Epson TM-T88III series Instrucciones de funcionamiento

ESC/POS

CONFIDENTIAL

Printers & Commands

What’s New in This Version?

About This Guide

Character Code Tables

How to Use This Guide

ESC/POS Information

EPSON

404394101

Confidentiality Agreement

Paper Roll Printers ESC/POS®Application

Programming Guide

Version 10.01

ESC/POS

EPSON

•Commands in Alphanumeric Order

•Commands Arranged by Function

•Commands Arranged by Printer

CONFIDENTIAL

TM-T88III

TM-T90

TM-L60II

TM-L90

TM-J2000/J2100

TM-U210

TM-U220

TM-U230

TM-U300A/U300B

TM-P60

printers & commands

ESC/POS

EPSON

CONFIDENTIAL

how to use this guide

Text

Any text colored blue is a link to another screen.

Click the text to go to that topic.

Printer information

Most information applies to all printers in a category.

If there is information specific to one printer, you see

its name in colored text, with a different color for

each printer. The model dependent information

appears if you click on the name of the printer or

look at the bottom of the screen for text in the

appropriate color.

blue

text

PRINTER

name

ESC/POS

EPSON

CONFIDENTIAL

what’s new in this version?

Version 10.00

TM-U220 added.

This guide (Paper Roll Printers) is now

separate from the guides for other

types of printers.

Version 10.01

TM-P60 added.

ESC/POS

CONFIDENTIAL

ESC/POS®Application Programming Guide for Paper Roll Printers

Version 10.01

Seiko Epson Corporation, System Device Division

Notice: The contents of this manual

are subject to change without notice

EPSON and ESC/POS are registered trademarks of Seiko Epson Corporation.

Adobe and Acrobat are registered trademarks of Adobe Systems

Incorporated in the United States and/or other countries.

EPSON

about this guide

ESC/POS

EPSON

CONFIDENTIAL

confidentiality agreement

BY USING THIS DOCUMENT, YOU AGREE TO ABIDE BY THE TERMS OF THIS

AGREEMENT. PLEASE RETURN THIS DOCUMENT IMMEDIATELY IF YOU DO NOT

AGREE TO THESE TERMS.

This document contains confidential, proprietary information of Seiko Epson

Corporation or its affiliates. You must keep such information confidential. If the

user is a business entity or organization, you must limit disclosure to those of

your employees, agents and contractors who have a need to know and who are

also bound by obligations of confidentiality.

On the earlier of (a) termination of your relationship with Seiko Epson, or

(b) Seiko Epson's request, you must stop using the confidential information. You

must then return or destroy the information, as directed by Seiko Epson.

If a court, arbitrator, government agency or the like orders you to disclose any

confidential information, you must immediately notify Seiko Epson. You agree to

give Seiko Epson reasonable cooperation and assistance in resisting disclosure.

You may use confidential information only for the purpose of facilitating

authorized sales and service of, or developing software and similar products for

authorized use with, EPSON products. Any other use requires the prior written

consent of Seiko Epson.

THE INFORMATION IN THIS DOCUMENT IS PROVIDED “AS IS,” WITHOUT

WARRANTY OF ANY KIND, INCLUDING ANY WARRANTY OF TITLE OR NON-

INFRINGEMENT. Seiko Epson has no liability for loss or damage arising from

or relating to your use of or reliance on the information in the document.

You may not reproduce, store or transmit the confidential information in any

form or by any means (electronic, mechanical, photocopying, recording,

or otherwise) without the prior written permission of Seiko Epson.

Your obligations under this Agreement are in addition to any other legal

obligations. Seiko Epson does not waive any right under this Agreement by

failing to exercise it. The laws of Japan apply to this Agreement.

CONFIDENTIAL

Paper roll ESC/POS proprietary command system

Ver. 10.01 p. 7

ESC/POS proprietary command system

The market for store automation equipment is changing rapidly with the widespread introduction of POS (point of sale)

terminals. These terminals are now appearing even in small retail stores and specialty shops.

As personal computers begin to be used as POS terminals, the demand for matching uniform peripheral devices is expected to

rise. At present, however, many of the competing POS terminal printers on the market employ mutually incompatible

command sets. This imposes limits on the expandability and range of applications possible with PC-based systems. There is a

need for a new command set designed to provide the expandability and universal applicability demanded by the market.

ESC/POS

EPSON took the initiative by introducing ESC/POS, a proprietary POS printer command system, which includes patented or

patent pending commands and enables versatile POS system construction with high scalability. Compatible with all types of

EPSON POS printers and displays, this proprietary control system also offers the flexibility to easily make future upgrades. Its

popularity is worldwide.

ESC/POS is designed to reduce the processing load on the host computer in POS environments. It comprises a set of highly

functional and efficient commands that enables the full realization of the potential of printers.

A command set designed for universal applicability

The commands that are supported by all EPSON POS printers and those that are specific to individual models are clearly

described. This means that ESC/POS compatible software will work with any system and be suitable for a wide range of

applications.

Superb expandability allowing the addition of new functions

New functions can be added and accommodated by the categories already provided in the command system.

Allows more effective use of software

Once a software application has been created for one printer in the TM series, it can be used as the basis for versions for the

other printers in the series. Only a small portion of the program source code needs to be modified.

ESC/POS®PROPRIETARY COMMAND SYSTEM

CONFIDENTIAL

Paper roll Command classification

Ver. 10.01 p. 8

Command classification

ESC/POS printer commands are classified by functions such as print, character, print position, printing paper, line spacing,

panel button, paper sensor, mechanism control, status, bar code, bit-image, macro function, control option, and miscellaneous

functions. The classification is called function classification.

ESC/POS printer commands are also classified by sheet and grade. The sheet and grade classification is called matrix

classification.

The sheet classification is divided into single sheet commands and multiple sheet commands. The grade classification is

separated into basic commands and extension commands.

Basic commands are defined as fundamental printer controls, including print commands and character type selection

commands. Extension commands are defined as control codes for functions specific to individual printers. These commands

are further divided into mechanical extension commands that relate to additional mechanical functions such as stamp and

autocutter units, hardware extension commands that relate to additional hardware functions such as panel button and status

transmission controls, and software extension commands that relate to additional software functions such as user-defined and

bar code controls. The next screen is an overview diagram of the matrix classification of ESC/POS.

COMMAND CLASSIFICATION

CONFIDENTIAL

Paper roll Command classification

Ver. 10.01 p. 9

Multiple sheet

Single sheet commands

Multiple sheet

Single sheet

Sheet

Basic commands

commands

Extension commands

Grade

Hardware extension commands

Mechanical extension commands

Software extension commands

CONFIDENTIAL

Paper roll Overview of data processing

Ver. 10.01 p. 10

Overview of data processing

Character Data and Normal Commands

The printer stores data sent from the host computer in the receive buffer temporarily, and then the printer interprets the data

and classifies them into commands or character data sequentially. If the data from the receive buffer is a normal command,

the printer processes the command corresponding to its function; for example, if the data interpreted is ESC 3, the printer

changes a setting value for the line spacing, and if it is LF, the printer prints the data in the print buffer and feeds the paper

one line.

If the data from the receive buffer is character data, the printer reads the appropriate font data from the resident character

generator and writes image data to the print buffer.

Real-time Commands

The printer stores data sent from the host computer in the receive buffer, interprets the data, and processes the commands

corresponding to their function one line at a time. The real-time commands are the commands that consist of a DLE

extension, such as DLE EOT or DLE ENQ. They are processed immediately. The real-time commands are ignored as

undefined codes in the main processing.

OVERVIEW OF DATA PROCESSING
