Emerson Bettis Electro-Hydraulic Operated Manual de usuario

Dimension

Double-Acting Actuator













 



























OUTLINE DIMENSION AND DETAILS

Actuator ABCDE

Approximate

Weight

INCH MM INCH MM INCH MM INCH MM INCH MM Lbs KG

G01001.5 39.8 1010.9 27.7 703.6 28.3 718.8 57.9 1470.7 2.4 61.0 513 233

G2002.0 40.6 1031.2 28.7 729.0 29.0 736.6 58.3 1480.8 2.9 73.7 546 248

G3004.0 46.8 1188.7 30.1 764.5 32.5 825.5 61.5 1562.1 3.5 88.9 626 284

G4003.0 52.0 1320.8 34.5 876.3 31.9 810.3 66.8 1696.7 4.3 109.2 770 349

G4004.0 53.0 1346.2 35.5 901.7 32.9 835.7 67.8 1722.1 5.3 134.6 783 355

G5004.0 58.3 1480.8 37.4 950.0 34.8 883.9 73.2 1859.3 5.5 139.7 1141 518

G5005.0 59.3 1506.2 38.4 975.4 35.8 909.3 74.2 1884.7 6.5 165.1 1300 590

G7005.0 64.3 1633.2 40.4 1026.2 39.7 1008.4 81.6 2072.6 6.8 172.7 1786 810

G7008.0 65.3 1658.6 41.4 1051.6 40.7 1033.8 82.6 2098.0 7.8 198.1 1829 830

G8008.0 76.5 1943.1 427.0 1085.8 39.5 1003.3 87.5 2222.5 8.0 203.2 2461 1116

G10008.0 93.6 2377.4 46.9 1191.3 43.6 1107.4 99.4 2524.8 10.5 266.7 3754 1703

Product Data Sheet EHO

March 2015

EHO.01.05.EN, Page 2 of 2, Rev. 0

Installation, Operation and Maintenance Manual

VCIOM-13254-EN Rev. 3

February 2021

Bettis™EHO (Electro-Hydraulic Operated)

Double-Acting Actuator

Installation, Operation and Maintenance Manual

VCIOM-13254-EN Rev. 3

Notes

February 2021

This page intentionally left blank

Installation, Operation and Maintenance Manual

VCIOM-13254-EN Rev. 3

Table of Contents

February 2021

Table of Contents

Section 1: Introduction

1.1 Scope............................................................................................................ 1

1.2 General Information...................................................................................... 1

1.3 Safety Information ........................................................................................ 2

1.4 Abbreviation Denitions ............................................................................... 3

Section 2: Installation

2.1 Preparation ................................................................................................... 4

2.2 Valve Preparation.......................................................................................... 5

2.3 Actuator Preparation..................................................................................... 5

2.4 Lifting the EHO Actuator ............................................................................... 6

2.5 Installing the EHO Actuator on the Valve..................................................... 11

2.6 Setting the Stroke Limit Stops ..................................................................... 12

2.7 Hydraulic Fluid ............................................................................................ 12

2.8 Accumulator (Optional) .............................................................................. 13

Section 3: Electrical Connections

3.1 Remove Separate Terminal Chamber (STC) Cover ........................................ 18

3.2 Sealing Cable/Conduit Entries ..................................................................... 19

3.3 Recommended Terminal Connections......................................................... 19

3.4 Separate Terminal Chamber (STC) Connections........................................... 20

3.5 Replace Terminal Chamber Cover ................................................................ 20

3.6 External Earth/Ground Connections............................................................ 20

3.7 Discrete Controlled Inputs Connection........................................................ 21

Section 4: Set-up/Start-up Procedure

4.1 Preparation ................................................................................................. 22

4.2 Initial Check of the Unit ............................................................................... 23

4.3 Initial Connections ...................................................................................... 23

4.4 Handpump.................................................................................................. 24

4.5 Hydraulic Test ............................................................................................. 28

4.6 Check Rotation ........................................................................................... 28

4.7 Limit Switch Adjustment ............................................................................. 29

4.8 Function Test .............................................................................................. 32

4.9 Other Options............................................................................................. 34

Installation, Operation and Maintenance Manual

VCIOM-13254-EN Rev. 3

Table of Contents

February 2021

Table of Contents

Section 5: Operation

5.1 Hydraulic Power System.............................................................................. 35

5.2 Reservoir..................................................................................................... 35

5.3 Main Components....................................................................................... 35

5.4 Functional Description ................................................................................ 39

Section 6: Pushbutton Module (PBM)

6.1 Selector Knob and Control Pushbuttons...................................................... 42

Section 7: Troubleshooting

Troubleshooting ................................................................................................... 43

Section 8: Hazardous Area Classication and SIL Certication

Hazardous Area Classication and SIL Certication................................................ 44

Section 9: Weights and Dimensions

9.1 EHO Standard Double-Acting...................................................................... 45

Installation, Operation and Maintenance Manual

VCIOM-13254-EN Rev. 3

February 2021

Section 1: Introduction

Introduction

Section 1: Introduction

1.1 Scope

This manual is offered as a guide to be used along with locally approved and safe practices

to install, operate, service and maintain the Bettis EHO Actuator. Carefully follow the

instructions in this manual and make sure you install the actuator correctly and according

to your requirements.

1.2 General Information

1.2.1 Overview

The Bettis EHO is a self-contained, quarter-turn, valve actuator that combines proven

technologies from Emerson’s Actuation Technologies. The actuator has been designed for

critical shutdown applications where reliability is crucial. The EHO utilizes a dependable

double-acting actuator for the Fail-safe stroke combined with an integral hydraulic power

pack and electronic control module.

The EHO accepts a wide range of single-phase, three-phase or DC power sources, also solar

panels are available for areas without electrical power. A hydraulic handpump can be used

to stroke the actuator during commissioning or in the event of an emergency power loss.

Electronic modules are contained within an explosion proof, IP68 enclosure and all

electronic components are isolated from the customer connection terminals.

The EHO provides a compact design with actuator and control components that have been

eld proven for decades in critical service applications.

1.2.2 Product Attribute

• Easy installation – Bettis™ EHO actuator is a totally self-contained system and

designed for compactness and adaptable to new or existing valves.

• Bettis™ G-Series hydraulic double-acting or spring-return fail-safe actuator

• Shafer™ hydraulic control technology

• EIM™ electronics and communication technology

• Multiple input power options with either AC or DC

• Local lockable Remote/Local/Ofine switch

• Local open/close/stop switch

• Partial stroke test

• Fast speed of operation to Fail-safe position if required

• Emergency shutdown – independent safety circuits and solenoid valve

• Dual sealed Separate Terminal Chamber, allows installation wiring to be performed

or fuses to be replaced without exposing control components to hostile

environmental conditions.

Installation, Operation and Maintenance Manual

VCIOM-13254-EN Rev. 3

February 2021

Section 1: Introduction

Introduction

• Control enclosure is made of low-copper aluminum alloy, powder-coated, salt

resistant also rated for IP68 ingress protection.

• Hydraulic handpump manual override

• Accumulators (optional)

• Solar power (optional)

• Operating pressures up to 3000 psi with standard components

• Easy control over actuator stroking speeds – The stroking speed is controlled

through adjustable hydraulic ow control valves. This enables eld personnel to

easily adjust actuator stroking speed to comply with eld requirements.

1.3 Safety Information

Safety notices in this manual detail precautions the user must take to reduce the risk of

personal injury and damage to the equipment. The user must read these instructions in

their entirety. Failure to observe these safety notices could result in serious bodily injury,

damage to the equipment, void of the warranty. Take special notice of all tags, warning

labels and instructions presented on the actuator. These may provide more specic and

signicant information regarding the actuator than this general manual.

It is the responsibility of the user to ensure proper safety practices are utilized. Always

take necessary precautions and use proper protective equipment when dealing with

compressed gasses, compressed hydraulic uid, pinch points and electricity.

Safety notices are presented in this manual in three forms (Warning, Caution and Note)

as follows:

! WARNING

Alerts user of potential danger; failure to follow the warning notice could result in serious

personal injury or death.

! CAUTION

Identies precautions the user must take to avoid personal injury or equipment damage.

NOTE:

Highlights information critical to the user’s understanding of the Bettis EHO valve actuator

installation or operation.

Installation, Operation and Maintenance Manual

VCIOM-13254-EN Rev. 3

February 2021

Section 1: Introduction

Introduction

1.4 Abbreviation Denitions

Abbreviations used in this manual and their denitions are listed in the table below:

Table 1. Abbreviation Denitions

Abbreviation Denition

IOM Installation Operation Manual

SCH Self-Contained Hydraulic

ESD Emergency Shutdown

FS Fail-safe

SR Spring-Return

DA Double-Acting

MAWP Maximum Allowable Working Pressure

MOP Maximum Operating Pressure

STC Separate Terminal Chamber

PBM Pushbutton Module

LDM Local Display Module

RDM Remote Display Module

CBM Circuit Breaker Module

PCB Printed Circuit Board

LS Limit Switch

PS Pressure Switch

NC Normally Closed

NO Normally Open

CCW Counterclockwise

CW Clockwise

OL Overload

PPE Personal Protective Equipment

GA General Arrangement Drawing

Installation, Operation and Maintenance Manual

VCIOM-13254-EN Rev. 3

February 2021

Section 2: Installation

Installation

Section 2: Installation

2.1 Preparation

2.1.1 Delayed Usage

If for any reason the actuator is not to be installed immediately, Bettis recommends the

following procedures. Failure to comply, with recommended procedures, could lead to

actuator malfunction and possibly void the warranty. For storage procedures exceeding

one year, consult Bettis for further recommendations.

As shipped from the factory, the Bettis EHO actuator is an inherently weatherproof unit,

providing that all compartment covers and cable entry plugs remain intact. The actuator

should be immediately stored in a clean, dry warehouse, free from vibration and rapid

temperature changes, until it can be installed and energized.

If the actuator must be stored outside, store it off of the ground at an elevation sufcient

to prevent it from being immersed in water or buried in snow. Check for any unpainted

or exposed metal surfaces and make sure they are protected with a coating of grease to

prevent any corrosion. Cover the actuator to prevent damage from site debris.

2.1.2 Tools and Materials Required

To complete these procedures, you will need the following documentation for the

Bettis EHO Actuator and items indicated in the table below:

• General Arrangement Drawing

• Bill of Material

• Hydraulic System Schematic

• System Wiring Diagram

Table 2. Tools and Material Requirements

Tools and Material Requirements

Primary Power Source for the EHO (check the EHO System Electrical Diagram for requirements)

Supplemental quantity of hydraulic uid, if needed

(See 2.7, Hydraulic Fluid and EHO specication, for required uid type)

Nitrogen Source (if an Accumulator is supplied with the EHO)

Hand Tools: complete complement of open end (SAE and metric) wrenches, screw drivers Philips

and at blade and a set of hex wrenches

Chains and lifting straps that are inspected and certied for the weight of the EHO

Actuator (check shipping weights)

Sealant for all cable and conduit entries (approvable by the National Electric Code or your country

standard and applicable local codes)

Installation, Operation and Maintenance Manual

VCIOM-13254-EN Rev. 3

February 2021

Section 2: Installation

Installation

2.2 Valve Preparation

2.2.1 Remove Valve Gearing if so equipped.

2.2.2 If valve is equipped with stops, remove valve stem extension housing. Examine

the valve stops to ensure no foreign material is present that would restrict normal

travel of the valve. Some valves are equipped with inspection ports in the valve

housing for ease in examining the stops.

2.2.3 Check alignment of stem key slot to the position of the valve. Normally with the

valve in the open position, the key slot is in line with the run of the pipeline. With

the valve in the closed position, the key slot should be 90° to the run of the valve.

2.2.4 The EHO Actuator may be mounted to the valve at any time regardless of whether

or not the valve is under pressure.

2.3 Actuator Preparation

2.3.1 Once the EHO Actuator is uncrated and cleaned for installation, check to ensure

there will be no interference with piping or other structure when the actuator is

properly mounted to the valve.

NOTE:

At this point, check to see that when the actuator is mounted to the valve and in its nal

orientation, the outboard end of the power cylinder positioned below the Hydraulic

Reservoir Breather. If this is not possible, contact Bettis for further instructions on piping to

elevate the breather. See Vertical Mounted Actuator 2.4.4.

2.3.2 Check that all mounting materials such as fasteners, adapters, brackets etc. are on

hand and ready for use.

2.3.3 Check the actuator and valve to see that they are in the same relative position,

that is either open or closed. If the actuator has to be moved, use the handpump

provided. For handpump operation, remove the plug in the reservoir and install

the breather (refer to 4.4 Handpump Operation).

Installation, Operation and Maintenance Manual

VCIOM-13254-EN Rev. 3

February 2021

Section 2: Installation

Installation

2.4 Lifting the EHO Actuator

NOTE:

All Bettis EHO G-Series Considerations

When handling any EHO G-Series, be aware of tubing, accessories, handpump,

accumulators, Pushbutton module and control enclosures. Straps and chains can become

entangled and cause damage to these components. Never use chains on the spring

cartridge as it may warp and cause the actuator not to function correctly or may cause

personal injury.

NOTE:

Do not use hydraulic tubing and electrical cable for lifting.

! CAUTION

Be sure to use appropriately rated crane/hoist and straps/chains to raise and lower

the actuator.

2.4.1 G01X – G2 and All E-Series Actuators

2.4.1.1 Horizontal Pipeline Vertical Stem

The small G-Series and all E-Series actuators mounting on a horizontal

pipeline with a vertical valve stem should be supported under the

“C” bracket and a two-point attachment for balance. A strap may be

attached to the stabilization tab on the spring module to balance the unit

while lifting. The weight of the actuator must be supported at the

“C” bracket, not the stabilization tab. See Figure 1.

Figure 1 G01 – G2 and all E-Series Actuators with Horizontal Pipeline

! CAUTION

Never lift the actuator with a valve attached. Always handle actuator/valve assemblies by

attaching lifting equipment to the valve only.

Tabla de contenidos

Otros manuales de Controladores de Emerson

Emerson

Emerson Fisher SR5 Manual de usuario

Emerson

Emerson Fisher FIELDVUE DVC6005 Series Guía de configuración

Emerson

Emerson Fisher FIELDVUE DVC5000 Guía de configuración

Emerson

Emerson PACSystems RSTi-EP EPSCPE100 Manual de usuario

Emerson

Emerson Yarway Manual de usuario

Emerson

Emerson El-O-Matic ELQ Series Manual de instrucciones

Emerson

Emerson Fisher FIELDVUE DVC6000 Manual de usuario

Emerson

Emerson IC695PNC001-BFBE1 2 Manual de usuario

Emerson

Emerson Branson 2000X Manual de usuario

Emerson

Emerson Bettis RTS Manual de usuario

Emerson

Emerson Tartarini OS/66 Manual de usuario

Emerson

Emerson Fisher 1190 Manual de usuario

Emerson

Emerson Dixell XR10C Instrucciones de funcionamiento

Emerson

Emerson Dixell XM660K Diagrama de cableado

Emerson

Emerson Asco Sentronic LP 617 Series Manual de usuario

Emerson

Emerson Y696 Manual de usuario

Emerson

Emerson Unidrive M700 Manual de usuario

Emerson

Emerson Dixell XR20T Diagrama de cableado

Emerson

Emerson Dixell XR30CX-4S1C1 Diagrama de cableado

Emerson

Emerson Powerdrive F300 Manual de usuario

Emerson

Emerson Fisher Type B NG Manual de usuario

Emerson

Emerson CASH VALVE A-32 Manual de usuario

Emerson

Emerson Bettis D Series Manual de instrucciones

Emerson

Emerson F-Series Manual de usuario

Manuales populares de Controladores de otras marcas

Digiplex

Digiplex DGP-848 Instrucciones de funcionamiento

YASKAWA

YASKAWA SGM series Manual de usuario

Sinope

Sinope Calypso RM3500ZB Manual de usuario

Isimet

Isimet DLA Series Style 2 Manual de instalación

LSIS

LSIS sv-ip5a Manual de usuario

Rockwell Automation

Rockwell Automation 1769-L31 Manual de usuario

Airflow

Airflow Uno hab Manual de usuario

ABB

ABB ACS580-01 drives Manual de usuario

Panasonic

Panasonic GM1 Series Manual de usuario

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manual de usuario

Panasonic

Panasonic FP? Positioning Unit RTEX Manual de usuario

Samson

Samson Type 5824 Manual de servicio

Alpha IP

Alpha IP MIOB 21001 Manual de usuario

Siemens

Siemens OpenAir GMA 1 Series Manual de usuario

Surecom

Surecom SR-629 Manual de usuario

Fishman

Fishman TriplePlay Manual de usuario

Regulus

Regulus SRS1 T Manual de usuario

3M MicroTouch EX113 Manual de usuario
