PERSONAL COMPACT DISC PLAYER

with 45 SECOND ANTI-SKIP MEMORY

CD-R and CD-RW COMPATIBLE

HD2700

OWNER’S MANUAL

Visit our web site at www.emersonradio.com

HD2700_ib.p65 21/11/2001, 15:5316

Thank you.........

For purchasing this Emerson Personal CD Player. It has a 24 track programmable

memory so you can listen to the songs on your favorite CD's in any order you

choose. Or you can use the Random playback feature and let the player select the

playback order for you. Use the 3-way Repeat feature to repeat a single track, the

entire disc, or a programmed sequence of tracks, indefinitely. We've also included

a 45 Second Electronic Anti-Skip Memory which makes this player virtually skip-

free under normal circumstances.

There's a Dynamic Bass Boost Control that increases and enhances the bass

response, and a set of lightweight stereo headphones that are so comfortable you

may forget you have them on. And finally, this player not only plays all professionally

recorded commercial CD's, but it plays recordable CD's (CD-R music discs) and

rewriteableCD's(CD-RWmusic discs) as well.So ifyou oryour friendsare "burning"

your own CD's on your computer CD-R drives, or on home audio type CD recorders,

you can be sure that they are playable on the CD Cruiser personal CD player from

Emerson.

Please read this instruction manual completely and carefully to make sure you

understand the proper operation of this product, and get the maximum enjoyment

out of all the features of this state-of-the-art CD player.

Once again, thanks for purchasing this Emerson product.

The serial number of your CD player can be found on the bottom cabinet. We

suggest that you record the serial number of your unit in the space below for future

reference.

Model Number: HD2700

Serial Number:

HD2700_ib.p65 21/11/2001, 15:461

WARNING: TO PREVENT FIRE OR SHOCK HAZARD,

DONOT EXPOSE THIS UNIT TO RAINOR MOISTURE.

This device complies with part 15 of the FCC rules. Operation is subject to the

condition that this device does not cause harmful interference.

CLASS 1 LASER PRODUCT

APPAREIL Á LASERDE CLASSE 1

PRODUCTO LASER DE CLASE 1

CAUTION

INVISIBLE LASER RADIATION

WHEN OPEN AND INTERLOCKS

DEFEATED.

AVOID EXPOSURE TO BEAM

This product contains a low power Laser Device.

• Places exposed to direct sunlight or close

to heat radiating appliances such as electric

heaters.

Avoid installing the unit in locations described below:

• Dusty places.

• Places subject to constant vibration.

• Humid or moist places.

CAUTION

THIS LASER COMPACT DISC PLAYER FUNCTIONS BY HELP OF INVISIBLE

LASER LIGHT AND IS EQUIPPED WITH SAFETY SWITCHES TO AVOID

EXPOSURE WHEN DOOR IS OPEN AND SAFETY INTERLOCKS ARE

DEFEATED. IT IS DANGEROUS TO DEFEAT OR BYPASS SAFETY

SWITCHES.

DANGEROUS VOLTAGE

Uninsulated Dangerous Voltage, that may be of sufficient

magnitude to constitute a risk of electric shock to persons is present

within this product's enclosure.

ATTENTION

The Owner's Manual contains important operating and

maintenance instructions.

For your safety, it is necessary to refer to the manual.

IMPORTANT NOTES

HD2700_ib.p65 21/11/2001, 15:462

1. CD Door.

2. LCD Display – Shows track number, playing time, Anti-Skip memory status,

Program, Repeat, Random, and Intro modes.

3. SKIP REV. Button – To skip tracks or search backward.

4. SKIP FWD. Button – To skip tracks or search forward.

5. PLAY/PAUSE Button – To begin playback, and to pause during playback.

6. MODE Button – Selects the playback mode: Repeat 1/All, Random, or Intro.

7. PROG (Program) Button – To program tracks in the CDmemory.

8. STOP Button – To stop playback, and to turn the power ‘Off’.

9. DC Input Jack – Connect an optional AC adapter, (not included), to this jack

to use 120V 60 Hz house current.

10. Battery Compartment (on bottom cabinet).

11. OPEN Switch – Slide to the right to unlock and open the CD door.

12. DBBS (Bass Boost) ON/OFF Switch - Switch On to increase bass response.

13. VOLUME Control – Raises or lowers the volume.

14. PHONES (Headphone) Jack – Connect stereo headphones, included, to this

jack.

15. LINE OUT Jack –To connect this CDplayer to an external amplifier or recording

device. Connection cable not included.

LOCATION OF CONTROLS

HD2700_ib.p65 21/11/2001, 15:463

1. PROG (Program) Indicator –Appears when programming tracks or playing

programmed tracks.

2. Repeat 1/ALL Indicators–Appears whenthe Repeatplayback mode isselected.

3. CD-RW Indicator –Appears when CD-RW disc is loaded.

4. Battery Level Indicator –Blinks when batteries need to be replaced.

5. ANTI-S (Anti-Skip) Memory Indicator –Bar display indicates the remaining

Anti-Skip memory capacity.

6. Time Display –Shows elapsed time of the track being played and total playing

time of the disc.

7. Track Number Display –Shows the track which is being played, and the total

tracks on the disc.

8. INTRO Indicator –Appears when Intro playback mode is selected.

9. RAND (Random) Indicator –Appears when Random playback mode is selected.

LCD DISPLAY INDICATORS

145

PROG

RAND

INTRO

NTI - S

HD2700_ib.p65 21/11/2001, 15:464

POWER SOURCE

This CD player can be operated on either 120V 60Hz AC house current with the

AC adapter (not included), or on 3V DC (2 "AA" batteries, not included).

AC OPERATION

Connect an optionalAC adapter (not included) to your 120V 60HzAC outlet. Then

connect the small plug to the "DC IN4.5V" jack on the side of the player as shown

in the following illustration.

If you decide to purchase an AC adapter for this unit, it must have the following

specifications:

Input: 120V/ 60Hz AC.

Output: 4.5V DC 500mA.

The adapter must have a female-type plug with a positive center:

•Be sure the adapter is UL listed. If you use a “Universal”-type adapter, be sure

to set the output selector to “DC 4.5V”.

•If theAC adapter will not be used for an extended period of time, remove it from

the wall outlet by pulling on the adapter housing.Do not remove the adapter by

pulling on the cord. Do not touch the AC adapter with wet hands.

AC 120V 60Hz

Outlet

AC / DC Adapter

(Optional)

DC 4.5V

Input Jack

Positive (+) Negative (–)

HD2700_ib.p65 21/11/2001, 15:465

BATTERY OPERATION

1. Open the battery compartment door on the bottom

cabinet by sliding it in the direction of the arrow and

then lifting it open. To prevent loss, the door cannot

be removed from the unit.

2. Insert 2 "AA" batteries (not included) into the

compartment. Use alkaline batteries for longest life.

Follow the polarity markings inside the compartment.

If the batteries are inserted incorrectly the unit will not

work.

NOTE:

In order to operate the player on batteries, the optional AC adapter must be

disconnected from the DC IN jack.

BATTERY REPLACEMENT

When the batteries become too weak the battery level indicator begins to flash

and operation may become erratic. When this occurs replace the batteries

immediately.

BATTERY PRECAUTIONS

Follow these precautions when using batteries in this device:

1. Use only the size and type of batteries specified.

2. Be sure to follow the correct polarity when installing the batteries as indicated in

the battery compartment. Reversed batteries may cause damage to the device.

3. Do not mix different types of batteries together (e.g.Alkaline and Carbon-Zinc) or

old batteries with fresh ones.

4. If the device is not to be used for a long period of time, remove the batteries to

prevent damage or injury from possible battery leakage.

5. Do not try to recharge batteries not intended to be recharged; they can overheat

and rupture (Follow battery manufacturer’s directions.)

HD2700_ib.p65 21/11/2001, 15:466

OPERATING INSTRUCTIONS

NORMAL PLAYBACK

NOTE: This player can play all normal CD's plus CD-Rs (CD Recordables) and

CD-RWs (CD Re-Writeables)

1. Connect the headphones to the PHONES jack.

Set the VOLUME control to a low level before you

begin playback and then adjust the volume to a

comfortable level after playback begins.

2. Slide the CD Door OPEN switch to the right to

release the lock and open the CD Door.

3. Place your disc on the center spindle with the

printedlabelsidefacingup. Pressdowngentlynear

the center hole to make sure the disc is properly

seated on the spindle.

4. Close the door completely until it locks shut.

5. Press the PLAY/PAUSE button. “45 sec”

followed by “00”appear in the display as the player

reads the disc. The total tracks and playing time

will appear momentarily and then playback begins

on Track 1. TheAnti-Skip indicator comes on and

the playing time shows in the display.

6. Adjust the VOLUME and DBBS (Bass Boost)

controls as desired.

7. When all tracks have been played the player stops

and the display again shows the total tracks and

playing time on the disc. After approximately 30

seconds the power shuts off and the display goes

blank.

To stop playback before the disc ends press the

STOP button at any time. Press the STOP

button again to shut the power off immediately.

To PHONES Jack

OL.

HD2700_ib.p65 21/11/2001, 15:467

8. Slide the CD Door OPEN switch to the right to open the door and remove your

disc. Close the CD Door and return your disc to its protective storage case.

PAUSE CONTROL

Press the PLAY/PAUSE button during playback

to pause momentarily. The sound stops, the track

and the time display flashes but the disc continues to

spin. Press the PLAY/PAUSE button again to

cancel pause and resume playback. The sound

returns and the display stops flashing.

SKIP/SEARCH CONTROLS

To skip forward or backward to another track during

playback press the SKIP FWD or SKIP REV

buttons repeatedly until the desired track number

appears in the display. Playback will begin on the

desired rack.

To search forward or backward within a track to locate a specific musical passage

press and hold either the SKIP FWD or SKIP REV buttons. The player

moves forward or backward at high speed. When you reach the desired point in the

track, release the buttons and normal playback resumes.

REPEAT PLAYBACK

To repeat a single track:

1. Press PLAY/PAUSE button to begin playback.

2. WhenplaybackbeginspressSKIP FWD orSKIP

REV button to select the desired track.

3. Press the MODE button once until the Repeat 1

“ ” indicator appears in the display. The

selected track will be repeated indefinitely.

To repeat the entire disc:

1. Press PLAY/PAUSE button to begin playback.

2. WhenplaybackbeginspresstheMODE button twice

until the Repeat All “ ” indicator appears

in the display. The entire disc will be repeated

indefinitely.

HD2700_ib.p65 21/11/2001, 15:468

To cancel repeat playback:

1. Press the STOP button, or;

2. Press the MODE button until no special mode indicators appear in the display.

INTRO SCAN

This feature plays only the first 10 seconds of each track on the disc.

1. Press PLAY/PAUSE button to begin playback.

2. Whenplayback begins pressthe MODEbutton 3times.

The “INTRO”indicator will begin flashing in the display.

3. Press the STOP button to stop the disc and then press the PLAY/PAUSE

button again. The “INTRO”indicator stops flashing and remains ‘On’. The player

returns to the beginning of track 1 and plays just the first 10 seconds of each

track on the disc. When the first 10 seconds of each track has been played, the

player stops.

To cancel Intro Scan press the STOP button or press the MODE button until

none of the special playback mode indicators appear in the display.

RANDOM PLAYBACK

Use Random playback to play all the tracks on a disc in a random order selected

by the CD player.

1. Press PLAY/PAUSE button to begin playback.

2. When playback begins press the MODE button 4 times

until the “RAND”indicator flashes in the display.

3. Press the STOP button to stop the disc and then press the PLAY/PAUSE

button again. The “RAND”indicator stop flashing and remains on. The player

randomly selects the first track for playback and continues randomly selecting

tracks until every track on the disc has been played once. After all tracks have

been played the player stops.

To cancel Random playback, press the STOP button, or press the MODE

button until no special mode indicators remain in the display.

INTRO

RAND

HD2700_ib.p65 21/11/2001, 15:469

Tabla de contenidos

Otros manuales de Reproductor de CD de Emerson

Emerson

Emerson PD9814 Manual de usuario

Emerson

Emerson SpongeBob Squarepants SB280 Manual de usuario

Emerson

Emerson HD8100 Manual de usuario

Emerson

Emerson CKD9902 Manual de usuario

Emerson

Emerson SR5999 Manual de usuario

Emerson

Emerson PD6559BK Manual de usuario

Emerson

Emerson HD8000 Manual de usuario

Emerson

Emerson PD9127 Manual de usuario

Emerson

Emerson PD6850 Manual de usuario

Emerson

Emerson PD6871 Manual de usuario

Emerson

Emerson HD7999 Manual de usuario

Emerson

Emerson HD8118 Manual de usuario

Emerson

Emerson HD7295 Manual de usuario

Emerson

Emerson SpongeBob SquarePants SB260 Manual de usuario

Emerson

Emerson PD5098 Manual de usuario

Emerson

Emerson PD6517 Manual de usuario

Emerson

Emerson Nick Jr. Dora the Explorer DTE515 Manual de usuario

Emerson

Emerson SpongeBob Squarepants SB250 Manual de usuario

Emerson

Emerson PD3811BL Manual de usuario

Emerson

Emerson SpongeBob Squarepants SB220 Manual de usuario

Emerson

Emerson HD7096A Manual de usuario

Emerson

Emerson HD8116 Manual de usuario

Emerson

Emerson PD6513 Manual de usuario

Emerson

Emerson HD7100 Manual de usuario

Manuales populares de Reproductor de CD de otras marcas

RCA

RCA RP-7923 Manual de usuario

Pioneer

Pioneer DEH-P3550MP XM Manual de usuario

Philips

Philips AZ1207 Manual de usuario

Philips

Philips CD582 Manual de usuario

Philips

Philips AZ 6821 Manual de usuario

Lasonic

Lasonic MSU-2020 Manual de usuario

THOMSON

THOMSON RCD150 Manual de usuario

Denon

Denon DCD-1420 Manual de usuario

Panasonic

Panasonic SJ-MR100 Manual de usuario

Onkyo

Onkyo DX-7210 Manual de usuario

Sony

Sony MZ-R3 Manual de usuario

Denon

Denon DVM-4800 Manual de usuario

JBL

JBL MR-32 Manual de usuario

RCA

RCA RCD152 Manual de usuario

Technics

Technics SL-PS770A Manual de usuario

Clarion

Clarion compact disc Manual de usuario

Sony

Sony MZ-M10 Manual de usuario

Philips

Philips Expanium AZ 1538 Manual de usuario
