Entel HT820 Manual de usuario
HT820/880
VHF/UHF submersible transceivers
OWNERS MANUAL
Submersible
Dependable
Tough
Class I,ll &lll
Groups A TO G
DIV l&ll T4
INTRINSICALLY SAFE
CLASSES I, II & III
GROUPS A TO G. DIV I & II T4
WARNING:
SUBSTITUTION OF COMPONENTS MAY
IMPAIR INTRINSIC SAFETY
USE DNLY WITH ENTEL BATTERY CNB840E
DO NOT CHARGE OR RECHARGE BATTERY
IN HAZARDOUS LOCATIONS
V/01
CE COMPLIANCE STATEMENT
The HT800 series transceiver displays "CE" on the serial number label,
indicating its compliance with the essential requirements of the EEC directive
for Electromagnetic Compatibility.
DECLARATION OF CONFORMITY
We Entel UK Limited,
OF:
4 Elstree Gate, Elstree Way,
Borehamwood, Herts.
WD6 1JD
United Kingdom
Declare under our sole responsibility that the product:-
HT800 series VHF/UHF handheld transceiver
Serial Number
To which this declaration relates, is in accordance with directive 95/5/EC and
conforms to the following standard or other nominative documents:-
EN 300 086-2 V1.1.1, EN 301 489-1 V1.5.1:2003, EN 60065:2002
Following provisions of the R&TTE directive.
I SO 9001
REGISTERED FIRM
M. Austin.
Quality Manager
Y
3
1.1 GENERAL FEATURES
1.2 PACKING LIST
1.3 OPTIONS (ACCESSORIES)
1.3.1 ATTACHING AUDIO ACCESSORIES
1.4 CONTROLS AND INDICATORS
1.5 LCD INDICATORS
1.6 RECEPTION
1.7 TRANSMITTING
1.8 ADDITIONAL FEATURES
1.9 VOX (voice operated transmit)
2.0 OPTIONAL TRICKLE CHARGER-model CCA230
2.1 OPTIONAL CHARGER-model CSA640E
2.2 BATTERY INDICATOR
2.3 BATTERY SAFETY
2.4 TROUBLE SHOOTING
2.5 SPECIFICATION (General, receive and transmit)
2.6 SAFETY TRAINING INFORMATION
2.7 NOTES
04
04
05
06
09
10
11
11
12
12
13
13
14
15
16
17
20
22
TABLE OF CONTENTS
4
U.S.T.C Certified intrinsically safe
Heavy duty, commercial grade construction
Submersible / Fully waterproof to JIS7
128 PC programmable channels
All CTCSS & DCS tones
Scan mode
Five programmable buttons
Lithium-lon battery technology
14 hour duty cycle
VOX (voice operated transmit)
Low battery warning bleep
Battery level indicator
Extensive range of accessories
XU
YU
ZU
[U
\U
]U
^U
_U
`U
XWU
XXU
XYU
XZU
1.1 GENERAL FEATURES
The supplied package: (U.S.T.C Certified, intrinsically safe)
HT820/880
CNB840E
CBH940
CAT20/80
Owners manual
Transceiver
1800mAh rechargeable lithium-lon battery pack
Spring loaded rear clip
High efficiency antenna
1.2 PACKING LIST
5
The HT800 is supported by a wide range of essential accessories.
For an up to date list visit our web site at www.entel.co.uk
CSA640E
CSB640E
CST640E
CCA230
CCA12
CNB840E
CMP840
EA19/840
EA15/840
EA12/840
CHP1/840
EPT40/840
CHP800/HD
CHP800/HS
CHP800D
CXR5/840
CXR16/840
CLC940
CAT40IS
CBH940
Single pod intelligent rapid charger, 110/230v operation
Six pod intelligent rapid charger, 110/230v operation
3 or 6 pod battery conditioner/analyser
230v drop in trickle charger. (Also available as 110v -CCA110)
12v drop in trickle charger
7.4V 1800mAh rechargeable lithium-Ion battery pack, with rear clip
Submersible, noise cancelling speaker microphone (heavy duty)
Earpiece microphone with PTT button
Covert style ear/microphone with transparent acoustic tube
D Shape earpiece microphone with in-line PTT
Single earpiece headset with in-line PTT(vox)
Bone conductive earpiece microphone
Heavy duty double ear defender for hardhat with PTT (vox)
Heavy duty single ear defender for hardhat and PTT (vox)
Heavy duty double ear defender with headband and PTT (vox)
Skull microphone (vox)
Throat microphone (vox)
Heavy duty leather case with belt loop & carry strap
Flexible antenna
Spring loaded rear clip
1.3 OPTIONAL ACCESSORIES (U.S.T.C Certified)
Accessories suitable for vox operation have been marked (vox)
NOTE: DO NOT CHARGE OR REMOVE THE BATTERY PACK IN
THE HAZARDOUS AREA LOCATION.
NOTE: THE USE OF NON ENTEL APPROVED ACCESSORIES WILL
INVALIDATE YOUR U.S.T.C INTRINSICALLY SAFE APPROVAL
6
Locate accessory connector cover marked "ACC" Lift cover and
rotate (screw) the connector clockwise.
1.3.1 ATTACHING AUDIO ACCESSORIES
1. Attaching the belt clip; Align the belt clip with the plastic
slots of the battery pack. Slide the belt clip downwards onto
the battery pack, pushing firmly until a click is heard.
2. BATTERY REMOVAL/ATTACHMENT
Preparation prior to use
Figure 1. Attachment the accessory connector
1.
Turn the transceiver off.
2. Using a coin, rotate the battery screw anti-clockwise 2 or 3 turns.
**Ensure that you do not hold the battery pack when
unscrewing the release screw!
Note: The accessory socket is waterproof
without the ACC cover in place. However, when
not using an audio accessory we strongly
advise keeping the ACC cover firmly pressed in
its recess to prevent foreign objects from getting
into the socket.
7
Figure 2.
Battery removal / Attachment
To remove rotate
the screw
anti-clockwise
3.
To attach the battery, locate
the bottom section of the
battery and press the battery
against the transceiver, then
rotate the battery screw
clockwise.
1.4 CONTROLS AND INDICATORS
POWER SWITCH/VOLUME CONTROL
Powers the transceiver on and off. Adjusts volume to
desired level.
PUSH TO TALK SWITCH
Hold down to transmit, release to receive.
UP/DOWN button
Select the desired channel by pressing the UP/DOWN buttons.
For fast channel selection hold down for more than 1 second.
LAMP/LOCK button
P1, P2, P3, P4 buttons
Dealer programmable.
button
Dealer programmable.
1.
2.
3.
4.
5.
6.
8
MON buttons
Dealer programmable.
ANTENNA CONNECTOR
Connects the supplied flexible antenna or an optional external
aerial adaptor.
BATTERY PACK
Rechargeable lithium-lon battery packs.
ACCESSORY CONNECTOR
To connect any HT800 Series radio to an Entel approved
audio accessory.
7.
8.
9.
10.
Figure 3. CONTROLS & INDICATORS
ྙPOWER SWITCH
ྚPTT
ྛUP/DOWN
ྞ
ྟMON
ྜLAMP/LOCK
ྠANTENNA CONNECTOR
ྡBATTERY PACK
ྡྷACCESSORY CONNECTOR
ྜྷDEALER
PROGRAMMABLE
(FUNCTION)
INTRINSICALLY SAFE
CLASSES I, II & III
GROUPSATOG. DIVI&IIT4
WARNING:
SUBSTITUTION OF COMPONENTS MAY
IMPAIR INTRINSIC SAFETY
USE DNLY WITH ENTEL BATTERY CNB840E
DO NOT CHARGE OR RECHARGE BATTERY
IN HAZARDOUS LOCATIONS
10
CHANNEL DISPLAY
The operating channel.
Appears when bleep sound is turned on.
H/L
H indicates high power L indicates low power.
SCAN
Appearswhenscanisactivated.
TX
Indicates transmission in progress.
RX
Indicates reception is in progress.
VOX
Voice operated mode enabled.
The keypad is locked.
BATTERY LIFE INDICATOR
The lithium-lon battery of your transceiver is continually
monitored for your convenience and safety.
MON
Monitor button, to open the squelch.
1.5 LCD INDICATORS
Figure 4. LCD indications
