user manual

Built-In Electric Oven

EOK86030

We were thinking of you

when we made this product

electrolux 3

Welcome to the world of Electrolux

Thank you for choosing a first class

product from Electrolux, which hopefully

will provide you with lots of pleasure in

the future. The Electrolux ambition is to

offer a wide variety of quality products

that make your life more comfortable.

You will find some examples on the cov-

er in this manual. Please take a few min-

utes to study this manual so that you

can take advantage of the benefits of

your new machine. We promise that it

will provide a superior User Experience

delivering Ease-of-Mind. Good luck!

4electrolux contents

Contents

Safety instructions 5

Description of the Appliance 10

Before using for the first time 13

Operating the Oven 15

Usage, Tables and Tips 38

Cleaning and care 60

What to do if … 63

Installation Instructions 65

Disposal 69

Guarantee/Customer Service 70

Index 73

Service and Spare Parts 74

he following symbols are used in this user manual:

Important information concerning your personal safety and information on

how to avoid damaging the appliance.

3General information and tips

2Environmental information

safety instructions electrolux 5

Safety instructions

This appliance conforms with the

following EU Directives:

–73/23/EEC dated 19.02.1973 Low

Voltage Directive

–89/336/EEC dated 03.05.1989 EMC

Directive inclusive of Amending Di-

rective 92/31/EEC

–93/68/EEC dated 22.07.1993 CE

Marking Directive

Electrical safety

•This appliance must be connected

by a qualified electrician only.

•In the event of a fault or damage to

the appliance: take the fuses out or

switch off.

•Should the door seal and the door

seal surfaces be damaged, the ap-

pliance must not be operated until

they are repaired.

•Repairs to the appliance must only

be carried out by qualified serv-

ice engineers. Considerable dan-

ger may result from improper repairs.

If repairs become necessary, please

contact your local Service Force

Centre.

Children’s safety

•Small children must be kept away

from the appliance. Make sure that

children do not touch the appliance

when playing.

•Always heat baby food in jars or bot-

tles with the lid or top off. After heat-

ing, stir well or shake so that the heat

is evenly distributed. Before you give

the baby food to the child, please

be sure to test the temperature.

•When operating the grill (alone or in

combination with the microwave) the

viewing window becomes hot.

Therefore keep small children away

from the door of the appliance.

•The appliance is fitted with a child

safety device.

Safety whilst Using

•This appliance is intended to be

used for cooking, roasting and bak-

ing food in the home.

•Take care when connecting electric

appliances to sockets nearby. Do

not allow connecting leads to come

into contact with or to catch beneath

the hot oven door.

•Warning: Risk of burns! The interi-

or of the oven becomes hot during

use.

•Using ingredients containing alcohol

in the oven may create an alcohol-air

mixture that is easily ignited. In this

case, open the door carefully. Do not

have embers, sparks or naked

flames in the vicinity when opening

the door.

Information about acrylamides

According to the latest scientific re-

search, intensive browning of food,

especially in products containing

starch, may present a health risk

due to acrylamide. Therefore we

recommend cooking at low temper-

atures and not browning foods too

much.

6electrolux safety instructions

Microwave

•Only switch the appliance on when

there is food inside it. Without food

inside it, the appliance could be

overloaded.

•Only use microwave-safe cook-

ware (see chapter Usage, Tables and

Tips / Suitable Cookware and

Material).

•To protect the interior or the door of

the appliance from corrosion through

escaping steam (condensed water),

please dry the appliance with a cloth

after each use.

•Do not leave the appliance unattend-

ed if food is being heated or cooked

in disposable containers made of

plastic, paper or other flammable

materials.

•If smoke appears, keep the appli-

ance closed. Switch off the appli-

ance and disconnect from the power

supply. Do not use the appliance un-

der any circumstances if it is no long-

er working correctly.

•When heating liquids always put a

coffee spoon or a glass rod in the

container to avoid delay in boiling.

With delay in boiling the boiling tem-

perature is reached without the

typical steam bubbles rising. If the

container is shaken even slightly the

liquid can suddenly boil over or spray

violently. Risk of burns!

•Prick food with „skin“ or „peel“, such

as potatoes, tomatoes, sausages,

with a fork several times before

cooking so that the food does not

burst.

safety instructions electrolux 7

Ensure that a minimum temperature of

70 °C is reached when cooking/ heating

food. For this please refer to the power

and time data in the tables. Never use

mercury or liquid thermometers to

measure the temperature of the food.

•Foods heated with microwaves give

off heat to the cookware. Use oven

gloves or something similar.

•Do not overcook the dishes by using

powers and times that are too high.

The food can dry out, burn or set it-

self alight in certain places.

•The interior of the oven, the grill heat-

ing element and the accessories be-

come hot when the appliance is

operating. Please be careful when

handling them and use oven gloves

or similar.

Risk of burns!

•Metal objects must be at least 2 cm

from the walls of the interior and the

oven interior door. Otherwise spark

discharge can occur and the appli-

ance can be damaged.

•If not advised otherwise, do not use

aluminium foil.

•Do not get anything caught between

the door and the door frame.

•Always keep the door seal, the door

seal surfaces and the interior clean.

Lack of cleanliness in the appliance

can lead to dangerous situations.

•Do not store any flammable objects

inside the oven. These could ignite

when the oven is switched on.

8electrolux safety instructions

How to avoid damage to the

appliance

•Do not line the oven with aluminium

foil and do not place baking trays,

pots, etc. on the oven floor, as the

heat that builds up will damage the

oven enamel.

•Fruit juices dripping from the baking

tray will leave stains, which you will

not be able to remove. For very moist

cakes, use a deep tray.

•Do not put any strain on the oven

door when open.

•Never pour water directly into the

oven when it is hot. This could cause

damage to the enamel and discolor-

ation.

•Rough handling, especially around

the edges of the front panel, can

cause the glass to break.

•Do not store any flammable materi-

als inside the oven. These could ig-

nite when the oven is switched on.

•Do not store any moist foods inside

the oven. This could damage the

oven enamel.

•After switching off the cooling fan, do

not keep uncovered dishes in the ov-

en. Moisture may condense in the

oven interior or on the glass doors

and may get into the units.

Note on enamel coating

Changes in the colour of the oven’s

enamel coating as a result of use do not

affect the appliance’s suitability for nor-

mal and correct use. They therefore do

not constitute a defect in the sense of

the warranty law.

safety instructions electrolux 9

Do not use the appliance...

... for cooking eggs in their shells (with

fried eggs, pierce the yolks first) and

snails, as otherwise these burst,

... for heating large amounts of cooking

oil (fondue, deep frying) and drinks with

high alcohol content. Spontaneous

combustion! Risk of explosion!

... for heating tightly closed containers,

e. g. tins, bottles, screw top jars,

... for drying animals, textiles, seeds and

gel pillows, and other inflammable ma-

terials: Danger of fire!

... for cookware made of porcelain, ce-

ramic or earthenware that has small

holes, e. g. on handles or unglazed bot-

toms. Moisture penetrating small holes

can cause the cookware to crack when

it is heated.

10 electrolux description of the appliance

Description of the Appliance

General Overview

If no function is selected and noth-

ing is changed on the appliance, the

appliance switches itself off, but the

light bars remain on.

To switch the light bars off, switch

the appliance on using the Start

button and switch it off again using

the Stop button (press twice).

Oven door

Control panel

Door

handle

Light bars.
