ProTag OPTIMA-II Printer (PT-OPT)
QUICK REFERENCE GUIDE
Introduction
Thank you for choosing our Protag Optima printer. The Protag Optima utilizes thermal printing
technology, hence it needs a unique direct thermal OPT (OPTIMA) test tags. Direct thermal OPT
(OPTIMA) test tags are ideal for indoor or limited outdoor applications and may fade under prolonged
exposed to the elements, such as heat and/or UV light.
Consumables Ordering Information
Please order and use the OPTIMA Tags.
Available in 6 colors. Part codes:
OPT-WHITE, OPT-RED, OPT-ORANGE, OPT-BLUE, OPT-GREEN, OPT-YELLOW
NOTE: For details on how to install the label rolls, please refer to the Printer User Guide.
PAT Tester - Printer Connection Setup
NOTE: If the Optima printer is already paired with tester, you will not need to perform the following.
PrimeTest 300
1. Turn the PrimeTest on and select Menu
Configuration Bluetooth Favorites
2. Highlight the Printer field and press Setup.
3. Switch the Optima Printer ON.
4. Press Search to scan for local Bluetooth
devices.
5. Select the printer in the New field (look for
device named “Emona [4-digit no]”).
6. Press Add New.
7. Change the Printer Type to “Protag Optima”
8. Press OK to accept the new printer setting then
press OK again to save the new Bluetooth
configuration.
PrimeTest ELITE
1. From the Home screen, press the Menu
key icon .
2. Select number 3) Bluetooth icon
3. Switch on the Optima Printer you wish to
pair.
4. Press the Search icon to start search
5. Select the printer from the Printer field and
look for device named “Emona [4 digit
no]”
6. Use the arrow keys: right and left to select.
7. Press Save to save changes and return.
