CONTENTS
1. SAFETY INFORMATION...................................................................................... 3
2. SAFETY INSTRUCTIONS.....................................................................................5
3. PRODUCT DESCRIPTION................................................................................... 7
4. CONTROL PANEL...............................................................................................8
5. PROGRAMMES ................................................................................................11
6. CONSUMPTION VALUES..................................................................................16
7. OPTIONS...........................................................................................................17
8. SETTINGS......................................................................................................... 19
9. DAILY USE - WASHING ONLY.......................................................................... 19
10. DAILY USE - DRYING ONLY............................................................................23
11. DAILY USE - WASHING & DRYING................................................................. 24
12. HINTS AND TIPS............................................................................................. 26
13. CARE AND CLEANING....................................................................................28
14. TROUBLESHOOTING......................................................................................32
15. TECHNICAL DATA...........................................................................................36
16. GUARANTEE ..................................................................................................36
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can be
safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent disability.
•This appliance can be used by children aged 8 years
and above and by persons with reduced capabilities
provided that they have been given instruction and/or
supervision regarding the safe use of the appliance and
understand the potential hazards involved.
•Do not let children play with the appliance.
•Children under 3 years of age should be kept away from
the appliance unless continuously supervised.
•Keep all packaging away from children and dispose of it
appropriately.
•Keep detergents away from children.
•Keep children and pets away from the appliance door
when it is open.
•If the appliance has a child safety device, this should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
•The appliance shall be installed as a freestanding
product or below the kitchen worktop if space margins
permit.
•Do not install the appliance behind a lockable door, a
sliding door or a door with a hinge on the opposite side,
ENGLISH 3
that would prevent the appliance door from being fully
opened.
•Connect the mains plug to the mains socket only at the
end of the installation process. Make sure that the
mains plug is accessible after installation..
•The ventilation opening in the base (if applicable) must
not be covered by a carpet, mat, or any floor covering.
•Ensure good air ventilation in the located room to avoid
the back flow of gases into the room from appliances
burning gas or other fuels, including open fires.
•Exhaust air must not be discharged into a flue which is
used for exhausting fumes from any appliances burning
gas or other fuels.
•The operating water pressure at the water entry point
from the outlet connection must be between 0.5 bar
(0.05 MPa) and 8 bar (0.8 MPa).
•Do not exceed the maximum load of 9 kg (refer to the
"Programme chart" chapter).
•The appliance must be connected to the water mains
using the new supplied hose sets, or other new hose
sets supplied by the Authorised Service Centre.
•Old hose sets must not be reused.
•If the mains power supply cable is damaged, it must be
replaced by the manufacturer, its Authorised Service
Centre or similarly qualified persons to avoid an
electrical hazard.
•Wipe away lint or packaging debris that has
accumulated around the appliance.
•Items that have been soiled with substances such as
vegetable or mineral oil, acetone, alcohol, petrol,
kerosene, spot removers, turpentine, waxes and wax
removers should be washed separately with an extra
amount of detergent before being dried in the washer
dryer.
•Do not use the appliance if items have been soiled with
industrial chemicals.
•Do not dry unwashed items in the wash dryer.
www.electrolux.com4
•Items such as foam rubber (latex foam), shower caps,
waterproof textiles, and rubber backed articles and
clothes, or pillows fitted with foam rubber pads should
not be dried in the washer dryer.
•Fabric softeners, or similar products, should only be
used as specified by the product manufacturer’s
instructions.
•Remove all objects from items that could be a source of
fire ignition such as lighters or matches.
•Never stop the washer dryer before the end of the
drying cycle unless all items are quickly removed and
separated so that residual heat can dissipate.
•The final part of the washer dryer cycle takes place
without heat (cool down cycle) to ensure that items
reach a temperature that will not cause damage to
them.
•Do not use high pressure water sprays and/or steam to
clean the appliance.
•Clean the appliance with a moist cloth. Use only neutral,
detergents. Do not use abrasive products, abrasive
cleaning pads, solvents or metal objects.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Follow the installation instruction
supplied with the appliance.
• Do not install or use the appliance
where the temperature can be less
than 0°C or where it is exposed to the
weather.
• Always keep the appliance vertical
when being moved.
• Make sure that there is air circulation
between the appliance and the floor.
• Remove all the packaging and the
transit bolts.
• The floor area where the appliance is to
be installed must be flat, stable, heat
resistant and clean.
• Keep the transit bolts in a safe place. If
the appliance is to be moved in future
they must be reattached to lock the
drum to prevent internal damage.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not install or use a damaged
appliance.
• Do not install the appliance where the
appliance door cannot be fully opened.
• Adjust the feet to have the necessary
space between the appliance and the
flooring.
• When the appliance is in its permanent
position, check that it is fully level with
ENGLISH 5
the aid of a spirit level. If it is not, adjust
the feet accordingly.
2.2 Electrical Connection
WARNING!
Risk of fire and electrical
shock.
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
• This appliance complies with the E.E.C.
Directives.
2.3 Water Connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes, pipes
not used for a long time, where repair
work has been carried out or new
devices fitted (water meters, etc.), let
the water flow until it is clean and clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
2.4 Use
WARNING!
Risk of injury, electrical
shock, fire, burns or damage
to the appliance.
• This appliance is for household use
only.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the glass door while a
programme is in operation. The glass
can get hot.
• Do not dry damaged (torn, frayed)
items that contain padding or fillings.
• If laundry has been washed with a stain
remover, carry out an additional rinse
cycle before starting a drying cycle.
• Make sure that all metal objects are
removed from the laundry.
• Only dry fabrics that are suitable to dry
in the washer dryer. Follow the
cleaning instruction on the item label.
• Plastic items are not heat resistant.
– If a detergent ball is used, remove
it before starting a drying
programme.
– Do not use a detergent ball if
setting a non-stop programme.
WARNING!
Risk of injury or damage to
the appliance.
• Do not sit or stand on the open door.
• Do not dry dripping wet clothes in the
appliance.
2.5 Disposal
• Disconnect the appliance from the
mains electrical and water supplies.
• Cut off the mains electrical cable close
to the appliance and dispose of it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the drum.
• Dispose of the appliance in
accordance with local requirements for
the disposal of Waste Electrical and
Electronic Equipment (WEEE).
www.electrolux.com6
3. PRODUCT DESCRIPTION
3.1 Appliance overview
1
2
3
5
6
7
4
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Rating plate
6Drain pump filter
7Feet for levelling the appliance
3.2 How to activate the child
safety device
This device prevents children or pets from
being closed in the drum.
Turn the device clockwise, until the groove
is horizontal.
You cannot close the door.
To close the door, turn the device
anticlockwise until the groove is vertical.
3.3 Fixing plate kit (4055171146)
Available from your authorised dealer.
If you install the appliance on a plinth,
secure the appliance in the fixing plates.
Read carefully the instructions supplied
with the accessory.
ENGLISH 7
4. CONTROL PANEL
4.1 Control panel description
Temp.
Flecken
Taches/
Vorw sche
Pr lavage
U./Min.
T/min.
Extra
Spülen
Rinçage +
Start/Pause
D part/Pause
Zeit Sparen
Gain de
Temps
Zeitvorwahl
D part
Diff r
Koch/Bunt
Blanc/Couleurs
Koch/Bunt
Blanc/Couleurs
Pflegeleicht
Synth tiques
Seide
Soie
Pflegeleicht
Synth tiques
Leichtbügeln
Repassage Facile
Feinw sche
D licats
Wolle
Laine
Wolle
Laine
20 min - 3 kg
Non Stop 60 min.
Anti-Allergie
Anti-Allergies
Schleudern/Pumpen
Essorage/Vidange
Dampf
Vapeur
Spülen
Rinçage
Energiesparen
Economique
Marche/Arrêt
Ein/Aus
Trockenzeit
Minuterie
Trockengrad
Niveau de
séchage
1 2 3
4
5
6789101112
1Ein/Aus - Marche/Arrêt button
2Programme knob
3Display
4Trockengrad - Niveau de séchage
button
5Trockenzeit - Minuterie button
6Start/Pause - Départ/Pause button
7Zeitvorwahl - Départ Différé button
8Zeit Sparen - Gain de Temps button
9Extra Spülen - Rinçage + button
10 Flecken - Taches / Vorwäsche -
Prélavage button
11 U./Min. - T/min. button
12 Temperatur - Température button
4.2 Display
A HC
NOP
D E F G I
LM
KB J
The display shows:
A
Temperature of the set programme
Cold water
www.electrolux.com8
B
Spin speed of the set programme
No Spin symbol1)
Rinse hold symbol
1) Only available for SPIN/DRAIN programme.
C
The phase symbols
When a programme is set, all the symbols of the phases related to the pro-
gramme come on.
When the programme starts, only the symbol of the phase in operation flashes.
When the programme is completed, the symbol of the last phase is on.
Prewash phase
Washing phase
Rinse phase
Spin phase
DThe drying symbol comes on when you set a drying programme.
EThe steam symbol comes on when you set a Steam programme.
FThe anti-crease symbol comes on when you set a drying pro-
gramme.
G
You cannot open the appliance door when the symbol is on. You
can open the door only when the symbol goes off.
If the programme is completed but the symbol stays on:
• The «Rinse hold» function is on.
• There is water in the drum.
HThe child safety lock symbol comes on when this device is activa-
ted.
IThe delay start symbol comes on when you set the delay start
function.
ENGLISH 9
J
Programme time (washing and/or drying phase)
When the programme starts, the programme time decreases with
steps of 1 minute.
Delay start
When you press the delay start button, the display shows the delay
start time
Alarm codes
If the appliance has a malfunction, the display shows alarm codes.
Refer to «Troubleshooting».
The display shows this message for some seconds when:
• You cannot set a function with the washing programme.
• You try to change the washing programme while it operates.
When the programme is completed.
K
Dryness level symbols: they come on when you set an automatic drying.
Extra dry level symbol
Store dry level symbol
Iron dry level symbol
LThe drying time symbol comes on when you set the a drying pro-
gramme.
MThe detergent overdosing symbol comes on at the end of the cycle
when the appliance detects too much detergent.
Graphic bars
The empty indicator bar appears only if the related function is
available for the set programme.
The indicator bar fills accordingly to the set functions.
If you make a wrong selection the message Err indicates that the selection
is not possible.
N
The Zeit Sparen - Gain de Temps symbol comes on when you set
one of the programme duration.
Shortened time
Extra Quick
www.electrolux.com10
Tabla de contenidos
Idiomas:
Otros manuales de Lavadora secadora de Electrolux
Electrolux
Electrolux EWW 1273 Manual de usuario
Electrolux
Electrolux Iron Aid EDI97170W Manual de usuario
Electrolux
Electrolux WTSL 6 E201 Manual de usuario
Electrolux
Electrolux EW8W7861E1 Manual de usuario
Electrolux
Electrolux EW1269W Manual de usuario
Electrolux
Electrolux WS 210 Manual de usuario
Electrolux
Electrolux EWW7024M3SB Manual de usuario
Electrolux
Electrolux EWW12832 Manual de usuario
Electrolux
Electrolux Husqvarna QW 16850 HT Manual de usuario
Electrolux
Electrolux EWW 1686 HDW Manual de usuario
Electrolux
Electrolux EWW1687SWD Manual de usuario
Electrolux
Electrolux EWW1142ADWA Manual de usuario
Electrolux
Electrolux EW7W4862LB Manual de usuario
Electrolux
Electrolux EWW12853 Manual de usuario
Electrolux
Electrolux EWW8024E3WB Manual de usuario
Electrolux
Electrolux EWX 127410 W Manual de usuario
Electrolux
Electrolux EWW1042Q7WB Manual de usuario
Electrolux
Electrolux EWW 148540 W Manual de usuario
Electrolux
Electrolux EW 1200 i Manual de usuario
Electrolux
Electrolux EWX 127410 W Manual de usuario
