Electrolux Dito TRK70VV Manual de usuario

Item

Model

ProjectName

Vegetable slicers

603324

TRK70

The TRK70 is a versitile machine capable

of changing from vegetable slicer to food

processor in a matter of seconds. With

the fast and easy to change attachments,

you can be ready to prepare a menu

ranging in anything from hors d'oeuvres to

dessert. When using the vegetable slicer

attachment, it is possible to quickly and

easily make over 70 different types of cuts

for stylish and imaginative presentations

of salads, garnishings, macedonies, chips

and many other combinations. When

using the food processing attachment, it

is possible to mince meat, create

elaborate: mousses, stuffings, creams,

pastries, etc. The capacities of the TRK70

make it a perfect complement for kitchens

of any size.

FEATURES

V Vegetable slicer attachment for shredding,

grating, dicing and mincing your favorite recipes.

V Cutter-mixer attachment to mix, blend, chop

and puree meats, vegetables and even

desserts.Designed for easy cleaning thanks to

the rounded shapes and stainless steel top.

V User friendly touch button control panel to

select required speed and pulse funcion.

V Efficient scraper eliminates the need to

manually remove food from the sides of the bowl

in addition to keeping the lid clean for optimal

visibility.

V The extensive range of slicing discs and

cutting blades makes even difficult preparations

possible.

V Specially designed smooth or microtoothed

blades in 420 AISI stainless steel guarantee food

will not separate.

V Base adjustable from flat to inclined with the

simple movement of a lever, making vegetable

preparations even easier.

Specifications

MODEL

TRK70VV

603324

External dimensions - mm

width 252

depth 485

height 530

Cutting capacity - kg/h

carrots 250

chips 500

dicing 450

Chopping capacity - kg/cycle

condiments 2

Mincing capacity - kg/cycle

meats 2.5

Preparation mayonnaise/sauces - kg/cycle

mayonnaise 3.5

Pastry preparation - kg/cycle 2.5

Power - kW

installed-electric 1.5

Net weight - kg. 27.9

Supply voltage 200...240 V, 1N, 50/60

V Designed for easy cleaning thanks to the rounded

shapes and stainless steel top.

V User friendly touch button control panel to select

required speed and pulse funcion.

V Efficient scraper eliminates the need to manually

remove food from the sides of the bowl in addition to

keeping the lid clean for optimal visibility.

V Specially designed smooth or microtoothed

blades in 420 AISI stainless steel guarantee food will

not separate.

V Thanks to its wide versatility, the machine always

allows to select the correct slicing/processing speed,

according to the accessory being used.

Included accessories

CODE DESCRIPTION

653593 7 LITRE S/S BOWL FOR CUTTER-MIXER 1

653592 LID+BOWL SCRAPER FOR 7 LT CUTTER-MIXER 1

653584 MICROTOOTHED BLADE ROTOR-7L CUTTER-MIXER 1

Optional accessories

CODE DESCRIPTION

653593 7 LITRE S/S BOWL FOR CUTTER-MIXER ✓

653568 DICING GRID 10 MM FOR VEGETABLE SLICER ✓

653569 DICING GRID 12 MM FOR VEGETABLE SLICER ✓

653570 DICING GRID 20 MM FOR VEGETABLE SLICER ✓

653566 DICING GRID 5 MM FOR VEGETABLE SLICER ✓

653567 DICING GRID 8 MM FOR VEGETABLE SLICER ✓

653122 DISC WITH CORRUGATED BLADES 2 MM ✓

653123 DISC WITH CORRUGATED BLADES 3 MM ✓

653126 DISC WITH CORRUGATED BLADES 6 MM ✓

653111 DISC WITH CURVED BLADES 1 MM ✓

653511 DISC WITH CURVED BLADES 10 MM ✓

653112 DISC WITH CURVED BLADES 2 MM ✓

653113 DISC WITH CURVED BLADES 3 MM ✓

653115 DISC WITH CURVED BLADES 5 MM ✓

653162 GRATING DISC 2 MM ✓

653163 GRATING DISC 3 MM ✓

653164 GRATING DISC 4 MM ✓

653167 GRATING DISC 7 MM ✓

653498 GRATING DISC 9 MM ✓

653008 GRATING DISC FOR KNODELN AND BREAD ✓

653170 GRATING DISC FOR PARMESAN AND BREAD ✓

653573 GRID FOR CHIPS 10MM FOR VEGETABLE SLICER ✓

653571 GRID FOR CHIPS 6MM FOR VEGETABLE SLICER ✓

653572 GRID FOR CHIPS 8MM FOR VEGETABLE SLICER ✓

653594 KIT VEG .SLICER FOR VAR.SP.CUTTER-MIXERS ✓

653592 LID+BOWL SCRAPER FOR 7 LT CUTTER-MIXER ✓

653584 MICROTOOTHED BLADE ROTOR-7L CUTTER-MIXER ✓

653283 S/S WORK TABLE+FOLDING SHELVES+DISK RACK ✓

653214 SHREDDING DISC 2X2 MM ✓

653153 SHREDDING DISC 3X3 MM ✓

653154 SHREDDING DISC 4X4 MM ✓

653289 SLICING BLADES VARIABLE DEPTH 1MM-7MM ✓

653565 SLICING DISC FOR MOZZARELLA 10 MM ✓

653101 SLICING DISC WITH STRAIGHT BLADES 1 MM ✓

653110 SLICING DISC WITH STRAIGHT BLADES 10 MM ✓

653185 SLICING DISC WITH STRAIGHT BLADES 14 MM ✓

653102 SLICING DISC WITH STRAIGHT BLADES 2 MM ✓

653103 SLICING DISC WITH STRAIGHT BLADES 3 MM ✓

653106 SLICING DISC WITH STRAIGHT BLADES 6 MM ✓

653108 SLICING DISC WITH STRAIGHT BLADES 8 MM ✓

653583 SMOOTH BLADE ROTOR FOR 7LT CUTTER-MIXER ✓

653180 TABLE+SHELF+GN 1/1 POLYCARBONATE TRAY ✓

AABD010

www.dito-electrolux.com

Vegetable slicers

The manufacturer reserves the right to modify and make improvements to the products without

giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an

indication only.

Installation drawings

XXX

I - Electrical connection 200...240 V, 1N, 50/60

MODEL

TRK70VV

603324

745

220

410

530

252

725

224

485

320

252

505
