Epson Stylus Color 740 Actualización de firmware

EPSON Stylu

OLOR 740

USB Software Installation Guide (Windows

/iMac )

USB Setup Guide (iMac)

This guide includes USB setup instructions for your iMac computer, as well as software

installation instructions for both iMac and Windows 98.

If you have an iMac computer, begin with “Connecting the Printer to an iMac Computer”.

If you have a Windows 98 system, begin with the instructions in the Start Here card for

connecting the printer to your USB port. Then continue with “Installing the USB Printer

Software (Windows 98)” on page 4 of this booklet.

Connecting the Printer to an iMac Computer

You can connect your printer directly to a port on the iMac or to a USB hub connected to a

port on the iMac. If you have any printing problems when the printer is connected via a USB

hub, try connecting the printer directly to the iMac instead.

1. Turn off the printer and computer.

2. To connect the USB cable to a USB port on the side of the iMac, first open the port door.

Hold the cable so the icon faces up and connect it to an available USB port.

If you’re using a USB hub, plug it into the USB port on your iMac, then connect one end

of the USB cable into an available port on the hub. If you have more than one hub,

connect the cable to the first hub.

®TM

optional USB hub USB cable

USB port

solusb1.fm Page 1 Monday, October 12, 1998 12:06 PM

To connect the cable to one of the USB ports on the iMac keyboard, hold the cable’s USB

connector so th

icon faces away from you and connect it to the USB port.

If you’re using a USB hub, plug it into a USB port on the iMac keyboard, then connect

the cable to an available port on the hub. If you have more than one hub, connect the

cable to the first hub.

3. Connect the other end of the USB cable to your printer’s USB connector.

4. Continue with the next section to install the USB Printer Device software and EPSON

Stylus COLOR 740 printer driver software.

USB port

USB cable

optional USB hub

solusb1.fm Page 2 Monday, October 12, 1998 12:06 PM

Installing the USB Printer Software (iMac)

Before you install the software, make sure you download and install the iMac Update 1.0

from Apple at http://swupdates.info.apple, com. Contact Apple Computer if you have

problems installing this update. Then continue with the instructions below.

1. Make sure your printer and computer are connected and turned off.

2. Turn on your computer and wait until you see the icons on your Macintosh desktop.

3. Insert the EPSON CD-ROM in your drive.

4. Double-click the STYLUS COLOR 740 Installer, then click Continue.

5. Click Install, then follow the on-screen instructions to install the printer driver and select

a default paper size.

6. After installation is complete, click Restart to restart your iMac.

7. Open the Chooser from the Apple menu.

8. Click the SC 740 icon.

9. Select the USB Port icon (if you’ve connected more than one EPSON Stylus

COLOR 740, the port is numbered).

10. Turn on background printing if you want, then close the Chooser.

If you don’t see your printer icon in the Chooser, make sure your USB port and printer

parallel port connections are secure and your printer is turned on. Check the MacOS Info

Center on your iMac desktop for additional information on USB connections.

If the printer doesn’t work correctly, uninstall the printer software as described in the Printer

Basics book. Also uninstall the EPSON USB Printer Device software the same way. Then

reinstall the USB device and printer software as described in this guide. If you still have

problems, contact your EPSON dealer or EPSON technical support as described in the

Printer Basics book.

To install your creative software and electronic manual, continue with “Installing Your

Creative and Internet Software and Electronic Manual” on page 6.

solusb1.fm Page 3 Monday, October 12, 1998 12:06 PM

Installing the USB Printer Software (Windows 98)

The USB Printer Device software works best with a Windows 98 system that has not been

upgraded from Windows 95. Follow the steps below to install the USB Printer Device

software and your EPSON Stylus COLOR 740 printer driver.

1. Make sure your printer and computer are connected and turned off.

2. Turn on your computer and wait until you see the Windows 98 desktop icons.

3. Turn on your printer. You see the Add New Hardware Wizard screen:

4. Insert the EPSON CD-ROM in your drive.

5. Click Next. At the next screen, select Search for the best driver for your device and

click Next.

6. Select Specify a location and type

:\DRIVERS\WIN98 (where

is your

CD-ROM drive letter). Then click Next.

7. The Add New Hardware Wizard now displays EPSON USB Printer; click Next. The

installer copies the USB printer files to your system. At the final screen, click Finish.

Windows 98 first

detects a USB

printer and installs a

device driver for it

Click Specify a location, type

the path, and click Next

solusb1.fm Page 4 Monday, October 12, 1998 12:06 PM

8. Windows 98 detects your printer and displays the following screen. Click Next to install

your printer driver.

9. At the next screen, select Search for the best driver for your device and click Next.

10. Select Specify a location and, if necessary, type

:\DRIVERS\WIN98 (where

is your

CD-ROM drive letter). Then click Next.

11. Follow the on-screen instructions to install your printer driver and Status Monitor 2, then

restart your system.

To verify that your USB software installed properly, check the Device Manager. Click Start,

point to Settings, and click Control Panel. Then double-click System and click the

Device Manager tab. You should see the device EPSON USB Printer Devices listed. Click

the +next to the device; you should see EPSON USB Printer (EPUSB1:) listed too.

If the printer doesn’t work correctly, uninstall the printer software as described in the Printer

Basics book. Also uninstall the EPSON USB Printer Device software the same way. Then

reinstall the USB device and printer software as described in this guide. If you still have

problems, contact your EPSON dealer or EPSON technical support as described in the

Printer Basics book.

You see your printer

model name here

Click Specify a location, type

the path, and click Next

solusb1.fm Page 5 Monday, October 12, 1998 12:06 PM

To install your creative and Internet software and view the electronic manual, continue with

the procedure below.

Installing Your Creative and Internet Software and Electronic

Manual

Once you’ve restarted your system, you can install the rest of the software on your EPSON

CD-ROM from the Start menu.

1. Make sure the EPSON CD-ROM is in your drive.

2. For Windows, click Start, select Run, and type

:\Epson (where

is your CD-ROM

drive letter). Then click OK.

On a Macintosh, double-click the EPSON icon in the EPSON CD-ROM folder.

3. After a moment, you see the EPSON Stylus COLOR 740 Installer Main Menu:

Click License Agreement to read your software license agreement. Then click OK to

return to the Main Menu.

4. To install a program or your electronic EPSON Stylus COLOR 740 Manual, just click the

button for your selection on the Main Menu. (If necessary, close any open windows

covering the Main Menu.)

Note:

To view your electronic manual, you must install Adobe Acrobat®Reader and QuickTime®

MoviePlayer™if you don’t already have them on your system. With Windows, the installer

automatically installs the programs for you. On a Macintosh, select the options to install the

programs and follow the on-screen instructions. Once you’ve viewed the manual, you can copy

it to your hard disk using the Copy Printer Manual to Hard Drive option.

First clickhere to read

your software license

agreement

Not available

with Macintosh

solusb1.fm Page 6 Monday, October 12, 1998 12:06 PM

5. Some of the software you install may restart your system. If you restart but want to install

more software, do the following:

Windows: Click Start, point to Programs, Epson, and click EPSON Stylus COLOR

740 Installer.

Macintosh: Double-click the EPSON icon in the CD-ROM folder.

If you’re running Windows, you can use the Guided Printing Exercise for a quick lesson

in printing (not available with Macintosh). See “Print an image” on your Start Here card

to get started.

solusb1.fm Page 7 Monday, October 12, 1998 12:06 PM

EPSON and EPSON Stylus are registered trademarks of SEIKO EPSON CORPORATION.

General Notice: Other product names used herein are for identification purposes only and may be trademarks of their respective owners.

EPSON disclaims any and all rights in those marks.

Printed on recycled paper with at least 10% post-consumer content. CPD-7634

solusb1.fm Page 8 Monday, October 12, 1998 12:06 PM
