Electronics Line Prime Manual de instrucciones
Quick Start Installation Guide
For detailed information please refer to the full Prime
Installer Manual provided on our website: www.electronics-line.com
2
Table of Contents
1. Introduction................................................................................................ 3
2. System Installation.................................................................................... 3
3. System Programming................................................................................ 5
3.1. Keys Menu Navigation................................................................ 5
3.2. Enter Installer Programming mode ........................................ 5
3.3. Registering Wireless Devices .................................................. 5
3.3.1. Detectors ....................................................................................................6
3.3.2. Keyfobs ......................................................................................................9
3.3.3. Wireless keypads .....................................................................................10
3.4. Program Communication to Monitoring Station .............. 11
3.5. Set Up Follow Me Destination................................................ 12
3.6. Set Time & Date ......................................................................... 12
3.7. Set/Edit Users.............................................................................. 13
4. Testing the System.................................................................................. 15
3
1. Introduction
Thank you for choosing Prime wireless intruder control panel. This quick start guide manual
describes the main steps for installing and programming the Prime Control System using the
keypad on the main unit. To view the full version of the Installer manual, please refer our website
www.electronics-line.com
2. System Installation
. Open the main unit housing.
2. Place the rear main unit in position against the wall and mark the upper and lower
mounting holes.
Note: If required, mark the hole for the rear tamper. The hole is located behind the main
board.
3. Install wall anchors in the appropriate positions
4. Thread the power cable through the wiring hole on the back cover and connect the cable
to the AC power input on the main board ( 0).
Caution: Do not apply AC power at this stage.
5. Connect the telephone and telephone line (2) to their connectors on the Communication
module.
6. Optional: If required connect external modules to the main unit such as: home
automation module ( 5) , GSM communication module ( 4). If GSM module is required
connect insert a SIM card as required.
7. Optional: Some devices, such as wireless siren, WSM, and wireless terminal require the
plug-in transmitter (4). Mount the transmitter on the Control System's main board. For
more details refer to the full installer manual.
8. Connect the battery pack ( 3) to the connector ( 2) on the main board.
9. Enter the master user code number (default 234) to silence the alarm.
0. Mount the control system to a wall
11. Close the front cover and apply AC power.
Note:
To recognize the external modules you should perform a system scan to program the
modules that are connected to the system. A system scan is performed from the main
menu: [9] Programming > [7] Initialize > [5] Find Modules > √. The generated list displays
the modules recognized by the system then save. If a connected module is not included in
the list, check the wiring connections and run this scan again.
4
12345678
4
LOCK LOCK
LOCK LOCK
8
9
100mA
max.
Aux.
5
6
7
1011
NLNL
4
2
1
15
13
14
12
Figure 1: Prime layout
1. PSTN Dialer module
2. Telephone line
3. Main board
4. Plug-in TX
5. Au iliary power (AC operated 10-15V, Battery operated 6-8V)
6. Relay output (100mA ma )
7. Hardwired zone (Zone 33)
8. Hardwired LCD keypad terminal block
9. Front tamper switch
10. AC power terminal block
11. Home Automation terminal block
12. Battery connector
13. Back up battery pack
14. GSM communication module
15. Home Automation module
5
3. System Programming
3.1. Keys Menu Navigation
This manual explains how to program the Prime from the keypad located on the main unit. Table
1 describes the uses of the keypad keys during programming.
Enter / Save (to move to the displayed menu or to save the updated data .
Used to cancel the current selection or to return to the previous menu level.
/ To scroll up or down through the menu options
[1]-[0] 1. To enter numeric values when required.
2. For quick key programming. Press the key number to access a programming
option.
3. To edit descriptors.
Table 1: Keypad usage
3.2. Enter Installer Programming mode
1. Go to the default display press √.
2. Enter your installer code (the default installer code is '1111' .
3. Using the arrow keys, select [9] Programming.
3.3. Registering Wireless Devices
In order to enable the Prime to recognize a device, its transmitter must be registered.
It is recommended to register all devices to the control panel before installing. To install the
wireless devices/accessories temporarily fit them to the desired locations, and then perform a range
test. Testing may show that you should relocate the panel or some of its devices/accessories.
Note:
For wireless siren registration refer to the full installer manual.
6
3.3.1. Detectors
Prime supports 33 security zones. Only one detector can be registered to each zone. Zones 1-32 are
intended for wireless detectors by default. Zone 33 is an on-board hardwire zone (N ).
Step 1: Register a detector
1. Go to the main menu select [9]>[1]>[1] (Programming > Devices > Zones)
2. Using the arrow keys, select a specific zone and press '√ʹ. The system initiates
Registration mode.
3. Send two transmissions from the detector. A confirmation sound is heard after each
successful signal (chime sound). After two successful transmissions a confirmation beep
is heard.
Sending the transmissions can be done in several ways, as summarized in Table 2.
Device Device P/N Sending Transmissions
PIR Detectors
EL-2745/2745PI
EL-2600/EL-
2600PI/EL-2645/
EL-2645PI
Apply battery power. Place the ode ju per over
pins 2 and 3 (Radio Mode); the LED flashes.
OR
Depress the ta per switch twice, in rapid
succession.
Magnetic contact EL-2601 When you apply battery power, and the ta per
switch is open, the device enters test ode during
which a trans ission is sent every few seconds. You
can ter inate the test ode by closing the ta per
switch.
Flood Sensor EL-2661
Universal
Trans itter EL-2602
Glass break EL-2606
S oke Detector EL-2603
Press the test button. Make certain that the
trans ission LED is lit o entarily. Wait for five
seconds, then press the test button again.
Table 2: Transmission summary
4. After the detector is successfully registered the display shows: 'Save?'
Press '√ʹ to confirm and continue entering other parameters for the chosen device (see
section below) or press X to go back and enroll additional zones.
7
Step 2: Set detector's parameters
1. Go to the main menu select [9]>[1]>[1] (Programming > Devices > Zones)
2. Using the arrow keys select a speci ic zone and press '√ʹ.
3. Set the main parameters or each zone, according to Table 3.
Quick
Key
Option Name Description and Notes
9>1>1>2 Zone Type Type of alarm this zone generates
9>1>1>3 Arm Set Arming methods in which the zone is included
1 (F): The zone is included in Full arming
2 (P): The zone is included in Part arming
3 (PE): The zone is included in Perimeter arming
9>1>1>4 Descriptor Descriptors help identify the device when you operate and
program the system
9>1>1>5 Bell (Siren) Activate the siren when the zone is triggered
9>1>1>6 Chime Activate the internal siren when the zone is triggered Note: To
enable the chime option enable Global Chime option, [Quick key
7>12]
9>1>1>7 Force Arm Enables you to arm the system even if this zone is not ready For
the force arm feature to function, you must also enable force
arming in system options
Table 3: Parameter set
I required scroll thorough the other menu parameters and modi y settings
8
Step 3: Test the detectors
1. Go to the main display press '√ʹ.
2. Enter your installer code (default code '1111').
3. Enter [7]>[07]>[2] (Service > Transmitters > T Test) to initiate the T communication
test. This test enables you to identify transmitters and test their signal strength.
4. Activate the transmitter you wish to test; the transmitter’s details appear on the
Prime LCD and a sequence of tones is heard indicating the transmitter’s signal
strength (Table 4).
Signal Strength Tones Note:
If the signal strength is less than
6, move the transmitter to a
better location.
0-2 1 Tone
3-5 2 Tones
6-8 3 Tones
8-9 4 Tones
Table 4: Signal strength
In addition the display shows the detectors status using the abbreviations (as seen in
Table 5).
Table 5: Abbreviations
Item Description… Item Description…
K The transmitter is
functioning correctly
S The transmitter is not
synchronized
TA Tamper condition NA The transmitter is inactive
BT Battery low
9
3.3.2. Keyfobs
The Prime Control System supports up to 19 keyfobs.
Step 1: Register a keyfob
1. Go to the main menu, select [9]>[1]>[2] (Programming > Devices > Keyfobs)
2. Using the arro keys select a specific keyfob and press '√ʹ. The system initiates
Registration mode.
3. Press a button on the keyfob assuring the keyfob’s LED lights up hen the button is
pressed.
4. Press the same button again.
5. When 'Save?' appears on the Control System’s LCD display, press '√ʹ.
Step 2: Set the keyfob's parameters
1. Go to the main menu, select [9]>[1]>[2] (Programming, Devices, Keyfobs)
2. Using the arro keys select a specific keyfob and press '√ʹ.
3. Set the parameters for each keyfob according to the Table 6.
Quick
Key
Option Name Description and Notes
9>1>2>2 Type Controlled or non-controlled. A controlled keyfob causes the
system to send arm/disarm e ent messages to the central station.
Non-controlled keyfobs ne er send arm messages and send a
disarm message only if the system is disarmed after an alarm
occurrence
9>1>2>3 Descriptor Descriptors help identify the de ice when you operate and
program the system. Use the / key to insert a space
9>1>2>4 KF1 B1 Assign the HA unit you want the button to control. (01–16,
or 30 for PGM output) or enter 00 to program the button’s default
function – Part arming
9>1>2>5 KF1 B2
Assign the HA unit you want the button / to control.
(01–16, or 30 for PGM output) or enter 00 to program the button’s
default function – Perimeter arming
9>1>2>6 Delete Delete a keyfob
Table 6: Parameter setting
Step 3: Testing the keyfobs
1. Go to the main display press '√ʹ.
2. Enter your Installer code (default code '1111').
3. Enter [7]>[07]>[2] (Service > Transmitters > TX Test) to initiate TX communication Test.
Revie the explanation in Detectors section.
10
3.3.3. Wireless keypads
Step 1: Register a wireless keypad
The Prime supports up to four wireless keypads.
1. Go to the main menu, select [9]>[1]>[3] (Programming > Devices > eypads) .
2. Select the keypad to register and press '√ʹ. The system initiates Registration mode.
3. Press a button on the keypad assuring that a LED lights up when the button is pressed.
4. Press the same button again. When 'Save?' appears on the Control System’s LCD display,
press '√ʹ.
5. Set the keypad descriptor.
Note:
The above procedure refers to keypad EL2620 AND EL 2640. For registration keypads
EL2621, EL2724, refer to the full installer manual.
Step 2: Test a keypad
1. Go to the main display and press '√ʹ.
2. Enter your Installer code (default code '1111').
3. Enter [7]>[07]>[2] (Service > Transmitters > TX Test) to initiate the TX communication
test. Review the explanation in Detectors section.
Otros manuales para Prime
2
Tabla de contenidos
Otros manuales de Panel de control de Electronics Line
Electronics Line
Electronics Line Summit 3208GLD Manual del propietario
Electronics Line
Electronics Line Penta Manual de usuario
Electronics Line
Electronics Line Commpact Manual de instrucciones
Electronics Line
Electronics Line Prime Manual de instrucciones
Electronics Line
Electronics Line infiniti Manual de usuario
Electronics Line
Electronics Line Prime Manual de instrucciones
Electronics Line
Electronics Line Penta Manual de usuario
