Vegetable slicers

Food processors

Combined machines

Quality,

Speed,

Performance

Bring vegetable preparation to

the next generation.

TRS

TRS - Vegetable slicers

Thanks to the vast selection of cutting discs, this new

and improved vegetable slicer guarantees outstanding

cut quality in addition to superior performance. All

types of vegetable preparations such as slicing, dicing,

shredding and julienne can be obtained with a simple

touch of a button. Cleaning made easy: all parts can be

dismantled without tools and are dishwasher safe.

K - Food processors

Able to chop, mash, mix, knead, and emulsify everything

from fresh salads, potatoes and pastry doughs to meats,

fruits, nuts and vegetables. New ergonomics, increased

capabilities and easier cleaning are only a few of the

advantages which make the K series food processors an

essential item in every kitchen.

TRK – Combined cutter-slicers

2 in 1! The ultimate in vegetable preparation. Slice, dice,

julienne, and grate with the vegetable slicer attachment or

chop, grind, puree and knead with the cutter attachment.

The specially designed base can easily be adjusted:

inclined for slicing vegetables and level for emulsifying,

thus adding to the superior quality and durability of the

TRK machines.

A new range of machines specially designed to slice, dice, shred, grate or

emulsify anything you require.

K 45/55/70

TRK 45/55/70

electrolux dito TRS / K / TRK

TRS

Vegetable slicers

Outstanding quality, superior performance. The ideal solution for slicing,

dicing, grating, shredding, and much more.

A vast assortment of slicing discs

allows vegetable preparations to be

performed quickly and easily

More than 70 different types of

slices ranging from the most simple to

the most creative

Long lifetime thanks to the durable

stainless steel construction

Maximum cleanability due to the

ergonomic design with rounded

shapes. All parts in contact with food

are either in stainless steel or plastic

Compact, powerful and with

angled base (20°) makes loading and

unloading operations quick and easy

Large hopper guarantees a higher

output and allows vegetables of large

size and unusual shapes to be easily

inserted

•

4 electrolux dito TRS / K / TRK

Touch button controlLong vegetable hopper

TRS

Speed Phases Power RPM

1 speed 1 ph 1/2 hp 430

1 ph 2/3 hp 430

1 ph 1 hp 430

2 speeds 3 ph 1 hp 430-870

External dimensions (wxdxh) 915/16”x1911/16”x193/4”

Large round hopper

Slice an entire cabbage or several tomatoes at

once thanks to the large round hopper (33 sq.in.) in

stainless steel

Save time and effort: powerful lever remains in upright

position so operator can freely use both hands to

feed vegetables

Easy access to the cutting chamber so discs and

ejector can be easily removed

Powerful, silent and requires no maintenance.

Asynchronous industrial motor for heavy duty and

longer life

High discharge zone permits the

use of deep containers (up to

7 ½”)

•

With a few simple movements all parts can be

removed, without tools, and placed in a dishwasher

for fast cleaning

Multiple safety devices to protect the operator and

stop the machine in case of misuse

Automatic start/stop function will stop the machine

when the lever hopper is lifted and will restart

automatically when lowered

•

Slicing celery, carrots, zucchini or cucumbers is made

easy thanks to the special long vegetable hopper

(2 3/8” diameter)

The waterproof control panel gives complete

protection against strong jets of water

1st speed (430 rpm) for fragile items, 2nd speed

(870 rpm) for resistant vegetables

Pulse control for precise slicing

Only minimal pressure is required to process the

vegetables thanks to the ergonomic and easy to lift

handle

•

electrolux dito TRS / K / TRK

K 45/55/70

Food processors

High powered, built to last. The ideal machines for the professional chef. Chop,

mince, grind, mix, puree, and blend any preparation your recipe requires.

The new 4.8, 5.8 and 7.4 quart

capacities are a compliment to any size

kitchen

A unique scraper / emulsifier allows

you to prepare everything from meats to

creams

Easily upgrade to a combined machine

with a special kit

Increased flexibility with your choice of

2 speeds or variable speed

Stainless steel cutter bowl guarantees

hygiene and food safety

The unique design of bowl bottom

guarantees perfect results when mixing

both large or small quantities of food

Special pulse function for an even more

precise cutting

•

6 electrolux dito TRS / K / TRK

K45 - 4.8 qt. capacity

Speed Phases Power RPM

2 speeds 3 ph 1 1/4 hp 1800-3600

Variable 1 ph 1 1/3 hp 300 to 3600

External dimensions (wxdxh) 101/16”x165/16”x181/2”

K55 - 5.8 qt. capacity

Speed Phases Power RPM

2 speeds 3 ph 1 1/3 hp 1800-3600

Variable 1 ph 1 3/4 hp 300 to 3600

External dimensions (wxdxh) 101/16”x165/16”x181/2”

K70 - 7.4 qt. capacity

Speed Phases Power RPM

2 speeds 3 ph 1 2/3 hp 1800-3600

Variable 1 ph 2 hp 300 to 3600

External dimensions (wxdxh) 101/16”x165/8”x201/16”

Variable speed controlTransparent lid

Transparent lid permits the operator to check the

consistency of the food during preparation and to

eventually add ingredients without opening the lid

Flat and waterproof control panel with easy to use

functions: on/off, 2 speeds, variable speed and pulse

A simple touch of a button lets you reach the

maximum speed of 3600 rpm

•

Bowl with high chimney

Produce more in less time. Unique high chimney

increases the real capacity of the bowl (use up to

75% of nominal capacity)

Smooth or microtoothed blades in 420 AISI stainless

steel allow you to prepare everything from coarse

meats to the finest creams

Ergonomic handle allows the bowl to be placed on

the base with ease and self-locking feature assures

maximum stability

Powerful induction motor built on ball bearings for a

silent process

•

Improved cleanability thanks to the new design with

rounded corners

Hinged cover, when lifted, remains open to permit a

fast, easy and practical check of the preparation when

necessary

The transparent lid can be easily dismantled and all of

its parts are dishwasher safe

Ergonomic scraper in composite material for added

resistance

Multiple safety devices ensure that the machine will

only operate when the cover is properly closed and all

parts are correctly positioned

•

electrolux dito TRS / K / TRK

TRK 45/55/70

Combined cutter-slicers

2 in 1! With TRK your culinary creativity has no limits. A versatile machine

able to prepare an entire menu from hors d’oeuvres to dessert.

Easily change from a vegetable slicer

to a food processor in a matter of

seconds

New Incline System to maintain

an inclined base when using the

vegetable slicer attachment

Designed for easy cleaning thanks to

the rounded shapes and stainless

steel top

User friendly touch button control

panel to select required speed and

pulse function

Efficient scraper eliminates the

need to manually remove food from

the sides of the bowl in addition to

maintaining the lid clean for optimal

visibility

The extensive range of slicing discs

and cutting blades makes even

difficult preparations possible

•

8 electrolux dito TRS / K / TRK

Combined cutter-slicer

TRK45 - 4.8 qt. combined cutter-slicer

Speed Phases Power RPM

Variable 1 ph 1 1/3 hp 300 to 3300

External dimensions (wxdxh)

Slicer 915/16”x1911/16”x193/4” Cutter 101/16”x165/16”x181/2”

TRK55 - 5.8 qt. combined cutter-slicer

Speed Phases Power RPM

Variable 1 ph 1 3/4 hp 300 to 3300

External dimensions (wxdxh)

Slicer 915/16”x1911/16”x193/4” Cutter 101/16”x165/16”x181/2”

TRK70 - 7.4 qt. combined cutter-slicer

Speed Phases Power RPM

Variable 1 ph 2 hp 300 to 3300

External dimensions (wxdxh)

Slicer 915/16”x1911/16”x193/4” Cutter 101/16”x165/8”x201/16”

Removable shaftAdjustable base

Adjust the base from flat to inclined by simply moving

a lever, making vegetable preparations even easier

Convert from vegetable slicer to food processor in a

few simple steps

Sauces and creams as smooth as silk thanks to the

variable speed from 300 to 3300 rpm

Pulse function for perfect results and complete control

Induction motor for heavy usage without brushes for

increased lifetime and reliability

•

Vegetable slicer attachment for shredding, grating,

dicing and mincing your favourite recipes

Cutter-mixer attachment to mix, blend, chop and

puree meats, vegetables, and even desserts

Specially designed smooth or microtoothed blades in

420 AISI stainless steel guarantee foods will not

separate

User friendly control panel automatically indicates

which speed can be selected based on

the attachment being used

Speeds 1-4 for vegetable cutting,

speeds 1-10 for food processing

•

electrolux dito TRS / K / TRK

TRS/TRK Slicing blades

Blades Model Size (inch)

J2 1/16”

J3 1/8”

Grating blades J4 5/32”

J7 9/32”

J9 23/64”

C1C 1/32”

C2C 1/16”

Curved serrated C3C 1/8”

slicing blades C5C 3/16”

C10C 3/8”

C2W 1/16”

Wavy cut C3W 1/8”

slicing blades C6W 1/4”

AS2 1/16”

Julienne blade AS3 1/8”

AS4 5/32”

FT06 1/4”

Grid for french fries / FT08 5/16”

vegetable sticks FT10 3/8”

MT05T 3/16”

MT08T 5/16”

Dicing grid MT10T 3/8”

MT12T 1/2”

MT20T 3/4”

C1 1/32”

C2 1/16”

C3 1/8”

Slicing blades C6 1/4”

C8 5/16”

C10 3/8”

C14 9/16”

Slicing blade for mozzarella C10M 3/8”

(can be used with grids)

10 electrolux dito TRS / K / TRK

Este manual sirve para los siguientes modelos

Otros manuales de Electrodoméstico de cocina de Electrolux

Electrolux

Electrolux ERC38810WS Manual de usuario

Electrolux

Electrolux EKC6562AOX Manual de usuario

Electrolux

Electrolux EB3GL70CN Manual de usuario

Electrolux

Electrolux TRS1V Manual de usuario

Electrolux

Electrolux ERGOPRESS EJP5000 Manual de usuario

Electrolux

Electrolux 603329 Manual de usuario

Electrolux

Electrolux Dito 603602 Manual de usuario

Electrolux

Electrolux E6AF1-6ST Manual de usuario

Electrolux

Electrolux EKI6762AOX Manual de usuario

Electrolux

Electrolux EWUS020B5B Manual de usuario

Electrolux

Electrolux Dito LMP400 Manual de usuario

Electrolux

Electrolux EKC603602 Manual de usuario

Electrolux

Electrolux EWUD040B8B Manual de usuario

Electrolux

Electrolux TrinityPro Instrucciones de funcionamiento

Electrolux

Electrolux Vintec VWM122SAA-X Manual de usuario

Electrolux

Electrolux EQT4520BOZ Manual de usuario

Electrolux

Electrolux Elco 700HP Series Manual de usuario

Electrolux

Electrolux VARIO STEAM S33-E Guía del producto

Electrolux

Electrolux EK 170 (S) Manual de usuario

Electrolux

Electrolux EKD60760 Manual de usuario

Electrolux

Electrolux Dito LUX300BS Manual de usuario

Electrolux

Electrolux EHJ36000 Manual de usuario

Electrolux

Electrolux THERMALINE 900 Manual de usuario

Electrolux

Electrolux EKG913A4OX Manual de usuario

Manuales populares de Electrodoméstico de cocina de otras marcas

Tayama

Tayama TYG-35AF Manual de usuario

AEG

AEG 43172V-MN Manual de usuario

REBER

REBER Professional 40 Guía del usuario

North American

North American BB12482G / TR-F-04-B-NCT-1 Manual de usuario

Presto

Presto fountain popper Manual de usuario

Westmark

Westmark 1035 2260 Manual de usuario

Zanussi

Zanussi ZCG64396XA Manual de usuario

HOFFEN

HOFFEN SM-9302M Manual de usuario

Philips

Philips HD3133 Manual de usuario

Ronco

Ronco Beef Jerky Manual de usuario

Hendi

Hendi 470411 Manual de usuario

Livoo

Livoo MEN386 Manual de usuario

Vogue

Vogue D446 Manual de usuario

croydon

croydon WR-10313-700 Manual de usuario

ADE

ADE AUTOMATIC-L Manual de usuario

Chefman

Chefman RJ43-SQ Series Manual de usuario

Vacmaster

Vacmaster VP680 Manual de usuario

Jetmaster

Jetmaster 900HG Manual de usuario
