Electrolux LFD619Y Manual de usuario
LFD619Y
EN Cooker Hood User Manual
CONTENTS
1. SAFETY INFORMATION AND INSTALLATION................................................ 2
2. BEFORE FIRST USE......................................................................................... 3
3. PRODUCT DESCRIPTION................................................................................ 3
4. DAILY USE......................................................................................................... 3
5. CARE AND CLEANING......................................................................................5
6. TROUBLESHOOTING........................................................................................7
7. ENVIRONMENTAL CONCERNS....................................................................... 7
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.electrolux.com/support
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION AND INSTALLATION
WARNING!
Refer to the separate
Installation Instructions
booklet for Safety
Information and Installation.
Read carefully the Safety
chapters before any use or
maintenance of the
appliance.
www.electrolux.com2
2. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
2.1 Closing the glass
When the slider do not open and the
panel blinks white the glass inside the
slider is loose. The glass must be closed
in order to open the slider and operate
the appliance.
1. Reach to the front side of the
appliance inside the furniture.
2. Open the small cover in front and
make sure that the glass inside is not
loosened.
Gently push the glass if it is loosened to
close it.
3. Close the cover in front of the
appliance.
The appliance is now ready to use.
3. PRODUCT DESCRIPTION
3.1 Control panel overview
1 2 3 4 5 6 7 8
1On / Off, Open / Close
2First motor speed
3Second motor speed
4Third motor speed
5Maximum motor speed
6Breeze function
7Filter notification
8Lamp
4. DAILY USE
4.1 Opening and closing the
hood
WARNING!
Risk of injury or damage to
the appliance! Do not put
any cookware or other
objects on and under the
slider.
ENGLISH 3
1. Press and hold until the slider
start to open.
The appliance turns on and slider goes
up.
2. To close the slider and turn off the
appliance press and hold until
slider starts to go down.
Use the hood only when slider stops and
is fully open.
4.2 Using the hood
Check the recommended speed
according to the table below.
While heating up food, cooking with covered pots.
While cooking with covered pots on multiple cook‐
ing zones or burners, gentle frying.
While boiling and frying big quantities of food with‐
out a lid, cooking on multiple cooking zones or
burners.
While boiling and frying big quantities of food with‐
out a lid, big humidity.
Refreshes the air in kitchen after cooking at a very
low noise level. It can be activated and de-activa‐
ted by touching the symbol. The function turns off
automatically after 60 minutes. Use after cooking
only.
It is recommended to leave
the hood operating for
approximately 15 minutes
after cooking.
The control Panel is a
sensor field. Touch the
symbols for 1 second to
activate the functions.
To operate the hood when the hood is
open:
1. Turn on the appliance by pressing
the symbol.
You can now activate the functions.
2. To activate the function touch the
symbol.
3. If needed, touch the light symbol
to illuminate the cooking surface.
To turn off the appliance press the
symbol again.
4.3 Activating Maximum Motor
Speed
When you press the button , the
Maximum Motor Speed starts to operate
for 8 minutes. After that time, the
appliance returns to its previous speed
settings.
When the function is turned
on, additional touch on the
button does not have any
effects.
www.electrolux.com4
4.4 Filter notification
Filter alarm reminds to change or clean
the charcoal filter and clean the grease
filter. The filter indicator is turned on
for 30 seconds if the grease filter must
be cleaned. The filter indicator flashes
for 30 seconds if the charcoal filter must
be replaced or cleaned.
Refer to cleaning the grease
filter in care and cleaning
chapter.
Refer to cleaning the
charcoal filter or replacing
the charcoal filter in care and
cleaning chapter.
To reset the function touch for 3
seconds.
To activate or deactivate function
(only for charcoal filter):
1. Switch on the control panel.
2. Make sure that the icons are turned
white.
3. To activate function touch for 3
seconds.
If the function is activated, the filter icon
flashes five times.
4. To deactivate function touch for 3
seconds.
If the function is deactivated, the filter
icon flashes three times.
5. CARE AND CLEANING
5.1 Notes on cleaning
Cleaning
Agents
Do not use abrasive detergents and brushes.
Clean the surface of the appliance with a soft cloth with warm water
and a mild detergent.
After cooking some parts of appliance can get hot. To avoid stains
appliance must be cooled down and dried with clean cloth or paper
towels.
Clean stains with a mild detergent.
Keep the hood
clean
Clean the appliance and grease filters each month. Clean the inte‐
rior and grease filters carefully from fat. Fat accumulation or other
residue may cause fire.
Follow the instructions for cleaning the accessories when filter noti‐
fication is on. Refer to Filter notification in daily use chapter.
Grease filters can be washed in a dishwasher.
The dishwasher must be set to a low temperature and a short cy‐
cle. The grease filter may discolour, it has no influence on the per‐
formance of the appliance.
Charcoal filter
The time of saturation of the charcoal filter varies depending on the
type of cooking and the regularity of cleaning the grease filter.
Charcoal filter is washable, clean or regenerate the filter after ap‐
proximately every two months. Refer to leaflet included in the ac‐
cessory.
ENGLISH 5
5.2 Cleaning the grease filter
Filters are mounted with the use of clips
and pins on the opposite side.
To clean the filter:
1. Pull the cover to open it.
Be careful! To prevent
accidental collapse, the
cover has two hooks on the
sides.
2. Press the handle of the mounting clip
on the filter panel underneath the
hood (1).
1
2
3. Slightly tilt the front of the filter
downwards (2), then pull.
Repeat the first two steps for all filters.
4. Clean the filters using a sponge with
non abrasive detergents or in a
dishwasher.
The dishwasher must be set
to a low temperature and a
short cycle. The grease filter
may discolour, it has no
influence on the
performance of the
appliance.
5. To mount the filters back follow the
first two steps in reverse order.
Repeat the steps for all filters if
applicable.
After closing the cover, the control panel
turns white. The appliance is ready to
use.
5.3 Cleaning the charcoal filter
To remove the filter:
1. Remove the grease filters from the
appliance.
Refer to "Cleaning the grease filter" in
this chapter.
2. Remove the clips holding the filter
bed (1), then the filter bed (2).
1
2
3. Wash the filter bed in hot water
without using detergent or use a
dishwasher.
Set the dishwasher without
using rinse aids or any other
detergents. The dishwasher
cannot be filled with dishes.
4. Leave the filter bed to dry or use an
oven.
WARNING!
Risk of burns! Refer to
safety chapter in oven user
manual.
Set the oven for 10 minutes in the
maximum temperature of 60°C.
5. To install the filter, perform the steps
in reverse order. The filter has to be
fully dried before installing it back into
appliance.
Replace the filter bed every 2 years or
when the cloth is damaged.
www.electrolux.com6
5.4 Replacing the lamp
This appliance is supplied with a LED
lamp. This part can be replaced by a
technician only. In case of any
malfunction refer to "Service" in the
"Safety Instructions" chapter.
6. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
6.1 What to do if...
Problem Possible cause Remedy
You cannot activate the
appliance.
The appliance is not con‐
nected to a power supply
or it is connected incorrect‐
ly.
Check if the appliance is
correctly connected to the
electrical supply.
You cannot activate the
appliance.
The fuse is blown. Make sure that the fuse is
the cause of the malfunc‐
tion. If the fuse is blown
again and again, contact a
qualified electrician.
You cannot open the slider
and the panel blinks red
and white.
The glass inside the appli‐
ance is opened.
Close the glass. Refer to
"Closing the glass" in the
"Before first use" chapter.
The lamp does not oper‐
ate.
The lamp is defective. Replace the lamp. Refer to
the "Care and Cleaning"
chapter.
The appliance does not
absorb enough vapours.
The motor speed is not ad‐
equate to the appearing
vapours.
Change the speed of the
motor.
The filter alarm indicator
is on.
The filter alarm is on. The
grease filter must be
cleaned or the charcoal fil‐
ter must be replaced or
cleaned.
Refer to the filter notifica‐
tion in "Daily use" chapter.
7. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
ENGLISH 7
www.electrolux.com/shop
867351206-D-192022
Otros manuales para LFD619Y
2
Tabla de contenidos
Otros manuales de Campana de ventilación de Electrolux
Electrolux
Electrolux ECC6681G Manual de usuario
Electrolux
Electrolux EFC 60131 Manual de usuario
Electrolux
Electrolux EI30HI55KS Manual de usuario
Electrolux
Electrolux EECH6001S Guía del usuario
Electrolux
Electrolux PLHV36W7CC Manual de usuario
Electrolux
Electrolux ERHC1238S Manual de instrucciones
Electrolux
Electrolux EFB70566OX Manual de usuario
Electrolux
Electrolux EFI739X Manual de usuario
Electrolux
Electrolux EFC6422 Manual de usuario
Electrolux
Electrolux EFA 9673 Manual de usuario
Electrolux
Electrolux LFC419X Manual de usuario
Electrolux
Electrolux EFC60401OW Manual de usuario
Electrolux
Electrolux EFC 928 Manual de usuario
Electrolux
Electrolux LFV619K Manual de usuario
Electrolux
Electrolux RH30WC55GSA Manual de instrucciones
Electrolux
Electrolux EFC90246 Manual de usuario
Electrolux
Electrolux PLHV36W7C Manual de usuario
Electrolux
Electrolux EFP 646 Manual de usuario
Electrolux
Electrolux Ventilation Hood Manual de usuario
Electrolux
Electrolux WHGL9040CN Manual de usuario
