Epoc Host2 Manual de usuario

This quick start guide provides rst time setup instructions and other useful

instructions for the epoc®Host2 (Motorola MC55A0). For complete user

instructions, please refer to the epoc System Manual.

epoc Host

Components

epoc Host2

Quick Start Guide

Sc n Button(s)

Sc n Button

(on side)

B rcode Sc nner

Cr dle Bl de

Keyp d

B rcode Sc n LED

Barcode scanning active

Successful scan/capture (blinking)

R dio St tus LED

(NOT USED!)

Touch Screen

(with screen protector)

51005527-04

Epocal, Inc.

2060 Walkley Road

Ottawa, ON K1G 3P5

CANADA

Emergo Europe

Molenstraat 15

2513 BH, The Hague

The Netherlands

Phone: +31.70.345.8570

Fax: +31.70.346.7299

Power Button



Ch rging/B ttery LED

Battery fully charged

Battery charging (blinking)

Charging error (fast blink)



epoc Host

Numeric Keyp d

Power

Sc n Toggle Key

•

Power button turns device on and off. Holding the

Power button for 5 seconds will reset the device.

• Scan key (and Scan Buttons on sides of Host)

activates the barcode scanner.

•

Alp anumeric keys default to numeric values.

Pressing the Toggle Key

allows entry of alpha

characters.

(Key is illuminated and orange symbol

appears on display when active).

Pressing the Toggle

Key again returns key functions to numeric values.

•

Tab & Enter keys navigate to the next editable eld.

•

Backspace key (BKSP) deletes entered characters.

Prior to use . . .

Step 1: Ch rge the

epoc Host

Before using the

epoc Host2

, charge its battery as follows:

Connect the

epoc

Reader power supply to the power jack on the back of the Reader.

2. nsert the

epoc Host2

into the

epoc

Reader’s pivot slot as shown. The initial charge

will take approximately eight hours.

Note: Shaded keys are not active

•A blinking Amber battery LED shows

that the

epoc Host2

is charging.

•A solid Amber battery LED shows that

the

epoc Host2

is fully charged.

For facilities not using an epoc Data Management System, skip steps 2 and 3.

Step 2: Connect to your Wi-Fi Network

NOTE:

Please read Step 2 in its entirety before starting. It may be necessary to

contact your facility’s Information Tec nology department to obtain t e

proper Wireless connection and security settings.

1. Run Motorol Wireless Fusion.

• Turn on the

epoc Host2

by pressing the power

button.

•

At the login screen, scan or enter the word

“dministr tor”

into the User D and

Password elds.

•To scan, aim the Barcode Scanner at the

barcode and press the Sc n Key.

• Exit the

epoc Host2

application

by tapping “Tools”, then “Exit”

from the menu.

For networks that broadcast their SS D:

• Tap the “Fusion” on-screen icon and

select “Find WLANS” from the menu.

• Tap and hold desired WLAN and select

“Cre te Prole” from the menu.

•

Proceed to Congure the Wi-Fi Network

Prole as described on the next page,

starting with the 3rd bullet. Typically, your

settings will be already entered.

For networks that DO NOT broadcast their SS D:

• Tap the “Fusion” on-screen icon and

select “M n ge Proles” from the menu.

•

Proceed to Congure the Wi-Fi Network

Prole as described on the next page

You will need to enter

your settings

manually.

Congure the Wi-Fi Network Prole

• Tap and hold the screen to bring up the

menu; then tap on “Add”.

• Enter correct Prole Name and Network

Name (ESS D), and then tap “Next”.

• Continue entering the correct network

security settings on the screens that follow

(Screenshots 2-8) by tapping “Next”, then

“S ve”.

NOTE:

Screens ots are examples only.

2 of 8

3 of 8

4 of 8

6 of 8

7 of 8

5 of 8

• When nished, tap and hold on the network name, then tap “Connect”.

• Tap “OK” on bottom of the screen to return to the “Today” screen..

• f required, tap on the “Fusion” icon and select “Options” to congure the

appropriate wireless network options.

NOTE:

On some networks, it may be required to disable 802.11d in “Regulatory” options.

2. Reset the

epoc Host

• Perform a warm reset by holding down the power button for 5 seconds.

Step 3: Connect to the

epoc D t M n ger

(EDM)

1. Congure EDM options

• Turn on the

epoc Host2

by pressing the power button.

•

At the login screen, scan or enter the word

“dministr tor”

into the User D and Password

elds. (Set date and time if prompted)

To scan, aim the Barcode Scanner at the barcode and

press the Sc n Key.

•

Select “Tools”

then

“Options”,

then

“EDM

Options” from the menu.

•

Set “EDM Present?”

“YES”,

and enter the correct EDM address and port number,

then tap the disk symbol.

2. Conrm EDM Connection

• Tap the

“Test EDM connection”

button to conrm a

successful EDM connection.

The

epoc Host

is now re dy for use.

NOTE: Refer to t e epoc System Manual for instructions on updating t e epoc Host

Software.

NOTE: Before placing t is unit into service, consult your facility’s internal quality control

procedures and regulatory requirements.

Resetting the epoc Host

There are two reset functions – warm reset and cold reset. n the rare event that the

epoc Host2

stops responding or is not functioning properly, perform a warm reset. f

the

epoc Host2

still does not respond, perform a cold reset. Data will not be lost with

either procedure, which takes approximately one minute.

• Perform a warm reset by holding down the power button for 5 seconds.

• Perform a cold reset by simultaneously holding down the power button, the “1”

key, and the “9” key, and then release.

Removing or repl cing the Screen Protector

A screen protector has been applied to the

epoc Host2 to minimize wear and tear to the

device. To remove the screen protector, lift the

corner using a thin plastic card (such as credit

card), then carefully lift it off the display. To install

a new screen protector, refer to the instructions

included with the replacement screen protector.

Inst lling the Cr dle

n the event that the cradle becomes separated

from the epoc Host2, position the cradle as

shown, and press the two together until both

cradle locking tabs snap into the pockets on the

side of the Host.

How to inst ll or repl ce the microSD C rd on the epoc Host

The SD card slot is located on the back of the epoc Host2 under the battery compartment.

NOTE: It is not necessary to remove t e plastic cradle.

1. Press and release the Power button to

suspend the

epoc Host2

2. Use your nger or stylus to slide the

battery latch to the right releasing the

battery. The battery ejects slightly.

3. Lift the battery from the device.

4. Lift the rubber access door and slide S M

card holder door to unlock.

5. Lift S M card holder door (if it exists), then

lift the microSD card holder door.

6. f removing microSD card, simply remove

the microSD card from holder.

7. nsert the microSD card, with gold bars

facing out, into the card holder door

ensuring that the card slides into the

holding tabs on each side of the door.

8. Then close microSD card door and slide

S M card holder door to lock position.

9. Close rubber access door.

10. nsert the battery; bottom rst, into the

battery compartment in the back of the

epoc Host2

11. Press the battery down into the battery

compartment until the battery release

latch snaps into place.

NOTE: T

o upgrade t e epoc Host2 software from an SD card, refer to t e epoc System

Manual

SIM card

holder door

Rubber access door

Battery Release Latch

Battery

microSD

card holder

door

microSD card

Holding tab
