Installation manual

Wascator FOM71 CLS

438 9200-41/EN

07.45

Contents

Technical data........................................................................................... 1:1

Installation................................................................................................. 2:1

Transportation and unpacking..............................................................2:1

Siting and floor ..................................................................................... 3:1

Mechanical installation ......................................................................... 4:1

Water connections ............................................................................... 5:1

Drain connection .................................................................................. 6:1

Sample cock......................................................................................... 6:1

Connection of external liquid supplies.................................................. 7:1

Electrical installation............................................................................. 8:1

Function checks, Clarus Control............................................................... 9:1

Assembling the ruler ...............................................................................10:1

Calibration of level control system .......................................................... 11:1

Calibration of the scale (weight function)................................................ 12:1

Connection of thermosensor................................................................... 13:1

The manufacturer reserves the right to make changes in design

and materials specifications.

Safety

This machine can only be used with water. Never use dry cleaning

agents.

Do not allow children to operate the machine.

Do not hose down or spray the machine with water.

All mechanical and electrical installation must be carried out by

qualified personnel.

Do not bypass the door locking device.

Should the machine malfunction, please report the fault to the

technician responsible for the machine.

1:1

438 9160-01/03

Wascator FOM71 CLS

520

5.4

350

195

Wascator FOM71 CLS

DN20

3/4"

200-600

50-1000

50/75

170

Water valves

connection

BSP

Rec. water pressure

kPa

Functioning limits

for water valve

kPa

Capacity

at 300 kPa

l/min

Drain valve

outer Ø mm

Draining capacity

l/min

Connections

Technical data

Innerdrum

volume litres

diameter mm

Heating

electricity kW

G-factor max

Weight, net kg

1:2

438 9160-01/02

Wascator FOM71 CLS

Function/subsystem

Ambient conditions

The machine shall be able to

function during the same ambient

conditions as normal washing

machines. However the functional

values with tolerances will only be

valid if following ambient condi-

tions are kept.

Voltage

Frequency

Water hardness

Inlet water Cold

Hot

Water pressure

Ambient temperature

Inner drum

Diameter

Depth

Volume

Lifting vanes: Number

Height

Radius

Base width

Perforation: Diameter

Depth of countersink

Total hole area

Material: Stainless steel

Outer drum

Diameter

Sump

Material: Stainless steel

Door opening

Opening diameter

Cabinet

Stainless steel

Nominal ±2%

(2.5±0.2) mmol/l

(15±2) oC

Max (60±2)oC

(240±50) kPa

(20±5) oC

(520±1) mm

(315±1) mm

61 l

53 mm

17 mm

65 mm

5 mm

2.5 mm

600 mm2

2333 (SS 18/8)

554 mm

~ (1300±25) ml

2333 (SS 18/8)

310 mm

2333 (SS 18/8)

Technical data

1:3

438 9160-01/02

Wascator FOM71 CLS

Drum speed

Washing speed: Programmable

Extraction: Programmable

Reversing rhythm

Programmable

Water level

Weight sensing

Repeatability

Stepsize

Dosing accuracy weight

control

Level sending:

Repeatability

Stepsize

Dosing accuracy level

control

Thermostat

Continuos variable in each

wash sequence

Selectable interval

Programming steps

Switch off temperature accuracy

in Interval 30-97 oC

Interval switch off temperature –

switch on temperature

(20 – 59±1) RPM

(200 – 1100±20) RPM

(0 – 250±0.1) = sec.

(Tolerance area

refers to timer

intervals)

±0.1kg/bath

≤0.05kg

≤0.2kg/bath

±5 mm

≤2 mm

≤0.8litre/bath

Yes

(4-97) oC

1 oC

±1 oC

≤4 oC

Technical data

1:4

438 9160-01/02

Wascator FOM71 CLS

Soap box

Number of compartments

Number of programmable liquid

detergents

Wash programs

Memory cards for

Approvals

The machine shall have same

approvals as normal washing

machines

Special equipment

Manual cook for sampling of bath

water on right side:

Connection for temperature

recording sensor in rear gable:

Possibility to connect lint trap:

Memory card with copy safe

programs for M&S and (IEC; ISO):

Procedure for calibration of the

machine according to ISO 9000 rules:

Possibility to take out test pieces from

wash bath during the wash:

Analog output from load cells to data

acquisition systems:

IEC 60456

ISO 6330

M&S

Yes

Technical data

1:5

438 9160-01/02

Pre- programmed wash programs

The Clarus Control in the Wascator FOM71 CLS contains 9 pre-

programmed ”wash programs”. They are not real wash programs but are

mainly designated for checking purposes. The stored programs are:

Place Name Content

Technical data

991 Start-up program If the machine has been idle more than

two hours, this program should be run

before any other program is run.

992 Level check Check with ruler insider

Program fills machine with water to a

reference level at 160 mm, maintains

this level 20 seconds and press PAUS

and it empties the machine. This

process is repeated five times. After

that, the program fills machine with

water to the following levels one after

the other: 100 mm, 130 mm, 160 mm

and 200 mm. Each level is maintained

40 seconds before emptying.

993 Weight check Program fills the machine with water to

18 kg, wait 30 seconds, rotates 60

seconds and fills to 26 kg (+8) and waits

30 seconds. Then drain.

994 Temperature check Program fills machine with water to

130 mm level and warms it in five steps:

25°C for 2 minutes, 40°C for 2 minutes,

60°C for 2 minutes, 80°C for 2 minutes

and 90°C for 2 minutes. The machine is

emptied, filled twice with cold water to a

high level 200 mm and finishes with a

two minute spin cycle 1000 rpm. The

buzzer sounds at the end of the

program.

995 Extraction 500 RPM 1 min.

996 Extraction 500 RPM 5 min.

997 Extraction 775 RPM 2 min.

998 Extraction 950 RPM 4 min.

999 Extraction 1100 RPM 5 min.

1:6

438 9160-01/02

ABC D E F G H I K L M N O PR

720 690 1315 200 750 555 720 1230 220 1010 135 825 45 100 240 135

Wascator

FOM71 CLS

5716

5717

5715

Technical data

1Electrical connection

2Cold water

3Hot water

4Drain

5Liquid detergent supply

6Control panel

7Soap box

8Door opening, ø 310

Rear side

Right side

Front
