Emerson Bettis XTE3000 Manual de usuario

Quick Start Guide

FCIM-20009-EN Rev. 0

March 2023

Bettis XTE Electric Actuator – RDM

Quick Start Guide

FCIM-20009-EN Rev. 0

Notes

March 2023

This page intentionally left blank

Quick Start Guide

FCIM-20009-EN Rev. 0

Table of Contents

March 2023

Table of Contents

Section 1: XTE3000 with Remote Display

Module (RDM) Overview

XTE3000 with Remote Display Module (RDM) Overview ................................................1

Section 2: XTE3000 – RDM Wiring Connection

XTE3000 – RDM Wiring Connection...............................................................................2

Section 3: XTE3000 – RDM Power Requirement

XTE3000 – RDM Power Requirement .............................................................................4

Section 4: XTE3000 – RDM Communication Cable Requirement

XTE3000 – RDM Communication Cable Requirement ....................................................5

Section 5: XTE3000 – RDM Parts List and Option Kits

XTE3000 – RDM Parts List and Option Kits .....................................................................6

Section 6: XTE3000 – RDM Operation Method

XTE3000 – RDM Operation Method ...............................................................................7

Section 7: XTE3000 – RDM Functional Table

XTE3000 – RDM Functional Table.................................................................................10

Quick Start Guide

FCIM-20009-EN Rev. 0

Notes

March 2023

This page intentionally left blank

Quick Start Guide

FCIM-20009-EN Rev. 0

March 2023

Section 1: XTE3000 with Remote Display Module (RDM) Overview

XTE3000 with Remote Display Module (RDM) Overview

Section 1: XTE3000 with Remote Display

Module (RDM) Overview

RDM module allows actuator to be remote controls, local control and monitors the status

of actuator through RS485 communication up to 4000 ft (1200) distance from XTE3000

electrical actuator.

Figure 1

A1 A2 A3 A4 A5 A6

RDM+ RDM- Shield

24 V DC

110 to 220 V AC

50/60 Hz

Quick Start Guide

FCIM-20009-EN Rev. 0

March 2023

Section 2: XTE3000 – RDM Wiring Connection

XTE3000 – RDM Wiring Connection

Section 2: XTE3000 – RDM Wiring Connection

Bettis electrical actuator XTE3000 with RDM card VAXTE-494MOD3400 provides one channel

of MODBUS at A1, A2, A3 terminal and one channel of RDM port at A4, A5, A6. The wiring

connection between XTE3000 to RDM module shows in Figure 2 and RDM module has 2

options to be powered.

Figure 2

Quick Start Guide

FCIM-20009-EN Rev. 0

March 2023

Section 2: XTE3000 – RDM Wiring Connection

XTE3000 – RDM Wiring Connection

a) RDM power by external single phase 110 V to 220 V AC, 50/60 Hz

• AC Line connect to pin1 on P2 connector

• AC Neutral connect to pin2 on P2 connector

• Connect RS485(+) from A4 to pin 3 (RDM+)

• Connect RS485(-) from A5 to pin 5 (RDM-)

• Connect Shield from STC24 to pin 4 (RDM)

b) RDM power by external 24 V DC

• 24 V DC(+) connects to pin10 on P2 connector

• 24 V DC(-) Ground connects to pin2 on P2 connector

• Connect RS485(+) from A4 to pin 3 (RDM+)

• Connect RS485(-) from A5 to pin 5 (RDM-)

• Connect Shield from STC24 to pin 4 (RDM)

Quick Start Guide

FCIM-20009-EN Rev. 0

March 2023

Section 3: XTE3000 – RDM Power Requirement

XTE3000 – RDM Power Requirement

Section 3: XTE3000 – RDM Power Requirement

RDM can be power by external power 24 V DC (+/-10%) or single phase 110 V to 220 V AC

(+/-10%) 50/60 Hz and the nominal power consumption of RDM is 10 Watts and maximum is

14 Watts.

Quick Start Guide

FCIM-20009-EN Rev. 0

March 2023

Section 4: XTE3000 – RDM Communication Cable Requirement

XTE3000 – RDM Communication Cable Requirement

Section 4: XTE3000 – RDM Communication

Cable Requirement

With the best performance, A4, A5, A6 communication cable requires using Belden 9841

(or equivalent) for RS485 communication.

Quick Start Guide

FCIM-20009-EN Rev. 0

March 2023

Section 5: XTE3000 – RDM Parts List and Option Kits

XTE3000 – RDM Parts List and Option Kits

Section 5: XTE3000 – RDM Parts List and

Option Kits

XTE3000 with RDM is option item from Standard XTE3000 unit.

Option: XTE RDM upgrade kits is also available, “480KAMOD45” for XTE 10/20/30 size,

“480KAMOD46” for XTE 40/50 size.
