The following symbols are used in this user manual:

Important information concerning your personal safety and information

on how to avoid damaging the appliance

General information and tips

Environmental information

Disposal

By ensuring this product is disposed of correctly, you will help

prevent potential damaging consequences for the environment

and human health.

The symbol on the product indicates that this product may not be

treated as household waste, but must be taken instead to a suitable

collection point for the recycling of electrical and electronic

equipment. For more detailed information about recycling of this

product, please contact your local city office, your household

waste disposal service or the shop where you purchased the

appliance.

electrolux 5

CCoonntteennttss

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

First use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Switch on-off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Switch on the freezer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Switch off the freezer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Daily use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Temperature adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Super Freeze function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Storage baskets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Security lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Opening and closing the lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Defrosting the freezer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

When not in use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Changing the light bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Helpful hints and tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Freezing food . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Food storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

In the case of a power failure or breakdown . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

What to do if... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Service or repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

6electrolux EN

SSaaffeettyyIInnffoorrmmaattiioonn

Before installing and using the appliance

read this user's instruction book carefully.

It contains safety precautions, hints,

information and ideas. If the freezer is

used in compliance with the instructions

written, it will operate properly and

provide you with greatest satisfaction.

These warnings are provided in the

interest of safety. You must read them

carefully before installing or using the

appliance.

Use the freezer only for storing frozen

food, freezing fresh food and making

ice cubes.

Do not eat ice cubes or ice lollies

immediately after taking them out of

the freezer, since they may cause frost

burns.

Do not allow children to play or hide

inside the freezer, since they may

become trapped inside and suffocate.

Do not store glass containers with

liguids in the freezer, since they may

burst.

Ensure that the freezer is not resting

on the power supply cable.

Before servicing or cleaning, always

unplug the appliance or disconnect

the power supply.

Do not use other electrical appliances

(such as ice cream makers) inside the

appliance.

Your appliance contains an

environmentally friendly natural gas,

isobuthane (R600a). Caution is

required however, since isobuthane is

flammable. Therefore it is essential to

ensure that the refrigerant pipelines

are not damaged.

It is most important that this instruction

book should be retained with the

appliance for future reference.

Product Description

1. Lid handle

2. Security lock

3. Seal

4. Defrost water drain

5. Control panel

6. Thermostat knob: temperature

adjustment

7. Upper edge

8. Light

9. Valve: easy re-opening of lid

A. Red light: Illuminates when the freezer

temperature is not sufficiently low.

B. Green light: Illuminates when the

appliance is on.

C. Yellow light: Illuminates when the

Super Freeze function is activated.

Control panel

electrolux 7

Installation

Wait at least 2 hours before

connecting the freezer to the power

supply to ensure the refrigerant

circuit is fully efficient.

Install the freezer in a dry, well

ventilated room. Avoid locations

near a source of heat or in direct

sunlight.

The room temperature should

correspond to the climatic

classification for which the freezer

was designed, see chapter

"Technical data".

Place the freezer horizontally on a

firm surface, resting on all four feet.

For optimum operation and in order

to avoid damage when the lid is

opened, leave a space of at least 5

cm from the rear wall and 5 cm at

the sides.

Before connecting the freezer to

the power supply, ensure that the

voltage corresponds to that

indicated in chapter "Technical

data" under "Voltage".

Danger!

Ensure that the freezer is not

resting on the power supply cable.

Do not remove the power supply

cable by pulling on its lead,

particularly when the freezer is

being pulled out of its niche.

The power supply cable may only

be replaced by a qualified service

personel.

Ensure that the power plug is not

squashed or damaged by the back

of the freezer.

There must be adequate ventilation

around the appliance.

Any electrical work required to

install this appliance should be

carried out by a qualified

electrician.

Warning! This appliance

must be earthed.

First use

Before first use, the freezer should

be cleaned inside, see chapter

"Care and cleaning".

Plug in the appliance.

The green light will come on.

The red light will also switch on and

the alarm will beep, since the

temperature inside the freezer is

not yet sufficiently low for food

storage.

Press button (D) to switch the alarm

off. The red light will normally

switch off after several hours.

Only place food inside the freezer

once the red light has switched off.

Switch on-off

Switch on the freezer

Turn the thermostat knob to a

postion between and .

The green light comes on.

D. Super Freeze button:

Activates/deactivates the Super

Freeze function for large quantities for

fresh food and switches off the

beeping alarm.

8electrolux EN

Switch off the freezer

Turn the thermostat knob to the Off

position

The green light goes off.

Daily use

Temperature adjustment

To adjust the temperature of the

freezer, proceed as follows:

Turn the thermostat knob clockwise

towards for a colder storage

temperature.

Turn the thermotat knob counter-

clockwise towards for a less

cold storage temperature.

Super Freeze function

If more than 3-4 kg of fresh food is to

be frozen, the freezer needs to be

pre-cooled.

At least 24 hours before placing

fresh food in the freezer, press

button (D).

The yellow light comes on.

Place the food in the freezer. After

52 hours this function will

automatically switch off and the

freezer will return to normal storage

temperature. This function can be

de-activated any time by pressing

button (D) again.

Alarm

If the freezer temperature is not

sufficiently low, the alarm will beep

and the red light will come on.

Press button (D) to switch the

sound off. The red light remains on

as long as the temperature in the

freezer is higher than the

thermostat setting.

The alarm can be due to:

Insertion of a large amount of fresh

food.

Opening the lid too long.

A defect in the system, see chapter

"What to do if...".

Storage baskets

Hang the baskets on the upper

edge (X) or place the stackable

baskets inside the freezer (Y).

Turn and fix the handles for these

two positions, as shown in the

drawings.

Spare baskets can be obtained from

your local Service Force Centre or

from the Electrolux website

(depending on country). The

illustrations on this page show how

many baskets can be placed in the

various freezer models.

Security lock

Push the key in the lock while

turning.

Spare keys can be obtained from your

local Service Force Centre.

Important! Keep the keys out of reach

of children. Before disposing of an old

freezer remove the keys

electrolux 9

Opening and closing the lid

As the lid is fitted with a tightly closing

seal, it will not re-open easily

immediatedly after closing.

Wait a few minutes before re-

opening the lid. A valve will allow

the lid to be re-opened easily.

Never pull the handle violently

Care and Cleaning

Defrosting the freezer

When the ice layer is 10-15 mm thick,

the freezer should be defrosted. We

suggest that you defrost your freezer

when there is little or no food inside.

Disconnect the appliance from the

power supply.

Remove the contents of the freezer,

wrap them in newspapers, and

keep them in a cold place.

Leave the appliance lid open.

Remove the plug from the water

drain.

The defrost water can be collected

in a tray as shown in the drawing. If

available, use the divider.

Speed up defrosting by using the

enclosed scraper to detach the ice

from the appliance walls.

Dry the interior of the appliance

thoroughly.

Remember to replace the plug in

the water drain.

Important! Never use a knife or any

other sharp implement to remove frost

or ice.

Cleaning

The best time to clean your freezer is

after defrosting.

Disconnect the appliance from the

power supply and remove all loose

accessories.

Use a damp cloth to clean your

freezer. Use hot water and a mild,

non-aromatic detergent.

Clean the loose accessories,

before replacing them again.

Important! Never use strong

detergents, scouring powder or

aromatic detergents to clean your

freezer.

When not in use

Disconnect the appliance from the

power supply.

Remove all food from the freezer.

Clean the freezer as described

above.

Leave the lid slightly open.

Changing the light bulb

Disconnect the appliance from the

power supply.

Unscrew the bulb, and replace it

with a new bulb (max. 15W).

Plug in the appliance.

10 electrolux EN

Helpful hints and tips

Freezing food

Before freezing, fresh food must be

packed in airtight and moisture-proof

packaging to prevent it from drying

out.

Only use fresh food of the best

quality.

Always leave hot food to cool to

room termperature before placing in

the freezer.

Divide food into small portions

before freezing; this ensures that

freezing is more rapid, and that you

only need to defrost the amount

needed for immediate consumption.

Mark the freezer packaging with the

date of freezing.

Place fresh food for freezing close to

the cold sides of the freezer, making

sure that it is not in contact with the

frozen food already in the freezer.

Frozen food can be stored anywhere

inside the freezer, but should be kept

at least 5 mm below the upper edge.

If freezing is too slow, the quality of the

food being frozen deteriorates. The

amount of fresh food (expressed in kg)

that can be frozen in 24 hours is

indicated in the chapter "Technical data"

under "Freezing capacity".

Food storage

For fresh frozen food, please refer to

the storage period table underneath.

For purchased frozen food, never

exceed the expiry date.

When you buy frozen food, make

sure that it has been stored at the

correct temperature. Do not buy

products which have wet or

damaged packaging. Place

purchased products in your freezer

as quickly as possible. We

recommend using an insulated bag

to bring such products home with

you.

Important! Remember that fully or

partially defrosted food must not be re-

frozen. However, dishes which have

been cooked using defrosted food may

be frozen.

In the case of a power failure or

breakdown

Do not open the lid.

Important! If the power has been off for

longer that the value shown in the

chapter "Technical data" under "Hold-

over time", the defrosted food must be

consumed quickly or cooked

immediately and then refrozen (after

cooling).

What to do if...

Try the solutions suggested here first to

avoid the cost of an unnecessary service

call.

Your freezer will not operate

Is the power supply cord unplugged?

Has a household fuse blown?

Is there a power failure?

Is the temperature control set to the

Off position?

The alarm remains audible and/or the

red light/symbol ( ) is on

Is the lid not closed completely? See

Tabla de contenidos

Idiomas:

Otros manuales de Refrigerador de Electrolux

Electrolux

Electrolux ERD 3464 X Manual de usuario

Electrolux

Electrolux IK327SA Manual de usuario

Electrolux

Electrolux ER 2520 B Guía rápida

Electrolux

Electrolux LNT7ME34X2 Manual de usuario

Electrolux

Electrolux French Door Bottom Freezer/Refrigerator Manual de usuario

Electrolux

Electrolux IK1910SZR Manual de usuario

Electrolux

Electrolux E23BC78IPS - 22.6 cu.ft Manual de usuario

Electrolux

Electrolux RCB732E3MB Manual de usuario

Electrolux

Electrolux ENN2800BOW Manual de usuario

Electrolux

Electrolux IK243SR Manual de usuario

Electrolux

Electrolux ER2849B Guía rápida

Electrolux

Electrolux EI23CS55 Manual de usuario

Electrolux

Electrolux KNT4FD18S Manual de usuario

Electrolux

Electrolux ER 7250B Guía rápida

Electrolux

Electrolux TR916 Manual de instrucciones

Electrolux

Electrolux ERE38202W Manual de usuario

Electrolux

Electrolux LXB2AF82S Manual de usuario

Electrolux

Electrolux ERB 3025 Guía rápida

Electrolux

Electrolux ei28bs55is1 Manual de usuario

Electrolux

Electrolux ERN 19500 Manual de usuario

Electrolux

Electrolux E32AR75FPS - 16.5 cu. Ft. Refrigerator Guía del usuario

Electrolux

Electrolux ERN29801 Manual de usuario

Electrolux

Electrolux flymo micro lite Manual de funcionamiento

Electrolux

Electrolux ICON Designer E23BC78ISS Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario

Teledyne

Teledyne 6712FR and Instrucciones de funcionamiento
