Epson EPL N2700 Guía de configuración

4010651

XXX-00

[Read This First]

Getting Ready!

Page Printer

Printer Parts

face-down tray control panel

lower cassette

MP tray

power switch

lock

lever

cover A

cover C1 duplex unit

connector

optional interface

slot cover

serial interface

connector

ethernet interface

connector

AC inlet

10-bin multi-purpose

unit connector

5-bin multi-purpose

unit connector

parallel interface

connector

cover B

Getting Ready!

Contents

Printer Parts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

1 ENERGY STAR Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

2 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Ozone safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Laser printer precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . 7

For United Kingdom users . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Warnings, Cautions, and Notes . . . . . . . . . . . . . . . . . . . . . . . . 10

3 Attaching the Quick Reference Box. . . . . . . . . . . . . . . . . . . . . . . 11

4 Attaching the Side Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

5 Installing the Large Capacity Paper Unit . . . . . . . . . . . . . . . . . . 13

6 Installing the 500-sheet Lower Cassette Unit. . . . . . . . . . . . . . . 18

7 Installing the Imaging Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . 23

8 Attaching the Power Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

9 Loading Paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Loading paper in the MP Tray . . . . . . . . . . . . . . . . . . . . . . . . . 28

Loading paper in the Lower Cassette . . . . . . . . . . . . . . . . . . . 32

Selecting the paper size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

10 Test Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

11 Connecting the Printer to a Computer . . . . . . . . . . . . . . . . . . . . 38

12 Installing Microsoft® Internet Explorer 4.0 . . . . . . . . . . . . . . . . 40

13 System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

14 For DOS programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Where to Find Information

Getting Ready!

This is a manual which explains setting up the printer and installing the

optional Large Capacity Paper Unit and optional 500-sheet Lower Cassette

Unit. It explains the preparations which are necessary before the printer can

be used, beforethe installation of the optional Large Capacity Paper Unit and

optional 500-sheet Lower Cassette Unit, and before the installation of the

Internet Explorer browser software used to view the online manual.

Administrator's Guide

This is an online manual which explains information needed by the

Administrator, including network settings and installation of printer

software. You will find this manual in the CD-ROM entitled "Online Guide

for the EPL-N2700". For information about how to access and read online

manuals, refer to the booklet accompanying the CD-ROM. Use the Internet

Explorer browser to view the online manual.

Reference Guide

This is an online manual which provides detailed information necessary for

using the printer, including explanations on the installation of the various

options and the different printer functions. You will find this manual in the

CD-ROM entitled "Online Guide for the EPL-N2700". For information about

how to access and read online manuals, refer to the booklet accompanying

the CD-ROM. Use the Internet Explorer browser to view the online manual.

Quick Reference Guide

This explains the printer messages, how to clear paper jams and how to

replace imaging cartridges. Place it in the small box on the front of the printer

for safekeeping and easy access.

Online Help (Microsoft®Windows®3.1x, 95, 98, and NT®only)

Provides you with detailed information and instructions on the Windows-

based printer software that controls your printer. (Online help is

automatically installed when you install the printer software.) See the online

Reference Guide for information on accessing online help.

EPSON is a registered trademark of SEIKO EPSON CORPORATION.

General Notice: Other product names used herein are for identification purposes only and may be

trademarks of their respective owners. EPSON disclaims any and all rights in those marks.

1ENERGY STAR Compliance

As an ENERGY STAR Partner, EPSON has

determined that this product meets the ENERGY

STAR guidelines for energy efficiency.

The International ENERGY STAR Office Equipment Program is

a voluntary partnership with the computer and office equipment

industry to promote the introduction of energy-efficient personal

computers, monitors, printers, fax machines, copiers, and

scanners, in an effort to reduce air pollution caused by power

generation.

2Safety Information

Laser safety

This printer is certified as a Class 1 laser product under the U.S.

Department of Health and Human Services (DHHS) Radiation

Performance Standard according to the Radiation Control for

Health and Safety Act of 1968. This means that the printer does

not produce hazardous laser radiation.

Since radiation emitted by the laser is completely confined within

protective housings and external covers, the laser beam cannot

escape from the machine during any phase of user operation.

For European users

United Kingdom

The EPL-N2700 is a page printer which utilizes a semiconductor

laser.

There is no possibility of danger from the laser, provided the

printer is operated according to the instructions in the guides

provided.

Since radiation emitted by the laser is completely confined within

protective housings, the laser beam cannot escape from the

machine during any phase of user operation.

wWarning:

Use of controls or adjustments, or performance of procedures

other than those specified in this guide may result in hazardous

radiation exposure.

This is a semiconductor laser. The maximum power of the laser

diode is 5 mW and the wavelength is 775 to 795 nm.

CDRH regulations

The Center for Devices and Radiological Health (CDRH) of the

U.S. Food and Drug Administration implemented regulations for

laser products on August 2, 1976. Compliance is mandatory for

products marketed in the United States. The label shown below

indicates compliance with the CDRH regulations and must be

attached to laser products marketed in the United States.

Laser safety labels

wWarning:

Use of controls, adjustments, or performance of procedures other

than those specified in this guide may result in hazardous

radiation exposure.

Your printer is a Class 1 laser product as defined in IEC 825

specifications. The label shown below is attached in countries

where required.

Ozone safety

Ozone emission

Ozone gas is generated by laser printers as a by-product of the

printing process. Ozone is produced only when the printer is

printing.

Ozone exposure limit

The recommended exposure limit for ozone is 0.02 parts per

million (ppm) expressed as an average time-weighted

concentration over an eight-hour period.

The EPL-N2700 laser printer generates less than 0.01 ppm for

eight hours of continuous printing in a closed room of

approximately 1000 cubic feet (8' × 10' × 12').

Minimize exposure risk

To minimize the risk of exposure to ozone:

❏Do not use more than one laser printer in a confined area.

❏Do not use your printer in conditions of extremely low

humidity.

❏Do not use your printer in a room with poor ventilation.

❏Avoid long, continuous printing in any of the conditions

mentioned above.

Printer location

The printer should be located so that the exhaust gases and

generated heat are:

❏Not blown directly into the user's face.

❏Vented directly out of the building whenever possible.

Laser printer precautions

This printer uses laser technology. The following list of

precautions applies whenever you open the printer cover. Even

if you are familiar with other types of printers, be sure to follow

these precautions carefully to ensure safe, efficient operation.

❏Do not touch the areas specified on the caution labels inside

cover A and cover B. If the printer has been in use, the fuser

can be very hot.

❏Avoid touching the components inside the printer unless

instructed to do so in this guide.

CAUTION

Hot Surface Avoid Contact

CAUTION

Hot Surface Avoid Contact
