elsner elektronik Sewi KNX L-Pr Guía
Item numbers 70396 (white), 70696 (jet black)
Sewi KNX L-Pr
Presence detector with
brightness sensor
EN
Installation and Adjustment
1 Contents
Elsner Elektronik GmbH • Sohlengrund 16 • 75395 Ostelsheim • Germany
Sensor Sewi KNX L-Pr • from application 1.1
Version 26.10.2021 • Errors excepted. Subject to technical changes.
1. Description ........................................................................................... 3
1.0.1. Scope of delivery .......................................................................................... 3
1.1. Technical data ........................................................................................................... 3
2. Safety and use instructions ................................................................. 4
3. Installation ........................................................................................... 5
3.1. Installation location and preparation ...................................................................... 5
3.1.1. Coverage area of the presence detector ..................................................... 5
3.2. Connection ................................................................................................................ 6
3.2.1. Layout of the circuit board ........................................................................... 6
3.2.2. Assembly ....................................................................................................... 7
4. Commissioning .................................................................................... 8
4.1. Addressing the equipment ...................................................................................... 8
5. Maintenance ......................................................................................... 8
6. Disposal ............................................................................................... 8
7. Transfer protocol ............................................................................... 10
7.1. List of all communication objects ......................................................................... 10
8. Parameter setting .............................................................................. 19
8.1. Behaviour on power failure/ restoration of power .............................................. 19
8.2. General settings ..................................................................................................... 20
8.3. Motion detector ...................................................................................................... 20
8.3.1. Master 1/2/3/4 .............................................................................................. 21
8.3.2. Align communication between master and slave .................................... 25
8.4. Light control ............................................................................................................ 26
8.5. Brightness Measurement ...................................................................................... 28
8.6. Brightness threshold values .................................................................................. 29
8.6.1. Threshold value 1/2/3/4 .............................................................................. 29
8.7. Night ........................................................................................................................ 31
8.8. Computer ................................................................................................................ 32
8.8.1. Computer 1-8 ............................................................................................... 32
8.9. Logic ........................................................................................................................ 36
8.9.1. AND logic 1-8 and OR logic outputs 1-8 ................................................... 36
8.9.2. AND logic connection inputs ..................................................................... 38
8.9.3. Connection inputs of the OR logic ............................................................. 40
2 Clarification of signs
This manual is amended periodically and will be brought into line with new software
releases. The change status (software version and date) can be found in the contents footer.
If you have a device with a later software version, please check
www.elsner-elektronik.de in the menu area "Service" to find out whether a more up-to-
date version of the manual is available.
Clarification of signs used in this manual
Safety advice.
Safety advice for working on electrical connections, components,
etc.
DANGER! ... indicates an immediately hazardous situation which will lead to
death or severe injuries if it is not avoided.
WARNING! ... indicates a potentially hazardous situation which may lead to
death or severe injuries if it is not avoided.
CAUTION! ... indicates a potentially hazardous situation which may lead to
trivial or minor injuries if it is not avoided.
ATTENTION! ... indicates a situation which may lead to damage to property if it is
not avoided.
ETS In the ETS tables, the parameter default settings are marked by
underlining.
3 Description
Sensor Sewi KNX L-Pr • Version: 26.10.2021 • Technical Changes and Errors excepted.
1. Description
The Sensor Sewi KNX L-Pr for the KNX building bus system captures brightness and
the presence of persons in rooms. The brightness value measured can be used for the
control of limit-dependent switching outputs. States can be linked via AND logic gates
and OR logic gates. Multi-function modules change input data as required by means of
calculations, querying a condition, or converting the data point type.
Functions:
•Brightness measurement with brightness control
• Presence of persons is detected
•Threshold values can be adjusted per parameter or via communication
objects
•8 AND and 8 OR logic gates, each with 4 inputs. All switching events as well
as 16 logic inputs in the form of communications objects can be used as inputs
for the logic gates. The output of each gate can be configured optionally as 1-
bit or 2 x 8-bit
•8 multi-function modules (computers) for changing the input data by
calculations, by querying a condition or by converting the data point type
Configuration is made using the KNX software ETS. The product file can be down-
loaded from the Elsner Elektronik website on www.elsner-elektronik.de in the “Ser-
vice” menu.
1.0.1. Scope of delivery
• Combined sensor
1.1. Technical data
General:
Housing Plastic
Colours • White similar to signal white RAL 9003
(skirting)/ grey white RAL 9002 (cover)
• Jet black RAL 9005
Assembly Surface, ceiling installation
Dimensions Ø x height approx. 105 mm x approx. 32 mm
Degree of protection IP 30
Weight approx. 50 g
Ambient temperature -20…+60°C
Ambient humidity 5...95% RH, non-condensing
Storage temperature -20…+70°C
KNX bus:
KNX medium TP1-256
Configuration mode S-Mode
Group addresses max. 2000
4 Safety and use instructions
Sensor Sewi KNX L-Pr • Version: 26.10.2021 • Technical Changes and Errors excepted.
The product conforms with the provisions of EU directives.
2. Safety and use instructions
Installation, testing, operational start-up and troubleshooting should
only be performed by an authorised electrician.
CAUTION!
Live voltage!
There are unprotected live components inside the device.
• Inspect the device for damage before installation. Only put undamaged
devices into operation.
• Comply with the locally applicable directives, regulations and provisions for
electrical installation.
• Immediately take the device or system out of service and secure it against
unintentional switch-on if risk-free operation is no longer guaranteed.
Assignments max. 2000
Communication objects 230
Nominal voltage KNX 30 V SELV
Power consumption KNX max. 10 mA
Connection KNX plug terminals
Duration after bus voltage
restoration until data is
received
approx. 5 seconds
Sensors:
Brightness sensor:
Measurement range 0 lux … 2,000 lux (higher values can be measured and out-
put)
Resolution 1 lux at 0…2,000 lux
Presence sensor:
Detection method Passive infrared method (PIR)
Coverage angle approx. 94° × 82° (see also Coverage area of the presence
detector)
Range approx. 5 m
5 Installation
Sensor Sewi KNX L-Pr • Version: 26.10.2021 • Technical Changes and Errors excepted.
Use the device exclusively for building automation and observe the operating instruc-
tions. Improper use, modifications to the device or failure to observe the operating in-
structions will invalidate any warranty or guarantee claims.
Operate the device only as a fixed-site installation, i.e. only in assembled condition and
after conclusion of all installation and operational start-up tasks, and only in the sur-
roundings designated for it.
Elsner Elektronik is not liable for any changes in norms and standards which may occur
after publication of these operating instructions.
3. Installation
3.1. Installation location and preparation
Install and use only in dry interior rooms! Avoid condensation.
The Sensor Sewi KNX L-Pr is installed surface mounted on ceilings.
To detect the presence of persons make sure that the desired area is covered by
the sensor's coverage angle and that no obstacles obstruct the recording.
3.1.1. Coverage area of the presence detector
Distance D Length L Width W
2.50 m approx. 5.40 m approx. 4.30 m
3.50 m approx. 7.50 m approx. 6.10 m
Angle of coverage:
approx. 94° × 82°
Range: approx. 5 m
Fig. 1
D
W
L
6 Installation
Sensor Sewi KNX L-Pr • Version: 26.10.2021 • Technical Changes and Errors excepted.
3.2. Connection
For installation and wiring at the KNX connection, the
provisions and standards applicable to SELV circuits must be
complied with!
The Sensor Sewi KNX L-Pr is surface-mounted but at the same time can also be
screwed to a flush-mounted socket.
If the Sensor Sewi KNX L-Pr is installed on a flush-mounted socket, it must not con-
tain any wiring with 230 V.
3.2.1. Layout of the circuit board
1 a+b Long holes for mounting (hole distance 60 mm)
2 Brightness sensor
3 Presence sensor
4 Programming button
5 Programming LED
6KNX-terminalBUS+/-
7 Cable bushing
A Mark for aligning the cover
1a
A
1b
4
6
7
5
2
3
Fig. 2
7 Installation
Sensor Sewi KNX L-Pr • Version: 26.10.2021 • Technical Changes and Errors excepted.
3.2.2. Assembly
1
Fig. 3 Housing from the outside
1 Brightness sensor
2 Presence sensor
A Recess to open the housing
A
2
Fig. 4
Open the housing. To do this, carefully lift the
cover from the skirting. Start at the recess,
e.g. with a flat-head screwdriver.
Fig. 5
Lead the bus cable through the cable bushing
in the skirting.
Fig. 6
Screw the skirting to the ceiling.
Hole distance 60 mm.
60 mm
8 Commissioning
Sensor Sewi KNX L-Pr • Version: 26.10.2021 • Technical Changes and Errors excepted.
4. Commissioning
Brightness sensor, presence sensor and ventilation slots on the side must not be dirty,
painted over or covered.
After the bus voltage has been applied, the unit will enter an initialisation phase lasting
5 seconds. During this period, no information can be received or transmitted via the
bus.
The presence sensor has a start-up phase of approx. 15 seconds, during which the
presence of persons is not detected.
4.1. Addressing the equipment
The individual address is assigned via the ETS. For this purpose there is a button with
a control LED on the unit (Fig. 2, No. 4+5).
The equipment is delivered with the bus address 15.15.255. Another address can be
programmed using the ETS.
5. Maintenance
As a rule, it is sufficient to wipe the device with a soft, dry cloth twice a year.
6. Disposal
After use, the device must be disposed of in accordance with the legal regulations. Do
not dispose of it with the household waste!
Fig. 7
Connect the KNX bus to the KNX terminal.
Fig. 8
Close the housing by positioning the cover
and snapping it into place. To do this, align
the recess on the cover to the marking on the
skirting (the presence sensor must protrude
through the opening in the cover).
