Electrolux EWF12763E Manual de usuario
EWF12763E
User ManualWashing Machine
CONTENTS
CUSTOMER CARE AND SERVICE
2 www.electrolux.com
SAFETY INFORMATION
PRODUCT DESCRIPTION
CONTROL PANEL
BEFORE FIRST USE
DAILY USE
WASHING HINTS
INTERNATIONAL WASH CODE SYMBOLS
CARE AND CLEANING
TROUBLESHOOTING
................................................................................... 3
................................................................................ 6
............................................................................................ 7
...................................................................................... 12
..................................................................................................... 12
............................................................................................ 18
.................................................... 21
................................................................................... 22
..................................................................................... 25
1
2
3
4
5
6
7
8
9
TECHNICAL DATA ......................................................................................... 2810
INSTALLATION ............................................................................................... 2911
ENVIRONMENT CONCERNS ......................................................................... 3412
WARRANTY .................................................................................................... 3513
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.
Environmental information.
Subject to change without notice.
Warning / Caution-Safety information.
General information and tips.
SAFETY INFORMATION
3
In the interest of your safety and to ensure the correct use, before
installing and first using the appliance, read this user manual care-
fully, including its hints and warnings.
This appliance is intended to be used in household and similar
applications such as:
Farm houses
By clients in serviced apartments, holiday apartments and
residential type environments.
CONDITIONS OF USE
To avoid unnecessary mistakes and accidents, it is important to
ensure that all people using the appliance are thoroughly familiar
with its operation and safety features.
Save these instructions and make sure that they remain with the
appliance if it is moved or sold, so that everyone using it through its
life will be properly informed on appliance use and safety.
1.1 GENERAL SAFETY
Make sure that small pets do not climb into the drum. To avoid this,
please check into the drum before using the appliance.
Any objects such as coins, safety pins, nails, screws, stones or any other
hard, sharp material can cause extensive damage and must not be placed
into the machine.
Only use the advised quantities of fabric softener and detergent. Damage
to the fabric or appliance can occur if you overfill. Refer to the
manufacturer’s recommendations of quantities.
Wash small items such as socks, laces, washable belts etc in a washing
bag or pillow case as it is possible for such items to slip down between the
tub and the inner drum.
1.
It is dangerous to alter the specifications or attempt to modify this product
in anyway.
During high temperature wash program the door glass may get hot.
Do not touch it!
4
www.electrolux.com
Do not use your washing machine to wash articles with whalebones,
material without hems or torn material.
Always unplug the appliance and turn off the water supply after use, clean
and maintenance.
This appliance is heavy. Care should be taken when moving it.
When unpacking the appliance, check that it is not damaged. If in doubt,
do not use it and contact the Service Centre.
All packing and transit bolts must be removed before use. Serious damage
can occur to the product and to property if this is not adhered to. See
relevant section in the user manual.
After having installed the appliance, check that it is not standing on the
inlet and drain hose and the worktop is not pressing the electrical supply
cable.
If the machine is situated on a carpeted floor, please adjust the feet in
order to allow air to circulate freely.
Always be sure, that there is no water leakage from hoses and their
connections after the installation.
Any plumbing work required to install this appliance should be carried out
by a qualified plumber.
Any electrical work required to install this appliance should be carried out
by a qualified electrician.
Under no circumstances should you attempt to repair the machine
yourself. Repairs carried out by inexperienced persons may cause injury or
serious malfunctioning. Contact your local Service Centre. Always insist on
genuine spare parts.
1.2 INSTALLATION
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
This washing machine is not intended for use by young children or infirm
persons without supervision.
Young children should be supervised to ensure that they do not play with
the appliance.
The packaging components (e.g. plastic film, polystyrene) can be dangerous
to children - danger of suffocation! Keep them out of children’s reach.
Make sure that children or pets do not climb into the drum.
Keep all detergents in a safe place out of children’s reach.
This appliance is designed for domestic use. It must not be used for
purposes other than those for which it was designed.
Only wash fabrics which are designed to be machine washed. Follow the
instructions on each garment label.
Do not overload the appliance. See the relevant section in the user manual.
Before washing, ensure that all pockets are empty and buttons and zips are
fastened. Avoid washing frayed or torn articles and treat stains such as
paint, ink, rust, and grass before washing. Underwired bras must NOT be
machine washed.
Garments which have been in contact with volatile petroleum products
should not be machine washed. If volatile cleaning fluids are used, care
should be taken to ensure that the fluid is removed from the garment before
placing in the machine.
Never pull the power supply cable to remove the plug from the socket;
always take hold of the plug itself.
Never use the washing machine if the power supply cable, the control panel,
the working surface or the base are damaged so that the inside of the
washing machine is accessible.
1.3 USE
1.4 CHILD SAFETY
5
PRODUCT DESCRIPTION2.
1
Worktop
2
Detergent/Softener Dispenser
3
Control Panel
4
Door Handle
5
Door
13
Rating Label
14
Drum Leaf Lifter
7
6
Level Adjustment Feet (Front)
8
Mains Cable
9
Water Inlet Hose
10
Water Drain Hose
11
Hose Support (2pcs)
12
Level Adjustment Feet (Back)
Transit Bolts (3pcs)
6
www.electrolux.com
To remove the transit
bolts.
To adjust levelling legs.
To connect the drain
hose on the edge of a
sink.
Plastic caps
To close the holes on
the rear side of the
cabinet after the
removal of the transit
bolts.
ACCESSORIES
Plastic hose guide
Spanner
7
12
9
8
13
14
11
10
3
4
5
2
1
6
CONTROL PANEL3.
1
On/Off Button
2
3
4
On/Off button is used to turn on
and turn off your washing
machine.
Program Touchpad ( )
Press this touchpad to select the
washing program. The relevant light
will light up. (For more information
about washing programs, please
see page 10)
Temperature Touchpad ( )
7
Press this touchpad repeatedly to
increase or decrease the wash
temperature if you want your
laundry to be washed at a
temperature different from the one
proposed by the washing machine.
Spin Touchpad ( )
Press this touchpad repeatedly to
increase or decrease the spin speed,
if you want your laundry to be spun
at a speed different from the one
proposed by the washing machine.
The relevant light will light up.
This option eliminates all the spin
phases and increases the number
of rinses.
No Spin
By selecting this option the water of
the last rinse is not emptied out and
the drum turns regularly to prevent
the laundry creases. The door is still
locked to indicate that the water
must be emptied out.
Rinse Hold
Different temperatures can be
combined which is dependent
on the program selected.
Different spin speed can be
combined which is dependent
on the program selected.
3.1 Control Panel Description
The relevant light will light up.
The door stays locked with the
water in the drum. To drain
the water refer to relevant
paragraph on page 16.
1 2 3 49 10 5 6 87
5
8
www.electrolux.com
Option Touchpad ( )
Press this touchpad, if you want
your laundry to be washed with
special functions.
The relevant light
will light up.
With this option you can decrease
the program duration.
Use this option for items with light
soil or items to refresh.
Time Save
Use this option if your clothes are
heavily soiled. The washing cycle
lasts longer with this option.
Heavy Duty
When selecting this option the
laundry is gently washed and spun
to avoid creasing. In this way
ironing is easier.
The appliance decreases the spin
speed, uses more water and
adapts the program duration
to the type of laundry.
Easy Iron
This option performs the final rinse
stage of the selected wash program.
Rinse Plus function “ ” can also
be selected to add more rinses.
Rinse & Spin
Use this option for very wet clothes
to remove the water and spin.
If “No Spin” is selected, appliance
will only drain.
Drain & Spin
Different options can be
combined which is dependent
on the program selected.
This option will reduce the
working time and the number
of rinses.
If you need to add more rinse
phases, press “ ” + “ ” at
the same time to add “Rinse
Plus” option. (see page 9)
Delay End Touchpad ( )
Before you start the program, this
option makes it possible to define
the end of the washing program
from minimum 3 hours to maximum
20 hours.
If program duration is longer
than 3 hours minimum Delay
End option starts from 4 hours.
For example, if the program duration
of your selected program is 3.20
hours and you define the “Delay
End” time to 6 hours. This means
your wash program will finish in 6
hours. (See diagram below)
After selecting Delay End time, press
Start/Pause touchpad to start the
program. Machine will then
countdown and update time on the
display every hour until it reaches
the starting point of the wash cycle.
Press the Delay End touchpad to
choose the end time as your wish.
The display will show the number of
hours and the indicator above the
touchpad will light up. This option
must be selected after choosing the
wash program, and before pressing
the “Start/Pause” touchpad.
6
Spin speed can also be modified. If
“No Spin” is selected, appliance will
only rinse.
3.20 hrs.2.80 hrs.
Working Cycle
“Delay End” Time : 6 hrs.
Pressed
Start/Pause
End of
Cycle
Start the
Program
Countdown
NOTE:
Display
Rinse Plus Option ( )
9
This option is recommended for
people who are allergic to
detergents, and in areas where the
water is very soft.
To deactivate press
and hold
these 2 touchpads at the same
time
until the LED “ ” goes off.
Start/Pause Touchpad ( )
To start the selected program,
press the “Start/Pause”.
To interrupt a program which is
running, press the “Start/Pause” to
pause the machine, t
he Start/Pause
pilot light flashes.
To restart the program from the
point at which it was interrupted,
press the “Start/Pause” again,
the
Start/Pause pilot light will stop
flashing
.
The display shows the following
information:
Child Lock Option ( )
Your appliance is provided with
CHILD SAFETY LOCK which
permits you to leave the appliance
unsupervised with the door closed
without having to worry that
children might be injured by or
cause damage to the appliance.
Set this option after pressing the
Start/Pause touchpad.
This function remains
enabled even after the
appliance is switched off.
Press and hold “ ” and “ ”
touchpads at the same time
until the LED “ ”
lights up
.
The touchpads are locked
(except for the On/Off
“ ” button).
To set “Child Lock” option:
When the program is
completed the display
will show “ ”.
Incorrect Option Selection
If an option which is
not compatible with
the set wash
program selected, the display will
show “ ” and flash with 3
consecutive short beeps.
End Of Program
In the event of
operating problems,
some alarm codes
can be displayed, for example .
(See “Troubleshooting”.)
Alarm Codes
Estimated time of the selected
program
After selecting a
program, the
estimated time is
The estimated time is calculated
automatically on the basis of the
maximum recommended load for
each type of fabric. After the
program has started, the time
remaining is updated every minute.
displayed in hours and minutes (for
example 3.01).
If you wish to modify or cancel Delay
End option after starting the
program, follow the steps below:
set the washing machine to
PAUSE by pressing “Start/Pause”
touchpad;
-
deselect this option by pressing
Delay End once;
-
press the “Start/Pause” to start
the program.
-
7
8
9
10
To deactivate press
and hold
these 2 touchpads at the same
time
until the LED “ ” goes off.
Press and hold “ ” and “ ”
touchpads at the same time until
the LED “ ”
lights up
.
10
www.electrolux.com
3.3 Programs + Options
Select this option to add rinsing
phases to a program.
This function increases the
program duration.
NOTE:
Program;
Temp.
Cottons;White cotton with
heavy level of soil.
Cold to
90 °C
Cold to
60 °C
30 °C
7 kg 1200 rpm
3.5 kg 1200 rpm
Program
Description
(type of load
and soil level)
Maximum
Dry Clothes
Capacity
(Model: Max.
kg)
Maximum
Spin
Speed
(Model: Max.
rpm)
Options
Time Save
Heavy Duty
Easy Iron
Rinse & Spin
Drain & Spin
Delay End
Rinse +
Mixed;Synthetic or mixed
fabric items with
normal level of soil.
Quick 30;Synthetic and
mixed fabric items.
Light soil and items
to freshen up.
Enabling/Disabling Buzzer
Sounds
If you want to disable the
buzzer sound (except for event
of appliance malfunction)
,
press
and hold
“Programs ( )” and
“Temp ( )” touchpads at the
same time for 3 seconds, and
listen for “BEEP, BEEP”.
To set “Rinse Plus” option:
No Spin
Rinse Hold
3.2
This function remains enabled
even after the appliance is
switched off.
3 kg 800 rpm
The program is completed.
The appliance has a malfunction.
The buzzer sounds operate when:
To enable the Buzzer press
and
hold
these 2 touchpads at the
same time for 3 seconds, and
listen for “BEEP”.
-
-
-
-
Cold to
40 °C
Cold to
40 °C
Delicates;Delicate fabrics as
acrylics, viscose,
polyester items
with normal soil.
Bedding;Special program
for one synthetic
blanket, duvet,
bedspread and
so on.
3.5 kg 1200 rpm
3.5 kg 800 rpm
Tabla de contenidos
Otros manuales de Arandela de Electrolux
Electrolux
Electrolux PW9 Manual de usuario
Electrolux
Electrolux EWF 1287 HDW2 Manual de usuario
Electrolux
Electrolux EW8TN3362C Manual de usuario
Electrolux
Electrolux EWF 1440 Manual de usuario
Electrolux
Electrolux EWF 10570 W Manual de usuario
Electrolux
Electrolux WF 1029 Manual de usuario
Electrolux
Electrolux WASHING-MACHINES & WASHER-DRYERS Manual de usuario
Electrolux
Electrolux EW2W3068E3 Manual de usuario
Electrolux
Electrolux EW 851 F Guía rápida
Electrolux
Electrolux simpson EZIloader 45S557E Manual de usuario
Electrolux
Electrolux EWT1174M7WA Manual de usuario
Electrolux
Electrolux EWS 0864 EDW Manual de usuario
Electrolux
Electrolux EWT 136451 W Manual de usuario
Electrolux
Electrolux EFLS210TIW Manual de usuario
Electrolux
Electrolux EW 1280F Manual de usuario
Electrolux
Electrolux Zanussi ZWF 1651 W Manual de usuario
Electrolux
Electrolux EWT 2264IDW Manual de usuario
Electrolux
Electrolux EWF 1408 WDL Manual de usuario
Electrolux
Electrolux Wave-Touch EWFLS70JMB0 Manual de usuario
Electrolux
Electrolux WH1028 Manual de instrucciones
