Epson Stylus SX205 Guía

are available.

Only numbered Service Parts

Rev.01 CA21-ACCE-011

EPSON STYLUS NX200/SX200/SX205/TX200/TX203/TX209 No.1

400

EPSON STYLUS NX200/SX200/SX205/TX200/TX203/TX209 No.2 Rev.01 CA21-CASE-011

are available.

Only numbered Service Parts

702

104

107 100

102

101

111

108

105

110

109

106

103

EPSON STYLUS NX200/SX200/SX205/TX200/TX203/TX209 No.3 Rev.01 CA21-CASE-021

are available.

Only numbered Service Parts

809

816

817

813

EPSON STYLUS NX200/SX200/SX205/TX200/TX203/TX209 No.4 Rev.01 CA21-ELEC-011

are available.

Only numbered Service Parts

202

203

201

200 300

Rev.01 CA21-MECH-011

EPSON STYLUS NX200/SX200/SX205/TX200/TX203/TX209 No.5

are available.

Only numbered Service Parts

501

528

503

706

702

709

502

704

701

703

700

504

535

504

527

511

531

533

523

524

521

530

513

514

534

509 510

532 525

512 708

707

520

516

517

519 518

505

506507

508

500

1491824

111

PartCode PartName RefNo. Category Qty Remark

2107706 POWERCABLE 400 Accessories 1

1495050 INKCART.UNBOXED,BK‐S2,PIG'T;H28FA/AN,AS NONFIG Accessories 1

1495051 INKCART.UNBOXED,C‐S3,PIG'T;H28FA/AN,AS NONFIG Accessories 1

1495052 INKCART.UNBOXED,M‐S3,PIG'T;H28FA/AN,AS NONFIG Accessories 1

1495053 INKCART.UNBOXED,Y‐S3,PIG'T;H28FA/AN,AS NONFIG Accessories 1

3103270 SOFTWARECD,CISMEA NONFIG Accessories 1

4113870 SETTINGUPMANUAL NONFIG Accessories 1

4113890 USER'SGUIDE NONFIG Accessories 1

4113891 USER'SGUIDE NONFIG Accessories 1

1487941 PAPERSUPPORTASSY;CA21;EPPI 100 Case 1

1460734 HOUSING,LOWER 101 Case 1

1487946 STACKERASSY;CA21;EPPI 102 Case 1

1460786 HOUSING,UPPER 103 Case 1

1487956 COVERCARDSLOTASSY;CA21;ASP;EPPI 104 Case 1

1460738 COVER,USB 105 Case 1

1460736 COVER,INKTUBE 106 Case 1

1467706 HINGE,ASSEMBLY 107 Case 1

1460787 HOUSING,PANEL 108 Case 1

1460756 BUTTON,SW,POWER 109 Case 1

1460788 BUTTON,SW 110 Case 1

1491824

SHEET PANEL;F

HEET,PANEL;F

111

Case

ase

2116337 HARNESS 203 Case 1

1464551 LABEL,POSITION,CARTRIDGE 702 Case 2

1461678 HOUSING,FRONT,SC 809 Case 1

2121940 SCANNERUNIT;CA21;A;EPPI 813 Case 1

1488753 COVERDOCUMENTASSY.,SC;EPPI 816 Case 1

1490509 COVER,ASF;B 817 Case 1

2120935 BOARDASSY.,MAIN 200 ElectronicParts 1

2116181 BOARDASSY.,PANEL 201 ElectronicParts 1

1460774 GROUNDINGPLATE,PANEL 202 ElectronicParts 1

2122615 PRINTERMECHANISM,ASP 500 MechanismParts 1

1475097 SUBCRASSY.;IEI 501 MechanismParts 1

2115990 CABLE,HEAD 502 MechanismParts 1

2115992 CABLE,HEAD;B 503 MechanismParts 1

1217084 FOOT 504 MechanismParts 4

1075955 ROLLER,LD;B 505 MechanismParts 1

1052673 EXTENSIONSPRING,0.143 506 MechanismParts 1

1459833 CLUTCH 507 MechanismParts 1

1486872 SCALE,CR 508 MechanismParts 1

1459802 TIMINGBELT,CR 509 MechanismParts 1

1482658 ROLLER,PFASSY.,C687;EPPI 510 MechanismParts 1

1476501 POROUSPAD,PAPERGUIDE,FRONT;ASP 511 MechanismParts 1

1488292 ASFASSY;CA21;EPPI 512 MechanismParts 1

1459817 SPURGEAR,51.5 513 MechanismParts 1

1486767 ROLLER,EJECT;B 514 MechanismParts 1

1491008 POROUSPAD,INKEJ,MIDDLE;E 516 MechanismParts 1

1491009 POROUSPAD,INKEJ,LOWER;E 517 MechanismParts 1

1487935 INKSYSTEMASSY;CA21;EPPI 518 MechanismParts 1

1487943

POWER SUPPLY ASSY EPPI

300

1459875 STOPPER,TUBE 519 MechanismParts 1

1459873 COVER,INKEJ 520 MechanismParts 1

1470961 POROUSPAD,CAP,LOWER;B 521 MechanismParts 1

1473327 DIFFUSIONSHEET,INKEJECT;ASP 523 MechanismParts 1

1484639 POROUSPAD,INKEJ,FB,UPPER;C 524 MechanismParts 1

2116016 DETECTOR,PE 525 MechanismParts 1

1436876 SPURGEAR,13.5 527 MechanismParts 1

2116014 BOARDASSY.,ENCODER 528 MechanismParts 1

1484641 POROUSPAD,INKEJ,FB,LOWER;C 530 MechanismParts 1

1477298 CLEANER,HEAD;ASP 531 MechanismParts 1

2122095 MOTOR,ASSY,PF 532 MechanismParts 1

2116012 MOTORASSY,CR 533 MechanismParts 1

1482702 SCALE,PFASSY.,C687;EPPI 534 MechanismParts 1

1476056 POROUSPAD,FRAME,RIGHT 535 MechanismParts 1

F182000 PRINTHEAD 700 MechanismParts 1

1487940 COVERCARTRIDGEASSY;CA21;ASP;EPPI 701 MechanismParts 1

1459776 COVER,CABLE,HEAD,INNER 703 MechanismParts 1

1487938 HOLDERBOARDASSY;CA21;EPPI 704 MechanismParts 1

1430589 HINGE,COVER,CARTRIDGE 706 MechanismParts 1

1487937 HOPPERASSY;CA21;EPPI 707 MechanismParts 1

1495647 COMPRESSIONSPRING,3.43 708 MechanismParts 1

1459778 GUIDE,I/C;F 709 MechanismParts 1

1487943

POWER SUPPLY ASSY;PSE;CA21;EPPI

  ;

PSE

;

CA21

;

300

Power Supply

ower

upp

PartCode PartName RefNo. Category Qty Remark
