EPSON

Product Support Bulletin

Subject: Proper Method for Running Benchmark and Diagnostics Programs

Date: 06/04/93 PSB No: S-0158

Page(s): 1 of 1 Originator: MWT

This bulletin describes the proper method for running any benchmark or diagnostics

programs. This applies to any computer system.

In most cases, the computer should be started using an MS-DOS boot diskette

that’s ‘clean’ -

in other words, one with no CONFIG.SYS or AUTOEXEC.BAT files.

The appropriate executable can then be run, either from diskette or hard drive.

There will be some exceptions to the above rule. In attempting to benchmark or

troubleshoot any add-on that requires a device driver (CD-ROM, local area network,

etc.), obviously the necessary device driver(s) must be loaded. Also, some

programs will require a minimum number of FILES or BUFFERS to be defined in

the CONFIG.SYS file. Such programs will usually display this requirement if they

are run without the necessary CONFIG.SYS file.

For the most consistent results, use the absolute minimal boot configuration that’s

allowed by the hardware being tested.

Product Support Bulletin

Subject:

Equity and Apex Series Compatibility with the Sysgen OmniBridge

Controller and BridgeFiler External Floppy Drives

Date:

04/11/90

Page:

1 of 3

PSB No:

S-0088B

Originator:

KAS

The purpose of this bulletin is to provide the results of compatibility testing

conducted by the Computer Product Support Center with the Sysgen

OmniBridge controller and Bridge - Filer external floppy disk drives.

Comments

Equity I

The Equity I was found compatible with the OmniBridge

controller. It was able to support one or two external

disk drives (daisychained) together. The external drives

could be used as high density (1.2M and 1.44M) or

normal (360K and 720K) disk drives.

Equity II

Equity III

Equity I +

Equity le

The Equity II was found to be totally incompatible with

the OmniBridge controller.

The Equity III was found compatible with the OmniBridge

controller. It was able to support one or two external

disk drives (daisychained) together. The external drives

could be used as high density (1.2M and 1.44M) or

normal (360K and 720K) disk drives.

The Equity I + was found compatible with the

OmniBridge controller.

It was able to support one or

two external disk drives (daisychained) together. The

external drives could be used as high density (1.2M and

1.44M) or normal (360K and 720K) disk drives.

The Equity le was found compatible with the OmniBridge

controller. It was able to support only one external

floppy drive, unlike the other models tested. The drive

could be used as a high density (1.2Mb and 1.44Mb) or

normal (360K and 720K) disk drive.

PSB No: S-0088B

Page: 2 of 3

Equity II +

Equity lIe

The Equity II + was found compatible with the

OmniBridge controller.

It was able to support one or

two external disk drives (daisychained) together. The

external drives could be used as high density (1.2M and

1.44M) or normal (360K and 720K) disk drives.

The Equity Ile was found compatible with the

OmniBridge controller.

It was able to support one or

two external disk drives (daisychained) together. The

external drives could be used as high density (1.2M and

1.44M) or normal (360K and 720K) disk drives.

Equity Ill +

The Equity III + was found compatible with the

OmniBridge controller.

It was able to support one or

two external disk drives (daisychained) together. The

external drives could be used as high density (1.2M and

144M) or normal (360K and 720K) disk drives.

Equity 386SX

The Equity 386SX was found compatible with the

OmniBridge controller.

It was able to support one or

two external disk drives (daisychained) together. The

external drives could be used as high density (1.2M and

144M) or normal (360K and 720K) disk drives.

Equity 386/20

The Equity 386/20 was found compatible with the

OmniBridge controller.

It was able to support one or

two external disk drives (daisychained) together. The

external drives could be used as high density (1.2M and

1.44M) or normal (360K and 720K) disk drives.

APEX

APEX +

The Epson APEX was found compatible with the

OmniBridge controller.

It was able to support one or

two external disk drives (daisychained) together. The

external drives could be used as high density (1.2M and

1.44M) or normal (360K and 720K) disk drives.

The Epson APEX was found compatible with the

OmniBridge controller.

It was able to support one or

two external disk drives (daisychained) together. The

external drives could be used as high density (1.2M and

1.44M) or normal (360K and 720K) disk drives.

PSB No: S-008B

Page: 3 of 3

APEX 100

APEX 200

The Epson APEX 100 was found compatible with the

OmniBridge controller.

It was able to support one or

two external disk drives (daisychained) together. The

external drives could be used as high density (1.2M and

1.44M) or normal (360K and 720K) disk drives.

The Epson APEX 200 was found compatible with the

OmniBridge controller.

It was able to support one or

two external disk drives (daisychained) together. The

external drives could be used as high density (1.2M and

1.44M) or normal (360K and 720K) disk drives.

NOTE:

The recommended switch settings for the OmniBridge controller are

as follows:

1-1 DOWN 2-1 DOWN

1-2 DOWN 2-2 DOWN

1-3 DOWN 2-3 UP

1-4 DOWN 2-4 UP

These settings select NO ADDRESS for the OmniBridge BIOS and

allow it to coexist with the internal FDC of the computer in which it

is being installed.

This way you do not need to disable the internal

FDC or connect any cables from the OmniBridge to internal floppy

drives. This was found to be a universal setting for all of the

computers listed above as compatible with the OmniBridge controller.

Product Support Bulletin

Subject:

Apex / Apex Plus / Equity Series Keyboards

Date: 4/19/89

Page: 1 of 1PSB No: S-0080

Originator: REM

The purpose of this bulletin is to provide information on the various keyboards

used with the Apex, Apex Plus and Equity series computers and the part

numbers of the keyboard subassemblies used with these keyboards.

The Apex and Apex Plus computer keyboards are to be replaced as whole

units.

The Equity series keyboards are repaired to the subassembly level.

The

Equity III keyboard PCB assembly is the only one that comes with the key top

set attached.

Since some of the keyboards have the same model numbers, the difference

can be determined by the FCC ID number in those cases.

The chart below provides a quick reference to determine the part number of

the main keyboard PCB assembly, key top set, control logic subassembly, and

keyboard cable.

Apex / Apex Plus Equity I, II, Ill

Keyboard Keyboard

Key Top

Keyboard

Model Unit Model

PCB Assy

set

Cable

Apex

A265091A

Equity I/II

Y145501001 Y145501021 Y144305000

Apex Plus 93553905410 Equity Ill

KAFLZ3AEPS1

attached KACCL060UCA

Equity I +, II +, Ill+, 386/20

Keyboard Control

Key Top

Keyboard

Model

Code

FCC ID

PCB Assy

Board

set Cable

attached Y127501022 Y127501031

none

Y127501022 Y163502020

Y171501017 Y127501022 Y163504006

Equity le

Keyboard Control

Key Top

Keyboard

Model

Code

FCC ID

PCB Assy

Board

set

Cable

E1160A -

C9S4D84701-201

Y163504007 Y171501017 Y171501007 Y171501006

Product

Support

Bulletin

Subject:

Equity Series HDD Controllers Jumper Settings

Date:

6/12/89

Page:

1 of 8

PSB NO.: S-0070A

Originator: APA

ap’

This bulletin provides information on the jumper settings for the hard

disk controllers used in Epson Equity computers.

Please refer to the following pages for information regarding specific

hard disk controllers:

Model # Page #

WD1002A - WX1 . . . . . . . . . .

WD1002S - WX2 . . . . . . . . . .

WD1003 - WAH . . . . . . . . .

WD1002 - WAH . . . . . . . . .

WHDC

. . . . . . . . . . . . . . . .

WD1006S - WAH . . . . .. 7

ACB - 2320 . . . . . . . . . . . . .

HDD Controller WD1002A-WX1 (8-bit)

Model number --------

FACTORY SETTINGS

-- Extra jumper

Jumper Position Description

N/A Not used.

1 to 2 BIOS ROM is enabled (on controller).

2 to 3 Device address 320H.

* hard-wired 1 to 2BIOS ROM size (32K or 64K).

2 to 3 Reduced write current (< = 8 heads).

* hard-wired 1 to 2IRQ 5.

2 to 3 Disk controller I. D. (set to be the first).

* No jumper pins - 1 and 2 are connected by a PCB board etch.

HDD Controller WD1002S-WX2 (8-bit)

FACTORY SETTINGS

Jumper

Position Description

Model number--j

1 to 2

W-2

1 to 2

2 to 3

* hard-wired 1 to 2

2 to 3

* hard-wired 1 to 2

Required for this configuration.

BIOS ROM is enabled (on controller).

Device address 320H.

BIOS ROM size (32K or 64K).

Reduced write current (< = 8 heads).

IRQ 5.

‘--Extra jumper

* No jumper pins - 1 and 2 are connected by a PCB board etch.

HDD Controller WD1003-WAH (16-bit)

Model number

FACTORY SETTINGS

Jumper Position Description

1 to 2

No jumper

* No jumper

2 to 3

Status read is latched.

Primary address selected.

Required for this configuration.

Standard configuration.

Connection of LED indicator cable :

Model Pin 1 of J6

Equity III

Equity II +

Equity III +

Orange wire

Blue wire

Red wire

* No jumper pins.

HDD Controller WD1002-WAH (16-bit)

FACTORY SETTINGS Model number

Jumper

Position Description

W1 1 to 2 Primary base address.

Center to NL HDD activity LED only lights when the controller accesses the drive.

Connection of LED indicator cable :Model Pin 1 of J4

Equity III Orange wire

Equity II +

Blue wire

Equity III +Red wire

Otros manuales para Equity III

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de De oficina de Epson

Epson

Epson ExpressStation Dimensiones

Epson

Epson Equity 4 Manual de usuario

Epson

Epson PC AX Manual de usuario

Epson

Epson Powerspan Manual de usuario

Epson

Epson ActionPC 8000 Manual de instalación y operación

Epson

Epson Equity 286 PLUS Manual de instalación y operación

Epson

Epson Powerspan Manual de usuario

Epson

Epson Apex Manual de usuario

Epson

Epson Equity Ie Dimensiones

Epson

Epson EL 3S/33 Dimensiones

Epson

Epson Powerspan Manual de instalación y operación

Epson

Epson ActionDesk 4000 Manual de instalación y operación

Epson

Epson Equity III Manual de usuario

Epson

Epson Equity 386SX/16 PLUS Manual de instalación y operación

Epson

Epson Equity 4 Manual de usuario

Epson

Epson EISA Tower Manual de instalación y operación

Epson

Epson Apex Manual de instalación y operación

Epson

Epson Equity 386/25 Manual de usuario

Epson

Epson EL 486UC+ Manual de instalación y operación

Epson

Epson EL 33 Manual de usuario

Epson

Epson Equity 320SX PLUS Manual de instalación y operación

Epson

Epson ActionPC 2600 Manual de instalación y operación

Epson

Epson Endeavor 486C Manual de instalación y operación

Epson

Epson EL 3S/33 Manual de usuario

Manuales populares de De oficina de otras marcas

HP m9060n - Pavilion - Elite Hoja de especificaciones

Asus

Asus E210 Series Manual de usuario

Dell

Dell Inspiron 600m Manual de usuario

Dell

Dell Inspiron 3662 Manual de usuario

TotalFlow

TotalFlow uFLO Manual de usuario

HP Presario SV7000 - Desktop PC Manual de usuario

HP ProDesk 400 G5 Manual

Logitech

Logitech MK320 Manual de usuario

Dell

Dell XPS 730 H2C Manual de usuario

Sony

Sony Vaio Series Manual de usuario

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manual de usuario

Alto

Alto MD 250 Manual de usuario

Lenovo

Lenovo ThinkCentre Edge 72 Manual

Lenovo

Lenovo ThinkStation D20 Manual

Arbor Technology

Arbor Technology FPC-7800 Series Manual de usuario

Sony

Sony VAIO VGX-TP1 Series Manual de usuario

Asus

Asus Eee Box B204 Manual de usuario

Dell

Dell Optiplex 9010 All In One Manual de usuario
