot Adjuster Front-centre

Tilt Angle 0 to 11 degrees

Keystone

Correction Vertical : PC -30 to +30 degrees

Source Search Yes

Auto Detection of

RGB/Component Yes

Operation Panel

Protected Function Yes

Password Protected

Function

(Security Function)

Yes

(Protection of User logo)

Analogue RGB I/O

Display

Performance Native 800 x 600dots

Input Signal Signal Type Separate signal

Video Signal Analogue (0.7 Vp-p, 75 ohm / Mac

0.714 Vp-p, 75 ohm)

Sync. Signal Separate (positive & negative, bi-

polarity 2-5 Vp-p)/

Composite (positive & negative,

bi-polarity 2-5 Vp-p)/

Sync-on-green (negative, 0.3 Vp-

Audio Signal 500 mVrms / 47 k-ohm

Input Terminal Video D-sub 15pin x 1 Blue moulding

Audio RCA x 1 (White/Red)

Output Signal Video Signal Analogue (0.7 Vp-p, 75 ohm / Mac

0.714 Vp-p, 75 ohm)

Sync. Signal Separate (positive & negative,

TTL) /

Composite (positive & negative,

TTL) /

Sync. on green (negative 0.2-0.4

Vp-p)

Output Terminal Video D-sub 15pin x 1 Black

moulding(Output signal :

Computer * only)

Video I/O Display

Performance NTSC: 560 lines, PAL: 560 lines (Depend on

observation of the multi-burst pattern)

Input Signal Video Standard NTSC / NTSC4.43 / PAL / M-PAL

/ N-PAL / PAL60 / SECAM

Video Signal Composite Video (1.0 Vp-p /

Sync.negative, 75 ohm) /

S-Video (Luminous 0.714 Vp-p,

Chrominous 0.286 Vp-p, 75 ohm)

Component Video (Analogue Y

level 0.7 V, 75 ohm / Cr Cb level

+/-0.35 V, 75 ohm / sync.negative

0.3 V or 3-state +/-0.3 V on Y) /

RGB Video (0.7 Vp-p, 75 ohm /

Mac 0.714 Vp-p, 75 ohm)

Audio Signal 500 mVrms / 47 k-ohm

Input Terminal Video Composite Video: RCA (Yellow) x

S-Video: Mini DIN

Component Video: D-sub 15pin

Blue moulding

(in common with AnalogueRGB

connector)

RGB Video: D-sub 15pin Blue

moulding

(in common with AnalogueRGB

connector)

Audio RCA x 1 (White/Red)

(in common with Analogue RGB

Audio terminal)

Control I/O USB I/O I/O Terminal Type B x1 (for K/B, control)

I/O Speed Ver. 1.1

Operating Temperature

5 °C to 35 °C <41 °F to 95 °F> ( 20%-80% Humidity )

Operating Altitude 0 m to 2286 m<0 ft to 7500 ft>

( over 1500 m / 4,921 ft :with High altitude mode)

Direct Power On Yes

Start-up Period about 5 seconds

warm-up period: 30 seconds

Cool-down Period Instant off

Theft Proof

Padlock & Security

Cable Hole Yes

Kensington Lock Yes

Power Supply Voltage

100 -240 V AC ±10%, 50/60 Hz

Power Consumption

Lamp On 231 W

Standby 5.8 W

Dimensions

Exclude Feet (D x W

x H) 245 x 327 x 92 mm

Maximum

Dimension (D x W x

245 x 327 x 108 mm

Weight Approx. 6.0 €bs. / 2.7kg

Fan Noise

High Brightness

Mode 35 dB

Low Brightness

Mode 28 dB

Supplied Accessories

Power Cable 1.8m

Computer Cable 1.8 m D-sub 15pin (Male) - D-sub

15pin(Male)

Remote Control

Battery Manganese dry cell ×2

Password Protect Sticker

User's Manual Set

Optional Accessories

Spare Lamp ELPLP41

Air Filter Set ELPAF13

Soft Carrying Case ELPKS16B

50” Portable Roll

Screen ELPSC06

60” Portable Roll

Screen ELPSC07

80” Portable Roll

Screen ELPSC08

100 Type Screen ELPSC10

Computer

Cable,1.8m ELPKC02

Computer Cable,

3.0m ELPKC09

Computer Cable,

20.0m ELPKC10

Component Video

Cable, 3.0m ELPKC19

HD-TV Cable, 3.0m ELPKC22

Ceiling Mount ELPMB18

Ceiling Plate ELPFC03

Pipe 370mm ELPFP04

Pipe 570mm ELPFP05

Pipe 770mm ELPFP06

Warranty

UK: 1 year next business day on-site repair or replace

Republic of Ireland: 1 year next business day on-site repair or loan

Errors and omissions excepted, all specifications are subject to change without

notice.

Otros manuales para EMP S52

Tabla de contenidos

Otros manuales de Proyector de Epson

Epson

Epson EB-1940W Manual de usuario

Epson

Epson EH-TW5950 Manual de usuario

Epson

Epson PowerLite 1751 Hoja de especificaciones

Epson

Epson PowerLite 84 Hoja de especificaciones

Epson

Epson 1450Wi Manual de usuario

Epson

Epson EX3210 Manual de usuario

Epson

Epson PowerLite Home Cinema 5020UB Manual de usuario

Epson

Epson AP-60 - Projector Sound Solution Manual de usuario

Epson

Epson PowerLite Pro G5200WNL Manual de usuario

Epson

Epson 1715C - PowerLite XGA LCD Projector Manual de usuario

Epson

Epson PowerLite Home Cinema 3010 Manual de usuario

Epson

Epson EB-1430Wi Manual de usuario

Epson

Epson BrightLink 475Wi Guía

Epson

Epson LightScene EV-110 Manual de usuario

Epson

Epson EB-PU1006W/EB Manual de usuario

Epson

Epson 835p - PowerLite XGA LCD Projector Hoja de especificaciones

Epson

Epson EX6220 Manual de usuario

Epson

Epson EB-1776W Manual de usuario

Epson

Epson 830p - PowerLite XGA LCD Projector Manual de usuario

Epson

Epson PowerLite TW-100 Manual de instalación y operación

Epson

Epson EMP-9100 Manual de uso y cuidado

Epson

Epson EB-L1750U Manual de usuario

Epson

Epson RS-353 Manual de usuario

Epson

Epson PowerLite 85 Manual de usuario

Manuales populares de Proyector de otras marcas

iEmmet

iEmmet MP-312 Manual de usuario

Sony

Sony VPL-HS10 Marketing Specifications & Features Manual de usuario

Sony

Sony VPL-HW65ES Manual de servicio

Toshiba

Toshiba TLP-791U Manual de usuario

Philips

Philips LC1341 Guía de referencia

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manual de usuario

NEC

NEC NP600S EDU Manual de usuario

BenQ

BenQ SH753P Manual de usuario

Eiki

Eiki EK-623U series Manual de usuario

Christie

Christie LHD700 Manual de usuario

Navitar

Navitar FX Manual de usuario

InFocus

InFocus LitePro 560 Manual de usuario

Sony

Sony SRX-R815P Manual de usuario

Vivitar

Vivitar DP1500 X Manual de usuario

Acer

Acer C20 Series Manual de usuario

Asus

Asus ZenBeam Latte Manual de usuario

BOXLIGHT

BOXLIGHT CP-322i/CP-634i Manual de usuario

JVC

JVC 1108TTH-AO-AO Manual de usuario
