Electrolux 970-6874 Manual de instrucciones

970-68612.eps T20G0097.eps T20V0231.eps T20T0205.eps T20D0061.eps

SEARS CANADA

Product No. 970-687420

Series 30" f/s elec

Color white

Market Canada

Owner's Guide 316417286

Installation Instructions 316259203

Service Data Sheet 316458450

Electrolux Major Appliances

North & Latin America

5855 TERRY FOX WAY

MISSISSAUGA, ONTARIO, CANADA L5V

3E4 Publication No.

5995502852

07/10/24

(EN/SERVICE/ECL)

369

30-INCH FREE-

STANDING ELECTRIC

RANGE

Model No.

970-6874

Publication No: 5995502852 970-687420

10/07 2

BACKGUARD

970-687420 Publication No: 5995502852

# Functional Parts 3 10/07

* Non-Illustrated Parts

BACKGUARD

POS. NO PART NO. DESCRIPTION

1 316416100 Shield, backguard, rear wall

13A 316095502 Switch, infinite, warmer

14 316022500 Light/Lamp, indicator, 125 V

15 316411403 Support, backguard, white, RH

15A 316411402 Support, backguard, white, LH

19 316402715 Panel, backguard, white

20 # 316462802 Controller, electronic, ES535

20A 316419801 Overlay, clock, white, ES515

27 5303935217 Switch, simmer select, push button, w/white bezel

28 316219300 Button, simmer select, white

31 316442400 Knob, control, white

31A 316442403 Knob, warm zone, white

31B 316442409 Knob, dual control, white

31C 316442406 Knob, simmer, white

46 316437800 Lens-light/lamp, indicator, clear

54 # 316436000 Switch, infinite, small element

54A# 316436001 Switch, infinite, large element

54B# 316238200 Switch, infinite, triple

56 316234012 Shield, backguard, white, inner

69 5303288565 Screw, truss sqdr, 8-32 x 3/16, switch mtg

77 316247900 Spacer, power board, (3)

77A 316114100 Spacer, (4)

97 316418101 Board, cooktop lockout

97A 316429301 Board, simmer select

100 5303289910 Screw, 8A, 1", power board mtg

* # 316525609 Harness, wiring, lockout

* 316417286 Owners Manual

* 316458450 Service Tech Sheet, w/wiring diagrm

* 316259203 Instructions, installation

* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black

* 316021109 Screw, 8-18 x 0.5, chrome

* 316021110 Screw, 8-18 x 0.5, black

Publication No: 5995502852 970-687420

10/07 4

BODY

970-687420 Publication No: 5995502852

# Functional Parts 5 10/07

* Non-Illustrated Parts

BODY

POS. NO PART NO. DESCRIPTION

1 316401800 Panel, main back

3 316400116 Panel, bodyside, white, RH

3 316400117 Panel, bodyside, white, LH

5 316272900 Screw, leveling, plastic, rear, (2)

5A 316498900 Leveling Leg Assy, metal, front, (2), bracket & leg

6A 316425800 Rack, oven, w/handle

6B 316425700 Rack, oven sump

8 316400601 Panel, oven bottom

8* 316064600 Support, oven bottom

8A 316411104 Base, bake element

9 316081900 Pan, broilerOPTIONAL ACCESS0RY

10 316082000 Insert, broiler panOPTIONAL ACCESS0RY

12 316445500 Switch, oven light, door frame

14 316116400 Receptacle, oven light

15 5303013071 Bulb/Lamp, light

16 08011086 Lens, oven light, glass

17 316087500 Retainer, lens

18 # 316405800 Latch Assembly, oven door

21 316408000 Clip, bodyside

26 316409000 Shield, warmer side, (2)

33A 316402100 Shield, rear wall, lower

37 # 316490000 Probe, oven temp

39 # 318113108 Cord, electric

42 316400702 Shield, wool, lower

43 3131732 Screw, 8-18 x 1.438, oven bottom

44 316517600 Spacer, oven door

45 316234100 Shield, wire, vent tube

57 316457800 Cover, access

58 316403802 Insulation, oven sump

58A 316406600 Insulation, oven wrapper

58B 316406500 Insulation, oven back

59 316208401 Vent Tube, assembly, w/catalyst

59A 316208304 Tube, oven vent, upper

62 5303935061 Terminal Block Kit

62* 316205500 Nut, hex flange, 3/8 10-32

66 # 316203301 Element, broil

67 316413800 Element, bake, hidden

68 316404000 Support, element, broil

71 316422304 Shield, rear wall

77 316456700 Glide, warmer drawer, outer/RH & LH, (2)

86 316530700 Receptacle, hinge

86* 316418901 Screw, trilobe, 10-32 x 5/16"

87 316081202 Bracket, cable mtg

88 316203500 Rod, auto latch

89 # 316464301 Motor-latch

106 316404100 Bracket, motor mtg.

107 316026701 Cover, fan

108# 316415800 Motor, fan

109 316136400 Blade, fan

111 316136600 Nut, fan retainer

151 316404600 Shield, bodyside

161# 316211603 Element, convection fan, 350 W

170 5303935180 Anti-tipKit, w/bracket, screw

170* 316107200 Bracket, anti-tip

170* 316112500 Template, anti-tip

170* 316116000 Screw, concrete, 1.75", anti-tip brkt

* # 316506240 Wiring Harness, main

* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black

* 316021110 Screw, 8-18 x 0.5, black

* 316021132 Screw, 8-18 X 11/16, black

* 316089500 Screw, 10-16 x .486

* 5303271648 Screw, wafer hd sq dr, 8-18AB x 0.5

* 5303285179 Screw, wafer head, 8-32T x 0.500, black

* 5308014215 Screw, 6-20 x 0.312

Publication No: 5995502852 970-687420

10/07 6

TOP/DRAWER

970-687420 Publication No: 5995502852

# Functional Parts 7 10/07

* Non-Illustrated Parts

TOP/DRAWER

POS. NO PART NO. DESCRIPTION

1 316408901 Drawer, warmer

2 316403303 Liner, drawer

4 316403509 Panel, drawer front, white

13 316415002 Glide, warmer, inner RH

13A 316415001 Glide, warmer, inner LH

15 # 318178110 Element, surface, 6", 1200, (2), radiant

15A# 316465001 Element-surface, 6"/9", 3000W, dual radiant

15B# 316464901 Element-surface dual, 1700W/2700W

15C# 318198832 Element, surface, warmer, 100 W

16 316456274 Main Top, smooth top, white

26 316427600 Channel, element support, (2)

26A 316498200 Bracket-support, chassis, aluminum

26B 316214200 Bracket, chassis support, front

39 316235407 Handle, drawer, white

52 316461700 Clip, element mtg

81 # 316437300 Element, warmer drawer

82 316093200 Bracket, element mtg

83 316093300 Shield, terminal, warmer drawer

84 316093501 Thermo disc, warmer drawer

85 316425900 Rack, warmer drawer

86 316095800 Clip, hold down, warmer element

87 316091900 Base, warmer drawer

* # 316466732 Harness-wiring, surface

* 316001917 Harness, warmer drawer

* 316112100 Cleaner, cooktop

* 316021105 Screw, hex head cup pt, 8-18 x 0.375, black

* 316021109 Screw, 8-18 x 0.5, chrome

* 316021110 Screw, 8-18 x 0.5, black

* 5308014215 Screw, 6-20 x 0.312

Publication No: 5995502852 970-687420

10/07 8

DOOR

970-687420 Publication No: 5995502852

# Functional Parts 9 10/07

* Non-Illustrated Parts

DOOR

POS. NO PART NO. DESCRIPTION

3 5303935243 Trim kit-door, 3 sided, white, w/tape

4 316427007 Glass, oven door, white, outer

6 316503801 Shield, wool

7 316513000 Insulation, oven door

8 316502500 Glass, door, inner, (2)

9 316503607 Liner, oven door

10 316433300 Screw, 10-14 x 2.125", handle mtg.

10B 316008401 Washer, 3/4 OD x 1/4 ID, steel

12 316405000 Seal, oven door

16 316502600 Glass, door, airwash

17 316502101 Spacer, door glass, (2)

20 316533800 Plate, distribution, load

23 316530600 Hinge, oven door

23* 316418900 Screw, sims lp, #8-32 x 5/16", black

39 316443601 Handle, oven door, white

40 316530401 Bracket, airwash glass, (2)

52 316468500 Cap, door trim, white

60B 316021110 Screw, 8-18 x 0.5, black

* 316021109 Screw, 8-18 x 0.5, chrome

* 5303285179 Screw, wafer head, 8-32T x 0.500, black
