Electrolux EBE5304 Manual de usuario

EMT5704

EBE5304

A12081675-A-072021

EN Refrigeration

FR Réfrigération

RU Охлаждение

User manual

Manuel de l'utilisateur

Руководство пользователя

2 www.electrolux.com

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can be safe

in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website to:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

www.electrolux.com/productregistration

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

We recommend the use of original spare parts.

When contacting Service, ensure that you have the following data available.

The information can be found on the rating plate. Model, PNC, Serial Number

Warning / Caution-Safety information.

General information and tips.

Environmental information.

Subject to change without notice.

CONTENTS

................................................................................................ 3

............................................................................ 5

.......................................................................................................... 19

......................................................................... 24

.................................................................................... 25

29..............................................................................................

............................................................................ 30

1. SAFETY INFORMATION

2. DESCRIPTION OF THE APPLIANCE

3. CONTROL PANEL

4. INSTALLING YOUR NEW APPLIANCE

5. USING YOUR REFRIGERATOR

6. AUTOMATIC ICE MAKER

............................................................................................... 31

7. CLEANING YOUR REFRIGERATOR

8. FOOD STORAGE GUIDE

32....................................................................................................

........................................................................................................................... 35

9. TROUBLESHOOTING

10. NOISES

WE’RE THINKING OF YOU

CUSTOMER CARE AND SERVICE

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

Regiﬆer your product for better service:

www.electrolux.com/productregiﬆration

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

Visit our website to:

Subject to change without notice.

Warning / Caution-Safety information.

General information and tips.

Environmental information.

Thank you for choosing this Electrolux product. We have created it to give you

impeccable performance for many years, with innovative technologies that help

make life simpler features you might not ﬁnd on ordinary appliances. Please spend

a few minutes reading to get the very beﬆ from it.

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the follow-

ing data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

CONTENTS

1. SAFETY INFORMATION..............................................................................................................3

2. SAFETY INSTRUCTIONS.............................................................................................................4

3. DESCRIPTION OF THE APPLIANCE......................................................................................6

4. TEMPERATURE CONTROL........................................................................................................8

5. INSTALLING YOUR NEW APPLIANCE.................................................................................12

6. USING YOUR REFRIGERATOR............................................................................................... 16

7. CLEANING YOUR REFRIGERATOR...................................................................................... 18

8. FOOD STORAGE GUIDE .......................................................................................................... 19

9. TROUBLESHOOTING ............................................................................................................... 20

10. NOISES .......................................................................................................................................... 23

3EN

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully read

the supplied instructions. The manufacturer is not responsible if an

incorrect installation and use causes injuries and damages. Always

keep the instructions with the appliance for future reference.

1.1 Children and vulnerable people safety

• This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental

apabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in

a safe way and understand the hazards involved.

• Do not let children play with the appliance.

• Keep all packaging away from children.

• Cleaning and user maintenance shall not be made by children

without supervision.

1.2 General Safety of the appliance.

• This appliance is intended to be used in household and similar

applications such as:

– Farm houses; staﬀ kitchen areas in shops, oﬃces and other

working environments

– By clients in hotels, motels, bed and breakfast and other

residential type environments

• Keep ventilation openings, in the appliance enclosure or in the

built-in structure, clear of obstruction.

• Do not use mechanical devices or other means to accelerate

the defrosting process, other than those recommended by the

manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type

recommended by the manufacturer.

• Do not use water spray and steam to clean the appliance.

• Clean the appliance with a moist soft cloth. Only use neutral

detergents. Do not use abrasive products, abrasive cleaning pads,

solvents or metal objects.

• Do not store explosive substances such as aerosol cans with a

ﬂammable propellant in this appliance.

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualiﬁed persons in order

to avoid a hazard.

4 www.electrolux.com

• If the appliance is equipped with an Ice maker or a water dispenser,

ﬁll them with potable water only.

• If the appliance requires a water connection, connect it to potable

water supply only.

• The inlet water pressure (minimum and maximum)must be between

1 bar (0,1 MPa) and 10 bar (1 MPa)

2. SAFETY INSTRUCTIONS

2.1 Installation

WARNING!

Only a qualiﬁed person must install

this appliance.

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Obey the installation instruction

supplied with the appliance.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Make sure the air can circulate around

the appliance.

• Wait at least 4 hours before connecting

the appliance to the power supply.

This is to allow the oil to ﬂow back in

the compressor.

• Do not install the appliance close to

radiators or cookers, oven or hobs.

• The rear of the appliance must stand

against the wall.

• Do not install the appliance where

there is direct sunlight.

• Do not install this appliance in areas

that are too humid or too colds, such

as the construction appendices,

garages or wine cellars.

• When you move the appliance, lift it

by the front edge to avoid scratching

the ﬂoor.

2.2 Electrical connection

WARNING!

Risk of ﬁre and electrical shock.

• The appliance must be earthed.

• All electrical connections should be

made by a qualiﬁed electrician.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not, contact

an electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to the

electrical components (e.g. mains plug,

mains cable, compressor). Contact the

Service or an electrician to change the

electrical components.

• The mains cable must stay below the

level of the mains plug.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there

is access to the mains plug after the

installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

5EN

2.3 Use

WARNING!

Risk of injury, burns, electrical shock

or ﬁre.

• Do not change the speciﬁcation of this

appliance.

• Do not put electrical appliances (e.g.

ice cream makers) in the appliance

unless they are stated applicable by

the manufacturer.

• Be careful not to cause damage to the

refrigerant circuit. It contains isobutane

(R600a), a natural gas with a high level

of environmental compatibility.This gas

is ﬂammable.

• If damage occurs to the refrigerant

circuit, make sure that there are no

ﬂames and sources of ignition in the

room. Ventilate the room.

• Do not let hot items to touch the plastic

parts of the appliance.

• Do not put soft drinks in the freezer

compartment. This will create pressure

on the drink container.

• Do not store ﬂammable gas and liquid

in the appliance.

• Do not put ﬂammable products

or items that are wet with ﬂammable

products in, near or on the appliance.

• Do not touch the compressor or the

condenser. They are hot.

• Do not remove or touch items from the

freezer compartment if your hands are

wet or damp.

• Do not freeze again food that has

been thawed.

• Obey the storage instructions on the

packaging of frozen food.

2.4 Internal light

• The type of lamp used for this

appliance is not suitable for household

room illumination.

2.5 Care and cleaning

WARNING!

Risk of injury or damage to the

appliance

• Before maintenance, deactivate the

appliance and disconnect the mains

plug from the mains socket.

• This appliance contains hydrocarbons

in the cooling unit. Only a qualiﬁed

person must do the maintenance and

the recharging of the unit.

• Regularly examine the drain of the

appliance and if necessary, clean it.

If the drain is blocked, defrosted water

collects in the bottom of the appliance.

2.6 Disposal

WARNING!

Risk of injury or suﬀocation.

• Disconnect the appliance from the

mains supply.

• Cut oﬀ the mains cable and discard it.

• Remove the door to prevent children

and pets to be closed inside of the

appliance.

• The refrigerant circuit and the insulation

materials of this appliance are ozone-

friendly.

• The insulation foam contains

ﬂammable gas. Contact your municipal

authority for information on how to

discard the appliance correctly.

• Do not cause damage to the part of

the cooling unit that is near the heat

exchanger.

6 www.electrolux.com

3. DESCRIPTION OF THE APPLIANCE

3.1 TOP MOUNT REFRIGERATOR FEATURESEATURES

Refrigerator/freezer control panel

From this panel you can control the temperature of the

refrigerator and freezer compartments as well as setting the

quick freeze function or resetting the door alarm.

For further information on how to use this feature refer to the

section “About the User Interface”.

Features may vary depending on model. Not all models will have features listed.

Refer to the section

“Temperature Control”

feature.

for details on using

this

Twist & Serve Ice

Refer to the section

“Using your Refrigerator”

for details on removing,

relocating and using this

feature.

Chiller drawer

Use the chiller drawer to

store foods like small

goods, fresh or cooked

meat and cheese, or as

an additional crisper. The

drawer will prevent

strong food odours from

impacting the rest of the

refrigerator. To remove

the chiller drawer, pull it

forward, then lift it up

and pull it further

forward.

TasteGuard Deodorizer

NutriPlusTM

Crisper

Use the crisper to store

goods.

vegetables, fruit or small

FlexStor® bins

Slide the bins to meet

diﬀerent storage needs.

To remove, lift and tilt.

and push down until

To replace, tilt the top

locked in place.

Egg tray

Removable egg tray

provided for your

convenience.

Door storage bin

The door bin can be

removed by lifting it

up over the support

lugs. To replace, push

down

over the support

lugs to lock in place.

Bottle storage bin

Use the bottle bin for tall

bottle bin can be

bottle storage. The

removed by lifting it up

over the support lugs.

To replace, push down

lock in place.

over the support lugs to

EMT5704 illustrated

control

Freezer temperature

Anti-Oxidant Filter

Quick

Chill

Colder

Less

Cold

Mid

Temp

Quick Chill

Hold 3sec

7EN

Features may vary depending on model. Not all models will have features listed.

BOTTOM MOUNT REFRIGERATOR FEATURES

Refrigerator/freezer control panel

From this panel you can control the temperature of the

refrigerator and freezer compartments as well as setting the

quick freeze function or resetting the door alarm.

For further information on how to use this feature refer to the

section “About the User Interface”.

deli

TasteGuard Deodoriser

FlexStor™ door bins

Door bin

bin

EBE5304 illustrated

8 www.electrolux.com

4. TEMPERATURE CONTROL

4.1 TEMPERATURE CONTROL

If you want to change the temperature, follow

the instructions in the section About the User

Interface for your model. Ensure that you make

only small adjustments and wait 24 hours to see

if it’s to your liking.

IMPORTANT

NOTE: When you set a temperature, you

set an average temperature for the

whole refrigerator cabinet.

Checking the softness of ice cream is a

good indication that your freezer is the

right temperature, while checking the

temperature of water kept in the

refrigerator is a good way of checking

the temperature of the food

compartment.

Temperatures inside each compartment

may vary, depending on how much food

you store and where you place it.

High or low room temperature may

also aﬀect the actual temperature inside

the refrigerator

Top mount freezer temperature adjustment

1. Select the freezer control.

2. Slide the control to the right

(as per image below).

3. Slide the control to the left

(as per image below).

Freezer temperature setting recommedation

Set to less cold

Normal

Summer (>35°c)

Winter (<15°c) Set to colder

Freezer Temp

Less

Cold

Less

Cold

Less

Cold

Colder

9EN

4.2 ABOUT THE USER INTERFACE

Control – EMT5704 Model

Temperature

adjust/quick chill

on/oﬀ button

Refrigerator

scale icons

temperature

Quick

Chill

Colder

Less

Cold

Mid

Temp

Quick Chill

Hold 3sec

Quick chill

on/oﬀ icon

Description Opration / Primary Function

Refrigerator temperature

scale icons

• Indicates the temperature setting of the refrigerator

compartment.

Quick Chill On/ O˜ icon • Indicates the status of the Quick Chill function

Temperature adjust/ quick

chill on/ oﬀ button

Temperature Control

• Touch the ‘Temp’ button to awaken control.

• Touch the ‘Temp’ button to decrease the refrigerator

temperature. Once the coldest temperature is reached the

display will return to the warmest setting with the next press.

Quick Chill

• Use the quick chill function when you add a large amount of

food to the refrigerator compartment.

• Press and hold the ‘Temp’ button for 3 seconds. The Quick Chill

icon will ﬂash indicating that the Quick Chill is active.

• Your refrigerator will run at 2°C for 90 minutes, then

automatically return to normal mode.

• The Quick Chill function can be cancelled anytime by pressing

the‘Temp’ button again.

Sabbath Mode • Press and hold button ‘Temp’ for 5 seconds.

• When enabled/disabled an alarm long beep 1 time and Top 2

LED on temp setting will appear on display when active.

IMPORTANT

The factory default settings for the refrigerator is “Mid”. If you want to change the

temperature, remember to make only small adjustments and wait 24 hours to see

if it’s correct.

10 www.electrolux.com

Control – EBE5304 Model

Button

/ Icon Description Primary Function

1Compartment Selector button Selects controllable compartment.

2 Lock Icon Indicates if the user interface is locked.

3 Compartment Icon Indicates controllable compartment.

4 ECO Icon Indicates if the appliance is operating in its most

energy eﬃcient mode.

5Digital display Indicates temperature of selected compartment.

6 Decrease button Decreases temperature of selected compartment.

7 Increase button Increases temperature of selected compartment.

8 Mode indicators

(Boost, Fast Ice, Holiday)

Indicates appliance operation mode.

9 Display Lock button Selects lock state of user interface.

10 Display Lock button Selects operation mode of appliance.

11 Drinks Chill button Selects drinks chill timer.

12 Door sensor Senses door state (open or closed).

IMPORTANT

The factory default settings for the refrigerator is “3°C” and “-18°C” for the freezer.

If you want to change the temperature, remember to make only small adjustments

and wait 24 hours to see if it’s correct.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Refrigerador de Electrolux

Electrolux

Electrolux ER 7020 D Manual de usuario

Electrolux

Electrolux ERD 43393 X Manual de usuario

Electrolux

Electrolux E42BS75ETT - 42" - Refrigerator Instrucciones de funcionamiento

Electrolux

Electrolux ERF4113AOW Manual de usuario

Electrolux

Electrolux IK159SL Manual de usuario

Electrolux

Electrolux ERY1401AOW Manual de usuario

Electrolux

Electrolux SANTO 72398-6 KA Manual de usuario

Electrolux

Electrolux SMART RH14DFD2FU 726485 Manual de usuario

Electrolux

Electrolux U24384 ER 7826/1 B Manual de usuario

Electrolux

Electrolux RF555A Manual de instrucciones

Electrolux

Electrolux IK2805SZR Manual de usuario

Electrolux

Electrolux S64246KA Manual de usuario

Electrolux

Electrolux ER 8225 B.60 Manual de usuario

Electrolux

Electrolux ENB 40400 X Manual de usuario

Electrolux

Electrolux ERA 39375 W Manual de usuario

Electrolux

Electrolux ERC2805 Manual de usuario

Electrolux

Electrolux ERG47800 Manual de usuario

Electrolux

Electrolux ERES31800 Manual de usuario

Electrolux

Electrolux SC310 Manual de usuario

Electrolux

Electrolux ER 6633 I Manual de usuario

Electrolux

Electrolux WRT21MG3AW6 Manual de usuario

Electrolux

Electrolux U24226 ERC3709 Manual de usuario

Electrolux

Electrolux RM2012 Manual de usuario

Electrolux

Electrolux ERN 16300 Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario

Teledyne

Teledyne 6712FR and Instrucciones de funcionamiento
