Epson ELP DC-06 Visualiser Manual de usuario
Document Camera
User's Guide
2
Thank you very much for purchasing this product. Read this document carefully to use this
product safely and correctly. To allow you to solve any unknown points quickly, keep this
information close at hand.
So that you can use the product safely and correctly, symbols are applied in this User's
Guide and on the product to indicate possible harm to the user or to others and the risk of
damage to property. The indications and their meaning are as follows. Make sure you
understand them properly before reading the guide.
Safety Instructions
Warning This symbol indicates information that, if ignored, could possibly
result in death or personal injury due to incorrect handling.
Caution
This symbol indicates information that, if ignored, could possibly
result in personal injury or physical damage due to incorrect
handling.
Warning
vIf any of the following situations occur, immediately disconnect the USB cable and
contact your local dealer or Epson service center:
Smoke, unusual odor, or unusual sound is emitted from the unit.
Water or a foreign object has entered the unit.
The product was dropped or the case is damaged.
Continued use may cause a fire. Due to the potential danger, never attempt to repair
the unit yourself.
vExcluding service personnel, never open the unit case. In addition, never disassemble
or modify the unit. A fire or accident may result.
vDo not place any containers of liquid on top of the unit. If anything spills into the unit, a
fire may result.
vDo not insert any metallic objects or other foreign materials into the unit. A fire may
result.
vDo not place the unit in locations with unusually high temperatures, such as in direct
sunlight or near the outlet of an air conditioner or heater. The unit may be deformed due
to heat, the internal components of the unit may be adversely affected, or a fire may
result.
vDo not use or place the unit in locations with high humidity or locations where it may
become wet, such as outdoors or near a bath or shower.
vWhen using the unit, do not look into the camera lens when the LED lamp is on.
3
vDo not place the unit in locations where it will be exposed to greasy smoke or steam, such
as cooking areas or near humidifiers, or in very humid or dusty locations.
vDo not store the unit in direct sunlight or near heaters.
vDo not place the unit in locations where it will be subject to a lot of vibration.
vDo not touch the camera lens with bare hands. The displayed images will not be clear if
there are fingerprints or oil from your skin on the lens surface.
vWhen moving the unit or when the unit is not in use, be sure to disconnect the USB cable.
vWhen cleaning the unit, wipe the unit with a soft dry cloth. Do not use volatile substances,
such as thinner or benzene.
vWhen transporting the unit, store it in the soft carrying case.
vWhen the unit is connected to a projector with the USB cable, the unit will not operate
properly if a USB hub is used. Use a direct connection.
vConnect the unit using the USB cable that is supplied with the unit or the projector.
vDo not use or store the unit where it will be exposed to greasy smoke or tobacco smoke,
or in very dusty locations.
Caution
vDo not place any heavy objects on the unit. It may tip over or break.
vWhen using the unit, be sure to extend the foot. The unit may fall, causing personal
injury if it strikes someone.
vBe careful not to pinch your fingers in the movable parts of the unit.
vDo not place the unit on an unstable location, such as a shaky table or slanted surface.
The unit may drop or tip over, causing personal injury.
vWhen raising the camera arm of the unit, use both hands. If you release the camera
arm before it is raised completely, the camera head may spring up, causing personal
injury.
vDo not place or store the unit where it is accessible to small children. The unit may drop
or tip over, causing personal injury.
vDo not place the unit near high-voltage power lines or sources of magnetism. The unit
may not operate properly.
vBefore cleaning the unit, disconnect the USB cable to prevent possible damage.
Usage Precautions
4
Check the following list to confirm that you have all of the supplied items. If by any chance
there is anything missing or damaged, please contact your dealer.
* The Soft carrying case is not included when the unit is packaged together with a
projector.
vCompact size
This document camera is compact and light, making it easy to carry and use in small
areas.
vEasy setup
You can connect the document camera directly to selected models of Epson projectors by
simply using a single USB cable. This will let you project enlarged images of printed
documents and other materials. (Check your projector User's Guide to verify
compatibility.)
vComputer compatible
You can also capture and edit images when you use the document camera with a
computer. Connecting is easy — just plug in the included USB cable (a separate power
cable is not needed).
Supplied Items List
YDocument Camera YUSB cable (for use with Document
Camera only) 3.0 m
YUser's Guide (this guide) YELPDC06 Soft carrying case *
YQuick Start Guide YSetup Label
YArcSoft Application software for ELPDC06
Product Features
5
Top/Side/Rear
Part Names and Functions
Name Function
Camera head Rotate the camera head ±90° to display images of a
document or from a wall.
Foot Extend the foot on the bottom of the case when using the
document camera.
Camera arm Extend or retract the camera arm to adjust the height of the
camera head.
Security slot The security slot is compatible with the Kensington
MicroSaver security system.
[Freeze] Press the [Freeze] button to turn on the indicator light on the
button and freeze the image displayed by the document
camera.
Press the [Freeze] button again to unfreeze the image and
to turn off the indicator light.
[Focus] Press the [Focus] button to automatically focus the image.
The unit cannot focus on objects that are approximately
10 cm (4 inches) or less from the camera lens.
[][] Press the [ ] button to enlarge the image size.
Press the [ ] button to reduce the image size.
[ ] Press the [ ] button to turn the LED lamp on and off.
[Source Search] When you plug in the USB cable, the source from the
document camera will be automatically selected.
When multiple devices are connected to the projector, press
the [Source Search] button repeatedly until the image you
want to display is shown.
This function does not work when the unit is connected to a
computer.
6
Camera Head
Power indicator This indicator comes on when power is supplied from a
projector or computer.
USB terminal (type B) This terminal is used to connect the unit to a projector or
computer using the supplied USB cable.
Name Function
Image rotation dial Turn this dial to rotate the displayed image ±90°.
Camera lens This lens captures the image.
LED lamp Turn on this lamp when there is not enough light on your
document.
7
Connect the document camera to a projector using the USB cable that is supplied with the
unit.
For information on the projectors that can be connected, see the User's Guide supplied with
the projector.
AExtend the foot, and then hold the base and raise the camera head.
vThe document camera will not operate properly
if a USB hub is used. Connect the projector
directly to the unit.
vBe careful not to pinch your fingers in the
movable parts of the unit.
vWhen using the document camera, be sure to
extend the foot. Otherwise, the unit may fall,
causing personal injury if it strikes someone.
BWhile holding the camera head, raise the camera arm.
Do not release the camera head before the camera
arm is vertical. The camera head may cause
personal injury if it strikes you.
CRotate the camera arm 90°and adjust the height according to the subject matter.
Do not look into the camera lens when the LED
lamp is on.
Connecting to a Projector to Display Images
Procedure
Caution
Caution
Warning
8
DTo display using the document camera, connect the supplied USB cable (3.0 m)
to the USB terminal (type A) identified by the Document Camera icon on the
projector.
Connecting to a Projector through a Computer
For information on connecting to a computer, see “Connecting to a Computer to Display
Images” on page 9.
Displaying an Image of Printed Documents and Other
Materials
APlace the document you want to
display directly under the camera
lens.
BExtend or retract the camera arm to
adjust the image size and press the
[ ][ ] buttons to enlarge or reduce
the image size.
CPress the [Focus] button to
automatically focus the image.
If you want to rotate the image, turn the
image rotation dial.
Displaying Images
Procedure
9
Displaying Live Action or an Image from a Whiteboard
ATurn the camera head to display live action or an
image from a whiteboard or wall.
BIf you want to rotate the image, turn the image
rotation dial.
To connect the document camera to a computer, you must install the included ArcSoft
Application software for ELPDC06. When the software is installed, the computer can be
used to operate the document camera and capture images.
In addition, large images can be displayed by connecting the computer to a projector.
Procedure
Connecting to a Computer to Display
Images
10
This section explains how to operate the unit when it is connected to a computer.
In the following explanations, unless otherwise noted, Windows screen shots are used.
However, the screens will be similar even when using Macintosh.
Installing the Software
Note the following points before installing the software:
vQuit all programs that are currently running before installing the software.
vFor users of Windows XP/Vista, install the software as a user with administrator rights.
vSee the Appendix for the operating environment necessary for the software.
For Windows
AInsert the CD-ROM into the computer to start the installation for ArcSoft
Application software for ELPDC06.
BWhen you see the license agreement, click "Yes".
CFollow the instructions to install the software.
DWhen the installation complete screen appears, click "Finish".
ELPDC06 Button Manager must also be installed. Do not clear the check box.
EInstall ELPDC06 Button Manager.
When you see the license agreement, click "Yes".
FFollow the instructions to install the software.
GWhen you click "Finish", the installation is complete and the icon appears
on the computer desktop.
Using the ArcSoft Application software for
ELPDC06
Procedure
