Elo TouchSystems Entuitive ET1566L-7SWA-1 Manual de usuario

Elo Entuitive Touchmonitor

User Guide

15"LCD Panel Mount Touchmonitor

1566L Series

Revision B

P/N 008531

Elo TouchSystems, Inc.

1-800-ELOTOUCH

www.elotouch.com

No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system,

or translated into any language or computer language, in any form or by any means, including, but not

limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written

permission of Elo TouchSystems.

Disclaimer

The information in this document is subject to change without notice. Elo TouchSystems makes no

representations or warranties with respect to the contents hereof, and specifically disclaims any

implied warranties of merchantability or fitness for a particular purpose. Elo TouchSystems reserves

the right to revise this publication and to make changes from time to time in the content hereof

without obligation of Elo TouchSystems to notify any person of such revisions or changes.

Trademark Acknowledgments

IntelliTouch, SecureTouch, AccuTouch, Entuitive, and MonitorMouse are trademarks of Elo

TouchSystems, Inc.

Other product names mentioned herein may be trademarks or registered trademarks of their

respective companies. Elo TouchSystems claims no interest in trademarks other than its own.

iii

Chapter 1

Introduction 1

Precautions . . . . . . . . . . . . . . . . . . . . 1

About the Product . . . . . . . . . . . . . . . . . 1

Chapter 2

Installation and Setup 3

Unpacking Your Panel Mount

Touchmonitor . . . . . . . . . . . . . . . . . . 4

Product Overview . . . . . . . . . . . . . . . . . 5

Main Unit . . . . . . . . . . . . . . . . . . . . 5

Rear View . . . . . . . . . . . . . . . . . . . 5

Bottom View . . . . . . . . . . . . . . . . . . 6

Remote OSD with Cable Attachment . . . . . 6

Mounting Your Touchmonitor . . . . . . . . . . . 7

Connecting Your Touchmonitor . . . . . . . . . . 8

Optimizing the LCD Display . . . . . . . . . . . 11

Installing the Driver Software . . . . . . . . . . 12

Installing the Serial Touch Driver. . . . . . . 13

Installing the Serial Touch Driver for Windows

2000, Me, 95/98 and NT 4.0 . . . . . . . 13

Installing the Serial Touch Driver for MS-DOS

and Windows 3.1 . . . . . . . . . . . . . 14

Chapter 3

Operation 15

About Touchmonitor Adjustments . . . . . . . . 15

Connecting the OSD Module . . . . . . . . . . 16

OSD Module Controls. . . . . . . . . . . . . . 17

Using the OSD Menus. . . . . . . . . . . . . . 18

Auto Adjustment. . . . . . . . . . . . . . . . . 18

First OSD Menu . . . . . . . . . . . . . . . . . 19

Contrast . . . . . . . . . . . . . . . . . . . 19

Horizontal Position . . . . . . . . . . . . . . 20

Vertical Position . . . . . . . . . . . . . . . 20

Horizontal Size . . . . . . . . . . . . . . . . 20

Tracking . . . . . . . . . . . . . . . . . . . 21

Second OSD Menu . . . . . . . . . . . . . . . 21

Display Mode. . . . . . . . . . . . . . . . . 22

OSD Off-Time . . . . . . . . . . . . . . . . 22

Language . . . . . . . . . . . . . . . . . . 22

Text-Graphic . . . . . . . . . . . . . . . . . 22

Reset . . . . . . . . . . . . . . . . . . . . . 22

Chapter 4

Troubleshooting 23

Solutions to Common Problems . . . . . . . . 23

Appendix A

Native Resolution 25

Appendix B

Touchmonitor Safety 27

Care and Handling of Your Touchmonitor. . . . 28

Appendix C

Technical Specifications 29

Compatibility Modes . . . . . . . . . . . . . . 29

Touchmonitor Specifications . . . . . . . . . . 30

15" LCD Touchmonitor (ET1566L)

Specifications . . . . . . . . . . . . . . . 30

AccuTouch Touchscreen Specifications . . . 31

CarrollTouch Specifications . . . . . . . . . 32

15" LCD Panel Mount Touchmonitor

(ET1566L-XSWA-X) Dimensions . . . . . 34

Panel Cutout. . . . . . . . . . . . . . . . . 36

Regulatory Information 37

Warranty 41

Index 43

Table of Contents

1-1

CHAPTER

HAPTER

NTRODUCTION

Congratulations on your purchase of an Elo TouchSystems Entuitive LCD panel

mount touchmonitor. Your new high-resolution industrial touchmonitor

combines the reliable performance of Elo’s touch technology with the latest

advances in LCD display design. This combination of features creates a natural

flow of information between you and your touchmonitor.

Precautions

Follow all warnings, precautions and maintenance as recommended in this

user’s manual to maximize the life of your unit. See Appendix B for more

information on touchmonitor safety.

About the Product

Your LCD panel mount Touchmonitor is a 15" XGA TFT color display with the

following features:

• Direct analog RGB input

• 15.1" diagonal screen size

• 16.7 million displayable colors

• 1024 x 768 resolution

• XGA / SVGA / VGA / VESA / Mac compatible

• 24-60kHz horizontal scan

• 56-85Hz high refresh rate

1-2 Elo Entuitive Touchmonitor User Guide

• Auto adjustment capability

• High quality full screen re-scaling

• Multilingual OSD menus in four languages: English, German, Spanish, and

Japanese

• Corded remote OSD controller

• VESA DDC 1/2B data communication

• VESA DPMS power saving

• VESA flat panel monitor physical mounting interface (75mm)

• 19 inch computer hardware rack adaptor available. Contact the factory.

• Worldwide agency approvals that include UL*, CUL*, TÜV- Bauart, FCC,

CE, C-Tick, VCCI

•Certified by UL to NEMA 4, 4x and 12: ET1566L-7SWA-1*

•Designed to meet NEMA 4, 4x & 12: ET1566L-9SWA-1/5*

*ITE recognized component

For full Product Specifications refer to Appendix C.

2-3

CHAPTER

HAPTER

NSTALLATION

AND

ETUP

This chapter discusses how to install your LCD panel mount touchmonitor and

how to install Elo TouchSystems driver software.
