Elmicro VacuScope easy Manual de usuario
VacuScope easy
Milking Machine Test Device
Users Manual Version V1.1 April 2022
VacuScope easy Version V1.1
1
CONTENTS
1. Notes on the instruction manual …….…………………….……..……..
2. Safety instructions.…………..…………………………………………………….
3. Description….………………..……………….………………………………………..
3.1 Introduction..……………………………………………….…………………………..
3.2 Technical Data…………………………………………………………………………
4. First start…….…..………………………..……………………………………………..
4.1 Preparation……………………………….……………………………………………..
4.2 Switch device on….…………….……………………………………………………
5. Operating elements…..……….……………………………………………………
5.1 Key board….....……………………………………….……………………….……….
5.2 Screen…………………………………………………..…………………………….……
5.3 Interfaces…….…………..…………………………………………….………..………
6. Programmes………….………………………………………….…………………….
6.1 Operation………………..……………………………..…………………..………......
6.2 Main menu..………….………………………………………………………………….
6.3 Settings and Service…………………...………..………………………..………
6.4 Programme Pulsation……………………………………………..……………..
6.4.1 Menu Pulsation………………………………………………………………………..
6.4.2 Measurement of Pulsation…………………………..………………………….
6.4.3 Data memory of Programme Pulsation…………………………….……
6.5 Programme Fluctuation..…………….……….………….……………………..
6.5.1 Menu Fluctuation..…………………………………………………………………..
6.5.2 Measurement of Fluctuation………………………………………….……….
6.4.3 Data memory of Programme Fluctuation…..……………….…………
6.5 Programme Sensors.……………………………………………………………….
2
2
3
3
3
5
5
6
7
8
9
9
10
10
11
12
13
13
14
15
17
17
18
19
20
VacuScope easy Version V1.1
2
1. NOTES ON THE INSTRUCTIONS MANUAL
2. SAFETY INSTRUCTIONS
In the interest of proper functionality and your own safety, please
familiarize yourself with the contents of this operating manual before
use. It contains important information that will enable you to use the
device properly.
The manufacturer reserves the right to make technical changes in the
interest of further development.
These instructions are part of the scope of delivery.
For your personal safety and to protect your warranty claims, please
read the operating manual and follow the safety instructions before
starting up the equipment.
Only persons who have been instructed in the intended use of the
VacuScope easy and who are familiar with the operating instructions
are authorized to commission the device. Knowledge of the accident
prevention regulations and the generally recognized safety rules is
required to perform measurements.
The manufacturer is not liable for damage caused by improper use or
unauthorized tampering, especially with the electronic assemblies.
VacuScope easy Version V1.1
3
3. DESCRIPTION
3.1 INTRODUCTION
VacuScope easy is a handy device for checking pulsators and measuring the vacuum
curve in milking systems with outstanding product features:
•Visualization of the vacuum courses by a graphic display during testing
•Clear operation with fixed and adjustable keys
•Several interface connections for devices and sensors
•Large memory for storing measurement data and settings
Based on a wide range of programmes the device is used in development,
maintenance and servicing of milking units.
3.2 TECHNICAL DATA
Graphic display
LCD-Modul with 128 x 128 Pixel and
und LED-backlight
Number of keys
10
Measuring range
Vacuum 0…60 kPa
Measuring accuracy
0,6 kPa; 0,3 kPa (typ.)
Measuring solution
0,1 kPa
Overload vac. sensors
max. 200 kPa
Interfaces
RS 232 for printer, computer and air flow meter
0-5V-interface for external temperature sensor and
pressure sensor
Data memory
200 series in programme Pulsation
200 series in programme Fluctuation
Power supply
4 x AA, NiCd, NiMH
Protection
IP 65
Operating temperature
+5 bis +40 °C
Storage temperature
-20 bis +60 °C
Dimensioning
195 x 100 x 50 mm
Weight
420 g (w.o. batteries)
Tests
EN 61000-6-3, EN 61000-6-1
VacuScope easy Version V1.1
4
External Sensors (optional)
Measuring range
Measuring accuracy
Measuring solution
Vacuum sensor/
Pressure sensor
0…-50,0 kPa
0… 20,0 kPa
<0,6 kPa, <0,3 (typ)
<0,6 kPa, <0,3 (typ)
0,1 kPa
0,1 kPa
Temp. sensor
-20,0….140,0 °C
1,5%
0,1 K
AFM 600l
50-600 l/min
at 50 kPa
50…100l/min 5l/min
100…600l/min 5%
1 l/min
AFM 3000l
100-3000l/min
at 50 kPa
5%
1 l/min
VacuScope easy Version V1.1
5
4. FIRST START
4.1 PREPARATION
The battery compartment is on the back of the device. The instrument operates with
4 1,5V- batteries (AA) or 4 accumulators (NiMH, NiCd).
Attention !
Check the polarity when inserting the batteries.
Incorrect polarity can destroy the electronics of the unit.
Attention !
VacuScope easy is designed for the measuring of
atmospheric pressure. Avoid measuring of other media.
This could falsify the measurement results or destroy the
electronics. Clean and dry hoses are required to ensure
proper functioning of the pressure sensors.
Attention !
Before commissioning, all hose connections must be
checked for leaks.
VacuScope easy Version V1.1
6
4.2 SWITCH DEVICE ON
The VacuScope easy is started by pressing the button.
While starting the instrument, the measuring systems zero calibration is checked.
This defines the predominant air-pressure as zero level of the device.
Achtung !
Measuring failures may appear when the device is started
under pressure, vacuum or pulsation
VacuScope easy Version V1.1
7
5. OPERATING ELEMENTS
Measuring channel 1 –CH1
Measuring channel 2 –CH2
LCD-Display 128 x 128
Key board
Interface RS 232
Belt holder
Sensor interface –CH3
VacuScope easy Version V1.1
8
5.1 KEY BOARD
The keys of the key board have the following meaning:
The function keys have the following meaning:
Switch on the device
Turn on / turn off the backlight of the display
Moving in the menu up, setting parameters
Moving in the menu down, setting parameters
ESC
Close programme, cancel action
OK
Start programme, confirm of action
Function key, function is displayed on screen
System setting (language, user, calibration values)
Delete Data
Print out Data
PC
Transfer Data to computer
Display measured data
Save settings or measurement results
12
Ruler, graphic tool
Next readings (data sheet)
Back to the first readings (first data sheet)
VacuScope easy Version V1.1
9
5.2 SCREEN
The instrument VacuScope easy has a backlit screen with a resolution of 128 x 128
pixels.
In the upper area of the menu windows, the current programme and the battery
charge status are displayed.
In the middle area are the menu items with the setting options for the respective
programmes.
The available functions are assigned to the function keys and displayed in the lower
part of the menu window.
5.3 INTERFACES
The VacuScope easy measuring device has a sensor interface (0-5V) for connecting a
temperature sensor or an external vacuum/pressure sensor.
The RS232 interface is used both to connect the air flow meter and to connect the
instrument to the computer.
The sensors, the air flow meter and the PC software are not included in the scope
of delivery of the meter and must be ordered separately.
Attention!
To ensure proper functioning of the external devices and
sensors, screw them tightly together with the meter.
