EN Refrigeration User manual

A12081680-A-362021

2 www.electrolux.com

CONTENTS

1. SAFETY INFORMATION ............................................................................................................... 3

2. SAFETY INSTRUCTION .............................................................................................................. 4

3. DESCRIPTION OF THE APPLIANCE ...................................................................................... 6

4. TEMPERATURE CONTROL ......................................................................................................... 8

5. INSTALLING YOUR NEW REFRIGERATOR ......................................................................... 11

6. USING YOUR REFRIGERATOR ................................................................................................ 12

7. CLEANING THE REFREIGERATOR FOOD ......................................................................... 17

8. FOOD STORAGE GUIDE ........................................................................................................... 18

9. TROUBLESHOOTING .................................................................................................................. 19

10. NOISES ............................................................................................................................................... 22

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings

with it decades of professional experience and innovation. Ingenious and stylish, it

has been designed with you in mind. So whenever you use it, you can be safe in the

knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website to:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com

www.electrolux.com/productregistration

Buy Accessories, Consumables and Original spare parts for your

appliance: www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

We recommend the use of original spare parts.

When contacting Service, ensure that you have the following data available. The

information can be found on the rating plate. Model, PNC, Serial Number

Warning / Caution-Safety information.

General information and tips

Environmental information.

Subject to change without notice.

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully read the

supplied instructions. The manufacturer is not responsible if an

incorrect installation and use causes injuries and damages. Always

keep the instructions with the appliance for future reference.

1.1 Children and vulnerable people safety

• This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved.

• Do not let children play with the appliance.

• Keep all packaging away from children.

• Cleaning and user maintenance shall not be made by

children without supervision.

1.2 General Safety

• This appliance is intended to be used in household and

similar applications such as:

– Farm houses; staff kitchen areas in shops, ofﬁces and

other working environments

– By clients in hotels, motels, bed and breakfast and other

residential type environments

• Keep ventilation openings, in the appliance enclosure or in

the built-in structure, clear of obstruction.

• Do not use mechanical devices or other means to

accelerate the defrosting process, other than those

recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type

recommended by the manufacturer.

• Do not use water spray and steam to clean the appliance.

• Clean the appliance with a moist soft cloth. Only use

neutral detergents. Do not use abrasive products, abrasive

cleaning pads, solvents or metal objects.

• Do not store explosive substances such as aerosol cans

with a ﬂammable propellant in this appliance.

English 3

4 www.electrolux.com

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualied persons

in order to avoid a hazard.

• If the appliance is equipped with an Ice maker or a water

dispenser, ll them with potable water only.

• If the appliance requires a water connection, connect it to

potable water supply only.

• The inlet water pressure (minimum and maximum)must be

between 1 bar (0,1 MPa) and 10 bar (1 MPa)

2. SAFETY INSTRUCTIONS

2.1 Installation

WARNING!

Only a qualied person must install

this appliance.

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Obey the installation instruction

supplied with the appliance.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Make sure the air can circulate around

the appliance.

• Wait at least 4 hours before connecting

the appliance to the power supply. This

is to allow the oil to ow back in the

compressor.

• Do not install the appliance close to

radiators or cookers, oven or hobs.

• The rear of the appliance must stand

against the wall.

• Do not install the appliance where there

is direct sunlight.

• Do not install this appliance in areas

that are too humid or too colds, such

as the construction appendices,

garages or wine cellars.

• When you move the appliance, lift it by

the front edge to avoid scratching the

oor.

2.2 Electrical connection

WARNING!

Risk of re and electrical shock.

• The appliance must be earthed.

• All electrical connections should be

made by a qualied electrician.

• Make sure that the electrical information

on the rating plate agrees with the

power supply. If not, contact an

electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to the

electrical components (e.g. mains plug,

mains cable, compressor). Contact the

Service or an electrician to change the

electrical components.

• The mains cable must stay below the

level of the mains plug.

• Connect the mains plug to the

mains socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

2.3 Use

WARNING!

Risk of injury, burns, electrical

shock or re.

• Do not change the specication of this

appliance.

• Do not put electrical appliances (e.g.

ice cream makers) in the appliance

unless they are stated applicable by the

manufacturer.

• Be careful not to cause damage to the

refrigerant circuit. It contains isobutane

(R600a), a natural gas with a high level

of environmental compatibility. This gas

is ammable.

• If damage occurs to the refrigerant

circuit, make sure that there are no

ames and sources of ignition in the

room. Ventilate the room.

• Do not let hot items to touch the plastic

parts of the appliance.

• Do not put soft drinks in the freezer

compartment. This will create pressure

on the drink container.

• Do not store ammable gas and liquid

in the appliance.

• Do not put ammable products or items

that are wet with ammable products

in, near or on the appliance.

• Do not touch the compressor or the

condenser. They are hot.

• Do not remove or touch items from the

freezer compartment if your hands are

wet or damp.

• Do not freeze again food that has been

thawed.

• Obey the storage instructions on the

packaging of frozen food.

2.4 Internal light

• The type of lamp used for this appliance

is not suitable for household room

illumination.

English 5

2.5 Care and cleaning

WARNING!

Risk of injury or damage to the

appliance.

• Before maintenance, deactivate the

appliance and disconnect the mains

plug from the mains socket.

• This appliance contains hydrocarbons

in the cooling unit. Only a qualied

person must do the maintenance and

the recharging of the unit.

• Regularly examine the drain of the

appliance and if necessary, clean it. If

the drain is blocked, defrosted water

collects in the bottom of the appliance.

2.6 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door to prevent children

and pets to be closed inside of the

appliance.

• The refrigerant circuit and the insulation

materials of this appliance are ozone-

friendly.

• The insulation foam contains ammable

gas. Contact your municipal authority

for information on how to discard the

appliance correctly.

• Do not cause damage to the part of

the cooling unit that is near the heat

exchanger.

BOTTOM MOUNT REFRIGERATOR FEATURES

EBE4500B

TasteGuard Deodoriser

NutriPlusTM

Anti-Oxidant Filter

Crisper

Use the crisper to store

vegetables, fruit or small

goods.

Twist & Serve Ice

Refer to the section

“Using your

Refrigerator” for details

on removing, relocating

and using this feature

Freezer storage bins

Refer to the section

“Using your Refrigerator”

for details on removing,

and using this feature.

FlexStor® bins

Slide the bins to meet

diﬀerent storage needs.

To remove, lift and tilt.

To replace, tilt the top

and push down until

locked in place.

Egg tray

Removable egg tray

provided for your

convenience.

Door storage bin

The door bin can be

removed by lifting it up

over the support lugs. To

replace, push down over

the support lugs to lock in

place.

Bottle storage bin

Use the bottle bin for tall

bottle storage. The bottle

bin can be removed by

lifting it up over the

support lugs. To replace,

push down over the

support lugs to lock in

place.

EBE4500 illustrated

Refrigerator/freezer control panel

From this panel you can control the temperature of the

refrigerator and freezer compartments as well as setting the

quick freeze function or resetting the door alarm.

For further information on how to use this feature refer to the

section “About the User Interface”.

Features may vary depending on model. Not all models will have features listed.

Quick

Freeze

0°

3°

7°

-14°

-18°

-23°

Temp

Zone

6www.electrolux.com

Features may vary depending on model. Not all models will have features listed.

BOTTOM MOUNT REFRIGERATOR FEATURES

Refrigerator/freezer control panel

From this panel you can control the temperature of

the refrigerator and freezer compartments as well

as setting the quick freeze function or resetting the

door alarm.

For further information on how to use this feature

refer to the section “About the User Interface”.

deli

TasteGuard Deodoriser

FlexStor™ door bins

Door bin

bin

EBE5304 illustrated

EBE5304

English 7

DESCRIPTION

Quick Freeze on/ oﬀ icon

OPERATION / PRIMARY FUNCTION

• Indicates the status of the Quick Freeze function.

Use the Quick Freeze function when you add a large amount of food to the

freezer compartment.

• Press the ‘Quick Freeze’ button. The Quick Freeze icon

will ﬂash indicating that

the quick freeze is active and the compressor will run continuously for 90 minutes.

• After 90 minutes the freezer will automatically return to normal mode.

• The Quick Freeze function can be cancelled anytime by pressing the

button again.

• Indicates the temperature setting of the refrigerator compartment.

• Indicates the temperature setting of the freezer compartment.

• Touch any button to awaken control.

• Touch the the ‘Temp’ button to decrease the selected compartment temperature.

Quick Freeze button

Refrigerator / Freezer

temperature scale icons

Temperature adjust button

Refrigerator/Freezer

indication icon Compartment

select button

IMPORTANT

There are 8 temperature settings indicated by the illumination sequence on the

display. Once the coldest temperature is reached the display will return to the

warmest setting with the next press.

• Indicates the selected zone.

• Press to select the desired compartment.

• The refrigerator / freezer indication icon will show which zone is selected.

The factory default settings for the refrigerator is “3°C” and “-18°C” for the freezer. If you want to change the

temperature, remember to make only small adjustments and wait 24 hours to see if it’s correct.

ABOUT THE USER INTERFACE

Control – EBE4500B Model

Quick freeze on/oﬀ icon

Quick

Freeze

Temp

-14º

-18º

-23º 0º

3º

7º

Zone

Refrigerator temperature

scale icons

Freezer indication icon

Temperature adjust

Refrigerator indication icon

Compartment select button

Quick freeze button

Freezer temperature

scale icons

8www.electrolux.com

Control – EBE5304 Model

Button

/ Icon Description Primary Function

1Compartment Selector button Selects controllable compartment.

2 Lock Icon Indicates if the user interface is locked.

3 Compartment Icon Indicates controllable compartment.

4 ECO Icon Indicates if the appliance is operating in its most

energy eﬃcient mode.

5Digital display Indicates temperature of selected compartment.

6 Decrease button Decreases temperature of selected compartment.

7 Increase button Increases temperature of selected compartment.

8 Mode indicators

(Boost, Fast Ice, Holiday)

Indicates appliance operation mode.

9 Display Lock button Selects lock state of user interface.

10 Display Lock button Selects operation mode of appliance.

11 Drinks Chill button Selects drinks chill timer.

12 Door sensor Senses door state (open or closed).

The factory default settings for the refrigerator is “3°C” and “-18°C” for the freezer.

If you want to change the temperature, remember to make only small adjustments

and wait 24 hours to see if it’s correct.

IMPORTANT

English 9

Function Icon Operation (depending on model)

Setting the temperature Press button 1 to select compartment on icon 3

Press buttons 6 or 7 to adjust temperature up or

down.

Boost mode

Increases the chill rate of the

refrigerator for 90mins before

returning to pre-set mode.

Boost mode

Increases the chill rate of the refrigerator for 90mins

before returning to pre-set mode.

Fast Ice

Decreases the freezer

temperature to -23°C for 12

hours before returning to pre-

set mode.

Press button 10 until the fast ice icon is illuminated.

Fast ice mode can be deselected using button 10.

Holiday mode

The refrigerator minimises

defrosting to save energy

when doors remain closed for

an extended period.

Press button 10 until the holiday icon is illuminated.

When holiday mode is enabled the temperature

settings will be set to 3°C for the refrigerator and

-18°C for the freezer.

Holiday mode can be deselected using button 10

or opening the fridge door. When holiday mode is

disabled the temperature settings will revert to the

previous settings.

Holiday mode can be deselected using button 10 or

opening the fridge door.

Display Lock

Deactivates the user interface

controls.

To turn on/oﬀ press and hold button 9 for 3 seconds,

the lock icon is illuminated when activated.

Drinks Chill

Sets a timer for between 1 and

30 minutes as a reminder for

when drinks are placed in the

freezer for quick chill.

To turn on press button 11 and initial time of 20 mins

will appear on digital display. To adjust time use

buttons 6 and 7.

Alarm will sound when time is ﬁnished.

Press button 11 to turn oﬀ during or after countdown.

The time taken to chill depends on the size of your

bottle.

Do not leave the bottle inside the freezer longer

than the time needed for chilling.

Sabbath Mode

Disables all lights and

other electrical activity

from occurring when the

refrigerator door is opened.

To enable and disable Sabbath mode, press and

hold buttons 6 and 9 for 3 seconds.

When enabled/disabled an alarm will beep 4 times

and “Sb” will appear on digital display when active.

Indicator Icon Operation

Eco Mode

Enabled when appliance set

to energy eﬃcient operating

temperatures.

ECO icon automatically appears when refrigerator

is set between +3°C and +7°C and freezer is set

between -14°C and -18°C

FUNCTIONS OF THE USER INTERFACE

The factory default settings for the refrigerator is “3°C” and “-18°C” for the freezer.

If you want to change the temperature, remember to make only small adjustments

and wait 24 hours to see if it’s correct.

IMPORTANT

10 www.electrolux.com

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Refrigerador de Electrolux

Electrolux

Electrolux ERB23000W Manual de usuario

Electrolux

Electrolux E42BS75ETT - 42" - Refrigerator Instrucciones de funcionamiento

Electrolux

Electrolux ENB3669 Manual de usuario

Electrolux

Electrolux LNT6ME36U2 Manual de usuario

Electrolux

Electrolux ERF3310AOW Manual de usuario

Electrolux

Electrolux EN93852JX Manual de usuario

Electrolux

Electrolux ERY1401AOV Manual de usuario

Electrolux

Electrolux EI23CS55GS - 22.5 cu. ft. Refrigerator Manual de usuario

Electrolux

Electrolux ETB4600 Manual de usuario

Electrolux

Electrolux Icon 242000100 Manual de usuario

Electrolux

Electrolux ERN29651 Manual de usuario

Electrolux

Electrolux RM212,F Manual de usuario

Electrolux

Electrolux JUNO JKG 8498 Manual de usuario

Electrolux

Electrolux Prostore PS06R1F 691179 Manual de usuario

Electrolux

Electrolux IK1910SZR Manual de usuario

Electrolux

Electrolux IK2355BR Manual de usuario

Electrolux

Electrolux NB430J Manual del propietario

Electrolux

Electrolux ERF3864AKW Manual de usuario

Electrolux

Electrolux ERN 1672 Manual de usuario

Electrolux

Electrolux IK283S Manual de usuario

Electrolux

Electrolux RF616D Manual de instrucciones

Electrolux

Electrolux Ecostore 727375 Cómo utilizar

Electrolux

Electrolux ERA 34391 W Manual de usuario

Electrolux

Electrolux EI23BC51IS0 Manual de usuario

Manuales populares de Refrigerador de otras marcas

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manual de usuario

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manual de usuario

Sharp

Sharp SJ-BA31IEXW2-EU Manual de usuario

CORBERO

CORBERO CC2300MCW Manual de usuario

KitchenAid

KitchenAid 2205264 Manual de usuario

Stengel

Stengel KU 1101 A++ Manual de usuario

NEFF

NEFF KI181 Series Manual de usuario

Hoshizaki

Hoshizaki Reach-In Manual de usuario

Amana

Amana ASD2524VES00 Manual de usuario

BOMANN

BOMANN KGC 213 Manual de usuario

Danby

Danby DAR044A1SLDD Instrucciones de montaje

Samsung

Samsung RF323TE Manual de usuario

Beko

Beko CSA31022 Manual de usuario

IKEA

IKEA FROSTIG C 185 E Manual de usuario

True

True TS-28 Manual de usuario

Frigidaire

Frigidaire FSC23R5DW9 Manual de usuario

Beko

Beko LSP4579W Manual de usuario

Teledyne

Teledyne 6712FR and Instrucciones de funcionamiento
