Entone URC 4 Manual de usuario

v2.56 for URC 4

Universal Remote Control

URC 

User’s Guide (NorthAmerica Edition)

v2.56 for URC 4

information protected by copyright. No part of this p blication may be reprod ced,

stored in a retrieval system, or transmitted in any form or by any means,

electronic, mechanical, photocopying, recording or otherwise, witho t the prior

written consent of Entone, Inc., 20863 Stevens, Creek Blvd, S ite 300, C pertino,

CA 95014, U.S.A.

DISCLAIMER

IF THIS PRODUCT DIRECTS YOU TO COPY MATERIALS, YOU MUST HAVE

PERMISSION FROM THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID

VIOLATING THE LAW WHICH COULD RESULT IN DAMAGES OR OTHER REMEDIES.

TRADEMARKS

Entone and the tagline “Connecting the Home” are trademarks of Entone, Inc. All

other trademarks or registered trademarks belong to their respective owners.

CHANGES

The material in this doc ment is for information only and is s bject to change

witho t notice. While reasonable efforts have been made in the preparation of this

doc ment to ass re its acc racy, Entone, Inc. ass mes no liability res lting from

the se of the information contained herein.

Entone, Inc. reserves the right to make changes in the prod ct design witho t

reservation and witho t notification to its sers.

P/N: 99-98xx10-00

CUSTOMER SUPPORT AND CONTACT INFORMATION

For Customer Support please call: 650.572.7000

C stomer Contact Information:

Entone, Inc.

20863 Stevens, Creek Blv

Suite 300,

Cupertino, CA 95014

U.S.A.

Tel: 650.572.7000

www.entone.com





2012

v2.5 for URC 4

Table of Contents

Declaration of Conformity .......................................................................................................................................................3

1.1

Introduction...................................................................................................................................................................4

Loading Batteries..............................................................................................................................................................4

2.1

Controlling STB using RF URC ..................................................................................................................................5

RAP Installation (in remote room)....................................................................................................................................6

Connecting STB to the TV coax network........................................................................................................................7

RF URC Registration........................................................................................................................................................8

3.1

Controlling STB using IR URC....................................................................................................................................9

IR Reception Range.......................................................................................................................................................10

4.1

Controlling Your Television and other A/V Devices.................................................................................................11

To Program a TV or AUX device...................................................................................................................................12

Toggle Power Key Punch-through Functionality ..........................................................................................................12

Toggle Volume Key Punch-through Functionality ........................................................................................................12

Toggle Channel Up/Down Keys for TV/AUX ................................................................................................................13

Auto Search Procedures................................................................................................................................................13

Appendix A – Device Code...................................................................................................................................................15

Appendix B – Other Features...............................................................................................................................................25

Showing URC 4 Firmware Version................................................................................................................................25

Showing Programmed Device Code.............................................................................................................................25

URC 4 User’s Guide



v2.5 for URC 4

Declaration of

Conformity

The manufacturer is not responsible for any radio or TV interference caused by unauthorized

modifications to this equipment. Such modifications could void the user’s authority to operate

the equipment.

URC 4 User’s Guide



v2.5 for URC 4

Chapter

1.1 Introduction

The Entone Universal Remote Control v4.x (URC 4) is designed to work either on Radio Signals (RF) or InfraRed (IR).

It can control Janus Media Hub using RF from another room where is not at direct sight distance from the Janus. Or, it

can use IR to control Amulet High Definition IP Television Receiver at direct sight distance. The URC 4 can also be

used to control other A/V devices such as TV, DVD player and audio equipment using IR. There are two types of

Entone URC 4: IR only (IR URC) and IR+RF (RF URC). IR URC is included in the package of Janus/Amulet while RF

URC is included in Entone Second Stream Kit.

Loading Batteries

The URC 4 comes with AA-size batteries, which need to be installed when you first receive your system. When

you replace old batteries, you should replace all of the batteries. Use batteries of the same kind, for example

alkaline or carbon zinc, and do not mix batteries of different kinds. Alkaline batteries last longer than carbon zinc.

Warning: Mixing old and new batteries or different types of batteries poses a fire hazard.

To load batteries to URC 4:

1. Press down on the battery cover’s top latch and slide the cover off.

2. If you are changing out batteries, take out all of the old batteries.

3. Put the new batteries in. Make sure you match the plus ( “+” ) ends with the plus markings on the battery

case.

4. Slide the cover back into place.

Figure 1-1 Loading Batteries to URC 4

URC 4 User’s Guide



v2.5 for URC 4

Chapter

2.1 Controlling STB using F U C

Janus is a multi-television media hub. It can support multiple outputs in multiple rooms viewing different

channels or TV programs. Amulet is a single output video receiver. You can connect Amulet to a primary

output only.

You can use RF URC 4 to control Janus/Amulet using radio signals (RF). These radio signals travel over

long distances and go though walls and other solid objects. You must connect the Remote Antenna

Package (RAP) to the rear panel of the Janus/Amulet.

Your Janus/Amulet comes with one IR URC 4 to be used for output 1 (primary). (Additional RF URC 4 can

be purchased separately.) Your RF URC 4 must be registered to one of the 2 outputs (primary or

secondary) before it can be used. One RF URC 4 can only be registered to one output. However, you can

to control the outputs.

Figure 2-1 Controlling STB using RF URC 4

URC 4 User’s Guide



v2.5 for URC 4

Here are some principles of the remote registration method:

Each output allows a maximum of 3 RF URC 4 to be registered and a registration list is maintained. If

the user has registered 3 RF URC 4 and tries to register another RF URC 4, the first registered RF

URC 4 will be removed from the registration list. This works as a first-in-first-out fashion.

Each RF URC 4 can only be registered for one output. If user tries to register a RF URC 4 which is

already registered to another output, that remote registration will be removed from the original

registration list.

The registration list is maintained in order. If the secondly registered RF URC 4 is removed from the list,

the third entry will move forth to the second and the third will be blank for a new RF URC 4 to be

registered.

You must install the Remote Antenna Package (RAP) comes with Entone Second Stream Kit before doing

the registration. Please refer to the following sections for installing the RAP.

AP Installation (in remote room)

Please follow the following diagram to install the RAP. The RAP is used to enhance the URC radio

frequency transmission using the TV coax cable network in your home.

1 Plug the RAP into the TV.

2 Connect the TV coax cable to the RAP and the TV coax network wall outlet.

Figure 2-2 Attaching Remote Antenna Package

NOTE: Don’t let the antenna touch anything.

ATTENTION: If your URC 4 isn’t working very well from far away, you may be experiencing interference

from objects near your receiver. To improve your URC 4’s reception range, try to adjust the antenna

orientation using screwdriver as shown. You may need to try different antenna orientation to achieve the

best reception.

Figure 2-3 Adjusting Antenna Orientation

URC 4 User’s Guide



v2.5 for URC 4

Connecting STB to the TV coax network

Connect the Entone STB to the TV coax network wall outlet according to whether you are using an Entone

Janus or Amulet STB. The rear panel of actual product may vary.

1. Janus without Tuner Connection: Connect the Janus “MATV” or “TV OUT” output to the TV coax

network as shown.

Figure 2-4 Connecting Janus without Tuner

2. Janus with Tuner Connection: Connect the Janus “MATV” or “TV OUT” and “RF IN” or “CABLE/ANT

IN” output to the TV coax network as shown using a 3-way splitter (which is not provided).

Figure 2-5 Connecting Janus with Tuner

3. Amulet F1 Connection: Connect the Amulet “REMOTE CONTROL” and “COAX” or ”TV OUT” output to

the TV coax network as shown using a 3-way splitter (which is not provided).

Figure 2-6 Connecting Amulet

URC 4 User’s Guide



v2.5 for URC 4

F U C egistration

You may need to register the RF URC to the STB before you can use the remote. The RF URC registration

procedures may vary for different middleware and TV service running in the Entone STB. Please refer to

the TV service user guide for detailed RF URC registration procedures.

Below lists the general RF URC registration procedures (NOTE: Refer to your TV service user guide for

exact RF URC registration procedures):

1. Press and hold the “OK” button on the STB front panel for 5 seconds until the touch panel backlight is

flashing. The STB is now in URC registration mode.

Figure 2-5 Janus in Remote Registration Mode

NOTE: If registration is not completed in 30 seconds, the touch panel backlight will stop flashing.

2. Press “STB” button once on the URC.

3. Press and hold the “STB” button on the URC for 5 seconds until the “STB” button backlight is on.

4. Press “STB” button once again. Both the “STB” and “AUX” button backlight will illuminate.

5. Press “1” or “2” to register the URC to output 1 (primary) or output 2 (secondary) (depending on the

middleware).

Upon successful registration, the STB POWER indicator will flash once and the touch panel backlight

will stop flashing.

NOTE:

The POWER key can be configured to control both the STB and TV while the URC 4 is in “STB” mode,

please refer to the section “Toggle Power Key Punch-through Functionality” in Chapter 4 for details.

The Volume +/- and MUTE key can be configured to control both the STB and TV while the URC 4 is in

“STB” mode, please refer to the section “Toggle Volume Key Punch-through Functionality” in Chapter 4

for details.

URC 4 User’s Guide



v2.5 for URC 4

Chapter

3.1 Controlling STB using I U C

Unlike RF, you do not need to do remote registration in order to use URC 4 to control Janus/Amulet through

IR. The remote comes with Janus/Amulet is IR URC 4. However, you have to program the RF URC 4

comes with Entone Second Stream Kit to use IR mode.

To set the RF URC 4 to use IR to control Janus/Amulet:

1. On the URC 4, press and hold the “STB” button for approx. 5 seconds. The “STB” button backlight will

illuminate. Now the URC 4 is in registration mode.

2. On the URC 4, press “STB” once again. Both the “STB” and “AUX” button backlight will illuminate.

3. Press “0” to set RF URC 4 to IR mode only. The RF URC 4 will not send any RF signal.

The “STB” button backlight on the URC 4 will blink twice to indicate that the setting was successful.

Pressing a key other than “0”, “1”, “2”, “3” or a button is not pressed within 30 seconds, the “STB”

backlight will blink rapidly for 7 times to indicate an error and then extinguish, and the URC 4

registration process will be terminated.
