ELNA 8200 Manual de usuario
1
Model 8200
Changing External Parts (1) Face Cover
Replacing th face cover
To remove:
1Remove the Screw .
2 Lift the habdle up and remove the Screw .
3Remove the top cover.
To attach:
2. Follow the above procedure in reverse.
Replacing th top cover
Top Cover
Handle
To remove:
1. Remove the Cap and Screw and remove
the Face Cover .
Cap
Screw
Face cover
To attach:
2. Follow the above procedure in reverse.
AB
C
A
B
C
A
B
C
BC
B
C
2
Model 8200
Changing External Parts (2) Belt Cover
Replacing the belt cover
To remove:
1. Remove the Cap and Screw .
2.Raise the Carrying Handle and remove the Screw .
3. Lay the machine on its back and remove Screws
(2 pcs.gold color), then remove the Belt cover .
Cap
Screw
Screw
Screw
Belt cover
To attach:
4. Attach the Belt Cover with Screws - .
5. Attach the Cap .
Handle
ABCD
E
E
D
C
B
A
B D
A
B
A
E
C
D
D
3
Model 8200
Changing External Parts (3) Base Cover
Replacing the base cover
To remove:
1. Remove Screws (4 pieces) to remove the base
cover .
Screws
Base cover
To attach:
2. Follow the above procedure in reverse.
A
B
A
B
A
B
A
AA
4
Model 8200
Changing External Parts (4) Bed Cover / Base Lid (2)
Replacing the bed cover
To remove:
1. Remove the base cover.(See page 3)
2. Remove Screw (2 pcs.), and remove the Base
Lid .
3. Remove Screw (2 pcs.), and remove the Bed
cover .
Screw
Base lid
Screw
Bed cover
To attach:
4. Follow the above procedure in reverse.
Replacing base Lid (2)
To remove:
1. Remove Screws (4 pieces), and remove the
Lid (2) .
Screw
Base lid (2)
To attach:
2. Follow the above procedure in reverse.
A
BC
D
C
B
A
A
B
B
A
A
B
C
A
A
AB
DD
5
Model 8200
Changing External Parts (5) Base Unit
Base
To remove:
1. Remove the Belt cover. (See page 2)
2. Remove Setscrew (4 pcs.), and remove
the base unit .
3. Remove the X-Motor Connector andY-Motor
Connector from the printed circuit board “A”.
Joint bosses
Y-motor connector (White)
X-motor connector (Blue)
To attach:
4. Attach the X,Y-Motor Connectors , into
the printed circuit board “A”.
5. Insert the X,Y-Motor Cords between the printed
cuircuit board “A” and Arm. Be sure the cords
are not caught between the Joint Bosses of
the arm and base.Tighten Screws (4 pieces)
temporarily.
Joint boss
6. Attach the Extension (Accessory) table .
Extension table (Accessory)
7. Tighten Screws while aligning the extension
table, base unit and free Arm.
Note: Attach the embroidery hoop with the template
on the carriage. Check the needle drop posi
tion against the template.
8. Attach the belt cover.
A
9
8
B
8
9
A
A
8
9
B
89
B
A
B
C
C
A
C
A
6
Model 8200
To remove:
1. Remove the face cover, belt cover, base cover and
top cover. (See pages 1-2).
2. Remove Screw and remove the Arm thread
guide (lower) .
3. Remove Screw .
4. Loosen Screws , 3 turns.
5. Disconnect the each connector and remove the front
cover.
Note: Disengage the Hooks to remove the Front
cover.
Screw
Arm thread guide (Lower)
Screw
Screw
Screw
Hooks (2 spots)
To attach:
6. Follow the above procedure in reverse.
Note: See pages 19 (Diagram) for Connectors
Connection.
Changing External Parts (6) Front Cover
Front cover
A
BC
A
B
C
D E
D
E
H
H
E
B
A
C
D
F
7
Model 8200
Changing External Parts (7) Rear Cover
1. Remove the face cover and belt cover.
2. Loosen Screw , , , , and remove the
rear cover.
To attach:
3. Follow the above procedure in reverse.
Rear cover
Rear cover
Carriage
To remove:
Handwheel
A B C D
A
B
C
D
8
Model 8200
Adjusting Needle Drop Position
1. Lower the needle to its lowest position by turning the
handwheel.
2. Remove the face cover and loosen Screw ,
move the Needle bar supporter to the right or
left until the needle comes to the center of the
Needle plate hole .
3. Tighten the Screw .
4. Attach the face cover.
Screw
Needle bar supporter
Needle
Nedle plate hole
Tthe needle should be positioned at the center of the needle plate hole.
A
B
C
D
A
B
C
D
A
B
A
C
D
9
Model 8200
Adjusting HookTiming
The hook timing is that amount of ascending travel of the needle bar from its lowest
position to where the tip of the rotary hook meets the left side of the needle should be 3.1
to 3.7 mm.
1. Remove the belt cover, bed cover, base cover, base
lid (1) and base lid (2).
2. Remove the presser foot, Needle plate and
Bobbin holder .
3. Lower the needle bar at its lowest position by
turning the handwheel toward you.
4. Raise the needle bar 3.4 mm up from the lowest
position.
5. Loosen the Screws of lower shaft gear, turn the
Lower shaft gear until the tip of rotary hook
meets with the left side of the Needle .
Tighten screw (2 pieces) of the lower shaft
gear.
6. Attach the Bobbin holder, Needle plate, presser foot
and Needle.
7. Attach the base lid (2), base lid (1) base cover, bed
cover and belt cover.
3.1 - 3.7 mm
A
B
A
B
D
D
C
C
C
D
D
E
E
C
Needle
