Epson Stylus Color Stylus Color II Manual de usuario

COLOR INK JET PRINTER

Setup and Software Guide for Windows

system, or transmitted in any form or by any means, electronic, mechanical, photocopying,

recording, or otherwise, without the prior written permission of Seiko Epson Corporation.

No patent liability is assumed with respect to the use of the information contained herein.

Neither is any liability assumed for damages resulting from the use of the information

contained herein.

Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this

product or third parties for damages, losses, costs, or expenses incurred by purchaser or

third parties as a result of: accident, misuse, or abuse of this product or unauthorized

modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to

strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.

Seiko Epson Corporation shall not be liable against any damages or problems arising from

the use of any options or any consumable products other than those designated as

Original EPSON Products or EPSON Approved Products by Seiko Epson Corporation.

EPSON and EPSON Stylus are registered trademarks and ESC/P 2 is a trademark of Seiko

Epson Corporation.

EPSON Connection is a service mark of Epson America, Inc.

Windows printer driver copyright Software 2000 Ltd Oxford, England. Portions copyright

Seiko Epson Corporation.

General Notice: Other product names used herein are for identification purposes only and

may be trademarks of their respective owners. EPSON disclaims any and all rights in

those marks.

The Energy Star emblem does not represent EPA endorsement of any product or service.

Printed on recycled paper with at least 10% post-consumer content

FCC Compliance Statement

For United States Users

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio or

television reception. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause interference to radio and television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures.

❑Reorient or relocate the receiving antenna.

❑Increase the separation between the equipment and receiver.

❑Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

❑Consult the dealer or an experienced radio/TV technician for help.

WARNING

The connection of a non-shielded equipment interface cable to this equipment will

invalidate the FCC Certification of this device and may cause interference levels which

exceed the limits established by the FCC for this equipment. It is the responsibility of the

user to obtain and use a shielded equipment interface cable with this device. If this

equipment has more than one interface connector, do not leave cables connected to unused

interfaces. Changes or modifications not expressly approved by the manufacturer could

void the user’s authority to operate the equipment.

For Canadian Users

This digital apparatus does not exceed the Class B limits for radio noise emissions from

digital apparatus as set out in the radio interference regulations of the Canadian

Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites

applicables aux appareils numériques de Classe B prescrites dans le règlement sur le

brouillage radioélectrique édicté par le Ministère des Communications du Canada.

Contents

Introduction

Getting the Most Out of Your Printer . . . . . . . . . . . . . . . 2

Three Resolutions to Choose From . . . . . . . . . . . . . . 2

Special Papers . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Specially Formulated Ink . . . . . . . . . . . . . . . . . . . . 3

Automatic Printer Driver Settings . . . . . . . . . . . . . . . 3

If You Are New to Color Printing . . . . . . . . . . . . . . . . . 3

Where to Get Help . . . . . . . . . . . . . . . . . . . . . . . . . 5

Electronic Support Services . . . . . . . . . . . . . . . . . . 6

Important Safety Instructions . . . . . . . . . . . . . . . . . . . 7

Chapter 1 Installing the Printer

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Choosing a Location . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Unpacking the Printer . . . . . . . . . . . . . . . . . . . . . . . 1-2

Removing the Protective Materials . . . . . . . . . . . . . . 1-3

Setting Up the Printer . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Attaching the Paper Support . . . . . . . . . . . . . . . . . . 1-4

Plugging In and Turning On the Printer . . . . . . . . . . . 1-4

Installing the Ink Cartridges . . . . . . . . . . . . . . . . . . 1-5

Checking the Paper Thickness Lever . . . . . . . . . . . . . 1-10

Loading Paper . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10

Testing the Printer . . . . . . . . . . . . . . . . . . . . . . . 1-12

Connecting the Printer to Your PC . . . . . . . . . . . . . . . . 1-13

iii

Chapter 2 Installing and Using the Printer Driver

Installing the Windows Printer Software . . . . . . . . . . . . . 2-1

Installing the Printer Software for Windows 3.1 . . . . . . . 2-2

Installing the Printer Software for Windows 95 . . . . . . . 2-4

Installing a Driver for DOS Programs . . . . . . . . . . . . . . . 2-7

Using the Windows Printer Driver . . . . . . . . . . . . . . . . . 2-7

Accessing the Driver . . . . . . . . . . . . . . . . . . . . . . . 2-8

Using the Driver Dialog Box . . . . . . . . . . . . . . . . . . 2-10

Changing Settings . . . . . . . . . . . . . . . . . . . . . . . . 2-12

Document Type . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13

Paper Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15

Printing Mode/Options Settings . . . . . . . . . . . . . . . . 2-16

Image Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19

Halftoning Settings . . . . . . . . . . . . . . . . . . . . . . . . 2-21

Chapter 3 Using the Printer Driver Utilities

Managing Print Jobs with Spool Manager . . . . . . . . . . . . . 3-1

Calibrating the Printer with Bi-D Calibration . . . . . . . . . . . 3-3

Index

Introduction

The EPSON®Stylus®COLOR II is an affordable, high-quality

ink jet printer that can print up to 16 million colors at a

resolution of 720 ×720 dpi to produce full-color, photo-quality

images. The printer also produces realistic grayscale images,

sharp text, and line art. The printer’s ink jet technology allows

it to operate quietly, keeping your workspace peaceful.

The Stylus COLOR II is easy to install and use. You simply set

it up and install the Microsoft®Windows®printer driver

software as described in this book. The printer has built-in

parallel and serial interfaces, so you can connect it to an IBM®

PC compatible computer or an Apple®Macintosh.

®You can

even connect both simultaneously; the printer automatically

switches between interfaces as it receives print data.

Note:

For instructions on using the printer with a Macintosh, see the

Setup and Software Guide for Macintosh.

This manual explains how to do the following:

❑Set up your printer, load plain paper, connect it to your

computer, and test it. See Chapter 1 to begin.

❑Install and use the printer driver to print your documents.

See Chapter 2 for step-by-step instructions.

❑Manage your print jobs and calibrate the printer using the

utilities that came with the printer driver; see Chapter 3.

After you’ve installed the driver, select the ReadMe icon in the

EPSON program group in Windows for the latest information.

Refer to the Reference Guide for instructions on operating and

maintaining your printer, as well as for troubleshooting steps

and technical specifications you may need.

Introduction 1

Getting the Most Out of Your Printer

The printer supports a wide variety of settings that let you

improve print quality or speed up printing. You can customize

these settings using the printer driver to produce a variety of

image types with EPSON’s specially formulated inks and

papers.

Three Resolutions to Choose From

Resolution is a measure of the amount of detail that can be

represented. The higher the resolution, the more detailed and

realistic the image, and the longer it takes to print. For printed

images, resolution is measured in dots per inch (dpi).

The printer has three resolutions, or printing modes: 720 dpi,

360 dpi, and 180 dpi. Use 720 dpi for the best possible images.

For high-quality images in less time, use 360 dpi. When speed

is important and draft quality is good enough, use 180 dpi. For

guidelines on selecting the best resolution for your print job,

see Chapter 2.

Special Papers

The type of paper you use is very important. Although you get

good results with plain bond paper, you will get better results

by using coated papers because they do not absorb as much ink.

To ensure the best possible quality, EPSON offers special

coated papers, glossy papers, and transparencies that are

formulated specifically for the inks used by the printer. You

can order these products directly from EPSON Accessories

at (800) 873-7766 (U.S. sales only). In Canada call

(800) BUY-EPSON for sales locations. For more information

about special papers and other media, see Chapter 1 of the

Reference Guide.

2 Introduction

Specially Formulated Ink

EPSON’s black and color ink cartridges are specially

formulated to work with EPSON papers and the driver to

deliver the best looking images. Always use genuine EPSON

ink cartridges and do not refill them. Other products may cause

damage not covered by EPSON’s warranty.

Automatic Printer Driver Settings

The printer driver includes an automatic Document Type

option that sets the Ink, Color Matching, and Halftone printer

driver settings for you, as described in Chapter 2. When set, the

driver analyzes the elements on a page to be printed and

automatically adjusts the settings so your printed results are

appropriate for the image type.

If You Are New to Color Printing

Color printing with the EPSON Stylus COLOR II produces

amazing images, whether you print text, line drawings,

photographs, or documents containing many different image

types. However you use your color printer, keep the following

in mind:

❑You need to leave a large amount of hard disk drive space

free to make room for your color images. A full-page color

photographic image, for example, may require 40MB or

more of disk space, depending on the resolution. To reduce

the file size, you can decrease the size and resolution of

your images using your printer driver and application

software.

Introduction 3

❑Color printing takes time because of the complex

processing required to create a color image. How much

time depends on the size and type of your image, the

resolution you use, the speed of your computer, and the

interface type. (Serial printing takes longer than parallel

printing.) However, the fantastic results make the time

spent well worth it.

❑Your screen colors will not exactly match the printed colors

because your monitor screen and the printer use different

methods to produce the colors you see. If you scan images

using a scanner, the image goes through another

interpretive process that also affects the color.

Monitors and scanners produce colors by combining red,

green, and blue—the RGB method. Your monitor can

produce up to 16 million colors by turning on and off the

tiny red, green, and blue phosphors contained in each pixel

on the screen. Colors produced this way differ from colors

produced by your printer’s cyan, magenta, yellow, and

black ink—the CMYK method.

Your printer driver’s Document Type settings help you

closely match colors as appropriate for your image type,

resolution, and paper.

If you need extreme precision in matching colors, you can

use a color calibration system available with many software

applications. If you use a scanner, make sure your scanning

software is set to the correct setting for ink jet printers to

help you match colors. Also, your application may include

image editing capabilities that let you adjust the colors.

4 Introduction

Where to Get Help

If you purchased your printer in the United States or Canada

and you need technical assistance, you can call an EPSON

Color Specialist at (800) 788-0343.

EPSON also provides customer support and service through a

network of Authorized EPSON Customer Care Centers and

provides the following services when you dial (800) 922-8911:

❑EPSON technical information library fax service

❑Product literature on current and new products

❑Assistance in locating your nearest Authorized EPSON

Reseller or Customer Care Center

❑Technical information on the installation, configuration,

and operation of EPSON products

❑Customer relations.

You can purchase ink cartridges, paper, parts, printed manuals,

and accessories for EPSON products from EPSON Accessories

at (800) 873-7766 (U.S. sales only). In Canada, call

(800) BUY-EPSON.

If you purchased your printer outside the United States or

Canada, contact your EPSON dealer or the marketing location

nearest you for customer support and service.

If you need help with any software program you are using,

see that program’s documentation for technical support

information.

Introduction 5

Electronic Support Services

If you have a modem, the fastest way to access helpful tips,

specifications, drivers, application notes, DIP switch or jumper

settings, and bulletins for EPSON products is through the

online services below.

World Wide Web

If you are connected to the Internet and have a Web browser,

you can access EPSON’s World Wide Web site at

http://www.epson.com. EPSON’s home page links users to

What’s New, EPSON Products, EPSON Connection,

SM Corporate

Info and EPSON Contacts. Link to the EPSON Connection for

the latest drivers and FAQs (Frequently Asked Questions) and

the EPSON Chat area. To get in touch with EPSON around the

world, EPSON Contacts includes Contact Information for local

EPSON subsidiaries.

EPSON Bulletin Board Service

You can call the EPSON Bulletin Board Service (BBS) at

(310) 782-4531. No membership is required. Make sure your

communications software is set to 8 data bits with 1 stop bit,

no parity bit, and a modem speed of 28.8 Kbps or less. See the

documentation that came with your communications software

for more information.

CompuServe online support

CompuServe®members can call the Epson America Forum on

CompuServe. If you are already a member, simply type

GO EPSON at the menu prompt to reach the Forum.

If you are not currently a member, you are eligible for a free

introductory membership as an owner of an EPSON product.

6 Introduction

Otros manuales para Stylus Color Stylus Color II

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora de Epson

Epson

Epson C31CE94061N Manual de uso y cuidado

Epson

Epson Inkjets Manual de usuario

Epson

Epson LQ-780 Manual de usuario

Epson

Epson Stylus Photo PX660 Instrucciones de montaje

Epson

Epson Stylus Pro GS6000 Manual de usuario

Epson

Epson WorkForce WF-2510WF Guía del usuario

Epson

Epson Stylus SX130 Series Manual de usuario

Epson

Epson GO ET-15000 SP Manual de usuario

Epson

Epson WorkForce AL-M400DN Manual de usuario

Epson

Epson Stylus CX4100 Series Manual de usuario

Epson

Epson EPL-N7000 Instrucciones de instalación y mantenimiento

Epson

Epson Stylus SX110 Manual de usuario

Epson

Epson WF-R5690 Manual de usuario

Epson

Epson L310 Manual de usuario

Epson

Epson LQ-570e Manual de instalación y operación

Epson

Epson U675 - TM Color Dot-matrix Printer Manual de usuario

Epson

Epson Stylus Photo 925 Manual de usuario

Epson

Epson R300 - Stylus Photo Color Inkjet Printer Manual de usuario

Epson

Epson Stylus Color 880i Manual de usuario

Epson

Epson AcuLaser MX14 Manual de usuario

Epson

Epson Stylus C88 Manual de usuario

Epson

Epson TM T70 Manual de uso y cuidado

Epson

Epson FX-1180 - Impact Printer Manual de usuario

Epson

Epson Stylus Pro 3880 Graphic Arts Edition Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario

IRA3D

IRA3D POETRY4 Manual de usuario

Ricoh

Ricoh Aficio AP400 Manual de usuario

BIXOLON

BIXOLON SRP-352plusV Manual de usuario
