OT-CU40 User’s Manual 2

English

OT-CU40

User’s Manual

This product (OT-CU40) is a replacement auto cutter unit exclusively for CW-C4000 Series.

This manual explains how to replace the OT-CU40 and precautions for handling it.

CAUTION

❏Do not subject the auto cutter unit to impact by dropping or bumping it. Doing so

may cause the unit to stop operating normally.

❏Do not touch the movable blade of the auto cutter. Doing so may result in injury.

❏Do not touch the gear shown in the figure. Turning the gear may cause the movable

blade to move and protrude from the auto cutter unit, making it impossible to install

the unit or the unit may not operate properly.

❏If you have moved the movable blade before installing it, return the blade to its

original position by turning the gear until you can see the triangle in the opening.

English

OT-CU40 User’s Manual 3

English

❏Do not pull the cables vigorously. The connector pins and cables may be damaged.

❏Store the cutter in a place out of reach of children.

OT-CU40 User’s Manual 4

English

How to Replace the Unit

1. Turn off the printer and unplug the power cable from the power

outlet.

2. Open the maintenance box cover.

3. Open the front cover.

OFF

OT-CU40 User’s Manual 5

English

4. Loosen one screw with a Phillips screwdriver and then remove the

auto cutter cover set.

5. Disconnect the connector of the auto cutter unit from the printer.

CAUTION

Grip the connector and pull it straight out. If you grip the cables to pull them, or pull

the connector at an angle, the connector may be damaged.

OT-CU40 User’s Manual 6

English

6. Loosen two screws with a Phillips screwdriver and then remove

the auto cutter unit.

7. Install the replacement auto cutter unit.

Align the holes on the left and right sides of the cutter unit with

the protrusions on the printer. Otherwise, the unit may not

operate properly.

CAUTION

Be careful not catch the cables in between the auto cutter unit and the printer. If

the cables get caught, you cannot connect the cables at the subsequent step or the

cables may be broken.

OT-CU40 User’s Manual 7

English

8. Secure the auto cutter unit with two screws.

9. Connect the connector of the auto cutter unit to the printer,

paying attention to its orientation.

CAUTION

❏Grip the connector and insert it straight. Inserting it at an angle may result in

incorrect connection and damage of the connector.

❏Make sure to insert the connector as far as it will go. If it is not inserted all the

way, the auto cutter unit may not work properly.

OT-CU40 User’s Manual 8

English

10. Attach the auto cutter cover set and then secure it with one screw.

11. Close the front cover.

12. Close the maintenance box cover.

OT-CU40 User’s Manual 9

English

13. Plug the power cable into a power outlet and then turn on the

printer.

If an error appears on the screen after turning on the power, start over from step 1.

14. Select the following menu on the operation panel to reset the

counter of the auto cutter.

[Menu] - [Printer Status/Print] - [Auto Cut Counter] - [After

Replacement]

15. Check that the auto cutter unit operates properly.

We recommend that you check the operation in advance. Load the paper in the printer

and use the auto cut button to check.

If an error appears on the screen after the operation, start over from step 1.

OT-CU40 Manuel d’utilisation 10

Français

OT-CU40

Manuel d’utilisation

Ce produit (OT-CU40) est une unité de coupe-papier automatique de remplacement pour

CW-C4000 Series uniquement.

Ce manuel vous explique comment remplacer l’OT-CU40 et les précautions à prendre pour sa

manipulation.

ATTENTION

❏Ne faites pas subir de choc à l’unité de coupe-papier automatique en la faisant

tomber ou en la heurtant. Cela pourrait empêcher l’unité de fonctionner

normalement.

❏Ne touchez pas la lame mobile du coupe-papier automatique. Cela pourrait entraîner

des blessures.

❏Ne touchez pas l’engrenage indiqué sur la figure. Faire pivoter l’engrenage peut

déplacer la lame mobile et la faire dépasser de l’unité de coupe-papier automatique,

rendant alors impossible l’installation de l’unité ou empêchant son bon

fonctionnement.

Français
