Enviro Berkeley-Nova Manual de usuario

1PB

OWNER’S MANUAL

50-3259

WARNING: If the information in this manual is not followed exactly, a

re or explosion may result causing property damage, personal injury

or loss of life. Installation and service must be performed by a qualied

installer, service agency or the gas supplier.

Version Française: www.enviro.com/fr.html

4001609

WARRANTY REGISTRATION

enviro.com/warranty

Berkeley-Nova

FREESTANDING GAS FIREPLACE

WARNING:

FIRE OR EXPLOSION HAZARD

Failure to follow safety warnings exactly could result in serious

injury, death, or property damage.

- Do not store or use gasoline or other ammable vapors and

liquids in the vicinity of this or any other appliance.

- WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your

building.

• Leave the building immeadiately.

• Immeadiately call your gas supplier from a neighbor’s phone.

Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the re

department.

- Installation and service must be performed by a qualied

installer, service agency or the gas supplier.

Massachusetts installations (Warning): This product must be installed by a licensed plumber or

gas tter when installed within the Commonwealth of Massachusetts. Other Massachusetts code

requirements: Flexible connector must not be longer than 36in., a shut off valve must be installed;

only direct vent sealed combustion products are approved for bedrooms/bathrooms. A carbon

monoxide detector is required in all rooms containing gas red direct vent appliances. The replace

damper must be removed or welded in the open position prior to installation of a replace insert.

Safety Precautions

INSTALLER:

Leave this manual with the appliance.

CONSUMER:

Retain this manual for future reference.

This appliance may be installed in an after-market permanently located,

manufactured (mobile) home, where not prohibited by local codes.

This appliance is only for use with the type of gas indicated on the rating plate. This

appliance is not convertible for use with other gases, unless a certied kit is used.

Only doors certied with the appliance shall be used

Safety Precautions

FOR SAFE INSTALLATION ANDOPERATION OF YOUR “ENVIRO” HEATER,

PLEASE CAREFULLY READ THE FOLLOWING INFORMATION:

• All ENVIRO gas- red appliances must be installed in

accordance with their instructions. Carefully read all the

instructions in this manual  rst. Consult the building

authority having jurisdiction to determine the need for a

permit prior to commencing the installation.

• NOTE: Failure to follow these instructions could cause

a malfunction of the  replace, which could result in death,

serious bodily injury, and/or property damage.

• Failure to follow these instructions may also void your

 re insurance and/or warranty.

GENERAL

• Installation and repair should be done by a quali ed

service person. The appliance should be inspected before

the  rst use and, at least, annually by a quali ed service

person. More frequent cleaning may be required due to

excessive lint from carpeting, bedding material, etc. It

is imperative the control compartments, burners and

circulating air passageways of the appliance be kept

clean.

• Due to high temperatures, the appliance should be

located out of high traf c areas and away from furniture

and draperies.

Children and adults should be alerted to the

hazards of high surface temperatures and should

stay away to avoid burn or clothing ignition.

• Young children should be carefully supervised when in

the same room as the appliance. Toddlers, young children

and others may be susceptible to accidental contact

burns. A physical barrier is required if there are at risk

individuals in the house. To restrict access to a  replace

or stove install an adjustable safety gate to keep toddlers,

young children and other at risk individuals out of the

room and away from hot surfaces. Any safety screen,

guard, or barrier removed for servicing an appliance must

be replaced prior to operating the appliance.

• Clothing or other  ammable materials should not be

placed on or near the appliance.

• A barrier designed to reduce the risk of burns from the

hot veiwing glass is provided with this appliance and shall

be installed for the protection of children and other at-risk

individuals. If the barrier becomes damaged, the barrier

shall be replaced with the manufacturer’s barrier for this

appliance

FOR YOUR SAFETY

• Installation and service must be performed by a quali ed

installer, service agency or gas supplier.

• This installation must conform to local codes or, in the

absence of local codes, with the National Fuel Gas Code,

ANSI Z223.1/NFPA 54, or the Natural Gas and Propane

Installation Code, CSA B149.1.

• To prevent injury, do not allow anyone who is unfamiliar

with the stove to operate it.

•To prevent injury, if the pilot or pilot and burners

have gone out on their own, open the glass door and

wait 5 minutes to air out before attempting to re-

light the stove.

• Always keep the area around these appliances clear of

combustible material, gasoline and other  ammable liquids

and vapours.

• These appliances should not be used as a drying rack for

clothing or for hanging Christmas stockings/decorations.

• Due to the paint curing on the stove, a faint odor and slight

smoking will likely be noticed when the stove is  rst used.

Open a window until the smoking stops.

Always connect this gas stove to a vent system and vent to

the outside of the building envelope. Never vent to another

room or inside the building. Make sure the speci ed vent

pipe is used, properly sized and of adequate height to

provide suf cient draft. Inspect the venting system annually

for blockage and signs of deterioration.

WARNING: Failure to position the parts in accordance

with the diagrams in this booklet, or failure to use only

parts speci cally approved with this appliance, may result in

property damage or personal injury.

WARNING: Do not operate with the glass front removed,

cracked or broken. Replacement of the glass should be done

by a licensed or quali ed service person.

• Never use solid fuels such as wood, paper, cardboard, coal,

or any  ammable liquids, etc., in this appliance.

• Do not use this appliance if any part has been under water.

Immediately call a quali ed service technician to inspect the

appliance and to replace any part of the control system or

any gas control which has been under water.

• Do not abuse the glass by striking it or slamming the door

shut.

• If the Berkeley unit is pulled out of its installation, and

the vent-air intake system is disconnected for any reason,

ensure that the vent-air intake pipes are reconnected and

re-sealed in accordance to the instructions noted in initial

inStallation - direct vent

HOT GLASS WILL

CAUSE BURNS

DO NOT TOUCH GLASS

UNTIL COOLED.

NEVER ALLOW CHILDREN

TO TOUCH GLASS.



A barrier designed to reduce the risk of burns from the

hot viewing glass is provided with this appliance and shall

individuals.

Table of Contents

Safety Precautions........................................................................................................2

Table of Contents.........................................................................................................4

Codes And Approvals....................................................................................................5

Specications.............................................................................................................6

Dimensions.....................................................................................................6

Rating Label Location.........................................................................................6

Operating Instructions..................................................................................................7

Lighting Instructions..........................................................................................7

Pilot Light.........................................................................................................8

Air Shutter.........................................................................................................8

Remote Controls................................................................................................8

Burner Lighting.................................................................................................9

Blower Speed .................................................................................................10

Normal Sounds During Operation......................................................................10

Maintenance And Service..............................................................................................10

Routine Maintenance.......................................................................................10

Cleaning Decorative Surfaces..........................................................................10

Cleaning the Glass...........................................................................................11

Cleaning the Firebox........................................................................................11

Replacing the Glass..........................................................................................11

Flashout Guard................................................................................................11

Cast Door Removal..........................................................................................12

Glass Door Removal.........................................................................................12

Burner Removal...............................................................................................13

Fuel Conversion...............................................................................................14

Initial Installation.......................................................................................................17

Preparation for Installation...............................................................................17

Clearance to Combustibles................................................................................17

Direct Vent......................................................................................................18

Venting Clearances..........................................................................................18

Approved Venting Parts.....................................................................................19

Horizontal Termination - Minimum Vent..............................................................20

Vent Termination Restrictions............................................................................21

Allowable Vent Congurations...........................................................................22

Air Restrictor Settings......................................................................................23

Horizontal Termination.....................................................................................24

Vertical Termination ........................................................................................25

B-Vent Drafthood Adaptor (50-3229).................................................................28

Gas Line Connection and Testing.......................................................................31

Electrical Requirements ...................................................................................32

Secondary Installation................................................................................................33

Log Set Installation.........................................................................................33

Safety Screen Replacement..............................................................................36

Trouble Shooting........................................................................................................37

Parts List....................................................................................................................38

Rating Label...............................................................................................................41

Notes.............................................................................................................................42

Warranty.................................................................................................................43

Installation Data Sheet...............................................................................................44

DIRECT VENT ONLY: This type is identied by the sufx DV. This appliance draws all of its air for

combustion from outside the dwelling, through a specially designed vent pipe system.

This appliance has been tested and approved for installations from 0 feet to 4500 feet (1372 m) above

sea level.

In the USA: The appliance may be installed at higher altitudes. Please refer to your American Gas

Association guidelines which state: the sea level rated input of Gas Designed Appliances installed at

elevations above 2000 (610 m) feet is to be reduced 4% for each 1000 feet (305 m) above sea level.

Refer also to local authorities or codes which have jurisdiction in your area regarding the de-rate

guidelines.

In Canada: When the appliance is installed at elevations above 4500 feet (1372 m), the certied high

altitude rating shall be reduced at the rate of 4% for each additional 1000 feet (305 m).

• This appliance has been tested by INTERTEK and found to comply with the established VENTED

GAS FIREPLACE HEATER standards in CANADA and the USA as follows:

VENTED GAS FIREPLACE HEATER (Berkeley; NG/LPG)

TESTED TO: ANSI Z21.88-2014/CSA 2.33-2014 VENTED GAS FIREPLACE HEATERS

CAN/CGA 2.17-M91 (R2014) GAS FIRED APPLIANCES FOR HIGH ALTITUDES

CSA P.4.1-15 TESTING METHOD FOR MEASURING ANNUAL FIREPLACE EFFICIENCY

This ENVIRO Berkeley Fireplace:

• Has been certied for use with either natural or propane gases. (See rating label.)

• Is not for use with solid fuels.

• Is approved for bedroom or bed sitting room. (IN CANADA: must be installed with a listed wall

thermostat. IN USA: see current ANSI Z223.1 for installation instructions.)

Codes And Approvals

• Must be installed in accordance with local codes. If none exist, use current

installation code CAN/CGA B149.1 in Canada or ANSI Z223.1/NFPA 54 in

the USA.

• Must be properly connected to an approved venting system and not connected

to a chimney ue serving a separate solid-fuel burning appliance.

IMPORTANT NOTICE (Regarding rst re up): When the unit is turned

on for the rst time, it should be turned onto high without the fan on

for the rst 4 hours. This will cure the paint, logs, gasket material and

other products used in the manufacturing process. It is advisable to open a

window or door, as the unit will start to smoke and can irritate some people.

After the unit has gone through the rst burn, turn the unit off including

the pilot, let the unit get cold then remove the glass door and clean it with

a good gas replace glass cleaner, available at your local ENVIRO dealer.

Specifications

Dimensions:

Figure 1. Berkeley Dimensions

Rating LabeL & Lighting instRuctions Location:

The rating label and lighting instructions are located on a plate hanging on the back of of the unit.

29 5/16" [75.5 cm]

4 5/8"

[11.7 cm]

30 1/4"

[76.8 cm]

31 3/8"

[79.7 cm]

22 15/16"

[58.3 cm]

Operating Instructions

For Your Safety, Read Safety Precautions And

Lighting Instructions Before Operating

WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY

RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OF LOSS OF LIFE.

Lighting anD tuRning off instRuctions:

Figure 2. Lighting Instruction Label

4. Turn the gas control knob clockwise to the “OFF” position.

5. Close the front control panel.

1. STOP! Read the safety information above on this label.

2. Set the thermostat to the lowest setting.

3. Turn off all electric power to this appliance.

4. Open the front control panel.

5. Turn off the gas control knob clockwise to the “OFF” position.

6. Open door. Wait fIve (5) minutes to clear out any gas. Close door.

Then smell for gas, including near the floor. If you smell gas, STOP!

Follow “B” in the saftey information above on this label. If you don’t

smell gas, go to the next step.

7. Find pilot-located near the center rear of the firebox. Turn the gas

control knob counter-clockwise to “PILOT”. Push the gas

control in fully and hold, keep knob depressed for about 30 seconds

after the pilot is lit. Release knob. If pilot goes out, repeat steps 4

through 5.

FOR YOUR SAFETY READ BEFORE LIGHTING

WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life

A. This appliance has a pilot which must be lighted by hand. When

lighting the pilot, follow these instructions exactly.

B. BEFORE LIGHTING smell all around the appliance area for gas.

Be sure to smell next to the floor because some gas is heavier

than air and will settle on the floor.

WHAT TO DO IF YOU SMELL GAS:

Do not try to light any appliance. Do not touch any electrical switch; do

not use any phone in your building. Immediately call your gas supplier

from a neighbor's phone. Follow the gas supplier’s instructions. If you

cannot reach your gas supplier, call the fire department.

C. Use only your hand to push in or turn the gas control knob.

Never use tools. If the knob will not push in or turn by hand,

don’t try to repair it. Call a qualified service technician. Force or

attempted repair may result in a fire or explosion.

D. Do not use this appliance if any part has been under water.

Immediately call a qualified service technician to inspect the

appliance and to replace any part of the control system and any

gas control which has been under water.

LIGHTING INSTRUCTIONS

WARNING: This gas valve has a lockout device, which will not allow the

pilot burner to be relit until the thermocouple has cooled.

-If the knob does not pop up when released, stop and immediately call your

service technician or gas supplier.

-If the pilot will not stay lit after several tries, turn the gas control knob

clockwise

to “OFF” and call your service technician or gas supplier.

8. Turn the gas control knob counter clockwise to the “ON” position.

Flip the burner switch to “ON” then turn the “HI/LOW” knob to the

desired setting.

9. Close the front control panel.

10. Turn on all electric power to the appliance.

11. Set thermostat to desired setting.

TO TURN OFF GAS TO APPLIANCE

1. Set the thermostat to the lowest setting.

2. Turn off all electric power to the appliance if service is to be performed.

3. Open the front control panel and flip burner switch to “OFF” C-12454

1. Turn off the gas to the replace. If not recently done, remove the

glass and let the unit air out for at least ve (5) minutes to

clear out any gas. Turn on gas to the heater.

2. Start the pilot by pressing the gas control knob (Figure 5) and turning it

to PILOT. While pushing the gas control knob in, press the piezo ignitor

several times until the pilot light starts. Hold the gas control knob in for

30 seconds. Check that the pilot has fully engulfed the thermocouple

assembly (see Figure 3).

aiR shutteRs:

Behind the valve access door is the air shutter adjustment levers on the right hand side of the venturi

box (see Figure 4) above the control panel. The air shutters allow the amount of air coming into the

replace to be adjusted in order to accommodate different climates and venting arrangements. The left

shutter adjusts the rear burner and the right shutter adjusts the front burner. Start the pilot and then the

burner. Make sure the pilot ame is burning normally and none of the burner ports are plugged. Let the

replace burn for roughly fteen minutes and then examine the ames, compare the ames to Figure 47

on page 35.

The ideal ame will be blue at the base and light orange above. The ames should be of medium height.

If the ames look like this, no venturi adjustment is needed. If the ames are fairly short and mostly blue,

the replace is getting too much air. Therefore, the air shutter should be closed (pushed in) slightly until

the correct ames are achieved. Flames that are very orange, with tall, dark, stringy tips, are not getting

enough air. Open (pull out) the venturi until the ames clean up. If the shut is opened, or closed all the

way, and the correct ames cannot be attained, turn off the gas and contact the dealer.

Warning: Incorrect shutter adjustment may lead to improper combustion, which is a safety hazard.

Contact the dealer if there is any concern about the venturi adjustment.

Figure 4. Air shutter adjustment lever.

Thermopile Thermocouple

Figure 3. Pilot Flame

Operating Instructions

PiLot Light:

Remote contRoLs:

This replace can use an optional remote control or wall thermostat. If either of these are to be used

to control the replace for the majority of the time, leave the burner switch (Figure 7) in the remote/

thermostat position. Consult the instructions included with the remote/wall thermostat for operation

guidelines.

Less Air More Air

Front Burner

Rear Burner

The Berkeley gas valve and control panel (Figures 5 & 6) are located behind the valve access door at the

front of the stove (Figure 4). To light the burner correctly follow the steps below:

Operating Instructions

For Your Safety, Read Safety Precautions And

Lighting Instructions Before Operating

A) Make sure the pilot is lit (see Pilot liGHt section) .

B) Turn gas control knob COUNTER CLOCKWISE to ON.

C) Flip the burner switch, located at the top right rear of

the Berkeley, to ON (see Figure 7)

D) Turn the HI/LO knob to the desired  ame height.

NOTE: Check that all burner holes are lit.

TO TURN GAS FIREPLACE OFF:

Flip switch to OFF to turn off burners only.

If the  replace is to be turned off for the season, or for

servicing, turn the gas shut off valve to OFF located at the

bottom right on the backside of the Berkeley. DO NOT

FORCE IT. If the unit is going to be serviced, turn off the

electrical power to the unit as well.

NOTE: When the unit is turned on for the  rst time, it

should be turned onto high, with the fan OFF, for the  rst

two to four hours. This will cure the paint, logs, gasket

material, and other products used in the manufacturing

process. It is advised that a door or window be opened

as the unit will start to smoke, which can irritate some

people. After the unit has gone through the  rst burn,

Figure 6. Control Panel

buRneR Lighting:

Piezo Ignitor

Fan Control

turn the unit OFF, including the pilot, and let the unit get completely cold. Then remove the glass and

clean it with a good gas  replace glass cleaner, available at your local Enviro dealer. See “Maintenance

and Service; GlaSS door reMoval” and “Maintenance and Service; cleaninG tHe GlaSS.”

Figure 7. Burner Switch

Burner Switch

TP TH TP TH

IN OUT

Hi/Low

Knob

Gas Control

Knob

Figure 5. Gas Valve Controls

Operating Instructions

bLoweR sPeeD:

The blower will come on only when the replace is up to temperature (approximately 15 minutes). The

speed of the fan can be changed by turning the fan control knob. The blower will continue to operate

automatically after the unit has been shut off (approximately 25 minutes).To turn the blower off, turn

the knob COUNTER CLOCKWISE until it “clicks” off (Figure 6).

It is advisable not to operate the blower below 1/3 speed as it puts a strain on the windings of the blower

and running the blower at lower speeds could also cause premature fan failure.

noRmaL sounDs DuRing oPeRation:

Table 1: Normal Sounds

Component Sound & Reason

Berkeley Creaking when heating up or cooling down.

Burner Light pop or poof when turned off; this is more common with LP units.

Temperature Sensor Clinking when it senses to turn the blower on or off.

Pilot Flame Quiet whisper while the pilot ame in on.

Blower / Fan Air movement that increase and decreases with the speed of the blower. The

blower is pushing the heat from the replace into the room.

Gas Control Valve Dull click when turning on or off, this is the valve opening and closing.

Maintenance And Service

Routine maintenance:

At least once a year, run through the following procedures to ensure the system is clean and working

properly. Check the burner to see if all the ports are clear and clean. Check the pilot to make sure it is not

blocked by anything. The pilot ame should be blue with little or no yellow on the tips.

Warning: Clearances must be sufcient to allow access for maintenance and service

Warning: Failure to position the parts in accordance with this manual, or failure to use only parts

specically approved with this appliance may result in property damage or personal injury.

The venting system must be periodically examined; it is recommended the examination is done by a

qualied agency.

cLeaning DecoRative suRfaces:

Painted, powder coated, or porcelain enameled surfaces should be wiped with a damp cloth periodically.

Never clean the face when it is hot. Do not use other cleaners as they may leave a residue, which can

become permanently etched into the surface.
