Elmo Visual Presenter HV-110u Manual de usuario

Printed in Japan(A)6/2007

Small Body

Great Impressions

Visual Presenter

HV-110u

All dimensions in inches (mm)

2 1/4" (57)

7 1/4" (184.5)

13 3/8" (338)

7 1/4" (184.5)

9 5/8" (243)

1 3/4" (43)

12 1/8"(307)

1/4" (7.5)

16 1/4" (411.4）

13 3/8" (338)

11 1/2" (290）

Profile

HV-110uSpecifications

Image pick-up device

Effective pixels

Frame rate

Resolution RGB output

Lens

Shooting area

Focus

Brightness control

White balance

Text mode

Digital zoom

Media Menu

Image save

Sync. system

Flickerless mode

Internal selection

Analog RGB output

RGB input

USB port

SD card slot

Illumination lamp

Accessories

Dimensions Setup

(W x D x H)

Weight

Power consumption

Power source

Camera

Optics

Functions

Interfaces

Lighting

Others

1/3" progressive scan CCD, 850,000 pixels

1024 (H) x 768 (V)

20 frames/sec.

600(H) x 600(V) TV lines

F4.0, f=3mm

Max. 15 7/8" x 11 7/8" (401 x 300mm)

Min. 8 3/4" x 6 1/2"(221 x 165mm)

FOCUSFREE

Auto (level control provided) / Manual (powered)

Full-Auto/Fixed

Provided

Provided (8x)

Provided

Provided (onto SD card )

Internal

Provided

Int./RGB

XGA (1024x768 @60Hz)

Provided

16 1/4"x13 3/8"x12 1/8" (411.4 x 338 x 307mm)

2 1/4"x13 3/8"x7 1/4" (57 x 338 x 184.5mm)

4.2lbs (1.9Kgs)

DC12V (AC adapter)

Model HV-110u

Setup

Folded

AC adapter, RGB cable, Instruction manual, AC cord,

anti-glare sheet (A5 size), holding band, USB cable,

Image Mate, TWAIN DS driver, Accessory case, Warranty card

USB2.0 connection to PC supports instant drawing to

highlight and annotate image

Annotation tools let you draw lines

( freehand or straight ) in a variety

of colors to highlight and enhance

screen images, right from your PC.

Split screen gives you a platform

for comparing live video to

stored image - side by side for

greater visual impact.

Image Mate for

Presentaion

USB2.0 PC Interface

for Comprehensible and Creative meeting and classwork

Presenter+Projector+PC

Presentations with 3 Ps persuade and impress.Change

smoothly from presenter to PC.

Multi

application

Real time presentation! Enjoy presentation!

You can store images directly to the SD card.

Note : Only image files saved to the HV-110u's

SD card or coverted using the supplied

conversion software are viewable through the

HV-110u.

SD Memory Card-ready

New Compact Design

RGB Switcher

Function

White LED

equipped

Brightness

control

FOCUSFREE 8x Digital Zoom USB2.0 SD card slot

Application

Software

Flickerless

Mode

Media Menu Text Mode

850K pixels

Progressive Scan CCD

Moving Picture

Output

20 frames/sec

Easy means fun!

Anytime,Anywhere

Worry-Free Meetings and Conferences

Weight 4.2lbs,

Only A4 size

when folded

Analog RGB input and output

terminals allow instant change

to PC screen with only one

touch of the button.

Clear!

LED provides uniform lighting

Speedy!

& Simple!

Compact

Easy!

Presenter

PC Projector

Built-in 850,000 pixels

progressive scan CCD camera

Two times mechanical zoom function,

Plus up to four times

digital zoom function

Set up in only three steps

The HV-110u is focus free

Visual Presenter

HV-110u
