Easy-touch buttons!
Individuals with mobility issues can control their own music with this
adapted Bluetooth speaker. Three 2½" diameter buttons control six
essential functions: On/Off; play/pause; volume up/volume down; and
track forward/track back. Use sustained pressure for on/off and
volume control and a quick touch control play/pause and track
changing. Pairs with any Bluetooth-enabled device. Or plays from
micro SD/TF card (not included). Includes USB charging cord. Size:
8½ L" x 5W" x 5H". Weight: 1¼ lbs.
Please Note: Computer required for downloading music to
Micro/SD/TF card.
Before first use, remove the safety lock tab, by pulling it out. This
is used for shipping and storage to prevent accidental activation.
Operation:
1. The Adapted Bluetooth Speaker has a built in rechargeable
battery, which is charged through your computer via the included
USB cable or using the included cable with any Tablet or
Smartphone wall charger for faster charging. You can use the
Adapted Bluetooth Speaker during charging. Play time is between
8 and 12 hours at 70% volume.
2. To charge Adapted Bluetooth Speaker, plug it into a USB port on
your computer while the computer is on or using the USB cable or
a better way to charge it is with a Table or Smartphone wall
charger. The LED light will glow red while charging with the power
OFF. When charging completes,(approximately 3 to 4 hours) the
light will go OFF with the power OFF or glow blue with the power
ON.
Modes of Play:
The Adapted Bluetooth Speaker can playback music via
Bluetooth, MicroSD/TF, USB/AUX via cable plugged into a PC
Press the big Mode button to change modes. You will hear an
audio prompt for each mode.
Please Note: FM Mode does not function on this device.
Please Reference the original manufacture instructions for all of
the Adapted Bluetooth Speaker functions and features and any
additional troubleshooting info.
Please Note: Some features or functions listed in the original
manufactures instructions may not work due to switch adaption.
3. To listen to music stored on a MicroSD/TF, insert the card or drive
into the appropriately marked slot on the side of the Adapted
Bluetooth Speaker. Turn on Adapted Bluetooth Speaker’s On/Off
switch On. Press the big “Play” switch on the base. Press it again
to pause the music. Press the “Track Forward” or “Track
Backward” switches to skip between songs. To adjust volume, use
the “Vol +” or “Vol –“switches by pressing and holding them down
to raise or lower the volume level.
4. When you are finished using the Adapted Bluetooth Speaker
make sure to press the big button ON/OFF switch on the base to
prevent the battery from draining down all the way. If not and the
battery drains out and left in this state could cause damage to the
battery.
Troubleshooting:
Problem: Adapted Bluetooth Speaker does not work.
Action #1: Make sure you have charged the Adapted Bluetooth
Speaker. Red LED ON: Charge, Red LED OFF: Full Power & Red
LED Flashing: Low Power.
Action #2: Make sure that there is nothing inhibiting the depression of
the button switches or holding any of the button switches down.
Action #3: Try reloading your music on the MicroSD/TF card, or try a
different MicroSD/TF card to rule this out as the issue.
Rev 4/4/23
