EPOX 6WEA4I Manual de usuario

TRADEMARK

All products and company names are trademarks or registered

trademarks of their respective holders.

These specifications are subjected to change without notice.

Manual Revision 1.0

November 23, 1999

A PA P

A Pentiumentium

entiumentium

entium®®

®®

®II or PII or P

II or PII or P

II or Pentiumentium

entiumentium

entium®®

®®

®III Slot1III Slot1

III Slot1III Slot1

III Slot1

PrPr

Processor basedocessor based

ocessor basedocessor based

ocessor based AAAAAGGP

GPGP

GP motherboard

(133/100/66MHz)(133/100/66MHz)

(133/100/66MHz)

6WEA4I

Features6WEA4I

Page 2

FEATURES

6WEA4I Features:

• 6WEA4I is based on the Pentium®II or Pentium®III Processor operat-

ing at 350 ~ 733MHz (100/133MHz) on Slot 1. The board is configured

by a BIOS setting to match your CPU clock speed.

• Designed with Intel’s 810E chipset.

• Supports up to 512 MB of DRAM (minimum of 16 MB) on board, You

can use 168-pin DIMM x 2. It will run Synchronous DRAM memory

(SDRAM) at 100MHz.

• 64-bit system memory interface with optimized support for SDRAM at

100MHz.

• Integrated 2D & 3D Graphics Engine, H/W Motion Compensation Engine,

230MHz DAC and 4MB Display Cache.

• AC’97 2.1 Audio CODEC onboard for enables the software Audio.

• Supports (5) 32 bit PCI slots, provides (2) independent high performance

PCI IDE interfaces capable of supporting PIO Mode 3/4 and Ultra DMA

66 devices. The 6WEA4I supports (5) PCI Bus Master slots and a

jumperless PCI INT# control scheme which reduces configuration confu-

sion when plugging in PCI card(s).

• Supports ATAPI (e.g. CD-ROM) devices on both Primary and Secondary

IDE interfaces.

• Designed with Winbond W83627HF LPC (Low Pin Count) I/O: (1) floppy

port, (1) parallel port (EPP, ECP), and (2) serial ports (16550 Fast UART)

• Includes a PS/2 mouse connector.

• Allows use of a PS/2 keyboard.

• Features Award Plug & Play BIOS. With 4MB(FWH) Flash Memory you

can always upgrade to the current BIOS.

Features 6WEA4I

Page 3

• 6WEA4I utilizes a Lithium battery which provides environmental

protection and longer battery life.

• Supports the Universal Serial Bus (USB) connector. The onboard ICH

(82801AA) chip provides the means for connecting PC peripherals such

as; keyboards, joysticks, speaker, and mouse.

• Built-in ATX 20-pin power supply connector.

• Software power-down when using Windows®95/98.

• Supports ring-in feature (remote power-on through external modem, allow

system to be turned on remotely.

• Resume by Alarm - Allow your system to turn on at a preselected time.

• Supports CPU Hardware sleep and SMM (System Management Mode).

• Supports Hot key, Any key or password Keyboard power ON function

(KBPO).

• Supports the CPU, PWR and Chassis fan Auto stop in the sleep mode.

• Supports the System Power LED (PANEL) blinks in the sleep mode.

• Built-in WOL (Wake On Lan) Connector.

• Supports the AMR Connector for enables the software modem.

• Y2K Compliant.

• Advanced Configuration Power Interface (ACPI) ready.

• Supports USDM software to offer motherboard various status on Windows®

95/98.

• Supports the STR (Suspend To RAM) power management by ACPI’s S3.

• Supports the STR indicator red LED (D23) to avoid pluging or un-pluging

DIMM modules when in a STR mode or power on mode.

• Supports ISA Slot.

Installation 6WEA4I

Page 4

Figure 1

6WEA4I Detailed Layout

Installation6WEA4I

Page 5

Easy Installation Procedure

The following must be completed before powering on your new system:

Configure Jumpers to match your hardware

System Memory Configuration

Device Connectors

Configure Jumpers

We design this motherboard with the a few jumpers to make your installation fast

and easy.

The following will describe all of the jumpers that you are required to set.

JP1 CMOS Clear

JP1 = 1-2 Normal (Default)

= 2-3 Clear CMOS

JP13 Keyboard Power-ON Function

JP13= 1-2 Enabled

= 2-3 Disabled (Default)

Installation 6WEA4I

Page 6

JP8 On Board AC’97 Codec Audio

JP8=1-2 Enabled (Default for 6WEA4I)

= 2-3 Disabled

AC’97/MR Configuration Table

8PJI4AEW6/4AEW6-PE

2-1 )yramirP(draobnO79'CA

)yradnoceS(CMroRM

3-279'CAdraobnOdelbasiD

)yramirP(CMAroCMroRM

* Audio Codec’97 (AC’97)

** Audio Codec (AC)

*** Modem Codec (MC)

**** Audio/Modem Codec (AMC)

***** Modem Riser Card (MR)

Note: In the BIOS setting, “AC97 Audio” of “Integrated Peripher-

als” must be changed from “Enabled” to “Disabled” as well to

come with JP8 setting (at “2-3” position). (refer to page 4-14).

Installation6WEA4I

Page 7

System Memory Configuration

Memory Layout

The 6WEA4I supports (2) 168-pin DIMMs (Dual In-line Memory Module).

The DIMMs can be either EDO (Extended Data Out) or SDRAM (Synchronized

DRAM).

• 100MHz system memory bus frequency. Even if the system host bus is

66MHz.

• 8MB to 256MB using 16MB/64MB technology (512MB using 128MB

technology).

• 256MB Support Registered synchronous DRAM Memory Modules.

• We recommend to installed the “PC/100MHz SDRAM Spec.”, using

DIMM SDRAM must be 125MHz (-8ns) bus speed. If used 100MHz

(-10ns) SDRAM may be critical timing for the motherboard.

• DIMM SDRAM may be 100MHz (-10ns) or 125MHz (-8ns) bus speed.

Figure 2 and Table 1 show several possible memory configurations using

* SDRAM only supports 16, 32, 64, 128, 256MB DIMM modules.

Table 1

yromeMlatoT 1MMID )1/0knaB( 2MMID )3/2knaB(

BM652= mumixaM

*MARDS ,BM46,BM23,BM61 1XBM652,BM821 enoN

BM215= mumixaM

*MARDS ,BM46,BM23,BM61 1XBM652,BM821

DIMM 2

DIMM 1

Bank 2/3

Bank 0/1 -Synchronous

Figure 2

Installation6WEA4I

Page 8

Device Connectors

Please install the motherboard into the chassis.

Now that your motherboard is installed you are ready to connect all your connec-

tions (figure 7).

J2,J3: Chassis Panel Connector

• Keylock, Speaker, Reset, Sleep, Turbo LED and HDD LED

J4: CPU Fan Power

• A plug-in for the CPU Fan Power

J5: Power Supply Fan Monitoring

• A plug-in for the Power supply so that BIOS can monitor the RPM’s

J6: Chassis Fan Power

• A plug-in for the chassis Fan Power

J7: WOL (Wake On Lan) Connector

PW2: ATX Power Connector

• 20-pin power connector

IDE1: Primary IDE Connector

IDE2: Secondary IDE Connector

FDD1: Floppy Controller Connector

CD-IN: CD Audio_IN Connector

• Pin1(CD_IN_Left), Pin2/Pin3(GND), Pin4(CD_IN_Right)

AUX_IN: Auxiliary Line_IN Connector

• Pin1(Left Line_IN), Pin2/Pin3(GND), Pin4(Right Line-IN)

MODEM_IN: Telephony Connector

• Pin1(Audio_in), Pin2/Pin3(GND), Pin4(Mic-out to Modem)

Figure 7

PS/2 Mouse

PS/2

KEYBOARD

COM1 VGA1

parallel port

Speaker

Joystick/Midi

USB port

Line_in

MIC

Installation 6WEA4I

Page 9

Device Connectors (continued)

Speaker - Connect to the system's speaker for beeping

1. Speaker 3. GND

2. N/C 4. GND

Reset - Closed to restart system.

KeyLock - Keyboard lock switch & Power LED connector

1. Power LED(+) 4. KeyLock

2. N/C 5. GND

3. GND

(This is connected to the power button on the case. Using the Soft-

Off by Pwr-BTTN feature, you can choose either Instant Off (turns

system off immediately), or 4 sec delay (you need to hold the button

down for 4 seconds before the system turns off). When the system is

in 4 sec delay mode, there is a special feature to make the system to

go into suspend mode when the button is pressed momentarily.)

Turbo LED indicator - LED ON when higher speed is selected

IDE LED indicator - LED ON when Onboard PCI IDE Hard disks

is activate

J3 1

IR Connector

1. VCC 4. GND

2. NC 5. IRTX

3. IRRX

Power On/Off

* The power LED lights when the

system is powered on and blinks in

SLEEP MODE (Suspend mode).
