Operational Manual
ECP-9000
Table of Contents
1. Introduction .......................................................................1
2. Package Contents .............................................................1
3. Classifications ...................................................................2
4. Designated Symbols ..........................................................3
5. Safety Instructions .............................................................4
6. Configurations ...................................................................6
7. Installation.........................................................................9
8. Focusing .........................................................................10
9. Operating Instructions......................................................11
10. Charts Description .........................................................12
11. Maintenance ..................................................................16
12. Basic Trouble Shooting ..................................................17
13. Transportation ...............................................................17
14. Technical Specifications .................................................18
15. Service Information ........................................................19
-1-
1. Introduction
Thank you for your purchase of the ELI EZER ECP-9000 Auto Chart Projector. In the
area of subjective refraction, the ELI EZER ECP-9000 is best used for measuring
visual acuity. There are 40 different charts including red/green and polarized filters for
the eye optometry. It is fully recommended that you carefully read, understand and
follow the steps in this manual in order to ensure safe operation, optimum
performance and a longer service life from your new instrument. Please retain this
manual for future reference.
2. Package Contents
ECP-9000 and accessories were carefully checked and packed prior to the shipment.
However, please check condition and contents upon delivery. In addition to ELI EZER
ECP-9000, this shipment includes:
-2-
3. Classifications
[ Classification under the provision of 93/42/EEC(MDD)] ClassⅠ
ECP-9000 is classified into ClassⅠsystem.
[Protection method against electric shock] ClassⅠ
ECP-9000 is Classified into ClassⅠinstrument.
ClassⅠinstrument in which protection against electric shock does not rely
on basic insulation only, but which includes an additional safety precaution
with the provision of the connection of the instrument to the protective
earth conductor in fixed wiring of the installation in such a way that any
accessible conductive parts cannot become live in the event of a failure
of the basic insulation.
[Degree of protection against ingress of liquids] IPX0
ECP-9000 is the ordinary instrument (enclosed instrument without
protection against ingress of liquids). Be careful not to splash water
on the instrument.
[Degree of protection against flammability]
ECP-9000 is classified as an equipment not suitable to be used in a
Potentially flammable anesthetic mixture with air or with oxygen
or nitrous oxide.
Do not use near flammable materials.
[Mode of operation]
Continuous operation
-3-
4. Safety Symbols
Symbol
Description
This symbol indicates a protective earth
This symbol indicates that important operation, caution, warning and
maintenance Instructions are included in this User’s Guide.
This symbol on the main switch indicates that the power is OFF.
This symbol on the main switch indicates that the power is ON.
Instruction for user manual
Operating instructions
Manufacturer
Date of Manufacturer
Authorized Representative in the European community
This symbol indicates a fuse.
Do not throw away the waste to inappropriate place
For EU Countries
The following mark, the name & address of the EU Representative shows compliance
of the instrument with Directive 93/42/EEC.
EU Representative:
Ellegi Medical Optics s.r.l.
Via Pisciarelli, 79 – 80078
Pozzuoli (NA) ITALY
TEL:081.5499645 - 081.5498044
Partita I.V.A. 05354730631
-4-
5. General Safety Information
At Operation
- To avoid risk of electric shock, this equipment must only be
connected to a supply main with protective earth.
- Never disassemble or touch the inside of the instrument.
“No modification of this equipment is allowed”
“Do not modify this equipment without authorization of the
manufacturer”
“If this equipment is modified, appropriate inspection and testing
must be conducted to ensure continued safe use of equipment”
This may result in an electric shock or instrument malfunction.
-Never yank the power cord to disconnect from wall outlet but hold
the plug while disconnecting.
-This can weaken the metal core of the cord and may result in a
short circuit or an electric shock.
- Temperature : +10℃ ~ +40℃
- Humidity: 30% ~ 90% RH
- Atmospheric pressure range: 700 hPa ~ 1060 hPa
At Storage
- Do not store the instrument in a place where it may get wet or
where poisonous gas or liquid is stored.
- Avoid storing the instrument in an area with excessive heat,
humidity, or dust.
Recommended ranges:
- Temperature : -10℃ ~ +70℃
- Humidity: 10% ~ 95% RH
- Atmospheric pressure range: 500 hPa ~ 1060 hPa
At Installation
- Do not install the instrument near water.
If water gets into the internal structure, there is the possibility of
electrical Shock or instrument malfunction.
- Install the instrument in a stable and level place where vibration or
shock does not occur.
-5-
-The instrument may not perform observation correctly or may
malfunction. Also, if the instrument is tripped over because of any
accidental shock, it may result in possible injury.
After Use
- If the instrument is not be used for a long time, disconnect the
power cord from the wall outlet. Otherwise, it may cause a tire.
- Remove batteries from the battery case of the remote controller
when the remote controller will not be used for a long time.
At Disposal
- Follow local governing ordinances and recycling plans regarding
disposal or recycling of device components.
- Check the specified disposing method for the specific waste in
advance, especially when disposing the batteries used in the
remote controller.
- When disposing packing materials, sort them by the materials and
follow local governing ordinances and recycling plans.
-6-
6. Configurations
[Fig.1 Front View]
[Fig.2 Bottom View]
1. Projection lens / Focusing wheel
2. Receiving window
3. Table stand
4. Pilot Lamp
3
2
1
4
-7-
[Fig.3 Rear View]
5. Power On/Off Switch
6. AC Power Inlet
7. Fuse Holder
8. RS-232 Port
7
5
8
6
-8-
[Fig.4 Remote control View]
9. Inflated ray transmitter
10. Letters chart
11. Number chart
12. Snellen chart
13. Program
14. Lamp ON/OFF
15. Vertical, horizontal line, single Letter Masking
16. Children chart
17. Landolt chart
18. Function chart
19. Red/Green Test
20. Direction
16
9
10
11
12
17
13
14
15
19
18
20
